WS-C3560X-24P-S Cisco Catalyst 3560-X Series 24 Ports Switch

Cisco WS-C3560X-24P-S 24-Port Manageable Switch

The Cisco WS-C3560X-24P-S is a high-performance, fully manageable Ethernet switch designed for modern enterprise networks. It offers robust connectivity, advanced Layer 2 switching capabilities, and scalable expansion options to optimize network performance. Ideal for businesses seeking reliability and efficiency, this Catalyst 3560-X series switch supports seamless integration across diverse network environments.

General Information

• Manufacturer: Cisco
• Part Number: WS-C3560X-24P-S
• Product Type: Ethernet Switch

Interfaces and Ports

• Total Network Ports: 24
• Port Configuration: 24 x Gigabit Ethernet
• Port Flexibility: Supports both standard and high-speed Ethernet connections

Media and Performance

• Ethernet Technology: Gigabit Ethernet, Fast Ethernet
• Network Speed: 10/100/1000Base-T
• Optimized Throughput: High-efficiency switching with low latency

I/O Expansion Capabilities

• Total Expansion Slots: 2
• Scalability: Supports additional modules for advanced network features
• Flexibility: Easily integrates with existing network infrastructure

Network and Communication Features

• Layer Supported: Layer 2 switching for reliable local network performance
• VLAN Support: Enables segmented network architecture for enhanced security
• Protocol Compatibility: Supports multiple network protocols for diverse environments

Management and Protocols

• Manageable: Yes, fully configurable through Cisco IOS Software
• Network Monitoring: Advanced monitoring tools for performance analysis
• Remote Management: Enables centralized control via SNMP and web interfaces

Power and Reliability

• Power Source: Internal Power Supply
• Redundant Power Support: Yes, ensures uninterrupted operation
• Energy Efficiency: Optimized power consumption for enterprise environments

Layer 2 Switching Capabilities

• VLAN support for efficient network segmentation
• Spanning Tree Protocol to prevent network loops
• High-speed switching for low-latency applications

Scalable Expansion Options

• Two expansion slots for additional uplink modules
• Supports stacking for network growth
• Flexible deployment for future upgrades

Centralized Management

• Supports Cisco IOS commands for advanced configuration
• Remote monitoring via SNMP, CLI, and web-based interfaces
• Real-time performance tracking and troubleshooting

Security and Reliability

• Redundant power supply support ensures continuous uptime
• VLAN-based traffic control enhances network security
• Advanced protocol support maintains network integrity

Energy-Saving Features

• Supports efficient power distribution across all ports
• Reduces operational costs through lower energy usage
• Environmentally friendly design for sustainable IT infrastructure

Cisco WS-C3560X-24P-S Catalyst 3560-X Series

The Cisco WS-C3560X-24P-S is a high-performance, fully manageable switch from the renowned Catalyst 3560-X Series. This series is engineered for enterprise networks, offering seamless connectivity, enhanced security, and robust operational reliability. Designed with both scalability and flexibility in mind, the WS-C3560X-24P-S accommodates growing network demands while ensuring uninterrupted performance for mission-critical applications.

Advanced Switching Capabilities

The Catalyst 3560-X Series delivers advanced Layer 2 and Layer 3 switching functionalities, making it a versatile choice for enterprise-grade networks. The WS-C3560X-24P-S switch is capable of supporting dynamic routing protocols, including OSPF, EIGRP, and RIP, allowing for intelligent traffic management and optimized network performance. Its enhanced Quality of Service (QoS) features ensure prioritization of essential applications and services, minimizing latency and maximizing efficiency across the network infrastructure.

Layer 2 Connectivity Features

At the Layer 2 level, the WS-C3560X-24P-S provides comprehensive VLAN support, including VLAN trunking and private VLANs, which enables network segmentation and improved security. The switch offers features such as Spanning Tree Protocol (STP), Rapid Spanning Tree Protocol (RSTP), and Multiple Spanning Tree Protocol (MSTP), which prevent network loops and maintain high availability. Port security mechanisms safeguard against unauthorized access, ensuring that only authenticated devices can connect to the network.

VLAN Trunking and Port Configurations

The switch supports IEEE 802.1Q VLAN trunking, allowing multiple VLANs to coexist over a single physical link. Its 24 Gigabit Ethernet ports are fully configurable, supporting auto-negotiation for speed and duplex settings. The Power over Ethernet (PoE) capabilities of this switch provide sufficient power to connected devices, including IP phones, wireless access points, and surveillance cameras, eliminating the need for additional power adapters and simplifying deployment.

Layer 3 Routing and Scalability

The WS-C3560X-24P-S is equipped with advanced Layer 3 routing capabilities, including static routing, dynamic routing, and support for IPv4 and IPv6 protocols. These features allow the switch to operate as a highly efficient routing platform, reducing the need for additional network routers. With support for scalable routing tables, the switch can handle large networks with multiple subnets and high traffic volumes, ensuring smooth communication across complex network topologies.

Enhanced Security Features

Security is a fundamental aspect of the Catalyst 3560-X Series, and the WS-C3560X-24P-S is no exception. The switch incorporates comprehensive security mechanisms that protect network infrastructure from internal and external threats. Access control lists (ACLs) enable administrators to filter traffic based on IP addresses, protocols, or ports, preventing unauthorized access. In addition, features such as Dynamic ARP Inspection (DAI), IP Source Guard, and DHCP Snooping guard against spoofing attacks and network exploits.

Authentication and Access Control

The Cisco switch integrates IEEE 802.1X authentication, ensuring that only authorized users and devices can gain access to network resources. It also supports MAC-based authentication and role-based access control (RBAC), providing granular security management. With these features, enterprises can enforce strict access policies while maintaining flexibility for legitimate users and devices. Integration with Cisco Identity Services Engine (ISE) further enhances network visibility and centralized policy enforcement.

Threat Mitigation and Monitoring

The WS-C3560X-24P-S provides robust threat mitigation tools to safeguard against malicious activities. Port-level security policies allow administrators to restrict device access based on MAC addresses, while logging and monitoring functions track network activity for anomalies. Cisco’s embedded security features, such as Control Plane Policing (CoPP) and Unicast Reverse Path Forwarding (uRPF), provide additional layers of protection, ensuring that critical network services remain operational under attack conditions.

Power over Ethernet Capabilities

One of the key advantages of the WS-C3560X-24P-S is its Power over Ethernet (PoE) support, enabling the switch to deliver electrical power directly to connected devices. This capability simplifies network deployment by eliminating the need for separate power sources and reducing cabling complexity. The switch adheres to the IEEE 802.3at PoE+ standard, providing sufficient power for high-demand devices while maintaining efficient energy management.

PoE Optimization and Efficiency

With its intelligent PoE management, the WS-C3560X-24P-S can allocate power to devices based on priority, ensuring mission-critical applications receive uninterrupted service. The switch supports both static and dynamic PoE allocation, allowing administrators to optimize power distribution and prevent overloading. Energy-efficient technologies, such as Cisco EnergyWise, further reduce operational costs by monitoring and managing power consumption across the network.

Device Compatibility and Expansion

The Catalyst 3560-X Series is compatible with a wide range of PoE devices, including IP phones, wireless access points, security cameras, and IoT sensors. Its flexible port configurations allow for seamless integration into existing networks, while maintaining scalability for future expansion. As network demands grow, additional switches from the same series can be easily stacked using Cisco StackWise Plus technology, creating a unified and high-performance network fabric.

Reliability and Redundancy

Reliability is a hallmark of the Cisco Catalyst 3560-X Series. The WS-C3560X-24P-S is built with redundant power supply options, enabling uninterrupted operation even in the event of a power failure. StackWise Plus technology allows multiple switches to be interconnected, providing high availability and simplified management. With features like Stateful Switchover (SSO) and Nonstop Forwarding (NSF), the switch ensures minimal downtime during software upgrades or hardware failures, maintaining continuous network operations.

Stacking Capabilities

The WS-C3560X-24P-S supports StackWise Plus technology, which allows up to nine switches to operate as a single logical unit. This configuration simplifies management, provides higher throughput, and increases redundancy. Stack members share a unified configuration and forwarding table, which enhances network efficiency and simplifies troubleshooting. In case of a stack member failure, traffic is automatically rerouted to maintain uninterrupted connectivity.

Hardware Durability

The switch is engineered with high-quality components to withstand demanding enterprise environments. It features robust chassis construction, advanced thermal management, and fan redundancy to ensure consistent performance. Its reliability is further enhanced by Cisco’s extensive testing and quality assurance processes, which guarantee long-term operational stability. These features make the WS-C3560X-24P-S ideal for deployment in both core and edge network environments.

Automation and Monitoring

With Cisco’s automation features, network administrators can streamline repetitive tasks, enforce consistent policies, and reduce operational overhead. Advanced monitoring tools provide real-time insights into network performance, port utilization, and potential bottlenecks. Integration with Cisco DNA Center allows for policy-based automation, analytics-driven insights, and enhanced visibility into the network, empowering IT teams to respond quickly to performance issues and security threats.

Software Features and Updates

The WS-C3560X-24P-S runs Cisco IOS Software, which provides a rich set of features for security, routing, and network management. Cisco IOS enables seamless software upgrades, bug fixes, and feature enhancements, ensuring the switch remains compatible with evolving network standards. Cisco’s Smart Licensing system simplifies license management and ensures compliance, allowing organizations to leverage the full capabilities of the Catalyst 3560-X Series without administrative complexity.

Applications and Use Cases

The Cisco WS-C3560X-24P-S switch is ideal for enterprise campus networks, branch offices, and data center access layers. Its combination of high-density Gigabit Ethernet ports, PoE support, advanced Layer 3 features, and robust security makes it suitable for diverse applications, including VoIP, video conferencing, wireless connectivity, and IoT integration. By leveraging its scalability and flexibility, organizations can deploy a reliable, high-performance network infrastructure that supports current and future demands.

Enterprise Networking

In enterprise environments, the Catalyst 3560-X Series provides the backbone for seamless connectivity and reliable service delivery. Its advanced routing and switching capabilities enable efficient communication between departments, data centers, and remote offices. With strong security features and integrated management tools, the switch ensures network integrity and optimal performance for business-critical applications.
