Cisco WS-C3650-48FD-L Catalyst 3650 Managed Switch, 48 Ports

Ports

The Cisco WS-C3650-48FD-L Managed Switch is equipped with 48 Ethernet ports, allowing for a seamless and efficient network connection. These ports offer a wide range of benefits and play a crucial role in ensuring smooth communication and data transfer within a network.

Key Specifications of Cisco WS-C3650-48FD-L Ethernet Switch

Model Overview

• Manufacturer: Cisco
• Model: WS-C3650-48FD-L
• Product Line: Catalyst
• Series: 3650
• Type: Ethernet Switch

48-Port Switch Interface & Connectivity

Network Ports Overview

• Total Ports: 48
• Supports Stack Port
• Power over Ethernet Plus (PoE+): 48 Ports (RJ-45), each delivering up to 30W

Detailed Port Configuration

• 48 x Gigabit Ethernet Network Ports
• 2 x 10 Gigabit Ethernet Uplink Ports

Performance and Speed Capabilities

Switching and Forwarding Rates

• Switching Capacity: 176 Gbps
• Forwarding Rate: 130.95 Mpps

Routing & VLAN Support

• IPv4 Route Capacity: 24,000
• Supports 255 VLANs
• Switched Virtual Interfaces (SVIs): Up to 1,000

Additional Performance Features

• MAC Address Table Size: 32,000 Entries
• Jumbo Frame Support: Up to 9,198 Bytes
• Routing Protocol: Static IP Routing

Remote Management & Monitoring Protocols

• SNMP (v1, v2c, v3)
• RMON (1, 2, 3, 9)
• Telnet, SSH, CLI

Expansion and Connectivity Features

Interface Options

• 48 x 1000Base-T RJ-45 PoE+ Ports (30W Each)
• 2 x 1000Base-X SFP Uplink Ports
• 2 x 10GBase-X SFP+ Uplink Ports

Expansion Slots

• 1 x Stacking Module Slot (Available)

Power Specifications

Power Supply and Redundancy

• Internal Hot-Plug Power Supply
• Power Supply Installed: 1 (Supports up to 2)
• Optional Power Redundancy (1+1 Scheme)

Power Capacity

• Total Power Provided: 1,025 Watts
• Voltage: AC 120/230V, 50/60Hz

Mounting and Environmental Compliance

Rack Mounting Features

• Rack Mount Kit Included

Compliance Standards

• CISPR 22 Class A, CISPR 24, EN 55022 Class A
• RoHS, UL 60950-1, FCC Part 15 Class A
• Other Certifications: GOST, BSMI CNS 13438, NOM, KCC

Environmental Conditions

Operating and Storage Conditions

• Operating Temperature: 23°F to 113°F (-5°C to 45°C)
• Operating Humidity: 5% to 96% (Non-Condensing)
• Storage Temperature: -40°F to 158°F (-40°C to 70°C)

Mean Time Between Failures (MTBF)

• MTBF: 383,760 Hours

Increased Connectivity

With 48 ports, this managed switch offers extensive connectivity options, making it ideal for businesses of all sizes. It provides ample room for connecting multiple devices such as computers, servers, printers, IP phones, and other networking equipment. This high level of connectivity eliminates the need for additional switches or hubs, simplifying the network infrastructure.

Flexibility and Scalability

The numerous ports on the Cisco WS-C3650-48FD-L Managed Switch allow for easy expansion and scalability of the network. As your business grows and demands increase, you can effortlessly connect more devices without compromising on performance. This flexibility ensures that your network can adapt to changing needs and accommodate future advancements in technology.

Gigabit Ethernet Capability

All 48 ports on this managed switch support Gigabit Ethernet, enabling high-speed data transfer rates of up to 1000 Mbps. This feature is particularly beneficial for businesses that rely on bandwidth-intensive applications or frequently transfer large files. The increased speed enhances productivity by reducing network congestion and minimizing data transfer times.

Improved Performance and Reliability

The Cisco WS-C3650-48FD-L Managed Switch's 48 ports contribute to improved network performance and reliability. By providing dedicated connections for each device, it eliminates the risk of bottlenecks and ensures consistent data flow throughout the network. This reliability is especially critical in environments where uninterrupted connectivity is vital, such as data centers, offices, or educational institutions.

Enhanced Network Security

Each port on this managed switch can be configured with specific security settings, enabling network administrators to implement granular access controls. With 48 ports at their disposal, administrators can allocate resources effectively, restricting unauthorized access and preventing potential security breaches. This feature helps safeguard sensitive data and ensures that only authorized devices can connect to the network.

Network Segmentation

The Cisco WS-C3650-48FD-L Managed Switch's 48 ports allow for efficient network segmentation. Network segmentation involves dividing a network into smaller, isolated segments to enhance security and optimize network performance. With multiple ports available, administrators can assign different devices or departments to separate segments, minimizing the impact of any network issues and providing greater control over network traffic.

Ease of Management

Managing a network with 48 ports can be a complex task without the right tools. However, the Cisco WS-C3650-48FD-L Managed Switch offers advanced management features that simplify the process. It provides a user-friendly web interface that allows administrators to monitor and configure each port individually, facilitating efficient troubleshooting, and ensuring optimal performance.

Cost-Effective Solution

The Cisco WS-C3650-48FD-L Managed Switch's extensive port capacity offers a cost-effective solution for businesses. By providing 48 ports in a single device, it eliminates the need for additional switches or equipment, reducing overall infrastructure costs. Additionally, the switch's scalability allows businesses to expand their network without significant investments in additional hardware.

In conclusion, the Cisco WS-C3650-48FD-L Managed Switch's 48 ports offer numerous benefits for users. From increased connectivity and flexibility to improved performance and enhanced security, these ports are essential for creating a robust and efficient network infrastructure. With its Gigabit Ethernet capability, ease of management, and cost-effectiveness, this managed switch is an excellent choice for businesses looking to build a reliable and scalable network.
