Cisco WS-C3850-24T-L Catalyst 24 Ports Switch

Device Specifications

General Information

• Type: Network Switch
• Ports: 24 Gigabit Ethernet (10/100/1000 Mbps)
• Management: Managed
• Form Factor: Rack-mountable (1U), Desktop

Performance Metrics

• Switching Capacity: 88 Gbps
• Stacking Bandwidth: 480 Gbps

Capacity and Tables

• IPv4 Routes: 24,000
• NetFlow Entries: 24,000
• Switched Virtual Interfaces (SVIs): 1,000
• MAC Address Table Size: 32,000 entries
• Jumbo Frame Support: 9,198 bytes

Advanced Features

Management and Protocols

• Remote Management: SNMP v1/v2c/v3, RMON v1/v2, Telnet, SSH, CLI
• Additional Features: Auto-negotiation, ARP Support, Trunking, VLAN Support, Auto-MDI/MDI-X

Network Optimization

• IGMP Snooping: Supported
• QoS: Quality of Service
• DHCP Snooping: Enabled
• Dynamic Trunking Protocol (DTP): Supported
• Port Aggregation Protocol (PAgP): Supported
• Link Aggregation Control Protocol (LACP): Supported
• Access Control Lists (ACLs): Available

Security and Reliability

• Dynamic ARP Inspection (DAI): Enabled
• STP Root Guard: Enabled
• Uni-Directional Link Detection (UDLD): Supported
• Remote Switch Port Analyzer (RSPAN): Supported

Energy Efficiency and Redundancy

• Energy Efficient Ethernet: Supported
• Power: AC 120/230 V (50/60 Hz)
• Power Redundancy: Optional

Compliant Standards

• IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1d
• IEEE 802.1q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x
• IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s

CISCO Technologies

• CISCO StackWise-480 Technology
• CISCO StackPower Technology
• Flexible NetFlow (FNF)

Ports

The Cisco WS-C3850-24T-L Switch comes equipped with 24 ports, making it an ideal choice for small to medium-sized businesses that require a reliable and scalable network solution. These ports offer a multitude of benefits and play a crucial role in enhancing the overall network performance and efficiency.

High Port Density

With 24 ports, this switch provides a high port density, allowing businesses to connect multiple devices simultaneously. Whether it's computers, printers, servers, or other networking equipment, the abundance of ports ensures that all devices can be easily accommodated without the need for additional switches or hubs. This not only simplifies the network architecture but also reduces the overall cost of infrastructure setup.

Versatility

The Cisco WS-C3850-24T-L Switch offers versatile connectivity options, including Gigabit Ethernet ports. These ports support high-speed data transfer rates, enabling seamless communication and data exchange between connected devices. The switch also supports Power over Ethernet (PoE) technology on some of its ports, allowing for power and data transmission over a single Ethernet cable. This feature eliminates the need for separate power adapters, reducing cable clutter and simplifying installation.

Scalability

The 24 ports on this switch provide ample room for future expansion. As businesses grow and their networking needs evolve, additional devices can be easily connected to the available ports. This scalability ensures that the network infrastructure can accommodate increased traffic and device connectivity without requiring significant upgrades or replacements.

Improved Network Performance

The abundance of ports offered by the Cisco WS-C3850-24T-L Switch enhances network performance by eliminating bottlenecks and congestion. Each port provides dedicated bandwidth, allowing devices to communicate with each other without interference or slowdowns. This results in faster data transfer speeds, reduced latency, and improved overall network efficiency. Additionally, the switch supports advanced features such as Quality of Service (QoS) and traffic prioritization, enabling businesses to allocate bandwidth to critical applications or devices, ensuring optimal performance.

Ease of Management

Managing a network with 24 connected devices can be a daunting task. However, the Cisco WS-C3850-24T-L Switch simplifies network management with its intuitive interface and comprehensive management capabilities. The switch supports various management protocols, including Simple Network Management Protocol (SNMP) and Cisco's own Network Plug and Play (PnP) technology. These features allow for centralized monitoring, configuration, and troubleshooting of the switch and connected devices, reducing administrative overhead and minimizing downtime.

Manageable

In addition to its impressive port count, the Cisco WS-C3850-24T-L Switch boasts the crucial feature of being manageable. This single manageable switch can prove to be immensely beneficial for businesses looking to streamline their network operations and ensure optimal performance.

Centralized Control

The manageability of this switch allows for centralized control over the entire network infrastructure. With a single interface, network administrators can monitor and manage all connected devices, configure settings, and apply security measures across the network. This eliminates the need for individually accessing each device, saving time and effort in managing the network.

Enhanced Security

Being manageable, the Cisco WS-C3850-24T-L Switch offers advanced security features that help safeguard the network against unauthorized access and potential threats. The switch supports features like Access Control Lists (ACLs), which enable administrators to control traffic flow based on specific rules and policies. Additionally, it provides secure management protocols such as Secure Shell (SSH) and Secure Sockets Layer (SSL), ensuring encrypted communication between the switch and management systems. These security measures enhance the overall network security posture, minimizing the risk of data breaches or unauthorized access.

Intelligent Monitoring

The manageability of this switch enables intelligent monitoring of network performance and traffic patterns. Network administrators can gather valuable insights into the network's behavior, identify potential bottlenecks, and proactively address issues before they impact user experience. With features like NetFlow, administrators can monitor traffic flow in real-time, analyze bandwidth utilization, and gain visibility into the types of applications or protocols consuming network resources. This data-driven approach helps optimize network performance and allocate resources efficiently.

Streamlined Troubleshooting

Troubleshooting network issues becomes significantly easier with a manageable switch like the Cisco WS-C3850-24T-L. The switch provides comprehensive diagnostic tools and logging capabilities, enabling administrators to quickly identify and resolve network problems. Features like Cisco Embedded Event Manager (EEM) allow for automated troubleshooting and remediation of common issues, minimizing downtime and improving network availability.

Flexible Configuration

The manageability aspect of this switch allows for flexible configuration options to cater to specific business requirements. Administrators can easily modify settings, implement policies, or deploy firmware updates across multiple devices simultaneously. This centralized configuration management simplifies network deployment and ensures consistency across the infrastructure.

In conclusion, the Cisco WS-C3850-24T-L Switch's 24 ports offer high port density, versatility, scalability, improved network performance, and ease of management. Additionally, its manageability feature provides centralized control, enhanced security, intelligent monitoring, streamlined troubleshooting, and flexible configuration options. These features make it an excellent choice for businesses seeking a reliable and scalable network solution that can adapt to their evolving needs.
