540-BCXM Dell Mellanox ConnectX-6 DX Dual Ports 100GbE Adapter

Highlights of Dell Dual Ports 100GBE Adapter

The Dell 540-BCXM Mellanox ConnectX-6 DX Dual-Port 100GbE Adapter is a cutting-edge enterprise networking solution engineered for ultra-fast connectivity. With PCI Express 4.0 support and QSFP56 ports, this adapter delivers exceptional throughput, reliability, and scalability for modern data centers and high-performance computing environments.

Main Information

• Manufacturer: Dell
• Model Number: 540-BCXM
• Device Type: Network Adapter

Technical Specifications

• Form Factor: Plug-in Card
• Interface: PCI Express 4.0 x16

Port Configuration

• Ports: Dual-port (2 x Ports)
• Port Type: QSFP56 (Quad Small Form-Factor Pluggable 56)
• Data Transfer Rate: Up to 100Gbps per port (200Gbps total)
• Supported Speeds: 1/10/25/40/50/100GbE
• Connectivity Technology: Wired
• Network Technology: 100GBase-X

Features

• Provides PCIe 4.0 interface for maximum bandwidth
• Compact, space-saving design for efficient installation
• Ideal for high-performance networking applications

Compatibility

Rack Servers

• PowerEdge C6520 / C6525
• PowerEdge R640 / R650 / R6525
• PowerEdge R660 / R6615 / R6625
• PowerEdge R740 / R740xd / R740xd2
• PowerEdge R750 / R750xa / R7525
• PowerEdge R760 / R760xa / R760xd2
• PowerEdge R7615 / R7625
• PowerEdge R840 / R860
• PowerEdge R940 / R940xa / R960

Specialized & XE Series

• PowerEdge Xe8640 / Xe9640 / Xe9680

XR Rugged Servers

• PowerEdge XR12
• PowerEdge XR5610
• PowerEdge XR7620
• PowerEdge XR8610t
• PowerEdge XR8620t
