HP Proliant ML350 G6 Tower Server - E5620 Xeon QC 2.40GHz 6GB RAM 594869-001

Processor

The HP ML350 G6 Tower Server is equipped with a powerful 1 X Xeon Qc 2.40GHz processor. This processor is designed to handle the most demanding tasks and provide exceptional performance for users. With its quad-core architecture and a clock speed of 2.40GHz, this processor ensures smooth and efficient operation.

General Specification of Ml350 G6 E5620

• Manufacturer: Hewlett Packard Enterprise
• Part Number: 594869-001
• Product Line: Proliant ML350 G6, 5U Tower

Processor & Chipset Specifications

• CPU: Intel Xeon E5620, 2.4 GHz (up to 2.66 GHz with Turbo Boost)
• Cores: Quad-core, 64-bit architecture
• Processor Features: Hyper-threading, Intel Turbo Boost
• CPU Upgrade Options: Supports up to 2 CPUs
• Chipset: Intel 5520

Cache Memory Details

• Cache Type: L3
• Cache Size: 12 MB per processor

Memory Capacity & Specifications

• Installed Memory: 6 GB DDR3 SDRAM
• Maximum Supported: 144 GB (Registered DDR3)
• Speed: 1333 MHz, PC3-10600 compliance
• Slots: 18 DIMM slots (15 available)
• Supported RAM: Up to 192 GB PC3-8500, 144 GB PC3-10600 (Registered), or 48 GB Unbuffered ECC

Storage & Optical Drive Specifications

• Hard Drive: None included
• Optical Drive: DVD-ROM, SATA interface

Storage Controller & RAID Capabilities

• Controller Type: RAID, Plug-in Card (PCIe 2.0 x4)
• Supported Interfaces: SATA 3Gb/s, SAS 6Gb/s
• Controller Model: Smart Array P410i with 256 MB BBWC
• RAID Levels: 0, 1, 5, 10, 50
• Buffer: 256 MB

Graphics & Display Features

• Graphics Processor: ATI RN50
• Video Memory: 64 MB

Networking & Communication

• Ethernet: 2 x Gigabit Ethernet ports
• Controller: HP NC326i
• Supported Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
• Networking Features: Wake on LAN, PXE, ACPI support
• Compliance Standards: IEEE 802.3, 802.3u, 802.3ab

Expansion Capabilities

• Expansion Bays: 5 external (4 available), 8 hot-swap 2.5" SFF (all available)
• Expansion Slots: 2 CPU slots, 18 DIMM slots (15 available), 4 PCIe 2.0 x8 (x4 mode), 1 PCIe 2.0 x16 (x8 mode), 1 PCIe 2.0 x8

Interfaces & Ports

• Video Ports: 1 x Display/Video
• PS/2 Ports: 1 for keyboard, 1 for mouse
• Serial Ports: 1
• LAN Ports: 2 x Gigabit Ethernet
• USB Ports: 4 x USB 2.0 (2 front, 2 rear)
• Additional Interfaces: 1 x HP iLO

Miscellaneous Features

• Security Features: System password, power-on password, serial port I/O control
• Compliance: ACPI 2.0, FCC Class B, WEEE, EN 61000-3-2, EN 55022, BSMI CNS 13438

Power Supply & Redundancy

• Power Supply: 460W hot-plug
• Power Redundancy: Optional 1+1 configuration (with an additional power supply)
• Voltage Range: AC 120/230V, 50/60 Hz

Dimensions & Weight

• Width: 8.6 inches
• Depth: 23.5 inches
• Height: 18.5 inches
• Weight: 54 lbs

Enhanced Performance

The Xeon Qc 2.40GHz processor offers enhanced performance compared to standard processors. Its quad-core design allows for simultaneous execution of multiple tasks, resulting in improved overall performance and faster response times. Whether you are running resource-intensive applications or multitasking, this processor can handle it all.

Improved Productivity

With the Xeon Qc 2.40GHz processor, you can expect increased productivity. The higher clock speed enables faster data processing, allowing you to complete tasks more quickly. This is particularly beneficial for businesses that rely on time-sensitive operations or need to handle large volumes of data.

Smooth Multitasking

Thanks to the quad-core architecture, the Xeon Qc 2.40GHz processor excels at multitasking. It can efficiently handle multiple applications simultaneously without compromising performance. This means you can run your critical business software, handle data-intensive tasks, and browse the web seamlessly without experiencing any lag or slowdown.

L3 Cache

The HP ML350 G6 Tower Server features an impressive 12 MB L3 cache. This cache plays a crucial role in improving system performance and responsiveness.

Reduced Access Time

The large L3 cache size of 12 MB significantly reduces access time to frequently used data and instructions. By storing frequently accessed information closer to the processor, the server can retrieve it more quickly when needed. This results in faster execution of commands and improved overall system performance.

Improved Efficiency

The L3 cache helps enhance the server's efficiency by reducing the need to access slower main memory. By keeping frequently used data in the cache, the processor can retrieve it without waiting for data to be fetched from RAM. This reduces latency and improves overall system efficiency, allowing for smooth and uninterrupted operation.

Better Multitasking

The large L3 cache size also benefits multitasking scenarios. With more cache available, the processor can store and retrieve data from different applications efficiently. This allows for seamless multitasking without significant performance degradation, enabling you to run multiple resource-intensive applications simultaneously.

Ram

The HP ML350 G6 Tower Server comes with 6GB of RAM, providing ample memory capacity for various business needs.

Increased System Performance

The 6GB of RAM ensures that the server can handle demanding applications and tasks efficiently. With sufficient memory capacity, the server can store and access data quickly, resulting in improved system performance. This is particularly important for businesses that rely on data-intensive operations, such as database management or virtualization.

Enhanced Virtualization

Virtualization has become a critical component in modern server environments. The 6GB of RAM allows for efficient virtual machine management, enabling businesses to consolidate their hardware resources and run multiple virtual machines simultaneously. This not only saves physical space but also reduces costs associated with maintaining multiple servers.

Future-Proofing

With 6GB of RAM, the HP ML350 G6 Tower Server provides room for future expansion. As your business grows and requires more memory capacity, you can easily upgrade the server's RAM to meet your evolving needs. This ensures that your investment in the server remains relevant and capable of handling future requirements.

Storage

The HP ML350 G6 Tower Server offers versatile storage options, supporting both SAS and SATA drives. This flexibility allows businesses to choose the storage solution that best suits their needs.

High Performance

The support for SAS (Serial Attached SCSI) drives enables businesses to benefit from high-performance storage solutions. SAS drives offer faster data transfer rates, lower latency, and higher reliability compared to SATA drives. This is particularly advantageous for applications that require rapid access to large amounts of data, such as databases or data analytics.

Cost-Effectiveness

SATA (Serial ATA) drives, on the other hand, provide a cost-effective storage solution. They offer high storage capacities at a lower cost per gigabyte compared to SAS drives. SATA drives are suitable for applications where performance is not a primary concern but ample storage capacity is required, such as file servers or backup systems.

Flexibility and Scalability

By supporting both SAS and SATA drives, the HP ML350 G6 Tower Server provides businesses with flexibility and scalability. You can mix and match different drive types according to your specific requirements. This allows you to optimize your storage configuration based on factors like performance needs, budget constraints, and data storage requirements.

Optical Drive

The HP ML350 G6 Tower Server comes equipped with a DVD optical drive, offering convenient access to various types of optical media.

Seamless Data Transfer

The DVD drive allows for easy installation of software or operating systems from DVDs or CDs. This is particularly useful during the initial server setup or when performing system upgrades. You can quickly transfer data from optical media to the server without relying on external devices or network connections.

Backup and Archiving

The DVD drive also facilitates backup and archiving operations. You can create backup copies of critical data onto DVDs for safekeeping or long-term archiving. This provides an additional layer of data protection and ensures that important information can be easily accessed when needed.

Compatibility

The inclusion of a DVD optical drive ensures compatibility with legacy software and media formats that still rely on optical media. This allows businesses to access and utilize older software, installation discs, or media content without any compatibility issues.

Networking

The HP ML350 G6 Tower Server features Gigabit Ethernet connectivity, providing fast and reliable network connectivity.

High-Speed Data Transfer

With Gigabit Ethernet, the server can deliver data at speeds of up to 1 gigabit per second. This enables fast and efficient data transfer between the server and other devices on the network. Whether you are transferring large files, accessing network resources, or running bandwidth-intensive applications, Gigabit Ethernet ensures smooth and uninterrupted network connectivity.

Improved Collaboration

Gigabit Ethernet connectivity enhances collaboration within a networked environment. It enables fast and seamless file sharing, allowing multiple users to access and edit files simultaneously without experiencing significant delays. This promotes teamwork and improves overall productivity within the organization.

Network Scalability

The Gigabit Ethernet capability of the HP ML350 G6 Tower Server ensures scalability for future network expansion. As your business grows and demands greater network capacity, Gigabit Ethernet provides the necessary bandwidth to accommodate increased traffic and additional devices. This allows you to scale your network infrastructure without compromising performance or stability.

Raid Controller

The HP ML350 G6 Tower Server is equipped with a RAID controller, offering enhanced data protection and storage management capabilities.

Data Redundancy

The RAID controller allows for various RAID configurations, such as RAID 0, RAID 1, RAID 5, or RAID 10. These RAID levels provide different levels of data redundancy, ensuring that your data is protected against drive failures. By storing redundant copies of data across multiple drives, the RAID controller safeguards your critical information and minimizes the risk of data loss.

Improved Performance

In addition to data protection, the RAID controller can also improve overall storage performance. By distributing data across multiple drives in a RAID configuration, the controller can parallelize read and write operations, resulting in faster data access and improved system performance. This is particularly beneficial for applications that require high-speed storage, such as databases or virtualized environments.

Storage Management

The RAID controller provides advanced storage management capabilities. It allows you to easily configure and manage your storage arrays, create logical volumes, and monitor drive health and performance. This simplifies storage administration tasks and ensures efficient utilization of your storage resources.

Form Factor

The HP ML350 G6 Tower Server features a 5U form factor, offering a balance between space efficiency and expandability.

Space Optimization

The 5U form factor allows for efficient use of rack space in data centers or server rooms. It provides a compact footprint while still offering ample room for expansion and hardware customization. This is especially important in environments where space is limited or costly.

Expandability

Despite its compact size, the 5U form factor provides excellent expandability options. It can accommodate multiple hard drives, expansion cards, and other peripherals without compromising airflow or system stability. This allows businesses to easily adapt the server to their changing needs without the need for significant hardware modifications.

Improved Cooling and Airflow

The 5U form factor incorporates efficient cooling mechanisms to ensure optimal thermal performance. The server's design allows for proper airflow, preventing overheating and maintaining stable operating temperatures. This results in improved system reliability and longevity, reducing the risk of hardware failures due to heat-related issues.
