HPE 240GB 2.5" SFF SSD 868814-B21
- — Free Ground Shipping
- — Min. 6-month Replacement Warranty
- — Genuine/Authentic Products
- — Easy Return and Exchange
- — Different Payment Methods
- — Best Price
- — We Guarantee Price Matching
- — Tax-Exempt Facilities
- — 24/7 Live Chat, Phone Support
- — Visa, MasterCard, Discover, and Amex
- — JCB, Diners Club, UnionPay
- — PayPal, ACH/Wire Transfer
- — Apple Pay, Amazon Pay, Google Pay
- — Buy Now, Pay Later - Affirm, Afterpay
- — GOV/EDU/Institutions PO's Accepted
- — Invoices
- — Deliver Anywhere
- — Express Delivery in the USA and Worldwide
- — Ship to -APO -FPO
- — For USA - Free Ground Shipping
- — Worldwide - from $30
Same product also available in:
SKU/MPN | Warranty | Price | Condition | You save |
---|---|---|---|---|
868814-B21 | Six-Month (180 Days) | $179.14 | New (System) Pull | You save: $96.13 (35%) |
868814-B21 | Six-Month (180 Days) | $75.56 | Excellent Refurbished | You save: $47.36 (39%) |
Main Details of HPE 240GB SATA-6GBPS SSD
- Brand: HPE
- Part Number: 868814-B21
- Type: Hot-Swap Solid State Drive
- Interface: SATA-6GBPS
Technical Specifications
SSD Type & Capacity
- Type: Read Intensive (≤ 1 DWPD)
- Storage Capacity: 240GB
- Form Factor: 2.5-inch SFF (Small Form Factor)
- Connectivity: Single-Port
- Hot Plug Capability: Yes, Hot Pluggable
Performance Features
- Firmware: Digitally Signed
- Bundled Carrier: Includes HPE SmartDrive Carrier
- Data Transfer Rate: Up to 6GBPS
Performance Metrics
Write & Read Endurance
- Total Lifetime Writes: 372TB
- Drive Writes Per Day (DWPD): 0.8
Input/Output Operations Per Second (IOPS)
- Random Read IOPS (4KiB, Q=16): 66,000
- Max Random Read IOPS (4KiB): 73,000 @ Q32
- Random Write IOPS (4KiB, Q=16): 9,800
- Max Random Write IOPS (4KiB): 9,800 @ Q4
Latency
- Random Read Latency: 120 microseconds
- Random Write Latency: 105 microseconds
Power Consumption
- Total Power Consumption: 2.34 Watts
Compliance & Standards
- Environmental Standards: WEEE Compliant
Environmental Specifications
Operating Temperature Range
- Minimum Operating Temperature: 0°C
- Maximum Operating Temperature: 60°C
Physical Dimensions & Weight
- Height: 0.63 inches
- Width: 3.10 inches
- Depth: 5.45 inches
- Weight: 1.50 lbs
Compatibility
HPE ProLiant BL Series
- BL460c Gen10 (2.5-inch)
HPE ProLiant DL Series
- DL360 Gen10 (2.5-inch)
- DL360 Gen10 Base (2.5-inch)
- DL360 Gen10 Entry (2.5-inch)
- DL360 Gen10 High Performance (2.5-inch)
- DL360 Gen10 Low (2.5-inch)
- DL360 Gen10 Performance (2.5-inch)
- DL360 Gen10 Solution (2.5-inch)
- DL388 Gen9 (2.5-inch)
- DL388 Gen9 Base (2.5-inch)
- DL560 Gen10 (2.5-inch)
- DL560 Gen10 Base (2.5-inch)
- DL560 Gen10 Entry (2.5-inch)
- DL560 Gen10 Performance (2.5-inch)
HPE ProLiant ML Series
- ML110 Gen10 (2.5-inch)
- ML110 Gen10 Performance (2.5-inch)
- ML350 Gen10 (2.5-inch)
- ML350 Gen10 Base (2.5-inch)
- ML350 Gen10 Entry (2.5-inch)
- ML350 Gen10 Performance (2.5-inch)
- ML350 Gen10 Solution (2.5-inch)
- ML350 Gen10 Sub-Entry (2.5-inch)
HPE ProLiant XL Series
- XL190r Gen9 (2.5-inch)
HPE Synergy Series
- 480 Gen10 Base Compute Module (2.5-inch)
- 480 Gen10 Entry Compute Module (2.5-inch)
- 480 Gen10 Performance Compute Module (2.5-inch)
- 480 Gen10 Premium Backplane Compute Module (2.5-inch)
- 480 Gen10 Standard BackPlane Compute Module (2.5-inch)
- 480 Gen10 w/o Drives Compute Module (2.5-inch)
- 660 Gen10 Base Compute Module (2.5-inch)
- 660 Gen10 Compute Module (2.5-inch)
- 660 Gen10 Entry Compute Module (2.5-inch)
- 660 Gen10 Performance Compute Module (2.5-inch)
- 660 Gen10 Premium Compute Module (2.5-inch)
Capacity: 240GB
The HPE 868814-B21 SSD offers a substantial storage capacity of 240GB. This generous amount of storage space allows users to store a wide range of data, including documents, photos, videos, and applications. Whether you are a business professional who needs to keep important files at hand or a creative individual with a passion for photography or videography, the 240GB capacity of this SSD ensures that you will have ample space to store your digital assets.
Benefits of 240GB Capacity
1. Ample Storage: With 240GB of storage space, you can store large amounts of data without worrying about running out of space. This is especially beneficial for professionals who work with large files, such as graphic designers, video editors, or architects.
2. Faster Access: Having sufficient storage capacity allows for better organization and faster access to your files. You can easily locate and retrieve the data you need without experiencing delays or bottlenecks.
3. Enhanced Productivity: When you have enough storage space, you can keep all your important files in one place, eliminating the need for external hard drives or cloud storage services. This streamlines your workflow and improves overall productivity.
Importance of 240GB Capacity
The importance of the 240GB capacity lies in its ability to meet the increasing demands for storage in today's digital world. As technology advances and file sizes continue to grow, having a larger storage capacity becomes essential. Whether you are a business owner looking to store customer data or an individual with a vast collection of multimedia files, the 240GB capacity ensures that you can comfortably accommodate your needs.
Scalability and Future-Proofing
Another crucial aspect of the 240GB capacity is its scalability and future-proofing capabilities. As your data storage requirements evolve, you can easily upgrade to larger capacities without the need to replace the entire SSD. This allows for cost-effective scalability, ensuring that your investment in the HPE 868814-B21 SSD remains relevant and efficient for years to come.
Interface: SATA-6GBPS
The HPE 868814-B21 SSD features a SATA-6GBPS interface, providing users with a reliable and high-speed connection between the SSD and their system. The SATA-6GBPS interface offers numerous benefits and plays a crucial role in optimizing the performance of the SSD.
Benefits of SATA-6GBPS Interface
1. Faster Data Transfer: The SATA-6GBPS interface supports data transfer rates up to 6 gigabits per second, allowing for rapid and efficient transfer of data between the SSD and the computer. This results in faster file access, reduced loading times, and improved overall system performance.
2. Compatibility: The SATA interface is widely adopted and supported by most modern computers and laptops. This ensures seamless compatibility with your existing system, eliminating the need for additional adapters or hardware upgrades.
3. Easy Installation: The SATA interface is known for its simplicity and ease of installation. Users can easily connect the HPE 868814-B21 SSD to their system without requiring advanced technical skills or specialized tools.
Importance of SATA-6GBPS Interface
The importance of the SATA-6GBPS interface lies in its ability to unlock the full potential of the HPE 868814-B21 SSD. By providing a high-speed connection, it maximizes the performance capabilities of the SSD, allowing users to fully leverage its speed and responsiveness.
Enhanced Gaming and Multimedia Experience
For gamers and multimedia enthusiasts, the SATA-6GBPS interface is particularly important. It ensures smooth gameplay, quick level loading, and seamless multimedia playback. Whether you are a professional gamer or a casual user, the SATA-6GBPS interface delivers an enhanced gaming and multimedia experience.
Form Factor: 2.5inch Small Form Factor SFF
The HPE 868814-B21 SSD adopts a 2.5inch Small Form Factor (SFF) design, making it compact and versatile. This form factor offers several benefits in terms of installation flexibility and compatibility with a wide range of systems.
Benefits of 2.5inch SFF Form Factor
1. Space Efficiency: The 2.5inch SFF form factor is smaller in size compared to traditional 3.5inch drives, allowing for more efficient use of space within your computer chassis. This is particularly beneficial for compact systems such as laptops or small form factor desktops.
2. Versatile Compatibility: The 2.5inch SFF form factor is widely supported across various systems, including desktops, laptops, servers, and storage arrays. This ensures that the HPE 868814-B21 SSD can be easily integrated into your existing infrastructure without compatibility issues.
3. Easy Installation: The compact size of the 2.5inch SFF form factor makes it easy to install in tight spaces or crowded system configurations. This simplifies the installation process and allows for efficient cable management within your system.
Importance of 2.5inch SFF Form Factor
The importance of the 2.5inch SFF form factor lies in its ability to provide flexibility and compatibility across various systems. Whether you are upgrading your laptop, expanding your server storage, or building a new desktop, the 2.5inch SFF form factor ensures that the HPE 868814-B21 SSD can seamlessly fit into your system.
Optimal Performance in Compact Systems
For users with compact systems, such as laptops or small form factor desktops, the 2.5inch SFF form factor is essential. It allows for optimal performance without compromising on space or sacrificing the benefits of SSD technology. With the HPE 868814-B21 SSD's 2.5inch SFF form factor, you can experience blazing-fast speeds and improved system responsiveness in your compact setup.
Intended Use: Read Intensive
The HPE 868814-B21 SSD is designed for read-intensive workloads, making it ideal for applications where data access speed is critical. Whether you are running virtualized environments, hosting databases, or working with large datasets, this SSD is optimized to deliver exceptional read performance.
Benefits of Read Intensive SSD
1. Faster Data Access: Read-intensive SSDs prioritize read operations, resulting in faster data access speeds compared to traditional hard drives or write-intensive SSDs. This is particularly beneficial for applications that require quick retrieval of data, such as database queries or virtual machine boot times.
2. Improved Application Performance: By reducing data access latency, read-intensive SSDs significantly improve application performance. This translates into faster application launches, reduced loading times, and overall enhanced user experience.
3. Enhanced Reliability: Read-intensive SSDs are designed to handle high read workloads over extended periods. They utilize advanced error correction and wear-leveling algorithms to ensure data integrity and maximize the lifespan of the drive.
Importance of Read Intensive SSD
The importance of a read-intensive SSD lies in its ability to meet the demanding requirements of data-intensive applications. By prioritizing read operations, these SSDs deliver exceptional performance, enabling users to process and access large volumes of data quickly and efficiently.
Optimized for Data-Driven Workloads
For professionals working with data-driven workloads, such as data analysts, scientists, or engineers, a read-intensive SSD is crucial. It allows for faster analysis, processing, and retrieval of data, accelerating productivity and enabling quicker decision-making based on real-time insights.
