P19937-H21 HPE 480GB 2.5in DS SATA-6GBPS SC Mixed Use SSD

Highlights of HPE 480GB Mixed Used SSD

Brand & Identification

• Manufacturer: Hewlett Packard Enterprise
• Item Code: P19937-H21
• Drive Category: Hot-Swap Solid-State Drive

Core Specifications

Storage Attributes

• Volume: 480GB
• Size Format: 2.5-inch Small Form Factor
• Interface Standard: SATA III 6Gbps
• Flash Architecture: Triple-Level Cell
• Insertion Type: Hot-Pluggable
• Connection Mode: Single Port
• Carrier Design: Smart Carrier
• Operational Profile: Optimized for Read-Heavy Tasks
• Included Accessory: HPE SmartDrive Carrier
• Security Protocol: Digitally Signed Firmware
• Supported Systems: HPE ProLiant Rack, Tower, BladeSystem, Synergy
• Drive Height: 7.00 mm (0.30 inch)

Performance Highlights

• Monthly Write Capacity: 1324 Terabytes
• Durability Index: 1.50 DWPD
• Data Transfer Rate: 6 Gigabits per second
• Sequential Read Speed: 510 MiB/s
• Sequential Write Speed: 395 MiB/s
• Latency (Read): 125 Microseconds
• Latency (Write): 38 Microseconds
• IOPS (Read): 65,000
• IOPS (Write): 38,000
• Max IOPS Read: 75,000 @ Q256
• Max IOPS Write: 40,000 @ Q4

Connectivity & Expansion Options

• Interface Port: 1 x SATA 6Gb/s
• Bay Compatibility: 2.5-inch Small Form Factor

Power Efficiency

Energy Consumption

• Idle Power: 1.16 Watts
• Random Read: 1.45 Watts
• Random Write: 1.45 Watts
• Sequential Read: 1.91 Watts
• Sequential Write: 2.61 Watts
• Mixed Read/Write: 1.45 Watts
• Peak Power Draw: 2.61 Watts

Physical Dimensions & Weight

• Height: 5.75 inches (14.61 cm)
• Width: 8.63 inches (21.92 cm)
• Depth: 9.00 inches (22.86 cm)
• Mass: 1.508 lbs (0.68 kg)

System Integration & Compatibility

HPE Nimble Storage dHCI Solutions

• Large Configuration: DL380 Gen10 (2.5")
• Medium Configuration: DL325 Gen10 Plus, DL360 Gen10 (2.5")
• Small Configuration: DL360 Gen10 (2.5")

HPE ProLiant DL Series Compatibility

DL160 Gen10

• Base, Entry, SMB Editions (2.5")

DL180 Gen10

• Base, Entry, SMB Editions (2.5")

DL20 Gen10

• Standard, Entry, Performance, Solution Variants (2.5")

DL325 Gen10

• Base, Entry, Plus, NVMe Flash Node, Weka Expansion, SMB, Solution Editions (2.5")

DL360 Gen10

• All Flash, Compute, Network Choice, Performance, Premium, ROBO, CTERA, SMB, Special Server (2.5")

DL380 Gen10

• All Flash, Entry SMB, Cohesity, SAP HANA, Hybrid, Network Choice, NVMe, CTERA, SMB Networking (2.5")

DL385 Gen10

• Plus, Entry, SMB Editions (2.5")

DL560 Gen10

• SAP HANA Compute Block (2.5")

HPE ProLiant ML Series Compatibility

• ML350 Gen10 High Performance, SMB, Special Server Editions (2.5")

HPE P19937-H21 480GB SATA 6GBPS SC RI MU SSD Overview

The HPE P19937-H21 480GB SSD SATA 6GBPS SC Read Intensive is a high-performance solid-state drive designed for enterprise storage environments where read-intensive workloads are the priority. This category of storage solutions is engineered to deliver superior reliability, low latency, and consistent performance for data-driven applications. The SATA 6Gbps interface ensures optimal connectivity with a wide range of HPE ProLiant servers and storage arrays, making it an essential component for organizations seeking to enhance operational efficiency and storage throughput.

Key Features of HPE P19937-H21 SSD

Read-Intensive Performance Optimization

HPE P19937-H21 SSDs are specifically optimized for read-intensive applications, providing rapid access to frequently used data. The drive’s architecture ensures minimal latency and high Input/Output Operations Per Second (IOPS), enabling applications such as database queries, virtual desktop infrastructure (VDI), and analytics workloads to run smoothly. These drives are ideal for enterprise storage tiers that demand consistent read performance without compromising system reliability.

Advanced SATA 6GBPS Interface

The SATA 6Gbps interface offers high-speed connectivity, ensuring efficient data transfer between the SSD and the host system. This interface is widely supported across HPE server platforms, providing seamless integration into existing storage infrastructures. By leveraging the full potential of SATA 6Gbps, the P19937-H21 SSD maintains fast read operations while reducing bottlenecks in high-demand environments.

Enterprise-Grade Reliability

Reliability is a cornerstone of the HPE P19937-H21 SSD series. These drives are built to withstand the rigorous demands of enterprise environments, featuring robust error correction, wear leveling, and power loss protection mechanisms. Such features guarantee data integrity and reduce the risk of drive failures, ensuring continuous availability of critical business data.

Compatibility and Integration

Seamless Integration with HPE ProLiant Servers

The HPE P19937-H21 SSDs are fully compatible with a wide range of HPE ProLiant servers. This compatibility ensures plug-and-play deployment, reducing installation complexity and enhancing system uptime. Administrators can integrate these drives into existing storage configurations without additional hardware modifications, simplifying maintenance and reducing operational overhead.

Optimized for Storage Arrays

These SSDs are engineered to perform efficiently within HPE storage arrays, allowing organizations to maximize storage density and performance. The read-intensive design ensures that high-demand workloads are prioritized, enhancing the overall efficiency of the storage environment. Whether used in hybrid arrays or all-flash setups, these drives contribute to improved data access speed and system responsiveness.

Endurance Characteristics

High IOPS and Low Latency

With optimized firmware and NAND architecture, the HPE P19937-H21 delivers impressive IOPS while maintaining low latency across read operations. This ensures that applications requiring frequent data access experience minimal delays, thereby improving operational efficiency and user experience. High IOPS performance is critical for applications such as online transaction processing and business intelligence analytics.

Power Efficiency

Energy-Efficient Design

HPE P19937-H21 SSDs are engineered to operate with minimal power consumption, reducing operational costs and environmental impact. The energy-efficient design ensures that even large-scale deployments maintain low power usage, supporting green IT initiatives and improving overall data center efficiency. Efficient power management also helps in reducing heat generation within storage arrays, contributing to long-term reliability.

Advanced Thermal Monitoring

These drives feature integrated thermal sensors and monitoring capabilities that detect temperature variations in real-time. Advanced thermal management helps prevent overheating and maintains optimal performance levels. This ensures the longevity of the SSD and the stability of the server environment, particularly in densely populated storage enclosures where heat buildup can affect drive performance.
