HPE 709943-001 Server G8 2x 10 Core E5 2690v2 Xeon 3.0GHz

Processor

The HPE G8 Server is equipped with a powerful processor - the 2x 10 Core E5 2690v2 Xeon 3.0GHz. This feature sets the server apart from its competitors, providing users with exceptional performance and reliability. In this section, we will delve into the benefits and importance of this processor, exploring its capabilities and the advantages it brings to users.

General Information

• Manufacturer: Hewlett Packard Enterprise
• Part Number: 709943-001
• Product Name: ProLiant DL380p G8 - 2U Rack Server (Performance Model)

Processor & Chipset

Processor Specifications

• Type: Intel Xeon E5-2690v2
• Base Clock Speed: 3.0 GHz
• Max Turbo Speed: 3.6 GHz
• Cores: 10-core
• Installed Processors: 2
• Max Supported Processors: 2
• 64-bit Computing: Yes
• Chipset Type: Intel C600
• Main Features: Hyper-Threading Technology, Intel QuickPath Interconnect, Intel Turbo Boost Technology 2

Cache Memory

• Cache Type: L3 Cache
• Installed Size: 50 MB
• Cache Per Processor: 25 MB

Memory

Installed RAM

• Size: 32 GB / Up to 384 GB
• Technology: DDR3 SDRAM
• Effective Memory Speed: 1866 MHz
• Form Factor: DIMM 240-pin
• Slots: 24 (total), 22 (empty)
• Features: Registered, HP SmartMemory

Supported RAM Configurations

• PC3-14900 - Up to 384 GB Registered
• PC3-14900 - Up to 768 GB Low Voltage, Load-Reduced
• PC3-14900 - Up to 128 GB Unbuffered, Advanced ECC
• PC3-10600 - Up to 384 GB Hypercloud

Storage & Optical Drives

• Hard Drive: None
• Optical Drive Type: DVD-RW/DVD-Writer - SATA

Storage Controller

Controller Details

• Type: Integrated RAID Controller - PCIe 3.0 x8
• Controller Interface: SATA 6 Gb/s / SAS 6 Gb/s
• Controller Name: Smart Array P420i with 2 GB FBWC
• Channel Quantity: 8
• RAID Levels Supported: RAID 0, 1, 5, 6, 10, 50, 60
• Buffer Size: 2 GB

Graphics & Display

• Graphics Controller: Integrated
• Graphics Processor: Matrox G200
• Video Interfaces: VGA

Networking & Communication

Network Interface

• Type: Plug-in Card
• Interface (Bus) Type: PCI Express 2.0 x8
• Ethernet Ports: 2 x 10 Gigabit Ethernet
• Ethernet Controller: HP 533FLR-T
• Data Link Protocol: 10 Gigabit Ethernet
• Remote Management Controller: Integrated Lights-Out 4
• Features: Wake On LAN (WOL), PXE Support
• Compliant Standards: IEEE 802.3, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1ax, IEEE 802.1qbb, IEEE 802.1qaz, IEEE 802.1qau, IEEE 802.1qbg, IEEE 802.2x

Expansion & Connectivity

Expansion Bays

• External 5.25-inch Slim Line: 1 total, 0 free
• Hot-swap 2.5-inch SFF: 8 total, 8 free

Expansion Slots

• DIMM 240-pin: 24 total, 22 free
• CPU Slots: 2 total, 0 free
• PCIe 3.0 x16: 2 total, 2 free
• PCIe 3.0 x8: 3 total, 3 free
• PCIe 2.0 x8 (X4 Mode): 1 total, 1 free
• SD Card Slot: 1 total, 1 free
• FlexibleLOM Slot: 1 total, 0 free

Interfaces & Ports

• Serial Port: 1
• VGA Ports: 2 (1 front, 1 rear)
• LAN Ports: 2 x 10 Gigabit Ethernet
• HP iLO Port: 1
• USB 2.0 Ports: 7 (2 front, 4 rear, 1 internal)

Miscellaneous

Included Accessories

• HP Ball Bearing Rail Kit

Additional Features

• Administrator Password
• Power-on Password
• Serial Port I/O Control

Compliance Standards

• ACPI 2.0b
• FCC Class A Certified
• EN 61000-3-2
• EN55022
• ICES-003
• EN 61000-3-3
• EN55024
• CISPR 22
• FCC CFR47 Part 15
• IEC 60950-1
• EN 60950-1
• WEEE
• BSMI CNS 13438
• GB 9254

Power Device

• Type: Hot-plug Power Supply
• Redundancy: Yes
• Redundancy Scheme: 1+1
• Installed Quantity: 2
• Nominal Voltage: AC 120/230 V (50/60 Hz)
• Unmatched Processing Power

  The 2x 10 Core E5 2690v2 Xeon 3.0GHz processor is designed to handle demanding workloads efficiently. With a total of twenty processor cores, it offers an unparalleled level of processing power. This means that the server can effortlessly handle resource-intensive tasks, such as data analysis, virtualization, and database management.

  Enhanced Multitasking

  Thanks to the high core count of the processor, the HPE G8 Server excels at multitasking. Users can run multiple applications simultaneously without experiencing any significant slowdowns or performance bottlenecks. This is particularly crucial for businesses that rely on their servers to handle various workloads concurrently, ensuring smooth operations and improved productivity.

  Improved Performance and Responsiveness

  The 3.0GHz clock speed of the processor further enhances its performance. It enables quick data processing and reduces latency, resulting in faster response times for applications and services running on the server. Users can expect a highly responsive environment, allowing them to carry out their tasks efficiently without any frustrating lags or delays.

  Optimized Virtualization

  Virtualization has become an integral part of modern IT infrastructure. The HPE G8 Server's processor is well-suited for virtualization tasks, allowing users to create and manage multiple virtual machines effortlessly. The combination of high core count and clock speed ensures that each virtual machine receives sufficient processing power, enabling smooth and reliable virtualization performance.

  Reliability and Scalability

  In addition to its impressive processing capabilities, the 2x 10 Core E5 2690v2 Xeon 3.0GHz processor offers excellent reliability and scalability. This is achieved through various features and technologies incorporated into the processor architecture.

  Robust Architecture

  The processor is built using advanced technologies that enhance its resilience and reliability. It features error correction codes (ECC) memory support, which helps detect and correct data corruption issues, ensuring data integrity even during high-intensity operations. This is crucial for businesses that handle critical data and cannot afford any data loss or corruption.

  Scalability for Growing Businesses

  The HPE G8 Server's processor is designed to accommodate the evolving needs of growing businesses. With its powerful multi-core architecture, it can handle increasing workloads as businesses expand without requiring significant hardware upgrades. This scalability allows businesses to save costs by avoiding frequent server replacements and ensures a smooth transition as their computing requirements grow.

  Energy Efficiency

  Apart from its exceptional performance, the processor is also energy-efficient. It is designed to minimize power consumption while delivering optimal performance. This not only reduces operational costs for businesses but also contributes to a greener environment by conserving energy.

  Part Number

  The HPE G8 Server comes with a unique part number - 709943-001. This identification code plays a significant role in identifying and sourcing the server, providing users with various benefits and advantages. Let's explore the importance of this feature in more detail.

  Easy Identification and Inventory Management

  The part number serves as a unique identifier for the HPE G8 Server model - 709943-001. This makes it incredibly easy for users to identify and differentiate the server from other models. When managing large inventories or multiple servers, having a distinct part number simplifies the process of tracking and managing stock. It ensures accurate record-keeping, making it easier to locate and manage specific servers within a network infrastructure.

  Efficient Sourcing and Spare Parts Replacement

  The part number is crucial when sourcing or replacing spare parts for the HPE G8 Server. With the part number, users can accurately communicate their requirements to suppliers or support teams. It eliminates confusion or errors that may arise due to similar server models with different specifications. This streamlines the procurement process, ensuring that users receive the correct spare parts promptly, minimizing downtime and improving overall reliability.

  Compatibility Assurance

  The part number provides an assurance of compatibility when expanding or upgrading the HPE G8 Server. By referring to the unique identifier - 709943-001, users can ensure that the new components or accessories are fully compatible with their specific server model. This prevents any compatibility issues that may arise from using incorrect parts, saving time, and avoiding unnecessary complications during upgrades or expansions.

  Technical Support and Documentation

  When seeking technical support or referring to documentation, the part number proves invaluable. It allows support teams and users to quickly identify and understand the specific server model in question. This expedites problem resolution as support personnel can provide accurate guidance based on the unique part number, ensuring efficient troubleshooting and minimizing downtime.

  Warranty Validation

  The part number is also essential for validating warranties associated with the HPE G8 Server. By providing the part number - 709943-001, users can easily verify the warranty coverage period and terms. This enables them to take full advantage of warranty services, such as repairs or replacements, ensuring that their servers are protected against any potential defects or failures within the warranty period.

  In conclusion, the 2x 10 Core E5 2690v2 Xeon 3.0GHz processor and the unique part number - 709943-001, are essential features of the HPE G8 Server. The processor delivers unmatched processing power, enhanced multitasking, improved performance, and optimized virtualization capabilities. It offers reliability, scalability, and energy efficiency, making it an ideal choice for businesses of all sizes. On the other hand, the part number simplifies identification, inventory management, spare parts sourcing, compatibility assurance, technical support, and warranty validation. Together, these features contribute to a high-performing and reliable server solution tailored to meet the diverse needs of users.
