Main Specifications of the HPE 804638-003 SSD
The HPE 804638-003 is a high-performance solid-state drive designed for demanding workloads. Below are its key specifications:
General Information
- Manufacturer: HPE
- Model Number: 804638-003
- Type: Solid State Drive (SSD) – Hot-Swap Capable
- Storage Capacity: 800 GB
- Interface: SATA-6Gbps
- Form Factor: 3.5-inch LFF
- NAND Flash Type: Multi-level Cell (MLC)
- Plug Type: Hot Pluggable
- Carrier Type: Smart Carrier Converter (SCC)
- Workload Type: Write Intensive (WI-2)
Key Features
- Digitally Signed Firmware (DS)
- Integrated Temperature Sensor
- High Endurance Technology (HET)
- Enhanced Power Loss Data Protection
- End-to-End Data Protection
- High-Performance Computing (HPC) Compatibility
- Power Failure Protection & Recovery
- Bundled with HPE Smart Carrier Converter (SCC)
Performance Metrics
Drive Performance Specifications
- Endurance (DWPD): 10
- Drive Transfer Rate: 6 Gb/sec (external)
- Maximum Sequential Read Throughput: 540 MiB/s
- Maximum Sequential Write Throughput: 370 MiB/s
- Random Read Latency (4KiB, Q1): 110 µSec
- Random Write Latency (4KiB, Q1): 35 µSec
IOPS Performance
- Random Read IOPS (4KiB, Q=16): 64,500
- Random Write IOPS (4KiB, Q=16): 46,500
- Max Random Read IOPS (4KiB): 72,000 (Q32)
- Max Random Write IOPS (4KiB): 46,500 (Q16)
- 4KiB Random 70% Read / 30% Write IOPS: 60,000
- 4KiB Random 50% Read / 50% Write IOPS: 55,000
Power Consumption Details
- Idle Power: 1.16 Watts
- Power During Random Read: 2.25 Watts
- Power During Random Write: 2.25 Watts
- Power for Sequential Read: 3.24 Watts
- Power for Sequential Write: 6.06 Watts
- Random R/W Power Consumption: 2.25 Watts
Physical Dimensions & Weight
- Height: 5.63 inches
- Width: 3.75 inches
- Depth: 7.00 inches
- Weight: 1.35 lbs
Compatibility Information
Supported HPE ProLiant DL Series
- DL180 Gen9 (3.5-inch)
- DL180 Gen9 Base (3.5-inch)
- DL180 Gen9 Entry (3.5-inch)
- DL180 Gen9 Storage (3.5-inch)
- DL20 Gen9 (3.5-inch)
- DL20 Gen9 Entry (3.5-inch)
- DL20 Gen9 Performance (3.5-inch)
- DL320e Gen8 (3.5-inch)
- DL320e Gen8 Base (3.5-inch)
- DL320e Gen8 Entry (3.5-inch)
- DL320e Gen8 Performance (3.5-inch)
- DL320e Gen8 Special Server (3.5-inch)
- DL320e Gen8 v2 (3.5-inch)
- DL320e Gen8 v2 Base (3.5-inch)
- DL320e Gen8 v2 Entry (3.5-inch)
- DL320e Gen8 v2 Performance (3.5-inch)
- DL360e Gen8 (3.5-inch)
- DL360e Gen8 Base (3.5-inch)
- DL360e Gen8 Entry (3.5-inch)
- DL360e Gen8 Performance (3.5-inch)
- DL360e Gen8 Special Server (3.5-inch)
- DL385p Gen8 (3.5-inch)
- DL385p Gen8 Dedicated Workload (3.5-inch)
- DL385p Gen8 Entry (3.5-inch)
- DL385p Gen8 Maximized Consolidation (3.5-inch)
- DL385p Gen8 Storage (3.5-inch)
- DL385p Gen8 Storage Centric (3.5-inch)
- DL388 Gen9 (3.5-inch)
- DL388 Gen9 Base (3.5-inch)
- DL80 Gen9 Entry (3.5-inch)
Supported HPE ProLiant ML Series
- ML110 Gen9 (3.5-inch)
- ML110 Gen9 Base (3.5-inch)
- ML110 Gen9 Entry (3.5-inch)
- ML310e Gen8 (3.5-inch)
- ML310e Gen8 Base (3.5-inch)
- ML310e Gen8 Entry (3.5-inch)
- ML310e Gen8 Performance (3.5-inch)
- ML310e Gen8 v2 (3.5-inch)
- ML310e Gen8 v2 Base (3.5-inch)
- ML310e Gen8 v2 Entry (3.5-inch)
- ML310e Gen8 v2 Performance (3.5-inch)
Capacity: 800GB
The Power of 800GB Capacity
When it comes to storage capacity, the HPE 804638-003 SSD stands out with its impressive 800GB storage space. This substantial capacity allows users to store a vast amount of data, ensuring that they never run out of room for their important files and applications. Whether you are a business professional or a casual user, having ample storage space is crucial, and the 800GB capacity of this SSD provides just that.
Efficiently Manage and Organize Your Data
With 800GB at your disposal, you can efficiently manage and organize your data without worrying about running out of space. This capacity allows you to store large files, such as high-resolution images, videos, and complex software applications, without any compromises. You can keep all your important documents, media files, and software in one place, making it easier to find and access them whenever you need.
Enhanced Performance and Speed
The 800GB capacity of the HPE 804638-003 SSD not only offers ample storage but also contributes to enhanced performance and speed. With more storage space available, the SSD can distribute data across a larger area, reducing the chances of data fragmentation. This results in faster read and write speeds, allowing you to access your files and applications quickly.
Future-Proof Your Storage Needs
As technology advances and file sizes continue to grow, having a high-capacity SSD like the HPE 804638-003 becomes increasingly essential. Investing in a product with an 800GB capacity ensures that you are future-proofing your storage needs. You won't have to worry about upgrading or replacing your SSD shortly because it will be able to accommodate your expanding storage requirements for years to come.
Flexible Storage Options
With 800GB of storage, you have the flexibility to allocate space for different purposes. You can partition the SSD to create separate storage compartments for specific files or applications. This flexibility allows you to keep your personal and business data separate or organize your files based on different categories, making it easier to manage and retrieve them when needed.
Effortless Backup and Recovery
Having a high-capacity SSD like the HPE 804638-003 makes backup and recovery processes effortless. You can easily create regular backups of your important files and applications without worrying about running out of space. In case of any data loss or system failure, you can quickly recover your data from the backup, ensuring minimal downtime and preserving your work and memories.
Form Factor: 3.5inch
A Perfect Fit in Your System
The HPE 804638-003 SSD features a form factor of 3.5 inches, making it a perfect fit for various systems and configurations. This form factor ensures compatibility with a wide range of desktops, servers, and storage arrays, offering versatility and ease of integration into your existing setup.
Optimal Use of Space
The 3.5-inch form factor of this SSD optimizes the use of available space inside your system. It allows for efficient airflow and heat dissipation, ensuring that the SSD remains cool even during intense usage. This optimal use of space helps in maintaining the overall performance and longevity of your system.
Easier Installation and Upgrade
The 3.5-inch form factor simplifies the installation and upgrade process for users. With its standardized size, you can easily replace or upgrade your existing storage device without any compatibility issues. Whether you are a tech enthusiast or a system administrator, the straightforward installation process ensures a hassle-free experience.
Expandable Storage Capacity
Choosing an SSD with a 3.5-inch form factor provides the advantage of expandable storage capacity. Many systems and servers support multiple 3.5-inch drive bays, allowing you to add additional SSDs for increased storage capacity. This expandability ensures that you can accommodate your growing data needs without significant hardware changes.
Seamless Integration with Existing Systems
The 3.5-inch form factor of the HPE 804638-003 SSD ensures seamless integration with your existing systems and configurations. Whether you are upgrading a personal desktop or expanding storage on a server, this SSD will fit right in without requiring any modifications or additional accessories.
Durability and Reliability
With its 3.5-inch form factor, this SSD offers enhanced durability and reliability. The larger size allows for robust construction and better protection against physical damage. The reliable performance of this form factor ensures that your data remains safe and accessible, even in demanding environments.
Intended Use: Write Intensive
The Power of Write Intensive SSD
The HPE 804638-003 SSD is designed for write-intensive applications, making it an ideal choice for users who require high-performance storage in scenarios involving frequent data writes. Whether you are running databases, virtualization platforms, or content delivery systems, the write-intensive nature of this SSD ensures optimal performance and endurance.
Exceptional Write Performance
Write-intensive SSDs like the HPE 804638-003 excel in delivering exceptional write performance. They are specifically engineered to handle heavy write workloads, ensuring that data is written quickly and efficiently. This capability is crucial for applications that involve continuous data updates, such as databases or transactional systems.
Extended Endurance and Longevity
Write-intensive SSDs are built to withstand the demands of frequent data writes, resulting in extended endurance and longevity. The HPE 804638-003 SSD is no exception, offering robust durability and reliability in write-intensive environments. You can rely on this SSD to consistently deliver high performance, even under heavy workloads.
Optimized for Data Integrity
With write-intensive applications, data integrity is of utmost importance. The HPE 804638-003 SSD features advanced error correction mechanisms and wear-leveling algorithms that ensure the integrity and consistency of your data. This optimization minimizes the risk of data corruption or loss, providing peace of mind for critical business operations.
Enhanced System Responsiveness
Write-intensive SSDs contribute to enhanced system responsiveness, as they can handle simultaneous read and write operations efficiently. This responsiveness is crucial for applications that require real-time data processing or quick response times, such as financial systems or virtualization platforms. With the HPE 804638-003 SSD, you can expect a smooth and lag-free user experience.
Cost-Effective Solution
Choosing a write-intensive SSD like the HPE 804638-003 can be a cost-effective solution in the long run. These SSDs offer higher endurance and longevity compared to standard SSDs, reducing the need for frequent replacements or upgrades. By investing in a durable and reliable write-intensive SSD, you are ensuring long-term savings and minimizing downtime.
Interface: SATA 6GBPS
The Speed and Efficiency of SATA 6Gbps
The HPE 804638-003 SSD features a SATA 6Gbps interface, delivering exceptional speed and efficiency for data transfer. This interface ensures that your SSD can communicate with your system at high speeds, allowing for quick access to your files and applications.
Blazing-Fast Data Transfer
The SATA 6Gbps interface provides blazing-fast data transfer speeds, enabling rapid file transfers and significantly reducing wait times. Whether you are copying large files, running resource-intensive applications, or performing data backups, the high-speed interface of the HPE 804638-003 SSD ensures that you can complete tasks in a fraction of the time.
Seamless Compatibility
The SATA 6Gbps interface is widely supported across various systems and devices, ensuring seamless compatibility with your existing infrastructure. You can easily connect the HPE 804638-003 SSD to your desktop, laptop, or server without any compatibility issues. This compatibility makes it an excellent choice for both personal and business users.
Efficient Power Management
SATA 6Gbps interface incorporates efficient power management features, optimizing power consumption and extending battery life in portable devices. This efficiency is particularly beneficial for laptop users who rely on their devices for extended periods without access to a power source. With the HPE 804638-003 SSD, you can enjoy improved battery life without compromising on performance.
Smooth Multitasking and Workflows
The high-speed interface of the HPE 804638-003 SSD ensures smooth multitasking and workflows. Whether you are working on resource-intensive tasks, running virtual machines, or editing multimedia content, the fast data transfer speeds enable seamless transitions between applications and smooth operation, eliminating any lag or slowdowns.
Enhanced System Boot Times
The SATA 6Gbps interface significantly reduces system boot times, allowing you to start your computer or server quickly. With faster boot times, you can save valuable time and increase productivity. Whether you are a professional who needs to access your work files promptly or a home user who wants to get straight into gaming, the HPE 804638-003 SSD ensures a swift and efficient startup process.
