HPE 836875-S01 Blade Server - 2x Intel Xeon E5-2650v3, 64gb DDR4 Sdram

Processor

The HPE 836875-S01 Blade Server is equipped with a powerful processor, the 2x Intel Xeon 10-core E5-2650v3 running at 2.3GHz. This processor is a key component of the server and plays a crucial role in its performance and capabilities.

Overview of the Hewlett Packard Enterprise Proliant BL460c G9

General Information

• Manufacturer: Hewlett Packard Enterprise
• Part Number: 836875-S01
• Product Name: Proliant BL460c G9 Blade Server

Processor & Chipset Details

Processor Specifications

• CPU: Intel Xeon E5-2650v3 at 2.3 GHz
• Max Turbo Frequency: 3 GHz
• Core Count: 10-core
• Number of CPUs: 2
• Maximum CPUs: 2
• Upgradability: Upgradeable

Processor Features

• Hyper-Threading Technology
• Intel Turbo Boost Technology 2

Cache Memory

• Cache Type: Smart Cache
• Installed Size: 50 MB
• Cache Per Processor: 25 MB

Memory Specifications

Installed and Supported Memory

• Installed Size: 64 GB, expandable to 512 GB
• Memory Technology: DDR4 SDRAM - Advanced ECC
• Memory Speed: 2133 MHz
• Compliance: PC4-17000
• Form Factor: DIMM 288-pin
• Configuration: 4 x 16 GB
• Supported RAM: PC4-17000 - 256 GB Registered ECC / 512 GB Load-Reduced ECC

Storage Capabilities

• Hard Drive: No HDD included
• Optical Drive: None

Storage Controllers

• Type: 1 x SAS-3 - PCIe 3.0 x8
• Controller Interface: SATA 6Gb/s / SAS 12Gb/s
• Controller Name: HP H244br Smart Host Bus Adapter
• RAID Levels: RAID 0, RAID 1

Graphics and Display

• Graphics Controller Type: Integrated Matrox G200eh

Network and Communication

• Interface Type: FlexibleLOM
• Ethernet Ports: 2 x 10 Gigabit Ethernet
• Ethernet Controller: HP FlexFabric 536FLB
• Data Link Protocols: Gigabit Ethernet, 10 Gigabit Ethernet, FCoE
• Remote Management: SNMP, IPMI 2.0, SMASH CLP
• Remote Management Controller: Integrated Lights-Out 4
• Compliant Standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ap, IEEE 802.1Qau

Expansion and Connectivity

Expansion Bays

• 2 x Hot-Swap 2.5" SFF (total)

Expansion Slots

• 2 x CPU slots (total)
• 16 x DIMM 288-pin slots (12 free)
• 2 x Expansion Slots (x16 mode)
• 1 x Internal microSDHC Card slot
• 1 x FlexibleLOM slot

Interfaces and Ports

• 1 x HP iLO
• 1 x USB 3.0 (internal)
• 2 x LAN (10 Gigabit Ethernet)

Miscellaneous Information

• Compliant Standards: ACPI 2.0, FIPS 140-2 Level 2, AES, Triple DES, ASHRAE
• Manufacturer Selling Program: HPE Smart Buy

Dimensions & Weight

• Width: 2.2 inches
• Depth: 20.4 inches
• Height: 7.1 inches
• Weight: 10.47 lbs

Unmatched Processing Power

Featuring two Intel Xeon 10-core E5-2650v3 processors, the HPE 836875-S01 Blade Server delivers exceptional processing power. With a base clock speed of 2.3GHz, this processor can handle demanding workloads and execute tasks quickly and efficiently. Whether you are running complex applications, virtualizing servers, or performing data-intensive tasks, the powerful processors ensure optimal performance.

Enhanced Multitasking

With a total of 20 cores and 40 threads, the HPE 836875-S01 Blade Server's processors enable efficient multitasking. You can run multiple applications simultaneously without experiencing any performance degradation. This is particularly beneficial in environments where there is a need to handle multiple tasks concurrently, such as virtualization or running multiple databases.

Improved Performance for Resource-Intensive Applications

Resource-intensive applications, such as database management systems or high-performance computing workloads, require substantial processing power. The 2x Intel Xeon 10-core E5-2650v3 processors deliver the performance needed to handle these demanding applications efficiently. With their high core count and clock speed, they can easily manage heavy workloads and provide smooth operation even under intense usage.

Efficient Power Consumption

Despite its exceptional performance, the Intel Xeon 10-core E5-2650v3 processors are designed with energy efficiency in mind. They feature Intel's advanced power management technologies, ensuring that power is utilized optimally without compromising performance. This results in lower power consumption, decreased energy costs, and a reduced environmental footprint.

Future-Proof Scalability

The HPE 836875-S01 Blade Server's processors offer excellent scalability, allowing you to adapt to evolving business needs. With the ability to support additional processors, you can easily expand your server's processing power as your workload grows. This scalability ensures that your server remains capable of handling future demands without requiring a complete hardware replacement.

Memory

Another essential feature of the HPE 836875-S01 Blade Server is its memory capacity. With 64GB (4x16GB) DDR4 SDRAM, this server provides ample memory to support demanding applications and workloads.

Improved Performance with Ample Memory

Memory plays a critical role in server performance, especially when dealing with memory-intensive applications such as virtualization or large databases. The 64GB DDR4 SDRAM in the HPE 836875-S01 Blade Server ensures that you have the necessary resources to handle these workloads efficiently. It allows for faster data access and retrieval, reducing latency and improving overall system performance.

Enhanced Multitasking and Virtualization

With 64GB of memory, the HPE 836875-S01 Blade Server can handle multiple tasks simultaneously without experiencing performance bottlenecks. This is particularly advantageous in virtualized environments where multiple virtual machines need to run concurrently. The ample memory capacity ensures smooth operation and minimal impact on performance even when running resource-intensive applications on multiple virtual machines.

Scalability and Future-Proofing

The HPE 836875-S01 Blade Server's memory capacity allows for future scalability. Should your workload grow and require additional memory, the server can accommodate up to its maximum supported capacity. This scalability ensures that your server can adapt to changing needs without the need for a complete hardware upgrade, providing a cost-effective solution for long-term growth.

Reliability and Data Integrity

Memory errors can lead to system crashes, data corruption, and potential data loss. The HPE 836875-S01 Blade Server utilizes DDR4 SDRAM, which includes built-in error detection and correction capabilities. This technology helps identify and correct memory errors on the fly, ensuring data integrity and improving system reliability.

Storage

The storage capabilities of the HPE 836875-S01 Blade Server are powered by the Smart Array H244br. This feature plays a crucial role in data management, storage performance, and overall system efficiency.

Optimized Data Storage and Management

The Smart Array H244br provides efficient data storage and management capabilities. It supports multiple RAID levels, allowing you to configure your storage for optimal performance, data redundancy, or a balance between the two. This flexibility ensures that you can tailor your storage solution to meet your specific requirements, whether it's maximizing performance or ensuring data integrity.

Improved Storage Performance

The Smart Array H244br enhances storage performance by utilizing advanced technologies such as caching and striping. Caching allows frequently accessed data to be stored in a high-speed cache, reducing latency and speeding up read operations. Striping distributes data across multiple drives, enabling parallel access and improving overall throughput. These technologies work together to deliver faster storage performance, reducing bottlenecks and improving overall system responsiveness.

Data Redundancy and Protection

Data loss can have severe consequences for businesses. The Smart Array H244br offers various RAID levels, including RAID 1, RAID 5, and RAID 10, which provide different levels of data redundancy and protection. RAID configurations help safeguard against drive failures by either mirroring data across multiple drives or using parity information to rebuild lost data. This redundancy ensures that your data remains accessible and protected, even in the event of a drive failure.

Scalability and Flexibility

The Smart Array H244br supports a wide range of storage configurations, offering flexibility and scalability. It can accommodate different drive sizes, including SAS and SATA drives, allowing you to choose the storage solution that best suits your needs. Additionally, the server's expansion capabilities enable you to add more storage capacity as your requirements grow, ensuring that your server can scale alongside your business.

Networking

The HPE 836875-S01 Blade Server is equipped with a 10Gb 2-port 536FLB Adapter for networking connectivity. This feature provides high-speed network connectivity, enabling efficient data transfer and communication within your network infrastructure.

High-Speed Data Transfer

The 10Gb 2-port 536FLB Adapter offers blazing-fast network connectivity, capable of transferring data at speeds of up to 10 gigabits per second (Gbps). This high-speed connection ensures minimal latency and faster data transfer between servers, storage systems, and other network devices. It is particularly beneficial in environments where large volumes of data need to be transferred quickly, such as data centers or high-performance computing clusters.

Enhanced Network Efficiency

The high-speed networking capabilities of the 10Gb 2-port 536FLB Adapter improve overall network efficiency. With its increased bandwidth, more data can be transmitted simultaneously, reducing bottlenecks and improving overall network performance. This is especially advantageous in environments with heavy network traffic or when multiple users are accessing shared resources simultaneously.

Virtualization Support

Virtualization is a key technology in modern IT environments, enabling efficient resource utilization and flexibility. The 10Gb 2-port 536FLB Adapter is designed to support virtualization, providing high-speed network connectivity to virtual machines. This ensures that network-intensive applications running on virtual machines can perform optimally, delivering a seamless user experience.

Future-Proofing and Compatibility

The 10Gb 2-port 536FLB Adapter offers compatibility with a wide range of network infrastructures, making it a future-proof networking solution. It supports various industry-standard protocols and can seamlessly integrate into existing network environments. This compatibility ensures that your server can adapt to changes in networking technologies without requiring hardware replacements, providing a cost-effective and scalable solution for your networking needs.

In conclusion, the HPE 836875-S01 Blade Server's Processor, Memory, Storage, and Networking features combine to deliver exceptional performance, scalability, and efficiency. The 2x Intel Xeon 10-core E5-2650v3 processors provide unmatched processing power and multitasking capabilities. The 64GB DDR4 SDRAM ensures efficient memory management for resource-intensive applications. The Smart Array H244br enhances storage performance, data protection, and scalability. Finally, the 10Gb 2-port 536FLB Adapter offers high-speed networking connectivity for efficient data transfer and network efficiency. Whether you are running complex applications, virtualizing servers, or managing large-scale data storage, the HPE 836875-S01 Blade Server provides the necessary features to meet your business needs.
