HPE 872505-001 400GB SAS-12GBPS SSD Hot Swap Mixed Use.

Overview of HPE 872505-001 Solid State Drive

• Manufacturer: Hewlett Packard Enterprise (HPE)
• Model Number: 872505-001
• Type: Solid State Drive (SSD)
• Capacity: 400GB

Technical Specifications

Drive Attributes

• Carrier Type: Smart Carrier
• Flash Memory Type: Multi-Level Cell (MLC)
• Sector Size: 512 bytes
• Firmware: Digitally Signed Firmware (DS)

Performance Metrics

Sequential Throughput

• Maximum Read Speed: 1075 MiB/s
• Maximum Write Speed: 1025 MiB/s

Random IOPS and Latency

• Average Latency for Random Reads (4KiB, Q1): 120 µs
• Average Latency for Random Writes (4KiB, Q1): 48 µs
• Random Read IOPS (4KiB, Queue Depth 16): 120,000 IOPS
• Random Write IOPS (4KiB, Queue Depth 16): 80,000 IOPS
• Maximum Random Read IOPS (4KiB, Queue Depth 32): 185,000 IOPS
• Maximum Random Write IOPS (4KiB, Queue Depth 16): 80,000 IOPS
• 4KiB Random Read/Write Performance (70% Read, 30% Write, Queue Depth 32): 105,000 IOPS
• 4KiB Random Read/Write Performance (50% Read, 50% Write, Queue Depth 32): 87,500 IOPS

Data Transfer Rate

• Drive Transfer Rate: 1.2 GB/s

Power Consumption

• Idle Power Consumption: 3.82 Watts
• Power for Random Reads: 4.33 Watts
• Power for Random Writes: 4.33 Watts
• Power for Sequential Reads: 6.41 Watts
• Power for Sequential Writes: 8.42 Watts
• Power for Random Read/Write: 4.33 Watts

Compatibility

HPE ProLiant DL Series

• DL120 Gen9 (2.5 Inch)
• DL160 Gen9 (2.5 Inch)
• DL360 Gen10 (2.5 Inch)
• DL380 Gen9 (2.5 Inch)
• DL385 Gen10 (2.5 Inch)
• DL560 Gen10 (2.5 Inch)
• DL580 Gen10 (2.5 Inch)

HPE ProLiant ML Series

• ML110 Gen10 (2.5 Inch)
• ML350 Gen10 (2.5 Inch)
• ML350 Gen9 (2.5 Inch)

HPE ProLiant WS Series

• WS460c Gen9 (2.5 Inch)

HPE ProLiant XL Series

• XL190r Gen9 (2.5 Inch)
• XL450 Gen10 (2.5 Inch)

Part Number: 872505-001

The HPE 400GB SAS-12GBPS SSD MLC is a high-performance solid-state drive designed for enterprise storage solutions. One of its key features is the part number, which in this case is 872505-001. This unique identifier plays a crucial role in ensuring compatibility and ease of ordering for users.

Compatibility and Interchangeability

The part number, 872505-001, is specific to the HPE 400GB SAS-12GBPS SSD MLC model. This means that it is designed to work seamlessly with the associated hardware and software configurations. By using the correct part number, users can ensure that the SSD will fit perfectly into their existing infrastructure.

Furthermore, the part number also allows for easy interchangeability. If a user needs to replace or upgrade their SSD, they can simply order another unit with the same part number and be confident that it will be compatible with their system. This eliminates the need for extensive compatibility checks and reduces downtime during the replacement process.

Ordering Convenience

Another benefit of the part number is that it simplifies the ordering process. Users can easily identify and select the HPE 400GB SAS-12GBPS SSD MLC by searching for its part number, 872505-001, on e-commerce platforms or contacting their preferred supplier. This ensures accurate ordering and avoids any confusion or delays that may arise from relying solely on product names or descriptions.

In addition, having a specific part number helps prevent users from accidentally purchasing incompatible or incorrect SSD models. This saves time and effort in returning or exchanging products, as well as avoiding potential compatibility issues that could impact system performance.

Warranty and Support

The part number, 872505-001, also plays a crucial role in warranty and support services. By registering the SSD with its unique part number, users can easily access technical support and warranty services specifically tailored to their product. This ensures prompt assistance in case of any issues or concerns, minimizing downtime and ensuring the longevity of the SSD.

Interface: SAS

The HPE 400GB SAS-12GBPS SSD MLC utilizes the Serial Attached SCSI (SAS) interface, which offers several advantages for users in enterprise storage environments.

High Data Transfer Rates

SAS provides exceptional data transfer rates, allowing for faster access to stored data. With a transfer rate of up to 12Gbps, the HPE 400GB SAS-12GBPS SSD MLC ensures quick and efficient data retrieval and storage. This is particularly important in demanding enterprise applications that require rapid access to large datasets.

Improved Scalability and Flexibility

SAS offers excellent scalability and flexibility for storage systems. It supports multiple devices connected in a daisy-chain configuration, allowing users to expand their storage capacity easily. This enables businesses to accommodate growing data requirements without significant infrastructure changes or disruptions.

In addition, SAS is compatible with both SAS and SATA hard drives, providing versatility when integrating different storage devices into a single system. This allows users to leverage existing hardware investments while benefiting from the superior performance of SAS SSDs like the HPE 400GB SAS-12GBPS SSD MLC.

Reliability and Redundancy

SAS also features robust error detection and correction capabilities, ensuring data integrity and minimizing the risk of data loss. It supports advanced features such as dual-port connectivity, which provides redundancy by allowing simultaneous connections to two independent host systems. This redundancy enhances system reliability and availability, making SAS an ideal choice for critical enterprise applications that require continuous operation.

Capacity: 400GB

The HPE 400GB SAS-12GBPS SSD MLC offers a storage capacity of 400GB, making it suitable for a wide range of enterprise storage needs.

Ample Storage Space

With 400GB of storage capacity, users can store large volumes of data, including applications, databases, and multimedia files. This allows businesses to consolidate their storage infrastructure and reduce the need for multiple drives or arrays.

Optimized Performance

The 400GB capacity of the HPE 400GB SAS-12GBPS SSD MLC strikes a balance between storage requirements and performance. It provides sufficient storage space for most enterprise applications while ensuring optimal read and write speeds. This allows for faster data access and improved application performance, enhancing overall productivity.

Scalability and Future-Proofing

While 400GB may meet the current storage needs of many enterprises, it is also important to consider future growth. The HPE 400GB SAS-12GBPS SSD MLC offers scalability options, allowing users to easily expand their storage capacity as their requirements increase. This ensures long-term viability and cost-effectiveness for businesses.

Speed: 12GBPS

The HPE 400GB SAS-12GBPS SSD MLC boasts a lightning-fast speed of 12Gbps, providing significant performance benefits for users in enterprise storage environments.

Rapid Data Transfer

The 12Gbps speed allows for ultra-fast data transfer rates, enabling quick access to stored information. This is especially crucial in data-intensive applications that require real-time processing or analysis. With the HPE 400GB SAS-12GBPS SSD MLC, users can experience reduced latency and improved system responsiveness, resulting in enhanced productivity and efficiency.

Accelerated Workloads

The high speed of 12Gbps significantly accelerates workloads, reducing the time required for data-intensive tasks. This is particularly beneficial for applications that involve complex calculations, simulations, or data processing. By leveraging the speed of the HPE 400GB SAS-12GBPS SSD MLC, users can improve overall system performance and deliver faster results.

Future-Proof Investment

Investing in a high-speed SSD like the HPE 400GB SAS-12GBPS SSD MLC ensures future-proofing for businesses. As technology advances and demands for faster data transfer rates increase, having a 12Gbps SSD allows users to stay ahead of the curve and effortlessly handle emerging workloads.

Hot Swap: 1

The HPE 400GB SAS-12GBPS SSD MLC features hot swap capability, offering convenience and flexibility for users in enterprise storage environments.

Minimized Downtime

The hot swap feature allows users to replace or upgrade SSDs without shutting down the entire system. This eliminates the need for system downtime, ensuring continuous operation and minimizing disruptions to critical business processes. Users can simply remove or insert the HPE 400GB SAS-12GBPS SSD MLC while the system is still running, saving valuable time and resources.

Ease of Maintenance

Hot swapping also simplifies maintenance procedures. With the HPE 400GB SAS-12GBPS SSD MLC, users can easily perform routine maintenance tasks such as firmware updates or drive replacements without interrupting normal operations. This reduces the complexity and time required for maintenance, allowing IT teams to focus on other critical tasks.

Flexibility in Configuration

The hot swap capability of the HPE 400GB SAS-12GBPS SSD MLC provides flexibility in storage configuration. Users can add or remove drives as needed, allowing for easy scalability and adaptability to changing storage requirements. This ensures that businesses can efficiently utilize their storage resources and optimize their infrastructure based on evolving needs.

Technology: Mixed

The HPE 400GB SAS-12GBPS SSD MLC utilizes mixed technology, combining the benefits of both Multi-Level Cell (MLC) and Single-Level Cell (SLC) NAND flash memory.

Enhanced Performance

The mixed technology employed in the HPE 400GB SAS-12GBPS SSD MLC offers improved performance compared to traditional MLC-only SSDs. By incorporating SLC NAND flash memory, which provides faster write speeds and higher endurance, the SSD can deliver superior overall performance, especially in write-intensive workloads.

Improved Endurance

SLC NAND flash memory offers higher endurance compared to MLC NAND flash memory. This means that the HPE 400GB SAS-12GBPS SSD MLC is capable of sustaining a larger number of program/erase cycles before reaching its maximum lifespan. The mixed technology ensures enhanced durability and longevity for the SSD, making it suitable for demanding enterprise environments.

Cost-Effective Solution

By incorporating both MLC and SLC NAND flash memory, the HPE 400GB SAS-12GBPS SSD MLC strikes a balance between performance and cost-effectiveness. The mixed technology allows users to benefit from the high performance of SLC NAND flash memory while still enjoying the affordability of MLC NAND flash memory. This makes the SSD an attractive option for businesses looking to maximize their storage performance without breaking the budget.
