HPE 877776-H21 480GB SATA 6GBPS Mixed Use SFF 2.5in SSD

877776-H21
Hover on image to enlarge

Brief Overview of 877776-H21

HPE 480GB SATA 6GBPS Mixed Use SFF 2.5inch SSD - 877776-H21. Excellent Refurbished with 6-Month Replacement Warranty
QR Code of HPE 877776-H21 480GB SATA 6GBPS Mixed Use SFF 2.5in SSD
$156.33
$110.40
You save: $45.93 (29%)
Ask a question
+
Quote
Additional 7% discount at checkout
SKU/MPN877776-H21Availability✅ In StockProcessing TimeUsually ships same day ManufacturerHPE Product/Item ConditionExcellent Refurbished ServerOrbit Replacement WarrantySix-Month (180 Days)
Our Advantages
  • Free Ground Shipping
  • — Min. 6-month Replacement Warranty
  • — Genuine/Authentic Products
  • — Easy Return and Exchange
  • — Different Payment Methods
  • — Best Price
  • — We Guarantee Price Matching
  • — Tax-Exempt Facilities
  • — 24/7 Live Chat, Phone Support
Payment Options
  • — Visa, MasterCard, Discover, and Amex
  • — JCB, Diners Club, UnionPay
  • — PayPal, ACH/Wire Transfer
  • — Apple Pay, Amazon Pay, Google Pay
  • — Buy Now, Pay Later - Affirm, Afterpay
  • — GOV/EDU/Institutions PO's Accepted
  • — Invoices
Delivery
  • — Deliver Anywhere
  • — Express Delivery in the USA and Worldwide
  • — Ship to -APO -FPO
  • For USA - Free Ground Shipping
  • — Worldwide - from $30

Same product also available in:

Description

HPE 480GB SATA 6GBPS Hot-Swap Solid State Drive

General Product Information

  • Manufacturer: HPE
  • Part Number: 877776-H21
  • Drive Type: Hot-Swap Solid State Drive
  • SSD Interface: SATA 6GBPS

Technical Details

  • Storage Capacity: 480 GB
  • Workload Classification: Mixed Use
  • Form Factor: 2.5 Inch Small Form Factor (SFF)
  • Plug Type: Hot Plug
  • Carrier Type: Smart Carrier
  • Flash Memory Type: Multi-Level Cell (MLC)
  • Firmware Features: Digitally Signed Firmware
  • Included Accessories: HPE Smart Drive Carrier

Performance Specifications

Endurance and Throughput

  • Total Lifetime Writes: 2950 TB
  • Drive Endurance (DWPD): 3.0
  • Maximum Sequential Read Throughput: 500 MiB/s
  • Maximum Sequential Write Throughput: 455 MiB/s

Random Access Performance

  • Average Latency for Random Reads (4KiB, Q1): 120 µs
  • Average Latency for Random Writes (4KiB, Q1): 48 µs
  • Random Read IOPS (4KiB, Q=16): 60,000
  • Random Write IOPS (4KiB, Q=16): 46,000
  • Maximum Random Read IOPS: 65,000 @ Q32
  • Maximum Random Write IOPS: 47,500 @ Q32
  • Drive Transfer Rate: 600 MB/s (External)

Physical Dimensions and Weight

Size Specifications

  • Height: 0.63 Inch (16 mm)
  • Width: 3.10 Inch (79 mm)
  • Depth: 5.45 Inch (138 mm)
  • Weight: 1.50 lbs (0.68 kg)

Power Consumption

Power Requirements

  • Idle Power Consumption: 1.25 Watts
  • Random Read Power Consumption: 2.42 Watts
  • Random Write Power Consumption: 4.25 Watts
  • Sequential Read Power Consumption: 2.19 Watts
  • Sequential Write Power Consumption: 4.44 Watts
  • Average Power (Random R/W): 3.06 Watts
  • Maximum Power Consumption: 5.00 Watts
  • Drive Height: 7 mm

Compatibility Information

Supported HPE ProLiant DL Series Models

  • DL120 Gen9 (2.5 Inch)
  • DL120 Gen9 Entry (2.5 Inch)
  • DL20 Gen9 (2.5 Inch)
  • DL20 Gen9 Base (2.5 Inch)
  • DL20 Gen9 Entry (2.5 Inch)
  • DL20 Gen9 Performance (2.5 Inch)
  • DL20 Gen9 Solution (2.5 Inch)
  • DL20 Gen9 Special Server (2.5 Inch)
  • DL385 Gen10 (2.5 Inch)
  • DL385 Gen10 Base (2.5 Inch)
  • DL385 Gen10 Entry (2.5 Inch)
  • DL385 Gen10 High-Performance (2.5 Inch)
  • DL385 Gen10 Performance (2.5 Inch)
  • DL385 Gen10 Solution (2.5 Inch)
  • DL580 Gen10 (2.5 Inch)
  • DL580 Gen10 Base (2.5 Inch)
  • DL580 Gen10 Entry (2.5 Inch)
  • DL580 Gen10 Performance (2.5 Inch)

Supported HPE ProLiant ML Series Models

  • ML110 Gen10 (2.5 Inch)
  • ML110 Gen10 Performance (2.5 Inch)
  • ML110 Gen10 Solution (2.5 Inch)
  • ML110 Gen9 (2.5 Inch)
  • ML110 Gen9 Base (2.5 Inch)
  • ML110 Gen9 Entry (2.5 Inch)
  • ML30 Gen9 Entry (2.5 Inch)
  • ML30 Gen9 Solution (2.5 Inch)
  • ML350 Gen10 (2.5 Inch)
  • ML350 Gen10 Base (2.5 Inch)
  • ML350 Gen10 Entry (2.5 Inch)
  • ML350 Gen10 Performance (2.5 Inch)
  • ML350 Gen10 Solution (2.5 Inch)
  • ML350 Gen10 Sub-Entry (2.5 Inch)

Supported HPE ProLiant XL Series Models

  • XL170R Gen10 (2.5 Inch) Server

Capacity

The HPE 480GB SATA 6GBPS Mixed Use SFF 2.5inch SSD Solid State Drive (SSD) offers a remarkable storage capacity of 480GB. This ample storage space provides users with the ability to store a vast amount of data, making it ideal for individuals and businesses alike.

Benefits of 480GB Capacity

Ample Storage Space

One of the key benefits of the HPE 480GB SSD is its ample storage space. With 480GB at your disposal, you can store a wide range of files, including documents, photos, videos, and even large software applications. This capacity ensures that you won't run out of storage anytime soon and can easily accommodate your growing data needs.

Efficient Workflow

Having a large storage capacity at your fingertips allows for a more efficient workflow. You can store all your essential files on the SSD, ensuring quick and easy access whenever you need them. This eliminates the need to constantly transfer files between devices or external storage solutions, saving you valuable time and effort.

Seamless Multimedia Experience

If you're an avid multimedia consumer or creator, the 480GB capacity of this SSD is perfect for you. You can store a vast collection of high-quality videos, music, and photos without worrying about running out of space. With quick access to your multimedia files, you can enjoy a seamless media experience without any lag or interruptions.

Importance of 480GB Capacity
Future-Proofing Your Storage Needs

Investing in a high-capacity SSD like the HPE 480GB ensures that you are future-proofing your storage needs. As technology advances and file sizes continue to grow, having a large capacity drive will become increasingly important. By choosing a 480GB SSD, you are preparing yourself for the future and avoiding the need to upgrade or expand your storage in the near future.

Accommodating Business Data

For businesses, having ample storage space is crucial. The 480GB capacity of this SSD allows businesses to store their essential data, including customer records, financial information, and important documents. With this capacity, businesses can easily manage their data without the need for multiple drives or external storage solutions.

Reducing Data Transfer Costs

By having a large storage capacity in a single drive, you can reduce data transfer costs. With 480GB of storage available, you can store all your necessary files in one place, eliminating the need for additional drives or cloud storage subscriptions. This not only saves you money but also simplifies your data management process.

Interface

The HPE 480GB SSD features a SATA 6GBPS interface, providing users with high-speed data transfer capabilities. This interface ensures efficient communication between your device and the SSD, resulting in enhanced performance and productivity.

Benefits of SATA 6GBPS Interface

Fast Data Transfer Speeds

One of the key benefits of the SATA 6GBPS interface is its fast data transfer speeds. With a maximum transfer rate of 6 gigabits per second (Gb/s), this interface allows for quick and seamless file transfers. Whether you're transferring large files or performing disk-intensive tasks, the high-speed interface ensures minimal waiting time.

Improved System Performance

The SATA 6GBPS interface significantly improves system performance by reducing data bottlenecks. With faster data transfer speeds, your operating system and applications can access and retrieve data from the SSD more quickly, resulting in improved overall system responsiveness. This is particularly beneficial for tasks that require frequent data access, such as video editing or running virtual machines.

Compatibility with Existing Systems

Another advantage of the SATA 6GBPS interface is its backward compatibility with previous SATA versions. This means that the HPE 480GB SSD can be seamlessly integrated into your existing system, whether it's a newer computer or an older one. You don't have to worry about compatibility issues or the need for additional hardware upgrades.

Importance of SATA 6GBPS Interface
Enhanced Data-intensive Tasks

For users who regularly work with large files or perform data-intensive tasks, the SATA 6GBPS interface is of utmost importance. It allows for quicker access to data stored on the SSD, reducing waiting times and improving productivity. Whether you're editing videos, rendering 3D models, or working with complex databases, the high-speed interface ensures smooth and efficient operation.

Upgrade Path for Older Systems

The SATA 6GBPS interface provides an upgrade path for older systems. If you have an older computer that lacks the latest connectivity options, upgrading to a SATA 6GBPS SSD can significantly improve its performance without the need for a complete system overhaul. By simply replacing your existing hard drive with the HPE 480GB SSD, you can experience faster data transfer speeds and improved overall system responsiveness.

Future-proofing Your Storage Solution

Investing in an SSD with a SATA 6GBPS interface ensures that you are future-proofing your storage solution. As technology advances and faster interfaces become standard, having a SATA 6GBPS SSD will ensure compatibility with future systems and devices. This means that you can continue using your HPE 480GB SSD in future systems without worrying about compatibility issues.

Form Factor

The HPE 480GB SSD has a form factor of 2.5 inches, specifically designed for Small Form Factor (SFF) applications. This compact size makes it suitable for a wide range of devices and allows for easy integration into both desktop and laptop computers.

Benefits of 2.5-inch SFF Form Factor

Space-saving Design

The 2.5-inch SFF form factor is known for its space-saving design. Compared to larger form factors, such as 3.5 inches, the smaller size of the HPE 480GB SSD allows for more efficient use of space within your computer chassis. This is particularly advantageous for users who have limited space or require multiple storage devices in their system.

Versatile Compatibility

The 2.5-inch SFF form factor offers versatile compatibility with a wide range of devices. Whether you want to upgrade your laptop or desktop computer, or even install the SSD in a server or storage array, the compact size ensures compatibility across various systems. This flexibility allows you to use the HPE 480GB SSD in different devices without any limitations.

Easy Installation

Installing the HPE 480GB SSD with a 2.5-inch SFF form factor is a breeze. The compact size and standardized mounting holes make it simple to fit the SSD into a compatible drive bay or enclosure. Whether you're a novice user or an experienced technician, the easy installation process saves you time and effort.

Importance of 2.5-inch SFF Form Factor
Compatible with Laptops

The 2.5-inch SFF form factor is particularly important for laptop users. Many laptops are designed to accommodate 2.5-inch drives, making the HPE 480GB SSD an ideal upgrade option. By replacing your laptop's existing hard drive with the SSD, you can experience faster boot times, improved application loading speeds, and overall enhanced performance.

Efficient Server Configuration

For servers or storage arrays that require multiple drives, the 2.5-inch SFF form factor allows for efficient configuration. The smaller size of the HPE 480GB SSDs enables more drives to be installed in a limited space, maximizing storage capacity without compromising on performance. This is crucial for businesses that require high-density storage solutions.

Flexibility for Desktop Systems

Desktop systems can also benefit from the 2.5-inch SFF form factor. Whether you have a compact desktop or a larger tower, the smaller size of the HPE 480GB SSD allows for more flexible configuration options. You can easily install the SSD in a drive bay or use an adapter to fit it into a larger slot, ensuring compatibility with various desktop systems.

Part Number

The HPE 480GB SSD has a part number of 877776-H21, which serves as a unique identifier for this particular model. The part number is essential for identifying and ordering the correct SSD, ensuring compatibility with your system.

Benefits of Part Number 877776-H21

Easy Identification

The part number 877776-H21 simplifies the identification process when purchasing or replacing an SSD. By referencing this unique identifier, you can ensure that you are selecting the correct model for your specific needs. This eliminates any confusion or potential compatibility issues that may arise from selecting the wrong product.

Compatibility Assurance

Having the correct part number guarantees compatibility with your system. Each part number is specifically assigned to a particular model, ensuring that it meets the necessary specifications and requirements for your device. By using the part number 877776-H21, you can rest assured that the HPE 480GB SSD will seamlessly integrate into your system without any issues.

Efficient Ordering Process

When ordering replacement parts or upgrades, having the correct part number streamlines the ordering process. By providing the part number 877776-H21 to your supplier or retailer, they can quickly locate and provide you with the exact SSD you require. This saves time and ensures that you receive the correct product promptly.

Importance of Part Number 877776-H21
Minimizing Compatibility Issues

Using the correct part number minimizes compatibility issues that may arise when replacing or upgrading your SSD. By referencing the part number 877776-H21, you can be confident that the SSD will work seamlessly with your existing system. This is particularly important for businesses that require consistent and reliable performance from their storage devices.

Streamlined Warranty and Support

Having the correct part number is vital when seeking warranty or support for your SSD. When contacting customer service or requesting assistance, providing the part number 877776-H21 helps expedite the process. It ensures that you receive the necessary support and services specifically tailored to your SSD model, ensuring a smooth resolution to any issues you may encounter.

Maintaining System Integrity

Using the correct part number when replacing or upgrading your SSD helps maintain system integrity. Each part number is associated with a particular model, ensuring that it meets the necessary specifications and requirements for your system. By using the part number 877776-H21, you are ensuring that your system remains stable and performs optimally with the new SSD installed.

Features
Product/Item Condition:
Excellent Refurbished
ServerOrbit Replacement Warranty:
Six-Month (180 Days)
