HPE 900GB 15K SAS 12GBPS LFF 512n Enterprise HDD 870761-H21

870761-H21
Hover on image to enlarge

Brief Overview of 870761-H21

HPE 900GB 15K RPM SAS 12GBPS LFF 512n Enterprise Hard Drive 870761-H21. Excellent Refurbished with 6-Month Replacement Warranty
QR Code of HPE 900GB 15K SAS 12GBPS LFF 512n Enterprise HDD 870761-H21
$607.50
$395.00
You save: $212.50 (35%)
Ask a question
+
Quote
Additional 7% discount at checkout
SKU/MPN870761-H21Availability✅ In StockProcessing TimeUsually ships same day ManufacturerHPE Product/Item ConditionExcellent Refurbished ServerOrbit Replacement WarrantySix-Month (180 Days)
Our Advantages
  • Free Ground Shipping
  • — Min. 6-month Replacement Warranty
  • — Genuine/Authentic Products
  • — Easy Return and Exchange
  • — Different Payment Methods
  • — Best Price
  • — We Guarantee Price Matching
  • — Tax-Exempt Facilities
  • — 24/7 Live Chat, Phone Support
Payment Options
  • — Visa, MasterCard, Discover, and Amex
  • — JCB, Diners Club, UnionPay
  • — PayPal, ACH/Wire Transfer
  • — Apple Pay, Amazon Pay, Google Pay
  • — Buy Now, Pay Later - Affirm, Afterpay
  • — GOV/EDU/Institutions PO's Accepted
  • — Invoices
Delivery
  • — Deliver Anywhere
  • — Express Delivery in the USA and Worldwide
  • — Ship to -APO -FPO
  • For USA - Free Ground Shipping
  • — Worldwide - from $30

Same product also available in:

Description

Specifications Overview

Product Identification

  • Brand: HPE
  • Part Number: 870761-H21
  • Spare Part Number: 870796-001
  • Model Number: EH000900JWCPN
  • Assembly Number: 867254-003
  • HPE Global Part Number (GPN): 868774-002

Device Characteristics

  • Type: Hot-Swap Hard Drive
  • Storage Capacity: 900 GB
  • Form Factor: 3.5 inch LFF Low Profile
  • Interface Type: SAS 12Gbps
  • Sector Size: 512 Bytes
  • Drive Technology: Air-Filled
  • Format: 512n
  • Carrier Design: Low Profile Carrier Converter (LPCC)
  • Workload Type: Enterprise
  • Special Features: Advanced format 512n, Dual Port, Digitally Signed Firmware
  • Included Accessories: HPE Low Profile Carrier Converter

Performance Metrics

Transfer Rates

  • External Drive Transfer Rate: 12 Gb/sec
  • Rotation Speed: 15000 RPM

Access Times

  • Average Seek Duration: 2.72 ms
  • Maximum Seek Duration: 5.36 ms
  • Track-to-Track Seek Duration: 0.22 ms

Throughput Performance

  • Maximum Sequential Throughput (MiB/s): 295 MiB/s
  • Random Read IOPS (128Kib): 235 IOPs
  • Random 70% Read / 30% Write IOPS (128Kib): 235 IOPs
  • Random 50% Read / 50% Write IOPS (128Kib): 235 IOPs

Connectivity and Expansion

  • Available Interfaces: 1 x SAS 12 Gb/s
  • Compatible Drive Bay: 3.5" LFF

Power Consumption

  • Idle Power Usage: 4.70 Watts
  • Random Read/Write Power Usage: 6.10 Watts
  • Sequential Read Power Usage: 6.30 Watts
  • Sequential Write Power Usage: 6.40 Watts

Physical Dimensions

  • Width: 4.20 inches
  • Depth: 6.20 inches
  • Height: 1.03 inches

Environmental Specifications

  • Minimum Operating Temperature: 50 °F
  • Maximum Operating Temperature: 95 °F

Compatibility

Supported HPE ProLiant DL Series

  • DL325 Gen10 Base (3.5 inch)

Supported HPE ProLiant ML Series

  • ML110 Gen10 (3.5 inch)
  • ML110 Gen10 Entry (3.5 inch)
  • ML110 Gen10 Performance (3.5 inch)
  • ML110 Gen10 Solution (3.5 inch)
  • ML30 Gen10 (3.5 inch)
  • ML30 Gen10 Entry (3.5 inch)
  • ML30 Gen10 Performance (3.5 inch)
  • ML30 Gen10 Solution (3.5 inch)
  • ML350 Gen10 (3.5 inch)
  • ML350 Gen10 Base (3.5 inch)
  • ML350 Gen10 Entry (3.5 inch)
  • ML350 Gen10 High Performance (3.5 inch)
  • ML350 Gen10 Performance (3.5 inch)
  • ML350 Gen10 Solution (3.5 inch)
  • ML350 Gen10 Sub-Entry (3.5 inch)

Supported HPE ProLiant XL Series

  • XL170r Gen9 (3.5 inch)
  • XL190r Gen9 (3.5 inch)

Capacity

The HPE 900GB 15K RPM SAS 12GBPS LFF 512n Enterprise Hard Drive Hard Drive boasts an impressive capacity of 900GB. This high storage capacity is a crucial feature for users who require ample space to store their data and applications.

Increased Storage Space

With 900GB of storage, users can store a vast amount of data, including documents, images, videos, and software applications. This allows businesses to consolidate their data in one location, making it easier to manage and access.

Efficient Data Management

The large capacity of the HPE 900GB hard drive enables efficient data management. Users can store and organize their files without worrying about running out of space. This eliminates the need for additional external storage devices, saving time and money.

Seamless Application Performance

The ample storage space provided by the HPE 900GB hard drive ensures smooth application performance. Users can install and run resource-intensive applications without experiencing slowdowns or crashes due to insufficient storage.

RPM

The HPE 900GB 15K RPM SAS 12GBPS LFF 512n Enterprise Hard Drive features a rotational speed of 15,000 revolutions per minute (RPM). This high-speed rotation offers numerous benefits for users in terms of performance and reliability.

Improved Data Access Speed

The 15K RPM rotational speed of this hard drive allows for faster data access times. Users can retrieve their files and applications more quickly, resulting in improved productivity and reduced wait times.

Enhanced Application Performance

The high RPM of the HPE 900GB hard drive contributes to enhanced application performance. Applications installed on this drive can load and run faster, delivering a seamless user experience even for resource-intensive tasks.

Reduced Latency

The 15K RPM speed of this hard drive helps to minimize latency, which refers to the delay between a request for data and its delivery. With reduced latency, users can enjoy a more responsive system, especially when working with large files or performing data-intensive operations.

Interface

The HPE 900GB 15K RPM SAS 12GBPS LFF 512n Enterprise Hard Drive is equipped with a SAS 12GBPS interface. This interface offers significant advantages in terms of data transfer speed, scalability, and reliability.

High Data Transfer Speed

The SAS 12GBPS interface provides a high data transfer rate, enabling users to quickly and efficiently move large amounts of data to and from the hard drive. This is particularly beneficial for tasks such as data backup, database management, and multimedia content creation.

Scalability and Flexibility

The SAS interface offers excellent scalability and flexibility. Users can easily add more SAS drives to their system, creating a storage solution that can grow with their needs. This makes it ideal for businesses that anticipate future expansion or require a scalable storage infrastructure.

Reliability and Redundancy

SAS drives are known for their reliability and redundancy features. The SAS 12GBPS interface ensures data integrity and minimizes the risk of data loss or corruption. Additionally, SAS drives support RAID configurations, allowing users to create redundant arrays for added data protection.

Form Factor

The HPE 900GB 15K RPM SAS 12GBPS LFF 512n Enterprise Hard Drive features a Large Form Factor (LFF). This physical size provides several advantages in terms of storage density, compatibility, and ease of installation.

Increased Storage Density

The LFF form factor allows for a higher storage density, meaning more data can be stored in the same physical space. This is particularly beneficial for data centers and server environments where maximizing storage capacity is essential.

Compatibility with Server Systems

The LFF form factor is widely used in server systems, making the HPE 900GB hard drive compatible with a wide range of server models and configurations. This ensures seamless integration into existing server infrastructure without the need for additional modifications or adapters.

Straightforward Installation

The LFF form factor simplifies the installation process. The hard drive can be easily inserted into the dedicated drive bays of compatible servers, allowing for quick and hassle-free setup.

Sector Type

The HPE 900GB 15K RPM SAS 12GBPS LFF 512n Enterprise Hard Drive utilizes a 512n sector type. This sector type offers several benefits in terms of data reliability, compatibility, and performance.

Data Reliability and Integrity

The 512n sector type ensures data reliability and integrity by using a traditional sector size of 512 bytes. This sector size has been widely adopted and proven to be highly reliable over time, minimizing the risk of data corruption or loss.

Compatibility with Legacy Systems

The 512n sector type is compatible with legacy systems that rely on the traditional sector size. This allows users to upgrade their storage capacity without worrying about compatibility issues or the need for additional system modifications.

Optimized Performance

The 512n sector type offers optimized performance for a wide range of applications and operating systems. It provides efficient data access and retrieval, resulting in improved overall system performance.

Part Number

The HPE 900GB 15K RPM SAS 12GBPS LFF 512n Enterprise Hard Drive has a part number of 870761-H21. This part number serves as a unique identifier for the specific hard drive model and is essential for ordering, compatibility, and warranty purposes.

Easy Ordering and Identification

The part number simplifies the ordering process, ensuring that users receive the correct hard drive model they require. It eliminates any confusion or ambiguity, allowing for accurate product selection and fulfillment.

Compatibility Verification

The part number also serves as a compatibility verification tool. Users can cross-reference the part number with their server or storage system specifications to ensure that the hard drive is compatible with their existing hardware.

Warranty and Support

The part number is crucial for warranty and support purposes. It allows users to register their product, request technical assistance, and access warranty services. Having the correct part number ensures a smooth and efficient support experience if any issues or concerns arise.

Features
Product/Item Condition:
Excellent Refurbished
ServerOrbit Replacement Warranty:
Six-Month (180 Days)
