P19892-K21 HPE 960GB SATA 6GBPS Read Intensive M.2 2280 SSD
- — Free Ground Shipping
- — Min. 6-month Replacement Warranty
- — Genuine/Authentic Products
- — Easy Return and Exchange
- — Different Payment Methods
- — Best Price
- — We Guarantee Price Matching
- — Tax-Exempt Facilities
- — 24/7 Live Chat, Phone Support
- — Visa, MasterCard, Discover, and Amex
- — JCB, Diners Club, UnionPay
- — PayPal, ACH/Bank Transfer (11% Off)
- — Apple Pay, Amazon Pay, Google Pay
- — Buy Now, Pay Later - Affirm, Afterpay
- — GOV/EDU/Institutions PO's Accepted
- — Invoices
- — Deliver Anywhere
- — Express Delivery in the USA and Worldwide
- — Ship to -APO -FPO
- — For USA - Free Ground Shipping
- — Worldwide - from $30
Same product also available in:
| SKU/MPN | Warranty | Price | Condition | You save |
|---|---|---|---|---|
| P19892-K21 | 1 Year Warranty | Contact us for a price | Factory-Sealed New in Original Box (FSB) | |
| P19892-K21 | 1 Year Warranty | $128.00 | Excellent Refurbished | You save: $44.80 (26%) |
Overview of the Storage Derive
The SSDs adhere to the M.2 2280 form factor, which has become a standard for modern enterprise and server storage solutions. The 2280 designation refers to a 22mm width and 80mm length, ensuring compatibility with a wide array of servers, storage appliances, and high-performance workstations. The compact form factor of M.2 drives allows for more efficient system designs, reduced cable clutter, and enhanced airflow, all contributing to the overall stability and thermal management of enterprise systems.
General Specification
- Brand: HPE
- Part Number: P19892-K21
- Device Type: Internal Solid State Drive (SSD)
Technical Information
- Storage Capacity: 960GB
- Form Factor: M.2 2280
- Interface: SATA 6Gbps
- Flash Memory Type: Triple-Level Cell (TLC)
- Firmware Security: Digitally Signed Firmware
- Plug Type: Non-Hot Pluggable
- Target Workload: Read-Intensive Operations
- Supported Platform: HPE Mainstream Compute Platforms
- Dimensions: M.2 2280
Performance Details
Endurance and Write Capacity
- 30-Day Writes: 2628 TB
- Endurance DWPD: 1.50
- Total SSD Endurance: 2628 TB
Data Transfer
- Drive Transfer Rate: 600 MBps (External)
- Maximum Sequential Read Throughput: 510 MiB/s
- Maximum Sequential Write Throughput: 490 MiB/s
Latency and Input/Output Operations Per Second (IOPS)
- Random Read Latency (4KiB, Q1): 125 µs
- Random Write Latency (4KiB, Q1): 38 µs
- Random Read IOPS (4KiB, Q=16): 67,000
- Random Write IOPS (4KiB, Q=16): 37,000
- Max Random Read IOPS (4KiB): 76,000 at Q32
- Max Random Write IOPS (4KiB): 38,000 at Q64
Expansion and Connectivity
Interface and Compatibility
- Interface Type: SATA 6 Gb/s - M.2 Card
- Compatible Bay: M.2 2280 Slot
Power Consumption
Power Efficiency in Different Modes
- Idle Power Consumption: 1.04 W
- Power During Random Read: 1.27 W
- Power During Random Write: 1.27 W
- Power During Sequential Read: 2.10 W
- Power During Sequential Write: 2.80 W
- Max Power Draw: 2.80 W
Compatibility Information
Supported HPE ProLiant DL Series Models
- DL110 Gen10 Plus Front Cabled Telco, DL160 Gen10 (Base, Entry, SMB)
- DL180 Gen10 (Base, Entry, SMB), DL20 Gen10 (Entry, Performance, Solution)
- DL325 Gen10 Plus (All-NVMe Flash Node for Qumulo, Software Defined Storage)
- DL345 Gen10 Plus (Base, Entry)
- DL360 Gen10 (All Flash, Network Choice, Premium, SMB)
- DL380 Gen10 (All Flash, Network Choice for SAP HANA, NVMe for Datera)
- DL385 Gen10 (SMB)
- DL560 Gen10 (SAP HANA Compute Block)
Supported HPE ProLiant ML Series Models
- ML350 Gen10 (High Performance, SMB, Special Server)
Compatibility with HPE SimpliVity Series
- HPE SimpliVity 325 Gen10 Plus V2 Node
Capacity: 960GB
The Benefits of a Large Storage Capacity
One of the standout features of the HPE P19892-K21 SSD is its impressive capacity of 960GB. This generous amount of storage space provides users with ample room to store their files, applications, and data without worrying about running out of space.
Whether you are a casual user who needs storage for personal documents, photos, and videos, or a professional who deals with large files and extensive databases, having a high-capacity SSD like the HPE P19892-K21 can greatly enhance your productivity and convenience.
Store More Data
With 960GB at your disposal, you can store a vast amount of data. This includes thousands of high-resolution photos, hours of HD videos, and even large software applications. You won't have to worry about constantly deleting files or transferring them to an external storage device to free up space. This increased storage capacity allows you to keep all your important files in one place for easy access.
Improve Performance
Aside from the convenience of having more storage space, a larger capacity SSD can also improve overall system performance. As the drive has more room to store files, it can distribute and access data more efficiently, resulting in faster read and write speeds. This means that tasks like booting up your computer, launching applications, and accessing files will be much quicker and seamless.
Interface: SATA 6GBPS
The Advantages of SATA 6GBPS
The HPE P19892-K21 SSD features a SATA 6GBPS interface, which offers several advantages for users. This advanced interface technology enhances data transfer speeds, reliability, and compatibility, making it an excellent choice for both casual users and professionals.
Faster Data Transfer Speeds
The SATA 6GBPS interface provides significantly faster data transfer speeds compared to its predecessors. With a maximum transfer rate of 6 gigabits per second, you can enjoy rapid file transfers, shorter loading times, and improved overall system performance. Whether you are transferring large files or regularly backup your data, the HPE P19892-K21's SATA 6GBPS interface ensures that these tasks are completed quickly and efficiently.
Backward Compatibility
One of the key advantages of the SATA 6GBPS interface is its backward compatibility. This means that the HPE P19892-K21 SSD can be easily connected to older systems that have SATA II or SATA III interfaces. You won't have to worry about compatibility issues or the need for additional adapters or converters. This makes upgrading to the HPE P19892-K21 SSD a seamless process, regardless of your current system configuration.
Reliability and Durability
SATA 6GBPS interfaces are known for their reliability and durability. The HPE P19892-K21 SSD's SATA 6GBPS interface ensures a stable and consistent connection between the drive and your system. This reduces the risk of data corruption or loss due to connection issues. Additionally, the interface is designed to withstand heavy usage and provides excellent resistance against shock and vibration, making it an ideal choice for portable devices or systems in demanding environments.
Usage: Read Intensive
The Advantages of Read Intensive SSDs
The HPE P19892-K21 SSD is specifically designed for read-intensive workloads, offering several advantages for users who require fast and reliable data access. This makes it an ideal choice for applications such as content delivery, virtualization, and media streaming, where read speeds play a crucial role.
Improved Read Performance
Read-intensive SSDs, like the HPE P19892-K21, prioritize read speeds over write speeds. This means that accessing data stored on the drive will be significantly faster compared to traditional hard drives or even other types of SSDs. Whether you are loading large files, retrieving data from a database, or accessing frequently used applications, the HPE P19892-K21's read-intensive design ensures that these tasks are completed swiftly and efficiently.
Enhanced Endurance
Read-intensive SSDs are built to withstand extensive read operations, making them highly durable and long-lasting. The HPE P19892-K21 SSD's read-intensive design ensures that it can handle continuous read requests without experiencing performance degradation or premature wear. This makes it suitable for applications that require constant data access, such as media servers or databases.
Form Factor: M.2 2280
The Advantages of M.2 2280 Form Factor
The HPE P19892-K21 SSD features the M.2 2280 form factor, which offers several advantages in terms of size, flexibility, and compatibility. This compact form factor has gained popularity in recent years due to its versatility and ability to fit into various devices and systems.
Compact Size
The M.2 2280 form factor is known for its compact size. Measuring only 22mm in width and 80mm in length, the HPE P19892-K21 SSD can fit into small form factor devices such as ultrabooks, tablets, and mini PCs without compromising on storage capacity or performance. This makes it an excellent choice for users who require high-speed storage in portable devices or space-constrained systems.
Better Heat Dissipation
M.2 2280 SSDs, including the HPE P19892-K21, are designed with heat dissipation in mind. The form factor allows for better airflow and heat dissipation compared to traditional 2.5-inch SSDs. This ensures that the drive stays cool even during intensive operations, reducing the risk of thermal throttling and maintaining optimal performance over extended periods of use.
One of the key advantages of the M.2 2280 form factor is its wide compatibility with modern systems. Most motherboards and laptops released in recent years come equipped with M.2 slots that support this form factor. This means that you can easily upgrade your existing system or build a new one without worrying about compatibility issues. The HPE P19892-K21 SSD's M.2 2280 form factor ensures that it can be seamlessly integrated into a wide range of devices and systems.
