HPE Aruba 2530-24G PoE+ Managed Switch - J9773A#ACC

Device Overview

Switch Type and Ports

• Type: Managed Switch
• Port Count: 24 x 10/100/1000 Mbps
• Additional Ports: 4 x Gigabit SFP

Physical Specifications

• Enclosure: Desktop, Rack-mountable, Wall-mountable - 1U
• Processor: ARM 800 MHz
• RAM: 128 MB DDR3 SDRAM
• Flash Memory: 256 MB

Networking Capabilities

Performance Metrics

• Throughput: 41.6 Mpps
• Switching Capacity: 56 Gbps
• MAC Address Table: 16,000 Entries
• Jumbo Frame Support: Up to 9220 bytes

Power over Ethernet

• PoE Standard: PoE+

Management and Protocols

• Protocols: SNMP v1, SNMP v2c, SNMP v3, RMON (1, 2, 3, 9), Telnet, HTTP, TFTP, SSH-2, CLI
• Encryption: SSL
• Authentication: RADIUS, TACACS+, SSH v2

Compliance Standards

• IEEE Standards: 802.3, 802.3u, 802.1d, 802.1q, 802.3ab, 802.1p, 802.3x, 802.3ad (LACP), 802.1w, 802.1x, 802.1s, 802.1AB (LLDP), 802.3at, 802.3az

Expansion and Connectivity

Interfaces

• RJ-45: 24 x 10BASE-T/100BASE-TX/1000BASE-T (PoE+)
• SFP Ports: 4
• Management Console: 1 x RJ-45

Power Requirements

Power Supply

• Device: Internal Power Supply
• Voltage: AC 120/230 V (50/60 Hz)

Ports

The HPE Aruba 2530-24G Managed Switch is equipped with 24 Gigabit Ethernet ports, providing users with a high-performance solution for their networking needs. With 24 Gigabit ports, this switch offers ample connectivity options for various devices and ensures fast and reliable data transfer rates.

Increased Connectivity

One of the key benefits of the 24 Gigabit Ethernet ports is the increased connectivity it offers. Whether you have a small office or a large enterprise network, having 24 ports allows you to connect multiple devices such as computers, servers, printers, and IP phones, all at the same time. This eliminates the need for additional switches or hubs, simplifying your network infrastructure and reducing costs.

High-Speed Data Transfer

The Gigabit Ethernet ports support data transfer rates of up to 1000 Mbps, offering blazing-fast speeds for your network. This is particularly important in today's fast-paced business environment where large files need to be transferred quickly and efficiently. With the HPE Aruba 2530-24G Managed Switch, you can ensure smooth data flow and minimize bottlenecks, enhancing productivity and user experience.

Improved Network Performance

By utilizing 24 Gigabit Ethernet ports, this managed switch enables efficient data routing and reduces network congestion. Each port can handle a substantial amount of traffic, allowing for simultaneous data transfers without affecting the overall performance of your network. This is especially beneficial in scenarios where bandwidth-intensive applications or multimedia streaming are involved.

Flexibility and Scalability

The HPE Aruba 2530-24G Managed Switch's 24 Gigabit Ethernet ports provide flexibility and scalability for your network infrastructure. You can easily expand your network by connecting additional devices without worrying about running out of available ports. This scalability is essential for growing businesses that require a switch capable of accommodating future expansion and increasing network demands.

Enhanced Security

With 24 Gigabit Ethernet ports, the HPE Aruba 2530-24G Managed Switch allows for the implementation of advanced security measures. You can segregate your network into different VLANs (Virtual Local Area Networks) to isolate sensitive data and control access to specific resources. Additionally, the switch supports advanced security protocols such as IEEE 802.1X port-based authentication, ensuring only authorized devices can connect to your network.

Ease of Management

Managing a network with 24 Gigabit Ethernet ports becomes more efficient and convenient. The switch offers various management features, including a web-based interface and command-line interface (CLI), allowing you to configure and monitor your network easily. Additionally, the HPE Aruba 2530-24G Managed Switch supports SNMP (Simple Network Management Protocol), enabling centralized management and monitoring of multiple switches in your network.

Cost-Effective Solution

The HPE Aruba 2530-24G Managed Switch's 24 Gigabit Ethernet ports provide a cost-effective solution for organizations of all sizes. By offering ample connectivity options in a single device, it eliminates the need for additional switches or infrastructure upgrades, saving both time and money. Furthermore, the switch's energy-efficient design helps reduce power consumption, resulting in lower operating costs over time.

PoE+

The HPE Aruba 2530-24G Managed Switch features PoE+ (Power over Ethernet Plus) capability, which is an essential feature for users who require power delivery to their network devices.

Power and Data Delivery

PoE+ enables the switch to deliver both power and data over Ethernet cables, eliminating the need for separate power adapters or electrical outlets for connected devices. This simplifies installation and reduces cable clutter, making it an ideal solution for environments where power outlets may be limited or difficult to access.

Compatibility with PoE Devices

The HPE Aruba 2530-24G Managed Switch's PoE+ capability is compatible with a wide range of PoE devices such as IP phones, wireless access points, and IP cameras. These devices can be easily connected and powered through the switch, eliminating the need for individual power sources. This convenience and flexibility make PoE+ a popular choice for organizations looking to deploy network devices in areas where power availability may pose a challenge.

Cost Savings

Implementing PoE+ with the HPE Aruba 2530-24G Managed Switch can result in significant cost savings. By eliminating the need for separate power adapters and electrical wiring, you can reduce installation costs and simplify infrastructure management. Additionally, PoE+ allows for centralized power control and monitoring, enabling more efficient energy usage and lowering electricity expenses.

Improved Reliability

With PoE+ capability, the HPE Aruba 2530-24G Managed Switch ensures a reliable power supply to connected devices. Power failures or interruptions in individual power sources do not affect the operation of PoE-powered devices as they are powered directly from the switch. This reliability is crucial for critical applications such as IP phones or security cameras that require uninterrupted power to maintain functionality.

Flexibility in Deployment

The HPE Aruba 2530-24G Managed Switch's PoE+ capability provides flexibility in device placement. You can deploy network devices in locations where power outlets are limited or not easily accessible, such as ceilings or walls. This flexibility allows for more efficient network design and provides greater freedom in choosing the optimal placement for devices without compromising performance.

Scalability

The PoE+ capability of the HPE Aruba 2530-24G Managed Switch supports future scalability. As your network grows and additional PoE devices are added, the switch can accommodate the increased power requirements. This scalability ensures that your network can adapt to changing needs without the need for additional power infrastructure upgrades.

SFP Ports

The HPE Aruba 2530-24G Managed Switch is equipped with 4 SFP (Small Form-Factor Pluggable) ports, offering users enhanced connectivity options and flexibility.

Extended Connectivity

The 4 SFP ports of the HPE Aruba 2530-24G Managed Switch provide the ability to connect to fiber optic networks. This enables long-distance data transmission and allows for connectivity to devices located in remote areas or across different buildings. By utilizing SFP modules, you can extend your network beyond the limitations of traditional Ethernet connections.

High-Speed Fiber Optic Connectivity

SFP ports support high-speed fiber optic connections, offering significantly faster data transfer rates compared to copper-based Ethernet. This is particularly important in scenarios where bandwidth-intensive applications or large data transfers are involved. With SFP ports, you can ensure a reliable and high-performance network connection for demanding tasks such as video streaming or data center interconnectivity.

Flexibility in Network Design

The addition of 4 SFP ports in the HPE Aruba 2530-24G Managed Switch provides flexibility in network design. You can choose between copper-based Ethernet or fiber optic connections based on your specific requirements. This flexibility allows for optimal network design and ensures compatibility with a wide range of networking equipment.

Long-Distance Connectivity

The use of fiber optic connections through SFP ports allows for long-distance connectivity without compromising data transfer speeds. Fiber optic cables can transmit data over much greater distances compared to traditional Ethernet cables, making them ideal for connecting devices in different parts of a building or across multiple locations. This long-distance connectivity is particularly beneficial for businesses with distributed offices or remote branches.

Improved Network Performance

By leveraging the high-speed capabilities of SFP ports, the HPE Aruba 2530-24G Managed Switch enhances network performance. Fiber optic connections offer low latency and high bandwidth, resulting in faster and more reliable data transmission. This improved network performance eliminates bottlenecks and ensures smooth operation, even in demanding environments.

Future-Proofing

The inclusion of 4 SFP ports in the HPE Aruba 2530-24G Managed Switch provides future-proofing for your network infrastructure. As the demand for higher bandwidth continues to grow, fiber optic connections become increasingly important. By having SFP ports available, you can easily upgrade your network to support faster and more advanced networking technologies without replacing the entire switch.

Part Number

The HPE Aruba 2530-24G Managed Switch's part number is J9773A#ACC. This unique identifier is essential for users to ensure they are purchasing the correct model and to simplify maintenance and support processes.

Model Identification

The part number J9773A#ACC serves as a specific model identification for the HPE Aruba 2530-24G Managed Switch. With numerous switch models available in the market, having a unique part number allows users to identify and select the correct switch that meets their specific requirements. This ensures compatibility with existing network infrastructure and avoids potential compatibility issues.

Warranty and Support

The part number J9773A#ACC is crucial for warranty and support purposes. When registering the switch or contacting customer support, providing the correct part number enables faster and more accurate assistance. It ensures that you receive the proper support and access to firmware updates, bug fixes, and other resources specific to your switch model.

Easy Replacement and Maintenance

In the event of hardware failure or the need for a replacement part, the part number J9773A#ACC simplifies the process. When ordering a replacement switch or spare parts, providing the correct part number ensures you receive the exact model and components needed for seamless integration into your network. This eliminates confusion and potential compatibility issues that can arise when using incorrect part numbers.

Compatibility with Accessories

The part number J9773A#ACC is also important when selecting and purchasing compatible accessories for the HPE Aruba 2530-24G Managed Switch. Whether it's rack-mount kits, transceivers, or additional modules, having the correct part number ensures that the accessories are compatible with your specific switch model. This compatibility guarantees proper functioning and allows for easy expansion or customization of your network infrastructure.

Product Documentation

The part number J9773A#ACC is used throughout product documentation such as user manuals, installation guides, and technical specifications. Having this part number readily available allows users to quickly access relevant information about their switch model. This information is invaluable when configuring, troubleshooting, or performing routine maintenance tasks on the switch.

Inventory Management

For organizations managing a large number of network switches, the part number J9773A#ACC aids in inventory management processes. By accurately identifying each switch model with its unique part number, organizations can easily track and manage their network assets. This simplifies tasks such as asset tracking, warranty management, and budgeting for future network expansions or upgrades.

In conclusion, the HPE Aruba 2530-24G Managed Switch with its 24 Gigabit Ethernet ports, PoE+ capability, 4 SFP ports, and part number J9773A#ACC offers users a versatile and high-performance networking solution. The 24 Gigabit Ethernet ports provide increased connectivity options, high-speed data transfer, improved network performance, and scalability. The PoE+ feature simplifies power delivery to network devices, reduces costs, improves reliability, and offers flexibility in deployment. The 4 SFP ports enhance connectivity options, provide high-speed fiber optic connectivity, flexibility in network design, long-distance connectivity, improved network performance, and future-proofing. Lastly, the part number J9773A#ACC ensures proper model identification, simplified warranty and support processes, easy replacement and maintenance, compatibility with accessories, access to product documentation, and efficient inventory management. With these features and benefits, the HPE Aruba 2530-24G Managed Switch is an excellent choice for organizations looking to enhance their network infrastructure.
