HPE BL2X220C Server 611116-B21 X5670/2.93GHz, 24GB DDR3 SDRAM

HPE 611116-B21 Processor

The HPE BL2X220C Server is equipped with a powerful 6-Core XEON X5670 processor. This processor is designed to deliver exceptional performance and efficiency, making it an ideal choice for demanding workloads and applications.

Main Information of 6-Core XEON

The Hewlett Packard Enterprise Proliant BL2x220c G7 Blade Server offers robust performance and reliability for enterprise needs. With its powerful processors and scalable memory options, it is designed to handle demanding applications and workloads efficiently.

Manufacturer Details

• Manufacturer: Hewlett Packard Enterprise
• Manufacturer Part Number: 611116-B21
• Product Name: Proliant BL2x220c G7 - 2-Way Blade Server

Processor and Chipset

• Processor Type: Intel Xeon X5670 / 2.93 GHz
• Number of Cores: Hexa-core
• 64-bit Computing: Supported
• Installed Processors: 2
• Maximum Supported Processors: 2
• Upgrade Options: Expandable
• Chipset: Intel 5500

Cache Memory

• Cache Type: L3 Cache
• Installed Cache Size: 24 MB
• Cache per Processor: 12 MB

Memory Specifications

• Installed RAM: 24 GB
• Maximum RAM Capacity: 96 GB
• Memory Technology: DDR3 SDRAM
• Memory Speed: 1333 MHz
• Compliance: PC3-10600
• Form Factor: DIMM 240-pin
• Memory Features: Registered
• Configuration: 6 x 4 GB
• Supported RAM Types: PC3-10600 - 96 GB (Registered), PC3-10600 - 24 GB (Unbuffered)

Storage Information

• Hard Drive: 1 x 250 GB SATA 300 (Non-hot Plug)

Storage Controllers

• Controller Type: Integrated SATA
• Interface Type: SATA-150

Graphics and Display

• Graphics Controller: Integrated

Networking and Communication

• Network Adapter: Integrated
• Ethernet Ports: 2 x Gigabit Ethernet
• Ethernet Controller: HP NC362i
• Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
• Features: Wake On LAN (WOL)
• Compliance: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

Expansion and Connectivity

• Expansion Bays: 1 x Internal 2.5" SFF (Total)
• Expansion Slots: 2 x Processor, 6 x Memory (DIMM 240-pin)

Interfaces and Ports

• Management Port: 1 x HP iLO - RJ-45
• Network Ports: 2 x Ethernet (10Base-T/100Base-TX/1000Base-T) - RJ-45

Dimensions and Weight

• Width: 2.2 inches
• Depth: 20.1 inches
• Height: 7.2 inches
• Weight: 15.5 lbs

Enhanced Performance

The 6-Core XEON X5670 processor offers six processing cores, which allows for the simultaneous execution of multiple tasks. This multi-core architecture enables higher processing power and improved performance, especially when handling resource-intensive applications such as virtualization, database management, and high-performance computing. With this processor, users can experience faster data processing, reduced latency, and improved overall system responsiveness.

Improved Productivity

The increased core count of the 6-Core XEON X5670 processor enables users to run multiple applications simultaneously without experiencing significant slowdowns. This capability is particularly beneficial for businesses that rely on multitasking or need to handle a large number of concurrent users. With the ability to handle more tasks at once, users can enhance productivity and streamline their workflows, resulting in improved efficiency and reduced downtime.

Optimized Virtualization

Virtualization has become a critical technology for businesses looking to improve server utilization and reduce infrastructure costs. The 6-Core XEON X5670 processor offers advanced virtualization features that enable efficient consolidation of multiple virtual machines onto a single physical server. With this processor, users can create virtual environments with ease, ensuring optimal performance, scalability, and resource allocation. Whether it is for running multiple operating systems or deploying complex applications in virtualized environments, the 6-Core XEON X5670 processor delivers the necessary power and capabilities.

611116-B21 Processor Speed

In addition to its impressive core count, the HPE BL2X220C Server boasts a high processor speed of 2.93GHz. This clock speed plays a crucial role in determining how quickly the processor can execute instructions and process data.

Faster Execution

The 2.93GHz processor speed allows for rapid execution of tasks, resulting in faster response times and improved overall system performance. Whether it is running complex calculations, executing database queries, or handling data-intensive applications, the high clock speed ensures that operations are completed swiftly, enabling users to accomplish their tasks more efficiently.

Smooth Multitasking

Multitasking is a common requirement for many users, especially in business environments. The high processor speed of the HPE BL2X220C Server enables seamless multitasking by ensuring that each task receives prompt attention from the processor. This means that users can switch between applications or work on multiple tasks simultaneously without experiencing significant delays or performance degradation.

Enhanced Gaming and Multimedia Experience

For users who enjoy gaming or work with multimedia applications, a high processor speed is essential. The 2.93GHz processor speed of the HPE BL2X220C Server ensures smooth gameplay and seamless multimedia playback by providing the necessary processing power to handle demanding graphics and audio processing tasks. Users can enjoy immersive gaming experiences, edit high-resolution videos, or work with resource-intensive design software without experiencing any lag or slowdowns.

Memory

The HPE BL2X220C Server comes equipped with 24GB DDR3 SDRAM memory, designed to provide ample capacity for efficient data storage and retrieval.

Improved System Performance

With 24GB of memory, the server can store a substantial amount of data in its volatile memory for quick access by the processor. This allows for faster data retrieval and improved system performance, particularly when dealing with large datasets or running memory-intensive applications. Users can experience reduced load times, smoother application performance, and overall enhanced system responsiveness.

Efficient Virtualization

Virtualization heavily relies on memory resources to ensure the optimal performance of virtual machines. The 24GB DDR3 SDRAM memory of the HPE BL2X220C Server allows for efficient consolidation of virtual machines, providing each virtual instance with sufficient memory to operate smoothly. This results in improved virtual machine performance, reduced latency, and enhanced overall system stability.

Future-Proofing

With technology evolving at a rapid pace, it is essential to future-proof server infrastructure to accommodate growing needs. The 24GB DDR3 SDRAM memory capacity of the HPE BL2X220C Server ensures that users have enough headroom to scale their operations and accommodate future growth. Whether it is expanding virtualized environments, handling larger datasets, or running memory-hungry applications, the server's memory capacity provides the flexibility to meet evolving requirements without compromising performance.

In conclusion, the HPE BL2X220C Server's 6-Core XEON X5670 processor, with its exceptional performance and efficiency, along with a processor speed of 2.93GHz and 24GB DDR3 SDRAM memory capacity, offers users a powerful and versatile platform for running resource-intensive workloads, multitasking efficiently, and accommodating future growth. Whether it is for businesses requiring robust computing capabilities or individuals seeking high-performance gaming and multimedia experiences, this server delivers the performance and features necessary to meet their needs and exceed expectations.
