HPE DL360 G9 Xeon 12 Core 2.3GHz 64GB DDR4 Server - 795236-B21

Processor

The Power of Xeon 12 Core 2.3GHz

The HPE DL360 G9 Server is equipped with a powerful Xeon 12 Core 2.3GHz processor, offering exceptional performance and efficiency for your business needs. This feature plays a crucial role in enhancing the server's capabilities, making it an ideal choice for businesses that require high-performance computing.

General Details

• Manufacturer: Hewlett Packard Enterprise
• Part Number: 795236-B21
• Product Name: Proliant DL360 Gen9 - 1U Rack Mountable Server (OneView Model)

Processor and Chipset

Processor Specifications

• Processor Type: Intel Xeon E5-2670v3, 2.3 GHz
• Max Turbo Speed: 3.1 GHz
• QuickPath Interconnect: 9.60 GT/s
• Number of Cores: 12-core
• 64-bit Computing: Yes
• Compatible Processor Socket: FCLGA2011-3
• Installed Qty: 2
• Max Supported Qty: 2
• Chipset Type: Intel C610 Series

Cache Memory

• Cache Memory Type: Smart Cache
• Installed Size: 60 MB
• Cache Per Processor: 30 MB

Memory Configuration

Installed Memory

• Installed Size: 64 GB (expandable up to 768 GB)
• Memory Technology: DDR4 SDRAM - Advanced ECC
• Effective Memory Speed: 2133 MHz
• Memory Form Factor: DIMM 288-pin
• Memory Slots: 24 (total), 20 (free)
• Configuration: 4 x 16 GB
• Supported RAM: Up to 3 TB Load-Reduced - Advanced ECC, 768 GB Registered - Advanced ECC

Storage and Controllers

Hard Drive and Optical Drive

• Hard Drive: None
• Optical Drive: None

Storage Controllers

• Controller Name: Smart Array P440ar
• Buffer Size: 2 GB
• Disk Drive Support: 12 Gb/s SAS / 6 Gb/s SATA
• SAS Port Link Rate: 12 Gb/s per physical link supported
• PCIe Link Rate: PCI Express 3.0 x8
• Physical Drives Supported: Up to 26 Drives
• Logical Drives Supported: Up to 64 Logical Drives
• RAID Support: RAID 0, 1, 5, 6, 10, 50, 60, 1 ADM, 10 ADM

Display and Graphics

Graphics Processor

• Type: Integrated
• Graphics Processor: Matrox G200
• Video Interfaces: VGA

Network and Communication

Network Interfaces

• Ethernet Ports: 2 x 10 Gigabit Ethernet, 4 x Gigabit Ethernet
• Ethernet Controller: HP 331i, HP 533FLR-T
• Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
• Remote Management Controller: Integrated Lights-Out 4 (iLO 4)
• Features: Wake On LAN (WoL), PXE Support
• Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

Expansion and Connectivity

Expansion Bays

• External Bays: 1 (total), 1 (free)
• Hot-swap Bays: 8 (total), 8 (free) x 2.5" SFF

Expansion Slots

• DIMM Slots: 24 (total), 20 (free)
• CPU Slots: 2 (total), 0 (free)
• PCIe Slots:
  • 1 x PCIe 3.0 x16 (three-quarter-length, full-height) - 1 (free)
  • 1 x PCIe 3.0 x8 (low-profile) - 1 (free)
  • 1 x FlexibleLOM - 1 (free)
  • 1 x MicroSD Card (internal) - 1 (free)

Interfaces and Ports

• VGA Port: 1
• Serial Port: 1
• LAN Ports: 4 x Gigabit Ethernet, 2 x 10 Gigabit Ethernet (RJ-45)
• HP iLO Port: 1
• USB Ports: 5 x USB 3.0 (1 Front, 2 Rear, 2 Internal)

Miscellaneous Features

Included Accessories

• HP Easy Install Rails

Security and Management Features

• Administrator Password
• Power-on Password
• Keyboard Password
• Serial Port I/O Control
• QuickLock
• UEFI BIOS

Compliance Standards

• ACPI 2.0b
• FCC Class A Certified
• EN 61000-3-2
• EN55022
• ICES-003
• EN 61000-3-3
• EN55024
• CISPR 22
• FCC CFR47 Part 15
• IEC 60950-1
• EN 60950-1
• WEEE
• GB 9254
• ASHRAE
• CNS 13438

Power Specifications

• Device Type: Power Supply - Hot-plug
• Power Redundancy: Yes
• Redundancy Scheme: 1+1
• Installed Qty: 2
• Max Supported Qty: 2
• Nominal Voltage: AC 120/230 V (50/60 Hz)
• Power Provided: 800 Watts
• 80 Plus Certification: 80 Plus Platinum

Dimensions and Weight

• Depth

  Unmatched Processing Power

  The Xeon 12 Core 2.3GHz processor provides unparalleled processing power, allowing for faster data processing and improved system responsiveness. With its multiple cores and high clock speed, this processor can handle demanding workloads with ease, ensuring smooth and efficient operations.

  Enhanced Multitasking

  Multitasking is a critical aspect of any server, especially in enterprise environments where simultaneous operations are common. The Xeon 12 Core 2.3GHz processor excels in multitasking by efficiently managing multiple threads and processes simultaneously. This capability enables your server to handle various tasks concurrently without compromising performance or causing delays.

  Improved Performance and Efficiency

  The HPE DL360 G9 Server's Xeon 12 Core 2.3GHz processor is designed to optimize performance and energy efficiency. Its advanced architecture and intelligent power management features ensure that your server delivers outstanding performance while minimizing power consumption. This not only reduces operational costs but also contributes to a greener and more sustainable IT infrastructure.

  Reliable and Stable Operation

  Reliability is paramount when it comes to server hardware. The Xeon 12 Core 2.3GHz processor is built to deliver reliable and stable performance, ensuring that your server remains operational even under heavy workloads or demanding conditions. This reliability ensures minimal downtime, maximizing productivity and minimizing the risk of data loss or disruptions.

  Future-Proofing Your Business

  Investing in a server with a powerful processor like the Xeon 12 Core 2.3GHz is a strategic move that future-proofs your business. As technology advances and software becomes more resource-intensive, having a robust processor ensures that your server can handle the evolving demands of your business. This scalability allows you to stay ahead of the competition and accommodate growth without needing to replace your server infrastructure frequently.

  Memory

  64GB DDR4: Unleashing Server Performance

  The HPE DL360 G9 Server is equipped with an impressive 64GB DDR4 memory, offering unparalleled speed and capacity to support your business operations. This high-performance memory plays a vital role in enhancing your server's capabilities and delivering reliable performance.

  Blazing-Fast Data Access

  With 64GB of DDR4 memory, your server can access data at lightning-fast speeds, significantly reducing latency and improving overall system responsiveness. This is particularly crucial for applications that rely on real-time data processing or require near-instantaneous access to large datasets. The high-speed memory ensures that your server can keep up with demanding workloads and deliver a seamless user experience.

  Efficient Workload Management

  Managing multiple workloads simultaneously can be resource-intensive, particularly for servers operating in enterprise environments. The 64GB DDR4 memory provides ample capacity to handle multiple tasks concurrently, ensuring efficient workload management without compromising performance. This capability allows your server to maintain optimal performance even during peak usage periods, preventing bottlenecks and delays.

  Future-Ready Scalability

  As your business grows, so do the demands on your server infrastructure. The 64GB DDR4 memory offers scalability, allowing you to expand your server's memory capacity as needed. This ensures that your server can accommodate future growth and handle increasingly complex workloads without requiring a complete hardware overhaul. This scalability provides a cost-effective solution to meet your evolving business needs.

  Reliable Data Integrity

  Data integrity is of utmost importance in any server environment. The 64GB DDR4 memory incorporates advanced error-correcting code (ECC) technology, which detects and corrects memory errors in real-time. This feature ensures that your server maintains data integrity, minimizing the risk of data corruption or loss. By safeguarding your critical data, the high-performance memory provides peace of mind and ensures the reliability of your server operations.

  Product Number

  795236-B21: Identifying Your Server

  The HPE DL360 G9 Server carries the product number 795236-B21, a unique identifier that distinguishes it from other server models. This product number holds significance and offers several benefits for users looking to identify and maintain their servers efficiently.

  Easy Identification and Ordering

  With the unique product number 795236-B21, you can easily identify and order the HPE DL360 G9 Server when procuring or searching for spare parts. This distinct identifier ensures that you receive the correct model and compatible components, preventing any compatibility issues or delays in sourcing the necessary hardware. It simplifies the procurement process, saving time and effort in managing your server infrastructure.

  Accurate Documentation and Support

  Using the correct product number when seeking documentation or support for your HPE DL360 G9 Server is crucial. By providing the product number 795236-B21, you ensure that you receive accurate and relevant information specific to your server model. This specificity is essential for troubleshooting issues, accessing firmware updates, or consulting technical documentation tailored to your exact server configuration.

  Seamless Integration with Existing Infrastructure

  When expanding your server infrastructure or integrating new servers into an existing setup, having a unique product number simplifies the process. By using the product number 795236-B21, you can seamlessly integrate the HPE DL360 G9 Server into your existing infrastructure without any conflicts or compatibility concerns. This ensures smooth operations and a hassle-free integration process, minimizing downtime and disruptions.

  Inventory Management and Tracking

  For businesses with multiple servers, maintaining an accurate inventory is crucial for resource planning, maintenance scheduling, and asset tracking. The product number 795236-B21 enables efficient inventory management by providing a unique identifier for each server. This identifier allows you to track and manage your servers effectively, ensuring optimal resource allocation and streamlining maintenance activities.

  Future Expansion and Scalability

  As your business grows and your server infrastructure expands, the product number 795236-B21 plays a crucial role in future scalability. By having a unique identifier for each server model, you can easily identify and procure additional servers when needed. This scalability ensures that your server infrastructure can accommodate growth without any compatibility issues or disruptions.

  In conclusion, the HPE DL360 G9 Server's Xeon 12 Core 2.3GHz processor, 64GB DDR4 memory, and product number 795236-B21 are essential features that contribute to its exceptional performance, scalability, and reliability. These features enable businesses to handle demanding workloads efficiently, ensure fast data access, maintain data integrity, and simplify server identification and management. Whether you require powerful processing capabilities, high-speed memory, or seamless integration with existing infrastructure, the HPE DL360 G9 Server delivers the performance and flexibility needed to meet your business needs.
