HPE DL360 Gen9 E5-2680 v3 (2-Proc) 64GB DDR4 8-SFF HDD 2 x 500W PS Server 784657-S01

Processors

The HPE ProLiant DL360 Gen9 Server is equipped with 2 x Intel Xeon E5-2680 v3 processors, making it a powerful and efficient server solution for businesses of all sizes. The processors are at the heart of the server's performance capabilities and play a crucial role in delivering exceptional speed, reliability, and scalability.

General Information

• Manufacturer: Hewlett Packard Enterprise
• Part Number: 784657-S01
• Product: ProLiant DL360 Gen9 - 1U Rack-Mountable Server (S-buy)

Processor & Chipset

CPU Specifications

• Processor: Intel Xeon E5-2680v3
• Base Clock Speed: 2.5 GHz
• Turbo Speed: Up to 3.3 GHz
• Core Count: 12 cores per processor
• Quantity: 2 CPUs
• Socket Type: FCLGA2011-v3

Main Features

• Hyper-Threading Technology
• Intel Turbo Boost Technology 2.0
• Intel Smart Cache

Cache Memory

Details

• Installed L3 Cache: 60 MB
• Cache Per Processor: 30 MB

RAM Specifications

Memory Configuration

• Installed RAM: 64 GB
• Maximum RAM Capacity: 768 GB
• Technology: DDR4 SDRAM with Advanced ECC
• Memory Speed: 2133 MHz
• Form Factor: DIMM 288-pin
• Slots: 24 (total), 20 (free)

Memory Features

• Registered
• Online Spare Memory
• Quad Channel Memory Architecture
• HP SmartMemory

Supported Configurations

• Up to 3 TB Load-Reduced - Advanced ECC
• 768 GB Registered - Advanced ECC

Storage Capabilities

Hard Drives

• Type: SSD, Hot-swappable
• Capacity: 2 x 80 GB
• Interface: SATA 6 Gb/s
• Endurance: Value Endurance

Storage Controllers

• Controller: Smart Array P440ar
• Buffer Size: 2 GB
• Drive Interfaces: 12 Gb/s SAS / 6 Gb/s SATA
• SAS Port Link Rate: 12 Gb/s per physical link
• PCIe Link Rate: PCI Express 3.0 x8
• Physical Drives Supported: Up to 26
• Logical Drives Supported: Up to 64
• RAID Levels: 0, 1, 5, 6, 10, 50, 60, 1 ADM, 10 ADM

Display & Graphics

Graphics Controller

• Type: Integrated
• Processor: Matrox G200
• Video Interfaces: VGA

Network & Communication

Network Interface

• Ethernet Controller: HP Ethernet 1 Gb 4-port 331i Adapter
• Network Processor: Broadcom BCM5719 Chipset
• Ethernet Ports: 4 Gigabit Ethernet
• Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management: Integrated Lights-Out 4 (iLO4)

Features

• Wake On LAN (WOL)
• PXE Support

Compliance

• IEEE 802.3
• IEEE 802.3u
• IEEE 802.3ab

Expansion & Connectivity

Expansion Bays

• External: 1 (total), 1 (free)
• Hot-Swap 2.5" SFF: 8 (total), 6 (free)

Expansion Slots

• DIMM: 24 (total), 20 (free)
• CPU: 2 (total), 0 (free)
• PCIe 3.0 x16: 1 (total), 1 (free)
• PCIe 3.0 x8: 1 (total), 0 (free)
• FlexibleLOM: 1 (total), 1 (free)
• MicroSD Card (internal): 1 (total), 1 (free)

Interfaces & Ports

• VGA Port: 1
• Serial Port: 1
• LAN Ports: 8 Gigabit Ethernet
• HP iLO: 1
• USB 3.0 Ports: 5 (1 Front, 2 Rear, 2 Internal)

Miscellaneous Features

Included Accessories

• HP Easy Install Rail Kit

Security Features

• Administrator Password
• Power-on Password
• Keyboard Password
• Serial Port I/O Control
• QuickLock
• UEFI BIOS

Compliance Standards

• ACPI 2.0b
• FCC Class A Certified
• EN 61000-3-2
• EN55022
• ICES-003
• EN 61000-3-3
• EN55024
• CISPR 22
• FCC CFR47 Part 15
• IEC 60950-1
• EN 60950-1
• WEEE
• GB 9254
• Enhanced Performance

  Featuring 2 x Intel Xeon E5-2680 v3 processors, the HPE ProLiant DL360 Gen9 Server offers enhanced performance that allows businesses to handle demanding workloads with ease. With a total of 24 cores and 48 threads, this server can effortlessly handle multiple tasks simultaneously, ensuring smooth and uninterrupted operation.

  The Intel Xeon E5-2680 v3 processors are built on the advanced Haswell architecture, which provides significant improvements in performance compared to previous generations. The improved microarchitecture enables faster data processing, better energy efficiency, and higher overall performance.

  Increased Productivity

  By leveraging the power of 2 x Intel Xeon E5-2680 v3 processors, users can experience increased productivity and improved efficiency in their day-to-day operations. The server's processing capabilities allow for faster data analysis, quicker response times, and seamless multitasking.

  Whether you are running resource-intensive applications, virtualization environments, or databases, the HPE ProLiant DL360 Gen9 Server with 2 x Intel Xeon E5-2680 v3 processors ensures that you have the computing power needed to handle complex tasks efficiently. This results in reduced downtime, increased user satisfaction, and ultimately, improved business productivity.

  Scalability and Future-Proofing

  One of the key advantages of the HPE ProLiant DL360 Gen9 Server's 2 x Intel Xeon E5-2680 v3 processors is its scalability. The server is designed to accommodate future growth and expansion, allowing businesses to easily upgrade their computing power as their needs evolve.

  With the ability to support up to two processors, the HPE ProLiant DL360 Gen9 Server provides a flexible platform that can adapt to changing workload requirements. This scalability ensures that users can continue to rely on the server's performance even as their business grows and demands increase.

  Furthermore, the Intel Xeon E5-2680 v3 processors offer support for advanced technologies such as virtualization, cloud computing, and big data analytics. This ensures that businesses can leverage these cutting-edge technologies without worrying about compatibility or performance limitations, making the HPE ProLiant DL360 Gen9 Server a future-proof investment.

  Memory

  The HPE ProLiant DL360 Gen9 Server is equipped with 64GB DDR4 DIMMs, providing ample memory capacity to handle demanding workloads efficiently. The server's memory plays a crucial role in ensuring smooth and responsive performance, enabling users to run multiple applications and processes simultaneously without any performance degradation.

  Improved Performance

  With 64GB of DDR4 memory, the HPE ProLiant DL360 Gen9 Server delivers improved performance compared to servers with lower memory capacities. The high-speed DDR4 technology offers faster data transfer rates, lower latency, and higher overall bandwidth, resulting in enhanced application responsiveness and reduced system bottlenecks.

  The ample memory capacity allows businesses to allocate more resources to virtual machines, databases, and other memory-intensive applications. This ensures that critical processes have the necessary resources to run smoothly, leading to improved overall system performance and user satisfaction.

  Efficient Workload Management

  The HPE ProLiant DL360 Gen9 Server's 64GB DDR4 DIMMs enable efficient workload management by providing sufficient memory capacity to handle multiple tasks concurrently. This is especially beneficial for businesses that rely on virtualization or run resource-intensive applications that require a large amount of memory.

  The server's memory capacity allows for the seamless execution of complex operations, ensuring that users can work efficiently without experiencing any performance slowdowns or delays. This enables businesses to maximize their productivity and achieve optimal operational efficiency.

  Scalability and Future-Proofing

  The HPE ProLiant DL360 Gen9 Server's memory capacity is not only sufficient for current needs but also offers scalability for future growth. The server supports up to 24 DIMM slots, allowing businesses to expand their memory capacity as their requirements evolve.

  By investing in a server with ample memory capacity like the HPE ProLiant DL360 Gen9, businesses can future-proof their IT infrastructure and avoid potential bottlenecks or performance limitations down the line. This scalability ensures that the server can continue to meet the demands of evolving workloads and applications, providing a reliable and efficient platform for years to come.

  Storage

  The HPE ProLiant DL360 Gen9 Server is equipped with 8-SFF HDD Bays, offering ample storage capacity for businesses to store and manage their critical data. The server's storage capabilities are essential for businesses of all sizes, providing a reliable and scalable solution for storing, accessing, and protecting valuable information.

  Increased Data Storage

  With 8-SFF HDD Bays, the HPE ProLiant DL360 Gen9 Server provides businesses with increased data storage capacity compared to servers with fewer drive bays. This allows businesses to store large amounts of data, including files, documents, databases, and media files, without worrying about running out of storage space.

  The ample storage capacity ensures that businesses can effectively manage their growing data volumes and avoid the need for external storage solutions or frequent data purging. This enables businesses to maintain a centralized and easily accessible data repository, facilitating efficient data management and retrieval processes.

  Data Redundancy and Protection

  The HPE ProLiant DL360 Gen9 Server's 8-SFF HDD Bays also offer opportunities for data redundancy and protection. By configuring the drives in RAID arrays, businesses can ensure that their critical data is protected against drive failures or other storage-related issues.

  RAID configurations provide various levels of data redundancy, such as mirroring or striping with parity, allowing for seamless data recovery in case of drive failures. This not only minimizes the risk of data loss but also reduces downtime and ensures continuous access to critical information.

  Scalability and Flexibility

  The HPE ProLiant DL360 Gen9 Server's 8-SFF HDD Bays offer scalability and flexibility for businesses that require additional storage capacity. The server supports a variety of storage options, including SAS, SATA, and SSD drives, allowing businesses to choose the most suitable storage technology based on their performance, capacity, and budget requirements.

  This flexibility enables businesses to adapt their storage infrastructure as their needs evolve, ensuring that they can efficiently manage their growing data volumes without incurring unnecessary costs. Whether it's expanding the storage capacity or upgrading to faster storage technologies, the HPE ProLiant DL360 Gen9 Server provides a scalable solution that can grow alongside the business.

  Power Supply

  The HPE ProLiant DL360 Gen9 Server is equipped with 2 x 500W PS power supplies, ensuring reliable and uninterrupted power delivery to the server components. The server's power supply is a critical component that directly impacts its performance, stability, and overall uptime.

  Redundant Power Supply

  The inclusion of 2 x 500W PS power supplies in the HPE ProLiant DL360 Gen9 Server offers redundancy, ensuring that the server remains operational even in the event of a power supply failure. This redundancy eliminates the risk of unexpected downtime and ensures continuous access to critical applications and data.

  Redundant power supplies also provide load balancing capabilities, ensuring that the server's power requirements are evenly distributed between the power supplies. This prevents overloading and increases the overall stability and reliability of the server.

  Energy Efficiency

  The HPE ProLiant DL360 Gen9 Server's 2 x 500W PS power supplies are designed with energy efficiency in mind. These power supplies adhere to industry standards and regulations, such as 80 PLUS certification, ensuring that they operate at high efficiency levels.

  Energy-efficient power supplies not only help reduce electricity consumption but also generate less heat, resulting in lower cooling requirements and reduced operational costs. By using energy-efficient power supplies, businesses can contribute to their sustainability goals while enjoying cost savings over the server's lifetime.

  Hot-Swappable Design

  The HPE ProLiant DL360 Gen9 Server's 2 x 500W PS power supplies feature a hot-swappable design, allowing for easy replacement without interrupting the server's operation. Hot-swappable power supplies minimize downtime during maintenance or in case of a failure, as they can be replaced while the server continues to run.

  This feature is particularly beneficial for businesses that require high availability and cannot afford significant periods of downtime. The hot-swappable design ensures that any necessary power supply replacements can be performed quickly and efficiently, minimizing the impact on business operations.

  Product Number

  The HPE ProLiant DL360 Gen9 Server has a product number of 784657-S01, which serves as a unique identifier for this specific server model. The product number plays an important role in ordering, inventory management, and support processes for businesses.

  Ordering and Inventory Management

  The product number, 784657-S01, is used by businesses to accurately identify and order the HPE ProLiant DL360 Gen9 Server. This unique identifier ensures that businesses receive the correct server model with the desired specifications and configuration options.

  Furthermore, the product number simplifies inventory management for businesses by providing a standardized way to track and organize the server models they have in stock. This streamlines procurement processes and ensures that businesses can efficiently manage their IT infrastructure.

  Support and Documentation

  The product number, 784657-S01, is also essential for accessing support and documentation specific to the HPE ProLiant DL360 Gen9 Server. When businesses encounter technical issues or require assistance, they can provide the product number to HPE's support team, enabling them to receive tailored support and troubleshooting guidance.

  Additionally, the product number serves as a reference point for accessing documentation, such as user manuals, technical specifications, and firmware updates. This ensures that businesses have the necessary resources to effectively deploy, manage, and maintain their HPE ProLiant DL360 Gen9 Server.

  Compatibility and Warranty

  The product number, 784657-S01, also ensures compatibility with other HPE products and warranties. By referring to the product number, businesses can verify compatibility with related hardware components or software solutions, ensuring a seamless integration within their existing IT infrastructure.

  Furthermore, the product number is associated with the server's warranty terms and conditions. It provides businesses with a clear understanding of the warranty coverage, duration, and any additional services or support included. This allows businesses to make informed decisions and ensure they receive the necessary support during the server's lifecycle.

  In conclusion, the HPE ProLiant DL360 Gen9 Server with its 2 x Intel Xeon E5-2680 v3 processors, 64GB DDR4 DIMMs, 8-SFF HDD Bays, 2 x 500W PS power supplies, and product number 784657-S01 offers a powerful and reliable server solution for businesses. The processors deliver enhanced performance, improved productivity, and scalability. The ample memory capacity ensures efficient workload management and future-proofing. The storage capabilities provide increased data storage, redundancy, and flexibility. The power supply ensures reliable and uninterrupted power delivery. Finally, the product number plays a crucial role in ordering, support, and compatibility processes. Overall, the HPE ProLiant DL360 Gen9 Server offers a comprehensive set of features that meet the demands of modern businesses and provide a solid foundation for their IT infrastructure.
