HPE DL360 Gen9 Xeon 10 Core 2.4GHz 16GB DDR4 Server 848736-B21

Processor

The HPE Proliant DL360 Gen9 Server is equipped with a powerful Xeon 10 Core 2.4GHz processor. This feature sets it apart from other servers in its class, providing users with exceptional performance and reliability.

Manufacturer Details

• Manufacturer: Hewlett Packard Enterprise
• Part Number: 848736-B21

Processor Specifications

• CPU Model: Intel Xeon E5-2640v4, 2.4 GHz
• Max Turbo Frequency: 3.4 GHz
• Core Count: 10 cores
• Socket Type: LGA2011-v3
• CPU Features: Hyper-Threading Technology, Intel Turbo Boost Technology 2.0
• Upgradability: Supports up to 2 processors

Cache Memory

• Total Cache Size: 25 MB
• Cache Per Processor: 25 MB

Memory Specifications

• Installed Memory: 16 GB
• Maximum Memory Capacity: 768 GB
• Memory Type: DDR4 SDRAM with Advanced ECC
• Memory Speed: 2133 MHz
• Memory Compliance: PC4-19200
• Form Factor: DIMM 288-pin
• Memory Features: Registered, Online Spare Memory, Quad Channel Architecture, HP SmartMemory

Storage and Controllers

• Hard Drive: None included
• Optical Drive: None included
• Storage Controller: Smart Array P440ar with 2 GB FBWC
• RAID Levels: RAID 0, 1, 5, 6, 10, 50, 60, 1 ADM, 10 ADM
• Controller Interface: SATA 6 Gb/s, SAS 12 Gb/s
• Buffer Size: 2 GB

Graphics and Display

• Graphics Processor: Matrox G200
• Video Interface: VGA

Network and Connectivity

• Ethernet Ports: 4 Gigabit Ethernet
• Ethernet Controller: HP 331i
• Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management: Integrated Lights-Out 4
• Features: Wake On LAN (WOL), PXE Support
• Compliance Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

Expansion and Connectivity

• Expansion Bays: 8 hot-swappable 2.5” SFF (all free)
• Expansion Slots:
  • 24 DIMM 288-pin (23 free)
  • 2 CPU (1 free)
  • 1 PCIe 3.0 x16 (full-height, three-quarter-length) (1 free)
  • 1 PCIe 3.0 x8 (low-profile) (1 free)
  • 1 FlexibleLOM (1 free)
  • 1 microSD Card (internal) (1 free)

Interfaces and Ports

• 1 VGA
• 1 Serial
• 4 Gigabit Ethernet LAN
• 1 HP iLO
• 5 USB 3.0 (1 front, 2 rear, 2 internal)

Additional Information

• Compliance Standards: ACPI 2.0b, FCC Class A, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, WEEE, GB 9254, CNS 13438
• Manufacturer Program: HPE Smart Buy

Power Supply

• Type: Hot-plug
• Redundancy: Optional, 1+1 (with additional power supply)
• Installed Quantity: 1
• Maximum Supported Quantity: 2
• Nominal Voltage: AC 120/230 V (50/60 Hz)
• Power Rating: 500 Watts
• 80 Plus Certification: 80 Plus Platinum

Dimensions and Weight

• Width: 17.1 inches
• Depth: 27.5 inches
• Height: 1.7 inches
• Weight: 27.01 lbs

Enhanced Performance

The Xeon 10 Core 2.4GHz processor is designed to handle demanding workloads efficiently. With its high clock speed and multiple cores, it can effortlessly handle complex calculations, data analysis, virtualization, and other resource-intensive tasks. This results in improved productivity and reduced processing time for users.

Seamless Multitasking

With ten cores at its disposal, the processor allows for seamless multitasking. Users can run multiple applications simultaneously without experiencing any lag or slowdowns. This is especially beneficial for businesses that rely on running numerous processes simultaneously, ensuring smooth operations and minimizing downtime.

Scalability

The Xeon 10 Core 2.4GHz processor offers scalability options to accommodate future growth and expansion. As businesses evolve, their computing needs may increase, requiring more processing power. This processor provides the flexibility to upgrade and scale the server's performance to meet evolving demands.

Efficient Virtualization

Virtualization has become a critical aspect of modern IT infrastructure. The Xeon 10 Core 2.4GHz processor excels in virtualized environments by efficiently handling multiple virtual machines (VMs). It ensures optimal performance and responsiveness, enabling businesses to leverage virtualization technologies for improved efficiency and cost savings.

Memory

The HPE Proliant DL360 Gen9 Server boasts 16GB DDR4 memory, offering users a significant advantage when it comes to data processing and storage capabilities.

Faster Data Access

The 16GB DDR4 memory provides faster access to data, enhancing overall system performance. It allows for quick retrieval of frequently accessed files and applications, reducing latency and improving user experience. This is particularly beneficial for businesses that deal with large datasets or require real-time data processing.

Improved Workload Management

With ample memory capacity, the server can efficiently manage multiple workloads simultaneously. It ensures smooth operation even when running resource-intensive applications or handling a large number of concurrent users. This capability is crucial for businesses that rely on consistent performance and need to handle heavy workloads without compromising efficiency.

Future-Proofing

The 16GB DDR4 memory provides room for future expansion and upgrades. As technology advances and software requirements evolve, businesses may need to increase their memory capacity. The server's memory can be easily expanded, allowing users to adapt to changing needs and ensuring long-term viability.

Enhanced Virtualization

Virtualization heavily relies on memory resources. The abundant 16GB DDR4 memory enables businesses to create and manage more virtual machines efficiently. This leads to better resource allocation, improved performance, and cost savings by consolidating multiple servers into a single physical machine.

Product Code

The HPE Proliant DL360 Gen9 Server is identified by its product code, 848736-B21. This code is more than just a label; it carries several benefits and importance for users.

Easy Identification

The product code serves as a unique identifier for the server model. By referencing the code, users can easily identify and distinguish the HPE Proliant DL360 Gen9 Server from other server models available in the market. This simplifies the procurement process and ensures that users can specifically request or order the desired server model without any confusion.

Compatibility Assurance

The product code plays a crucial role in ensuring compatibility with other hardware and software components. Each server model has specific requirements and compatibility considerations. By using the designated product code, users can be confident that the HPE Proliant DL360 Gen9 Server will work seamlessly with the recommended hardware configurations and software applications.

Support and Warranty

The product code is essential when seeking technical support or warranty services. It helps the support team to identify the exact server model, allowing for efficient and accurate troubleshooting. Additionally, warranty coverage may be tied to specific product codes, ensuring that users receive the appropriate level of support and service for their HPE Proliant DL360 Gen9 Server.

Product Documentation

Product codes are often utilized to access detailed documentation and resources related to the server model. These resources can include user manuals, technical specifications, firmware updates, and compatibility guides. By referencing the product code, users can easily find relevant information that assists in server setup, maintenance, and troubleshooting.

In conclusion, the HPE Proliant DL360 Gen9 Server offers a powerful Xeon 10 Core 2.4GHz processor, 16GB DDR4 memory, and is identified by the product code 848736-B21. These features provide significant benefits to users in terms of enhanced performance, improved multitasking capabilities, scalability, efficient virtualization, faster data access, improved workload management, future-proofing, easier identification, compatibility assurance, support and warranty coverage, and access to relevant product documentation. Whether it's for small businesses or enterprise environments, this server delivers the performance and reliability needed to meet demanding computing requirements.
