HPE DL380 Gen10 Server 875763-S01 6126 1P 32GB-R P408I-A 8 SFF 2X500W PS S-Buy

875763-S01
Hover on image to enlarge

Brief Overview of 875763-S01

HPE Proliant DL380 Gen10 Server 875763-S01 6126 1P 32GB-R P408I-A 8 SFF 2X500W PS S-Buy. Excellent Refurbished with 6-Month Replacement Warranty
QR Code of HPE DL380 Gen10 Server 875763-S01 6126 1P 32GB-R P408I-A 8 SFF 2X500W PS S-Buy
$1,505.25
$887.00
You save: $618.25 (41%)
Ask a question
+
Quote
Additional 7% discount at checkout
SKU/MPN875763-S01Availability✅ In StockProcessing TimeUsually ships same day ManufacturerHPE Product/Item ConditionExcellent Refurbished ServerOrbit Replacement WarrantySix-Month (180 Days)
Our Advantages
  • Free Ground Shipping
  • — Min. 6-month Replacement Warranty
  • — Genuine/Authentic Products
  • — Easy Return and Exchange
  • — Different Payment Methods
  • — Best Price
  • — We Guarantee Price Matching
  • — Tax-Exempt Facilities
  • — 24/7 Live Chat, Phone Support
Payment Options
  • — Visa, MasterCard, Discover, and Amex
  • — JCB, Diners Club, UnionPay
  • — PayPal, ACH/Wire Transfer
  • — Apple Pay, Amazon Pay, Google Pay
  • — Buy Now, Pay Later - Affirm, Afterpay
  • — GOV/EDU/Institutions PO's Accepted
  • — Invoices
Delivery
  • — Deliver Anywhere
  • — Express Delivery in the USA and Worldwide
  • — Ship to -APO -FPO
  • For USA - Free Ground Shipping
  • — Worldwide - from $30

Same product also available in:

Description

Sku: 875763-S01

The HPE Proliant DL380 Gen10 Server is a state-of-the-art server that boasts exceptional performance, reliability, and scalability. One of its standout features is the SKU number, specifically the 875763-S01 variant. This SKU number represents a specific configuration of the server that offers a range of benefits and advantages for users.

General Specifications of HPE Proliant

  • Manufacturer: Hewlett Packard Enterprise
  • Part Number: 875763-S01
  • Product Name: Proliant DL380 Gen10 - 2U Rack-Mountable Server (SMB NC Model)

Processor and Chipset Details

  • Processor: 1st Gen Intel Xeon Gold 6126, 2.6 GHz
  • Max Turbo Frequency: 3.7 GHz
  • Cores: 12-core
  • Quantity: 1 (up to 2)
  • Upgrade Capability: Yes
  • Socket Type: FCLGA3647
  • Chipset: Intel C621
  • Features: Hyper-threading, Intel Turbo Boost Technology 2

Cache Memory

  • Cache Size: 19.25 MB L3 per processor

Memory Specifications

  • Installed Memory: 32 GB (expandable to 384 GB)
  • Technology: DDR4 SDRAM
  • Effective Speed: 2666 MHz
  • Form Factor: DIMM 288-pin
  • Slots: 12 (10 free)
  • Features: Registered, Dual Rank, HP SmartMemory, 6-channel Memory Architecture
  • Configuration: 2 x 16 GB

Supported RAM Types

  • PC4-20800: Up to 384 GB Registered
  • PC4-20800 Load-reduced: Up to 768 GB

Storage Controllers

  • Type: RAID
  • Interface: SATA 6Gb/s, SAS 12Gb/s
  • Controller: HPE Smart Array P408i-a
  • Channels: 8
  • RAID Levels: 0, 1, 5, 6, 10, 50, 60, 1 ADM, 10 ADM
  • Buffer Size: 2 GB

Graphics and Network

  • Video Memory: 16 MB
  • Interfaces: VGA

Network Connectivity

  • Ethernet Ports: 4 x Gigabit Ethernet
  • Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
  • Remote Management: SNMP 3, IPMI 2.0, SMASH CLP
  • Controller: Integrated Lights-Out 5
  • Features: Wake On LAN (WoL), PXE Support

Expansion and Connectivity

  • External Bays: 1 (1 free)
  • Hot-Swap Bays: 8 (all free)
  • CPU Slots: 2 (1 free)
  • DIMM Slots: 12 (10 free)
  • FlexibleLOM: 1 (1 free)
  • PCIe Slots: 1 x PCIe 3.0 x16 (half-length, full-height), 2 x PCIe 3.0 x8 (half-length, full-height)
  • MicroSD Card Slot: 1 (1 free)

Interfaces

  • LAN Ports: 4 x Gigabit Ethernet (RJ-45)
  • HP iLO: 1 x RJ-45 (rear), 1 x Type A (front)
  • VGA: 1 (rear)
  • SATA/SAS: 8 x SATA-600 / SAS 3.0
  • USB Ports: 5 x USB 3.0 (1 front, 2 rear, 2 internal)

Additional Information

  • HP Easy Install Rail Kit
  • 4 x Standard Hot Plug Fans
  • CPU Standard Heatsink

Compliance and Certification

  • AES, FIPS 140-2
  • IPv6 Ready
  • PCI DSS
  • TLS v1.2
  • ASHRAE Class A4, Class A3
  • WEEE 2002/95/EC
  • ACPI 6.1

Power Specifications

  • Type: Hot-plug Power Supply
  • Redundancy: Optional (1+1 with optional power supply)
  • Installed Quantity: 2
  • Max Supported Quantity: 2
  • Nominal Voltage: AC 120/230 V (50/60 Hz)
  • Power Output: 500 Watt
  • 80 Plus Certification: 80 Plus Platinum

Dimensions and Weight

  • Width: 17.5 in
  • Depth: 26.7 in
  • Height: 3.4 in
  • Weight: 32.85 lbs

Enhanced Performance

The Sku 875763-S01 of the HPE Proliant DL380 Gen10 Server is designed to deliver enhanced performance for demanding workloads. It features powerful components and advanced technologies that enable it to handle resource-intensive applications with ease. Whether you are running virtualization, database management, or high-performance computing tasks, this SKU ensures optimal performance and responsiveness.

Increased Processing Power

The 875763-S01 configuration comes equipped with the Intel Xeon Scalable 6126 processor, which offers impressive processing power. With 12 cores and a base frequency of 2.6 GHz, this processor can handle complex calculations and multitasking efficiently. It allows for faster data processing, improved system responsiveness, and seamless execution of demanding workloads.

Expanded Memory Capacity

Memory plays a crucial role in server performance, and the 875763-S01 Sku takes it to the next level with its 32GB-R memory configuration. This server variant supports up to 3TB of memory capacity, enabling smooth operation of memory-intensive applications and efficient data processing. The generous memory allocation ensures that your server can handle multiple concurrent tasks without compromising performance.

Reliability and Scalability

In addition to its impressive performance capabilities, the HPE Proliant DL380 Gen10 Server with Sku 875763-S01 offers exceptional reliability and scalability.

Redundant Power Supply

The server is equipped with two 500W power supplies, providing redundancy and ensuring uninterrupted operation. In the event of a power supply failure, the redundant power supply seamlessly takes over, minimizing downtime and protecting your critical workload.

Flexible Storage Options

The 875763-S01 configuration features 8 Small Form Factor (SFF) drive bays, allowing you to customize your storage setup according to your specific needs. This flexibility enables you to choose the most suitable storage configuration for your applications, whether it's high-capacity HDDs or lightning-fast SSDs. The expandable storage capacity ensures that you can easily accommodate growing data requirements without compromising performance.

Optimized Purchase Option

The HPE Proliant DL380 Gen10 Server with Sku 875763-S01 is available with the S-Buy purchase option, providing users with a range of benefits and convenience.

Simplified Procurement Process

The S-Buy option streamlines the purchasing process, making it easier and more efficient for businesses to acquire the server. It eliminates unnecessary complexities and simplifies the procurement process, ensuring a seamless experience from order placement to delivery.

Cost-Effective Solution

S-Buy offers cost-effective pricing for the DL380 Gen10 server, making it an attractive option for businesses looking to maximize their budget. With competitive pricing and the same high-quality components and features as other configurations, this purchase option provides excellent value for money.

Conclusion

In conclusion, the HPE Proliant DL380 Gen10 Server with Sku 875763-S01 is a high-performance, reliable, and scalable solution for businesses in need of robust computing capabilities. Its impressive specifications, including the Intel Xeon Scalable 6126 processor, 32GB-R memory, 8 SFF drive bays, redundant power supply, and the S-Buy purchase option, make it a versatile and efficient choice for a wide range of applications. Experience enhanced performance, reliability, and flexibility with the HPE Proliant DL380 Gen10 Server Sku 875763-S01.
