HPE DL380P Gen8 Server 2.3GHz 16GB DDR3 - 642119-001

Processor Speed

The HPE Proliant DL380P Gen8 Server is equipped with a powerful processor that boasts a speed of 2.3GHz. This feature sets it apart from other servers in its class and provides users with numerous benefits and advantages.

General Specification of Proliant

• Manufacturer: Hewlett Packard Enterprise
• Part Number: 642119-001
• Product Model: Proliant DL380p Gen8

Processor & Chipset Specifications

• Type: Intel Xeon E5-2630
• Clock Speed: 2.3 GHz
• Turbo Boost Speed: Up to 2.8 GHz
• Cores: 6-core
• Installed Quantity: 1
• Maximum Supported Quantity: 2
• 64-bit Computing: Supported
• Chipset: Intel C600

Processor Features

• Hyper-threading Technology
• Intel QuickPath Interconnect
• Intel Turbo Boost Technology

Cache Memory

• Cache Type: L3 Cache
• Installed Cache Size: 15 MB
• Cache Per Processor: 15 MB

RAM Specifications

Installed and Maximum RAM

• Installed RAM: 16 GB
• Maximum RAM: 384 GB

Memory Technology and Configuration

• Type: DDR3 SDRAM
• Effective Memory Speed: 1333 MHz
• Memory Compliance: PC3-10600
• Form Factor: DIMM 240-pin
• Slots: 24 total, 20 available
• Features: Registered, Dual Rank, Quad Channel Memory Architecture
• Supported Configurations: Various ECC and non-ECC options

Storage Options

Drive Configuration

• Hard Drive: Not Included
• Optical Drive: Not Included

Storage Controller Details

• Type: RAID - Integrated
• Controller Interface: SATA 6 Gb/s, SAS 6 Gb/s
• Controller Name: Smart Array P420i with 1GB FBWC
• Channel Quantity: 8
• RAID Levels Supported: RAID 0, RAID 1, RAID 10
• Buffer Size: 1 GB

Display & Graphics

• Type: Integrated
• Graphics Processor: Matrox G200
• Video Interfaces: VGA

Network & Communication

• Type: Plug-in Card
• Bus Type: PCI Express x4
• Ethernet Ports: 4 x Gigabit Ethernet
• Ethernet Controller: HP 331FLR
• Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management: Integrated Lights-out 4
• Features: Wake On LAN (WoL), PXE Support
• Standards Compliance: IEEE 802.3, IEEE 802.3u, IEEE 802.1q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad (LACP)

Expansion & Connectivity

Expansion Bays

• External Bays: 8 (total), all free for hot-swap 2.5” SFF drives

Expansion Slots

• DIMM Slots: 24 (total), 20 available
• CPU Slots: 2 (total), 1 available
• PCIe 3.0 x16: 1 (total), 1 available
• PCIe 3.0 x8: 1 (total), 1 available
• PCIe 2.0 x8: 1 (total), 0 available
• FlexibleLOM: 1 (total), 1 available
• SD Card (Internal): 1 (total), 1 available

Interfaces & Ports

• Serial Ports: 1
• VGA Ports: 2 (1 front, 1 rear)
• LAN Ports: 4 x Gigabit Ethernet
• HP iLO Port: 1
• USB Ports: 7 (2 front, 4 rear, 1 internal)

Miscellaneous Features

Included Accessories

• HP Friction Rail Kit
• Cable Management Arm

Additional Features

• Administrator and Power-on Password Protection
• Serial Port I/O Control
• Redundant Fans

Compliance Standards

• ACPI 2.0b
• FCC Class A Certified
• Various EN, IEC, and BSMI Standards

Power Specifications

• Device Type: Hot-plug Power Supply
• Power Redundancy: Optional (1+1 with additional power supply)
• Installed Power Supply: 1
• Maximum Supported Power Supplies: 2
• Nominal Voltage: AC 120/230 V (50/60 Hz)
• Power Output: 460 Watts
• 80 Plus Certification: Platinum
• Efficiency: 94%

Dimensions & Weight

• Width: 17.5 inches
• Depth: 27.5 inches
• Height: 3.4 inches
• Weight: 40.98 lbs

Improved Performance

The 2.3GHz processor speed ensures that the HPE Proliant DL380P Gen8 Server delivers exceptional performance. With a higher clock speed, the server can process instructions and perform tasks more quickly, resulting in improved overall performance. This is particularly important for businesses that rely on their servers to handle resource-intensive applications or large-scale data processing.

Enhanced Productivity

The fast processor speed of the HPE Proliant DL380P Gen8 Server translates into enhanced productivity for users. Tasks that require significant processing power, such as virtualization, database management, or running complex software applications, can be completed more efficiently. This allows businesses to maximize their productivity and accomplish more within the same time frame.

Smooth Multitasking

The 2.3GHz processor speed enables the HPE Proliant DL380P Gen8 Server to handle multiple tasks simultaneously without compromising performance. This is particularly beneficial for businesses that rely on their servers to support a large number of users or run multiple applications simultaneously. The server can efficiently allocate resources and process requests, ensuring a smooth and seamless user experience even during peak workloads.

Quick Response Time

The high processor speed of the HPE Proliant DL380P Gen8 Server results in a quick response time for user requests. Whether it's accessing files, running queries, or executing commands, the server can swiftly respond to user actions, reducing latency and improving overall responsiveness. This is crucial for businesses that require real-time data processing or rely on their servers for critical operations.

Future-Proofing

Investing in a server with a 2.3GHz processor speed, like the HPE Proliant DL380P Gen8 Server, ensures future-proofing to some extent. As technology advances and software applications become more resource-intensive, having a fast processor will allow the server to handle future demands without needing immediate upgrades. This can save businesses both time and money in the long run.

Ram Size

The HPE Proliant DL380P Gen8 Server is equipped with a generous 16GB DDR3 RAM. This feature provides users with several benefits and plays a crucial role in the server's performance and efficiency.

Improved System Responsiveness

The 16GB DDR3 RAM allows the HPE Proliant DL380P Gen8 Server to handle multiple tasks simultaneously without experiencing performance bottlenecks. The ample amount of RAM ensures that there is sufficient memory available for applications and processes to run smoothly, resulting in improved system responsiveness. Users can expect faster loading times, reduced lag, and an overall seamless experience when utilizing the server.

Efficient Virtualization

Virtualization has become a fundamental aspect of modern IT infrastructure. The 16GB DDR3 RAM of the HPE Proliant DL380P Gen8 Server enables efficient virtualization by providing ample memory for hosting multiple virtual machines simultaneously. Virtualization requires significant memory resources, and having a large RAM capacity ensures that each virtual machine can operate smoothly without impacting overall performance.

Enhanced Database Performance

Databases are critical components for businesses that manage large amounts of data. The 16GB DDR3 RAM of the HPE Proliant DL380P Gen8 Server allows for efficient database management by providing sufficient memory for storing and accessing data quickly. With more RAM, databases can hold a larger portion of frequently accessed data in memory, reducing the need for disk access and improving overall performance.

Seamless Multitasking

The generous RAM size of the HPE Proliant DL380P Gen8 Server enables seamless multitasking. Users can run multiple applications simultaneously without experiencing a slowdown in performance. This is particularly beneficial for businesses that require their servers to support a large number of users or run resource-intensive applications concurrently.

Scalability and Future Expansion

The 16GB DDR3 RAM provides scalability and allows for future expansion of the server's capabilities. As business needs grow and more memory is required, the HPE Proliant DL380P Gen8 Server can accommodate additional RAM modules to increase its capacity. This scalability ensures that the server can adapt to changing demands without requiring a complete hardware replacement, saving both time and money.

Part Number

The HPE Proliant DL380P Gen8 Server has the part number 642119-001. This unique identifier plays a crucial role in identifying, ordering, and maintaining the server, offering several benefits and importance to users.

Accurate Identification

The part number 642119-001 allows for accurate identification of the HPE Proliant DL380P Gen8 Server. In an IT infrastructure that may comprise multiple servers and equipment, having a distinct part number ensures that the correct server is identified when ordering spare parts or performing maintenance tasks. This minimizes errors and ensures compatibility, ultimately saving time and resources.

Easy Ordering of Spare Parts

The part number simplifies the process of ordering spare parts for the HPE Proliant DL380P Gen8 Server. By providing the part number to suppliers or vendors, users can ensure that they receive the exact components needed for repairs or upgrades. This streamlines the procurement process and eliminates the potential for errors that could arise from vague or incomplete descriptions.

Efficient Maintenance and Support

Maintenance and support are crucial aspects of server management. The part number 642119-001 allows users to easily communicate with technical support teams, enabling them to quickly identify and troubleshoot issues. Additionally, when seeking assistance for specific components or modules, providing the part number ensures that support personnel can understand and address the problem accurately, hastening the resolution process.

Compatibility Assurance

The part number serves as a compatibility assurance for users of the HPE Proliant DL380P Gen8 Server. When expanding or upgrading the server, knowing the part number of existing components ensures that new components are compatible with the server's specifications. This eliminates the risk of purchasing incompatible parts, reducing downtime and potential performance issues.

Documentation and Knowledge Base Access

Having the part number facilitates access to relevant documentation and knowledge bases for the HPE Proliant DL380P Gen8 Server. Users can search for technical specifications, user manuals, firmware updates, and other resources specific to their server model by referencing the part number. This enables users to stay informed about their server's capabilities, optimize its performance, and troubleshoot any issues effectively.

In conclusion, the HPE Proliant DL380P Gen8 Server's 2.3GHz processor speed, 16GB DDR3 RAM size, and 642119-001 part number offer significant benefits and importance to users. From improved performance and productivity to seamless multitasking and future-proofing capabilities, these features contribute to a reliable and efficient server solution for businesses of all sizes.
