HPE DL380p Gen8 Xeon 6 Core 2.1GHz 16GB DDR3 8Sff SSD Server 734790-S01

Processor: Xeon 6 Core 2.1GHz

The HPE Proliant Dl380p Gen8 Server is equipped with a powerful Xeon 6 Core 2.1GHz processor, providing users with exceptional performance and reliability. This processor is specifically designed to handle demanding workloads and deliver optimal performance in a wide range of applications.

Product Overview

• Manufacturer: HPE
• Part Number: 734790-S01
• Product Name: ProLiant DL380p G8 2U-Rack Server S-Buy

Processor and Chipset Details

Processor Information

• Processor Type: Intel Xeon E5-2620 V2, 2.1 GHz
• Socket Compatibility: LGA2011
• Core Technology: Hexa-core (6 cores)
• 64-bit Computing: Supported
• Installed Processors: 1
• Maximum Supported Processors: 2
• Chipset Model: Intel C600

Cache Memory Specifications

• Cache Type: L3 Cache
• Installed Cache Size: 15 MB
• Cache Per Processor: 15 MB

Memory Configuration

Installed Memory

• Installed Size: 16 GB (expandable to 768 GB)
• Memory Technology: DDR3 SDRAM
• Memory Speed: 1600 MHz
• Memory Form Factor: DIMM 240-pin
• Memory Slots: 24 Total
• Configuration: 1 x 16 GB

Supported RAM Types

• PC3-12800 - Up to 384 GB - Registered
• PC3-10600 - Up to 768 GB
• PC3-10600 - Up to 128 GB - Unbuffered - Advanced ECC

Storage Options

Drive Configuration

• Hard Drive: Not Included by Default
• Internal Storage Bays: 8 Small Form Factor SAS/SATA HDD Bays
• Optical Drive Bay: Optional Slim Optical Bay (SATA DVD-RW/ROM)

Storage Controllers

• Controller Type: RAID Plug-in Card
• Interface Type: SATA 6 Gb/s / SAS 6 Gb/s
• Controller Name: Smart Array P420i with 512 MB FBWC
• RAID Levels: 0, 1, 5, 10, 50
• Buffer Size: 512 MB

Display and Graphics Features

• Graphics Type: Integrated
• Graphics Controller: Matrox G200

Network and Communication Interfaces

• Networking Type: Plug-in Card
• Interface Type: PCIe x4
• Ethernet Ports: 4 Gigabit Ethernet
• Ethernet Controller: HP 331FLR
• Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management Controller: Integrated Lights-Out 4 (iLO 4)
• Additional Features: Wake On LAN (WOL), PXE Support
• Standards Compliance: IEEE 802.3, 802.3u, 802.1q, 802.3ab, 802.1p, 802.3ad (LACP)

Expansion and Connectivity

Expansion Bays

• Front Accessible Bays: 1 x 5.25-inch Slim Line
• Hot-swap Bays: 8 x 2.5-inch Small Form Factor

Expansion Slots

• Memory Slots: 24 DIMM 240-pin (23 free)
• Processor Slots: 2 (1 free)
• PCIe x16 Slots: 2 (Full-length, Full-height, 2 free)
• PCIe x8 Slots: 3 (Half-length, Full-height, all free)
• PCIe x8 (X4 Mode) Slot: 1 (Half-length, Full-height, 1 free)
• FlexibleLOM Slot: 1 (X4 Mode, 0 free)

Interfaces and Ports

• Serial Port: 1 x RS-232, 9-pin D-sub
• Display Ports: 2 x VGA, 15-pin HD D-sub (1 Front, 1 Rear)
• USB Ports: 7 x USB Type-A (2 Front, 4 Rear, 1 Internal)
• Network Ports: 4 x RJ-45
• Management Port: 1 x HP iLO, RJ-45

Power Supply Details

• Type: Hot Plug
• Redundancy: Yes, 1+1 Scheme
• Installed Power Supply: 1
• Maximum Supported Power Supplies: 2
• Voltage Required: AC 120/220 V
• Power Provided: 460 Watts
• Certification: 80 Plus Platinum

Dimensions and Weight

• Width: 17.5 inches
• Depth: 27.5 inches
• Height: 3.4 inches
• Weight: 41 lbs

Enhanced Performance

The Xeon 6 Core 2.1GHz processor offers enhanced performance capabilities that enable users to effortlessly handle resource-intensive tasks. With its six cores, this processor can efficiently handle multiple threads, allowing for faster data processing and improved overall system performance.

Increased Throughput

With a clock speed of 2.1GHz, the Xeon 6 Core processor ensures increased throughput by executing instructions at a high rate. This results in faster data transfer and reduced latency, enabling users to accomplish tasks more quickly and efficiently.

Efficient Virtualization

Virtualization has become a critical aspect of modern server environments, enabling users to maximize their hardware resources. The Xeon 6 Core 2.1GHz processor is built with advanced virtualization technologies, such as Intel Virtualization Technology (VT-x), which allows for efficient utilization of server resources and improved virtual machine performance.

Better Energy Efficiency

Energy efficiency is a key concern for organizations as it directly impacts operational costs and environmental sustainability. The Xeon 6 Core 2.1GHz processor incorporates Intel's power management technologies, such as Enhanced Intel SpeedStep® Technology and Intel Turbo Boost Technology, which dynamically adjust the power consumption based on workload demands. This results in optimized energy usage and reduced power consumption without compromising performance.

Improved Security

Data security is of utmost importance in today's digital landscape. The Xeon 6 Core 2.1GHz processor includes advanced security features, such as Intel Trusted Execution Technology (TXT) and Intel Advanced Encryption Standard New Instructions (AES-NI). These security enhancements provide hardware-based protection against malicious attacks and help safeguard sensitive data.

The Xeon 6 Core 2.1GHz processor is a vital component of the HPE Proliant Dl380p Gen8 Server, offering users enhanced performance, increased throughput, efficient virtualization, better energy efficiency, and improved security. Whether you are running resource-intensive applications, managing virtualized environments, or prioritizing data security, this powerful processor delivers the performance and reliability you need to drive your business forward.

Ram: 16GB DDR3

The HPE Proliant Dl380p Gen8 Server is equipped with 16GB DDR3 RAM, providing users with ample memory capacity to support their demanding workloads. The high-performance DDR3 technology ensures fast and efficient data processing, enabling users to multitask seamlessly and run resource-intensive applications smoothly.

Improved Multitasking

The 16GB DDR3 RAM allows users to multitask with ease. Whether you are running multiple applications simultaneously or handling complex data operations, the ample memory capacity ensures smooth and efficient multitasking without any performance bottlenecks.

Enhanced Application Performance

Resource-intensive applications require a significant amount of memory to operate optimally. The 16GB DDR3 RAM provides sufficient memory capacity to accommodate these applications, allowing for improved performance and reduced latency. Users can experience faster response times and seamless application execution even under heavy workloads.

Efficient Virtualization

Virtualization environments rely heavily on memory resources to allocate virtual machines and manage workloads efficiently. The 16GB DDR3 RAM enables users to create and manage virtualized environments with ease, ensuring optimal performance for virtual machines and minimizing resource contention.

Scalability and Future-proofing

The 16GB DDR3 RAM offers scalability options to accommodate future growth and evolving business requirements. With the ability to expand the memory capacity, users can easily upgrade their server's memory to meet the increasing demands of their applications and workloads.

Reliability and Data Integrity

Data integrity is crucial for businesses, especially when dealing with critical operations and sensitive information. The 16GB DDR3 RAM incorporates error-correcting code (ECC) technology, which detects and corrects memory errors in real-time. This ensures reliable data processing and helps prevent system crashes or data corruption.

The 16GB DDR3 RAM is an essential feature of the HPE Proliant Dl380p Gen8 Server, providing users with improved multitasking capabilities, enhanced application performance, efficient virtualization, scalability options, reliability, and data integrity. Whether you are running resource-intensive applications, managing virtualized environments, or prioritizing data security, this high-performance RAM ensures optimal performance and enables you to meet the demands of your business.

Storage: 8Sff SSD

The HPE Proliant Dl380p Gen8 Server offers exceptional storage capabilities with its 8Sff SSD configuration. This storage feature provides users with high-speed access to data, enhanced reliability, and flexibility for various storage needs.

High-Speed Data Access

The 8Sff SSD configuration delivers lightning-fast data access speeds, enabling users to retrieve and process information quickly. With solid-state drive (SSD) technology, the server can read and write data at significantly faster rates compared to traditional hard disk drives (HDDs). This results in reduced latency and improved overall system performance.

Improved Application Performance

Resource-intensive applications often require fast storage solutions to deliver optimal performance. The 8Sff SSD configuration ensures that applications can access data swiftly, resulting in faster response times and seamless application execution. Users can experience enhanced productivity and efficiency when working with demanding applications or handling large datasets.

Reliability and Durability

Solid-state drives are more reliable and durable compared to traditional hard disk drives. They have no moving parts, making them less prone to mechanical failures. The 8Sff SSD configuration offers increased reliability, reducing the risk of data loss due to drive failures and minimizing system downtime.

Flexibility in Storage Configuration

The 8Sff SSD configuration provides users with flexibility in storage configuration options. It allows for various RAID configurations, enabling users to customize their storage setup based on their specific needs. Whether you require high-performance storage for critical applications or fault-tolerant storage for data redundancy, this configuration offers the flexibility to meet your requirements.

Scalability and Future-proofing

As businesses grow, their storage requirements tend to increase. The 8Sff SSD configuration offers scalability options, allowing users to expand their storage capacity as needed. With the ability to add more SSDs or upgrade to higher-capacity drives, users can easily accommodate future growth and evolving storage demands.

The 8Sff SSD configuration is a key feature of the HPE Proliant Dl380p Gen8 Server, providing users with high-speed data access, improved application performance, reliability, durability, flexibility in storage configuration, scalability options, and future-proofing capabilities. Whether you are running resource-intensive applications, managing large datasets, or prioritizing data security, this storage configuration ensures optimal performance and enables you to meet the storage demands of your business.

Product Code: 734790-S01

The HPE Proliant Dl380p Gen8 Server is identified by its unique product code, 734790-S01. This product code serves as a reference for identifying and ordering the specific server model, ensuring accuracy and reliability in the procurement process.

Easy Identification

With its distinct product code, the HPE Proliant Dl380p Gen8 Server can be easily identified among other server models. This simplifies the process of ordering and managing servers, especially in large-scale deployments, where multiple servers may be involved. Users can quickly reference the product code to ensure they are procuring the correct server model.

Accurate Specification Verification

The product code, 734790-S01, is directly associated with the specifications of the HPE Proliant Dl380p Gen8 Server. When referencing this product code, users can verify that the server they are purchasing matches their desired specifications accurately. This helps eliminate any discrepancies or misunderstandings during the procurement process.

Efficient Inventory Management

For organizations that manage a large inventory of servers, accurate identification and tracking are crucial. The product code enables efficient inventory management by providing a unique identifier for each HPE Proliant Dl380p Gen8 Server. This simplifies inventory tracking, facilitates stock management, and ensures seamless logistics operations.

Streamlined Maintenance and Support

The product code plays a vital role in maintenance and support activities. When requesting technical assistance or ordering replacement parts, users can reference the product code to ensure they receive the correct support or components for their specific server model. This streamlines maintenance processes and minimizes downtime.

Future Compatibility

As technology evolves, newer server models may be released with different specifications and features. The product code allows users to differentiate between different generations or versions of the HPE Proliant Dl380p Server easily. This ensures compatibility when ordering additional servers or expanding existing server deployments.

The product code, 734790-S01, is an essential element of the HPE Proliant Dl380p Gen8 Server, providing users with easy identification, accurate specification verification, efficient inventory management, streamlined maintenance and support, and future compatibility. Whether you are procuring servers for a small business or managing a large-scale deployment, this product code ensures accuracy and reliability throughout the entire lifecycle of your server infrastructure.
