EO000800JWTCA HPE 800GB SAS-12GBPS SFF 2.5" SSD

Highlights of HPE 800GB SAS 12GBPS SSD

Essential Product Details

• Brand Name: HPE
• Item Code: EO000800JWTCA
• Drive Type: Solid-State Drive Hot-Swap

Technical Specifications

Storage & Hardware Attributes

• Storage Capacity: 800 GB
• Drive Size: 2.5-inch Small Form Factor
• Connection Interface: SAS 12GBPS
• Flash Memory Architecture: Triple-Level Cell

Design & Integration Features

• Plug Configuration: Hot-Pluggable
• Connectivity Mode: Dual Port
• Mounting Carrier: SmartDrive Carrier
• Usage Profile: Write-Intensive Applications
• Security Feature: Digitally Signed Firmware
• Supported Systems: HPE ProLiant Rack, Tower, BladeSystem, Synergy
• Drive Height: 15.00 mm (0.60 inches)

Performance Metrics

Data Transfer Speeds

• External Bandwidth: 12 GBps
• Sequential Read Rate: Up to 1075 MiB/s
• Sequential Write Rate: Up to 1030 MiB/s

Latency & IOPS Statistics

• Read Latency: 135 µs (4KiB, Q1)
• Write Latency: 35 µs (4KiB, Q1)
• Random Read IOPS: 109,000 (4KiB, Q=16)
• Random Write IOPS: 120,000 (4KiB, Q=16)
• Max Read IOPS: 165,000 (4KiB @ Q32)
• Max Write IOPS: 120,000 (4KiB @ Q16)

Durability & Endurance

• 30-Day Write Volume: 14,600 TB
• Drive Writes Per Day (DWPD): 10.00

Connectivity & Expansion Options

• Interface Port: 1 x SAS 12Gb/s
• Bay Compatibility: 2.5-inch SFF

Energy Usage Profile

Power Draw Statistics

• Idle Consumption: 4.26 Watts
• Random Read: 4.97 Watts
• Random Write: 4.97 Watts
• Sequential Read: 6.71 Watts
• Sequential Write: 6.95 Watts
• Combined Read/Write: 4.97 Watts
• Peak Power: 6.71 Watts

Physical Dimensions & Weight

• Height: 5.00 inches (12.70 cm)
• Width: 7.00 inches (17.78 cm)
• Depth: 9.00 inches (22.86 cm)
• Weight: 1.10 lbs (0.50 kg)

System Compatibility Details

Supported HPE ProLiant DL Series Servers

Gen10 Models

DL180, DL325, DL360, DL380, DL385, DL388, DL580

• Includes Entry, Base, SMB, Performance, Plus, Solution, and All-Flash configurations

Supported HPE ProLiant ML Series Servers

Gen10 Models

ML110, ML350

• Includes Base, High-Performance, SMB, Solution, Special Server, and Sub-Entry variants

Supported HPE Synergy Series Modules

Gen10 Compute Modules

• 480 Gen10 Compute Module (2.5-inch SFF)

HPE EO000800JWTCA 800GB SAS-12GBPS WI SFF SSD Overview

The HPE EO000800JWTCA is a premium 800GB SAS-12GBPS Write Intensive Small Form Factor (SFF) 2.5-inch solid-state drive designed to deliver exceptional performance, reliability, and endurance for enterprise-level applications. This category of SSDs is specifically engineered for environments where high-speed write operations and sustained workloads are critical. The HPE 800GB Write Intensive SSDs offer a robust storage solution for data centers, virtualization, and mission-critical applications, providing low latency and consistent throughput that traditional hard drives cannot achieve.

Enterprise-Grade Write Performance

HPE's 800GB Write Intensive SSDs are optimized for write-heavy workloads, making them ideal for transaction-intensive databases, caching, and logging operations. The SAS-12GBPS interface ensures high-speed data transfer, enabling rapid read and write operations, while maintaining data integrity and minimizing latency. These drives are particularly suitable for enterprises that require continuous, high-speed write access without compromising durability or reliability.

Advanced SAS-12GBPS Connectivity

The SAS-12GBPS interface in this SSD category allows for seamless integration into HPE ProLiant servers and other enterprise storage environments. With dual-port SAS connectivity, these drives offer high availability and redundancy, ensuring uninterrupted operations in multi-path environments. The interface supports full-duplex communication, allowing simultaneous read and write operations at high speeds, which is essential for large-scale database transactions and real-time analytics.

Optimized for High-Intensity Workloads

The HPE EO000800JWTCA 800GB Write Intensive SSD is designed to handle rigorous workloads that demand frequent and sustained write cycles. Applications such as online transaction processing (OLTP), enterprise resource planning (ERP), and virtualization benefit from the consistent write performance and endurance of these drives. By delivering predictable input/output operations per second (IOPS) and minimal latency, this category of SSDs ensures that high-performance environments maintain operational efficiency and responsiveness.

Durability and Endurance

Durability is a cornerstone of the HPE 800GB SAS Write Intensive SSD category. These drives are built with advanced NAND flash technology that provides high write endurance and extended operational lifespan. Write-intensive SSDs are rated for a higher total bytes written (TBW) compared to mainstream drives, making them suitable for environments with frequent data updates. This category also incorporates sophisticated error correction algorithms and wear-leveling mechanisms to maintain consistent performance over the entire lifespan of the drive.

Thermal Management and Reliability

Effective thermal management is a critical feature in enterprise SSDs. HPE's 800GB Write Intensive SSDs integrate advanced heat dissipation technologies that prevent overheating during continuous high-speed operations. The drives are engineered to operate reliably across a wide temperature range, maintaining optimal performance in demanding data center conditions. Additionally, these SSDs undergo rigorous testing for shock, vibration, and power loss protection, ensuring that enterprise data remains secure and accessible at all times.

Compatibility with Enterprise Storage Ecosystems

This category of SSDs is fully compatible with HPE ProLiant Gen10 and Gen11 servers, as well as other enterprise-class storage systems that utilize SAS-12GBPS interfaces. The small form factor (SFF) 2.5-inch design allows for flexible deployment in high-density storage arrays, maximizing storage capacity without increasing physical footprint. Enterprises can easily scale their storage infrastructure using these drives, benefiting from seamless integration with existing RAID configurations and storage management solutions.

Performance Metrics and Specifications

The HPE EO000800JWTCA 800GB SAS-12GBPS Write Intensive SSD delivers impressive performance specifications designed to meet the demands of modern enterprise workloads. These drives achieve high sequential write speeds and consistent random write IOPS, ensuring rapid data access and processing. In addition, low latency characteristics make this category of SSDs suitable for latency-sensitive applications, including high-frequency trading, real-time analytics, and critical database operations.

Small Form Factor Advantages

The 2.5-inch SFF design provides multiple benefits, including reduced power consumption, optimized cooling, and increased storage density. Small form factor drives like the HPE 800GB Write Intensive SSD allow data centers to deploy more drives per rack unit, significantly enhancing storage scalability and efficiency. This form factor also contributes to lower energy costs and improved thermal management, which is crucial for large-scale enterprise operations.

Write Intensive Applications and Use Cases

HPE's 800GB Write Intensive SSDs are particularly suitable for applications that require frequent data modifications and high-volume write operations. These use cases include enterprise databases, virtual machine storage, content management systems, and transactional processing. The SSDs' ability to maintain consistent write performance under heavy workloads ensures that enterprises can achieve predictable operational performance, reduce bottlenecks, and enhance overall system responsiveness.

Data Protection and Security Features

Data protection is a critical aspect of this SSD category. HPE Write Intensive SSDs include features such as end-to-end data path protection, power loss protection, and advanced error correction. These capabilities ensure that data remains secure even in the event of unexpected power failures or system interruptions. Enterprise environments that handle sensitive information, such as financial institutions and healthcare organizations, benefit from these built-in safeguards.

Firmware and Management Tools

HPE provides robust firmware and management tools for this SSD category, allowing administrators to monitor drive health, performance, and endurance metrics in real-time. Management software provides predictive failure analysis, firmware updates, and configuration options, empowering IT teams to optimize storage performance and prevent downtime. These tools are essential for maintaining the reliability and longevity of enterprise storage deployments.

Comparison with Other Enterprise SSD Categories

Within the enterprise SSD landscape, write-intensive drives like the HPE EO000800JWTCA differ significantly from read-intensive or mixed-use SSDs. Write-intensive SSDs are engineered for workloads that involve frequent data writes, while read-intensive drives are optimized for applications that predominantly perform data retrieval operations. Mixed-use SSDs offer a balance between read and write workloads but may not provide the same endurance as dedicated write-intensive models. Selecting the appropriate SSD category ensures that enterprises achieve the best balance of performance, endurance, and cost-effectiveness for their specific workloads.

Scalability and Integration

The HPE 800GB Write Intensive SSD category is designed with scalability in mind. Enterprises can expand their storage infrastructure without compromising performance or reliability. These drives integrate seamlessly into existing server architectures and support a wide range of RAID configurations, enabling flexible deployment across multiple storage tiers. This scalability is critical for growing businesses that require adaptable and high-performing storage solutions.

Energy Efficiency and Operational Cost Savings

Another important aspect of this SSD category is its energy efficiency. HPE's write-intensive SSDs consume less power compared to traditional spinning disk drives, reducing overall operational costs and environmental impact. Energy-efficient storage solutions are particularly advantageous in large-scale data centers, where power consumption represents a significant portion of total operational expenditure. By deploying energy-efficient SSDs, enterprises can achieve both cost savings and improved sustainability.

End-to-End Enterprise Storage Solutions

The HPE EO000800JWTCA 800GB SAS-12GBPS Write Intensive SSD is part of HPE's broader portfolio of enterprise storage solutions. This category complements high-performance storage arrays, all-flash storage systems, and hybrid configurations, enabling enterprises to tailor their infrastructure to specific performance requirements. HPE's comprehensive storage ecosystem ensures compatibility, high availability, and simplified management across all storage layers, supporting mission-critical business applications and long-term strategic objectives.

Future-Ready Storage Technology

With continuous advancements in flash technology, the HPE 800GB Write Intensive SSD category is positioned to meet future enterprise storage demands. These drives support firmware updates and compatibility with emerging server architectures, ensuring that investments remain relevant as technology evolves. Enterprises can rely on these SSDs to deliver high-performance storage for years to come, providing both short-term and long-term operational benefits.

Key Benefits of HPE EO000800JWTCA SSDs

Overall, the HPE 800GB SAS-12GBPS Write Intensive SFF SSD category delivers unparalleled performance, high endurance, and enterprise-grade reliability. These drives offer consistent write performance, advanced data protection, thermal management, and energy efficiency. By integrating seamlessly into existing enterprise storage environments, they enable scalable, high-density deployments that meet the demands of modern data centers, virtualization, and mission-critical applications. The category represents a strategic choice for businesses seeking high-performing, reliable, and future-ready storage solutions.
