HPE P04480-B21 3.84TB SSD SATA 6GBPS SFF Read Intensive

P04480-B21
Hover on image to enlarge

Brief Overview of P04480-B21

3.84TB Solid State Drive SATA 6GBPS SFF Read Intensive HPE P04480-B21. Excellent Refurbished
QR Code of HPE P04480-B21 3.84TB SSD SATA 6GBPS SFF Read Intensive
$1,174.50
$734.00
You save: $440.50 (38%)
Ask a question
+
Quote
Additional 7% discount at checkout
SKU/MPNP04480-B21Availability✅ In StockProcessing TimeUsually ships same day ManufacturerHPE Product/Item ConditionExcellent Refurbished ServerOrbit Replacement WarrantySix-Month (180 Days)
Our Advantages
  • Free Ground Shipping
  • — Min. 6-month Replacement Warranty
  • — Genuine/Authentic Products
  • — Easy Return and Exchange
  • — Different Payment Methods
  • — Best Price
  • — We Guarantee Price Matching
  • — Tax-Exempt Facilities
  • — 24/7 Live Chat, Phone Support
Payment Options
  • — Visa, MasterCard, Discover, and Amex
  • — JCB, Diners Club, UnionPay
  • — PayPal, ACH/Wire Transfer
  • — Apple Pay, Amazon Pay, Google Pay
  • — Buy Now, Pay Later - Affirm, Afterpay
  • — GOV/EDU/Institutions PO's Accepted
  • — Invoices
Delivery
  • — Deliver Anywhere
  • — Express Delivery in the USA and Worldwide
  • — Ship to -APO -FPO
  • For USA - Free Ground Shipping
  • — Worldwide - from $30

Same product also available in:

Description

Product Overview of P04480-B21 SSD

HPE Solid State Drive Specifications

  • Brand: HPE
  • Model Number: VK003840GWSXL
  • Part Numbers: P04480-B21 (Option), P05315-001 (Spare)
  • Assembly Number: P03483-004

General Characteristics

  • Type: Solid State Drive - Hot-Swap
  • Storage Capacity: 3.84 TB
  • Connection Interface: SATA 6Gbps
  • Form Factor: 2.5-inch SFF
  • NAND Flash Memory Type: Triple-Level Cell (TLC)
  • Hot-Pluggable: Yes
  • Carrier Type: Smart Carrier (SC)
  • Workload Type: Read Intensive
  • Firmware: Digitally Signed
  • Bundled With: HPE Smart Carrier
  • Compatibility: HPE ProLiant Rack, Tower, BladeSystem Servers, Synergy
  • Height: 0.30 inch (7.00 mm)

Performance Metrics

Drive Endurance and Throughput

  • 30-Day Write Capacity: 7700
  • DWPD: 1.10
  • External Transfer Rate: 600 MBps
  • Max Sequential Reads: 520 MiB/s
  • Max Sequential Writes: 495 MiB/s

Random Performance

  • Average Latency (Read, 4KiB, Q1): 125 µSec
  • Average Latency (Write, 4KiB, Q1): 45 µSec
  • Random Read IOPS (4KiB, Q=16): 55,000
  • Random Write IOPS (4KiB, Q=16): 210,000
  • Max Random Read IOPS (4KiB): 58,000 @ Q32
  • Max Random Write IOPS (4KiB): 22,000 @ Q4

Power Efficiency

Power Consumption Values

  • Idle: 1.50 Watts
  • Random Read: 2.30 Watts
  • Random Write: 2.30 Watts
  • Sequential Read: 4.20 Watts
  • Sequential Write: 6.30 Watts
  • Random Read/Write: 2.30 Watts
  • Maximum Power Consumption: 6.30 Watts

Compatibility Details

Supported Systems

  • HPE Nimble Storage dHCI Solutions with ProLiant DL380 Gen10
  • ProLiant DL Series (Various Models)
  • ProLiant ML Series (Various Models)
  • HPE Synergy 480 Gen10 Compute Module

Capacity: 3.84TB

The HPE P04480-B21 Solid State Drive offers an impressive capacity of 3.84TB, making it a top choice for users who require high storage capabilities. With this vast amount of storage space, you can store an extensive range of data, including large files, applications, databases, and multimedia content. Whether you are an individual user or a business, having such a large capacity drive ensures that you have enough storage space to accommodate your needs.

Increased Storage Flexibility

The 3.84TB capacity of the HPE P04480-B21 Solid State Drive provides you with increased flexibility when it comes to storing your data. You no longer need to worry about constantly managing your storage space or deleting files to free up memory. This drive allows you to keep all your important data in one place without the need for additional storage solutions.

Efficient Data Management

With its high capacity, this solid state drive enables you to efficiently manage and organize your data. Whether you need to access specific files quickly or perform backups, having ample space ensures that you can easily locate and retrieve your data without any delays or interruptions.

Seamless Workflow

The 3.84TB capacity is particularly beneficial for professionals who work with large files, such as graphic designers, video editors, and architects. With this drive, you can seamlessly work on projects without worrying about running out of storage space. This eliminates the need for constantly transferring files or using external storage devices, streamlining your workflow and improving productivity.

Future-Proof Solution

Investing in a solid state drive with a high capacity like the HPE P04480-B21 ensures that you are prepared for future storage needs. As technology advances and file sizes continue to increase, having a drive with a large capacity will ensure that you can adapt and accommodate these changes without the need for frequent upgrades or replacements.

Interface: SATA 6GBPS

The HPE P04480-B21 Solid State Drive features a SATA 6Gbps interface, providing users with fast and reliable data transfer speeds. The SATA interface has become a standard in the industry, offering numerous benefits to users.

High-Speed Data Transfer

The SATA 6Gbps interface enables the HPE P04480-B21 Solid State Drive to deliver exceptional data transfer speeds. Whether you are transferring large files, backing up data, or running resource-intensive applications, this interface ensures that your data is quickly processed and accessed without any bottlenecks or delays.

Improved System Performance

By utilizing the SATA 6Gbps interface, this solid state drive enhances the overall performance of your system. With faster data transfer speeds, your computer can read and write data more efficiently, resulting in quicker boot times, faster application launches, and improved overall system responsiveness.

Compatibility

The SATA 6Gbps interface is widely supported by most modern computers and devices. This means that the HPE P04480-B21 Solid State Drive can easily be integrated into your existing system without compatibility issues. Whether you have a desktop computer, laptop, or server, this drive can seamlessly connect to your system via the SATA interface.

Cost-Effective Solution

SATA drives are generally more affordable compared to other interfaces such as PCIe. The use of the SATA 6Gbps interface in the HPE P04480-B21 Solid State Drive allows users to benefit from high-speed data transfer without breaking the bank. This makes it an excellent choice for individuals or businesses on a budget who still require reliable and fast storage solutions.

Form Factor: SFF

The HPE P04480-B21 Solid State Drive features a Small Form Factor (SFF) design, offering compactness without compromising on performance. The SFF form factor has become increasingly popular due to its numerous advantages.

Space-Saving Design

The SFF form factor allows for a smaller physical size compared to traditional larger drives. This compact design is particularly beneficial for users who have limited space in their systems, such as small form factor PCs or servers. With the HPE P04480-B21, you can maximize your available space without sacrificing storage capacity or performance.

Improved Airflow

The smaller size of the SFF drive contributes to improved airflow within your system. By occupying less space, the drive allows for better ventilation and cooling, reducing the risk of overheating and enhancing overall system stability and reliability.

Easy Installation and Maintenance

The SFF form factor simplifies the installation and maintenance process. The compact size of the HPE P04480-B21 Solid State Drive makes it easy to install in tight spaces and ensures compatibility with a wide range of systems. Additionally, if you need to replace or upgrade your drive in the future, the SFF design allows for easy removal and replacement without extensive disassembly of your system.

Versatility

The SFF form factor is designed to be versatile, making it suitable for a variety of applications. Whether you need to upgrade your laptop, desktop computer, or server, the HPE P04480-B21 Solid State Drive can seamlessly integrate into different systems without any compatibility issues.

Intended Use: Read Intensive

The HPE P04480-B21 Solid State Drive is specifically designed for read-intensive workloads, making it an ideal choice for users who require fast and reliable access to their data.

Optimized Reading Performance

The read-intensive nature of this drive ensures that reading data is a smooth and efficient process. Whether you are accessing large files, performing data analytics, or running virtual machines, the HPE P04480-B21 delivers superior read speeds, allowing you to quickly retrieve the information you need.

Enhanced Data Access

By prioritizing read performance, this drive provides users with faster access to their data. This is particularly beneficial for applications that heavily rely on reading operations, such as content delivery networks, databases, and web servers. With the HPE P04480-B21, you can ensure that your data is readily available whenever you need it.

Increased Lifespan

Read-intensive drives are engineered to handle a higher number of read operations compared to write-intensive drives. This longevity ensures that the HPE P04480-B21 Solid State Drive can withstand intense workloads and heavy usage over an extended period without compromising on performance or reliability.

Cost-Effective Solution

Read-intensive drives often offer a more cost-effective solution compared to write-intensive drives. As read operations typically outnumber write operations in many applications, investing in a drive optimized for reading can provide significant cost savings without sacrificing performance.

Features
Product/Item Condition:
Excellent Refurbished
ServerOrbit Replacement Warranty:
Six-Month (180 Days)
