HPE P04535-B21 1.6TB SAS 12GBPS SSD LFF Mixed Use Internal
- — Free Ground Shipping
- — Min. 6-month Replacement Warranty
- — Genuine/Authentic Products
- — Easy Return and Exchange
- — Different Payment Methods
- — Best Price
- — We Guarantee Price Matching
- — Tax-Exempt Facilities
- — 24/7 Live Chat, Phone Support
- — Visa, MasterCard, Discover, and Amex
- — JCB, Diners Club, UnionPay
- — PayPal, ACH/Wire Transfer
- — Apple Pay, Amazon Pay, Google Pay
- — Buy Now, Pay Later - Affirm, Afterpay
- — GOV/EDU/Institutions PO's Accepted
- — Invoices
- — Deliver Anywhere
- — Express Delivery in the USA and Worldwide
- — Ship to -APO -FPO
- — For USA - Free Ground Shipping
- — Worldwide - from $30
Same product also available in:
SKU/MPN | Warranty | Price | Condition | You save |
---|---|---|---|---|
P04535-B21 | Six-Month (180 Days) | $1,064.00 | Excellent Refurbished | You save: $586.00 (36%) |
P04535-B21 | Six-Month (180 Days) | $1,112.00 | New (System) Pull | You save: $638.00 (36%) |
Overview of the HPE P04535-B21
General Information
- Brand: HPE
- Part Number: P04535-B21
- Spare Part Number: P06581-001
- Model Identifier: MO001600JWTBT
- Assembly Identifier: P04174-003
Device Characteristics
- Type: Hot-Swap Solid State Drive
- Storage Capacity: 1.6 TB
- Form Factor: 3.5 inch LFF
- Interface Standard: SAS 12Gbps
- NAND Type: Triple-level cell (TLC)
- Connectivity Ports: Dual Port
- Hot Plug Capability: Yes
- Carrier Type: Low Profile Converter (LPC)
- Optimal Workload: Mixed Use
- Included Accessories: HPE Low Profile Converter (LPC)
- Firmware Features: Digitally Signed
- Supported Platforms: HPE ProLiant Rack/Tower/BladeSystem Servers/Synergy
- Height: 15.00 mm
Performance Metrics
- 30-Day Write Capacity: 8760 writes
- Endurance (DWPD): 3 Drive Writes Per Day
- External Transfer Rate: 12 Gb/sec
- Random Read IOPS (4KiB, Q=16): 109,000
- Max Random Read IOPS (4KiB): 165,000 @ Q32
- Random Write IOPS (4KiB, Q=16): 105,000
- Max Random Write IOPS (4KiB): 105,000 @ Q16
- Max Sequential Read Throughput: 1075 MiB/s
- Max Sequential Write Throughput: 1030 MiB/s
- Average Random Read Latency (4KiB, Q1): 135 microseconds
- Average Random Write Latency (4KiB, Q1): 35 microseconds
Expansion and Connectivity Features
- SAS Interface: 1 x SAS 12 Gb/s
- Compatible Bay Size: 3.5" LFF
Power Consumption Specifications
- Idle Consumption: 5.00 Watts
- Random Read Power Usage: 6.00 Watts
- Random Write Power Usage: 6.00 Watts
- Sequential Read Power Usage: 6.98 Watts
- Sequential Write Power Usage: 6.98 Watts
- Random Read/Write Power Consumption: 5.43 Watts
- Maximum Power Consumption: 8.98 Watts
Physical Dimensions and Weight
- Height: 5.50 inches (13.97 cm)
- Width: 7.25 inches (18.41 cm)
- Depth: 8.75 inches (22.23 cm)
- Weight: 3.00 lbs (1.36 kg)
Capacity
The HPE P04535-B21 SSD offers an impressive storage capacity of 1.6TB. This generous amount of storage space is essential for users who require high-performance storage solutions for their data-intensive applications and workloads.
Enhanced Storage Efficiency
With a capacity of 1.6TB, this SSD enables users to store a vast amount of data in a compact form factor. By consolidating multiple smaller drives into a single 1.6TB SSD, users can save valuable physical space in their server racks or storage arrays. This increased storage efficiency not only leads to cost savings but also improves overall system performance.
Seamless Scalability
The 1.6TB capacity of the HPE P04535-B21 SSD ensures that users have enough headroom for future growth and expansion. As businesses generate more data and require additional storage, this SSD allows for seamless scalability without the need for disruptive hardware upgrades or migrations. Users can easily add more drives to their existing infrastructure, ensuring their storage solution keeps up with their evolving needs.
Optimized Workflows
By offering a substantial 1.6TB capacity, this SSD enables users to streamline their workflows and improve productivity. Large datasets can be stored and accessed quickly, allowing for faster data analysis, processing, and decision-making. Whether it's running complex simulations, rendering high-resolution graphics, or managing large databases, the 1.6TB capacity of the HPE P04535-B21 SSD ensures that users can work efficiently without facing storage limitations.
Interface
The HPE P04535-B21 SSD features a SAS (Serial Attached SCSI) interface, which offers numerous benefits for users seeking reliable and high-performance storage solutions.
Robust Data Transfer
The SAS interface provides exceptional data transfer speeds, allowing users to access and retrieve their data quickly. With a maximum data transfer rate of 12Gbps, the HPE P04535-B21 SSD ensures that users can efficiently handle demanding workloads and experience minimal latency. This high-speed interface is particularly beneficial for applications that require real-time data processing, such as financial transactions or video streaming.
Increased Scalability
The SAS interface enables users to connect multiple drives in a daisy-chain configuration, increasing storage capacity and scalability. This feature is especially advantageous in enterprise environments where large-scale storage solutions are required. Users can easily expand their storage infrastructure by adding more SAS drives, ensuring their storage solution can accommodate future growth.
Enterprise-Grade Reliability
SAS drives, including the HPE P04535-B21 SSD, are renowned for their reliability and durability. The SAS interface incorporates advanced error detection and correction mechanisms, minimizing the risk of data loss or corruption. Additionally, SAS drives often include features like hot-swappable capabilities and redundant paths for enhanced fault tolerance and continuous operation. This reliability is crucial for businesses that rely on their storage systems for critical operations and cannot afford downtime or data loss.
Speed
The HPE P04535-B21 SSD boasts an impressive speed of 12Gbps. This high-speed capability provides users with significant performance advantages for their data-intensive tasks and applications.
Accelerated Data Access
The 12Gbps speed of the HPE P04535-B21 SSD ensures that users can access their data rapidly, resulting in improved system responsiveness and reduced wait times. Whether it's loading large files, launching resource-intensive applications, or executing complex queries on databases, the high-speed capabilities of this SSD enable users to complete tasks more efficiently.
Optimized Workloads
The increased speed offered by the HPE P04535-B21 SSD allows users to optimize their workloads and achieve higher productivity levels. Time-consuming tasks, such as data backups, file transfers, and software installations, can be completed in significantly less time, freeing up valuable resources for other essential operations. This speed advantage is particularly beneficial for businesses that rely on quick turnaround times and need to maximize their operational efficiency.
Improved System Performance
By leveraging the 12Gbps speed of the HPE P04535-B21 SSD, users can significantly enhance the performance of their entire system. Storage-intensive applications can execute faster, resulting in reduced latency and improved user experiences. Additionally, high-speed data transfers enable faster replication and synchronization processes, ensuring data consistency across multiple systems. The improved system performance translates to increased productivity and ultimately, better business outcomes.
Form Factor
The HPE P04535-B21 SSD features a Large Form Factor (LFF), providing users with flexibility and compatibility with a wide range of server and storage configurations.
Optimal Space Utilization
The LFF form factor allows the HPE P04535-B21 SSD to fit seamlessly into existing server racks and storage arrays. This compatibility ensures that users can make the most efficient use of their available physical space without requiring additional modifications or investments. The ability to integrate the SSD into various form factors enables users to optimize their storage infrastructure while maintaining a compact and organized setup.
Versatile Deployment Options
The LFF form factor offers versatility in deployment options, allowing users to choose the most suitable configuration for their specific needs. Whether it's a standalone server, a storage array, or a hyper-converged infrastructure, the HPE P04535-B21 SSD can be easily integrated into diverse environments. This flexibility ensures that users can adapt their storage solutions to meet evolving requirements and take advantage of the latest technological advancements.
Scalability and Future-Proofing
The LFF form factor also facilitates scalability and future-proofing. The ability to accommodate larger-capacity drives in the LFF form factor ensures that users can seamlessly upgrade their storage infrastructure as their data storage needs grow. This scalability eliminates the need for costly hardware replacements and allows for a more cost-effective and sustainable approach to storage expansion.
Internal/External
The HPE P04535-B21 SSD is designed for internal use, which offers several benefits and advantages for users seeking reliable and efficient storage solutions.
Enhanced Data Security
By being an internal drive, the HPE P04535-B21 SSD provides an additional layer of data security. Internal drives are not easily accessible to unauthorized individuals, reducing the risk of data breaches or theft. This enhanced security is particularly crucial for businesses that handle sensitive or confidential information and need to comply with strict data protection regulations.
Reduced Environmental Impact
Internal drives, such as the HPE P04535-B21 SSD, contribute to a more environmentally friendly IT infrastructure. By keeping storage solutions internal, there is less reliance on external devices that consume additional power and generate heat. This reduction in energy consumption not only lowers operational costs but also minimizes the carbon footprint of the organization. The internal nature of this SSD aligns with sustainable business practices and supports green initiatives.
Simplified Maintenance
Internal drives are easier to manage and maintain compared to external drives. With an internal drive like the HPE P04535-B21 SSD, users can avoid dealing with external cables, connectors, or enclosures. This streamlined setup simplifies maintenance tasks such as troubleshooting, firmware updates, or drive replacements. The internal nature of this SSD ensures that users can focus on their core tasks and spend less time on peripheral device management.
Use Type
The HPE P04535-B21 SSD is categorized as a Mixed Use drive, offering a versatile solution that can handle a wide range of workloads and applications.
Flexible Workload Support
As a Mixed Use drive, the HPE P04535-B21 SSD is designed to accommodate various workload types. Whether it's read-intensive operations, write-intensive applications, or a combination of both, this SSD can deliver optimal performance and reliability. This flexibility allows users to leverage the same drive for different tasks, simplifying storage management and reducing the need for multiple specialized drives.
Cost-Effective Solution
By opting for a Mixed Use drive like the HPE P04535-B21 SSD, users can achieve cost savings without compromising performance. Mixed Use drives strike a balance between performance and endurance, providing a more affordable option compared to high-endurance drives designed exclusively for write-intensive workloads. This cost-effectiveness makes the HPE P04535-B21 SSD an attractive choice for businesses looking to maximize their storage budget while still meeting their performance requirements.
Future-Proofing and Adaptability
The Mixed Use nature of the HPE P04535-B21 SSD ensures that users are prepared for future changes in workload requirements. As workloads evolve or new applications emerge, this versatile drive can adapt and continue to deliver reliable performance. This future-proofing capability eliminates the need for frequent drive replacements or costly infrastructure upgrades, providing long-term value and investment protection.
