HPE P05320-001 480GB SATA 6GBPS SSD Read Intensive SC Firmware Signed

Product Overview

The HPE P05320-001 is a high-performance Read Intensive Solid State Drive with a compact 2.5-inch form factor, featuring a SATA-6Gbps interface. With a substantial capacity of 480 GB, this SSD is engineered for demanding workloads, delivering rapid data access and reliability.

General Information

• Brand: HPE
• Model Number: P05320-001
• Option Part Number: P04560-B21
• Spare Part Number: P05320-001
• Assembly Number: P02760-002

Technical Specifications

• Device Type: Solid State Drive - Hot-Swap
• Total Capacity: 480 GB
• Form Factor: 2.5 inch SFF
• Interface: SATA 6Gbps
• Workload Type: Read Intensive
• Carrier Type: Smart Carrier (SC)
• NAND Flash Type: TLC (Triple-Level Cell)
• Connection Type: Single Port
• Plug Type: Hot Plug
• Features: Digitally Signed Firmware
• Bundled With: HPE Smart Drive Carrier
• Height: 7 mm

Performance Metrics

Endurance and Data Transfer Rates

• 30 Days Writes: 700
• Endurance (DWPD): 0.80 Drive Writes Per Day
• Drive Transfer Rate: 600 MBps (external)

Sequential and Random Performance

• Max Sequential Reads Throughput: 535 MiB/s
• Max Sequential Writes Throughput: 495 MiB/s
• Random Read Average Latency: 105 µSec (4KiB, Q1)
• Random Write Average Latency: 36 µSec (4KiB, Q1)
• Random Read IOPS: 68,000 (4KiB, Q=16)
• Random Write IOPS: 25,000 (4KiB, Q=16)
• Max Random Read IOPS: 77,000 @ Q32 (4KiB)
• Max Random Write IOPS: 25,000 @ Q1 (4KiB)

Expansion and Connectivity

• Interfaces: 1 x SATA 6 Gb/s
• Compatible Bay: 2.5" SFF

Power Consumption

• Idle Power: 1.12 Watt
• Power During Random Read: 2.29 Watt
• Power During Random Write: 2.29 Watt
• Power During Sequential Read: 1.89 Watt
• Power During Sequential Write: 2.50 Watt
• Power During Random Read/Write: 2.29 Watt
• Maximum Power Requirement: 3.00 Watt

Product Dimensions and Weight

• Height: 5.00 inches (12.70 cm)
• Width: 7.00 inches (17.78 cm)
• Depth: 9.00 inches (22.86 cm)
• Weight: 1.10 lbs (0.50 kg)

Compatibility Information

Designed For Various HPE Servers

• HPE Apollo Series: 4200 Gen9 for Google (2.5-inch)
• HPE ProLiant BL Series: BL660c Gen9 (2.5-inch), DL180 Gen10 (2.5-inch)
• HPE ProLiant DL Series: DL180 Gen10 Entry, DL180 Gen10 SMB, DL20 Gen10, DL325 Gen10, DL360 Gen9, DL380 Gen10, and more (all 2.5-inch)
• HPE ProLiant ML Series: ML30 Gen10, ML350 Gen10 (multiple configurations, all 2.5-inch)
• HPE Synergy Series: 680 Gen9 (multiple configurations, all 2.5-inch)

Capacity: 480GB

The HPE P05320-001 SSD is equipped with a generous capacity of 480GB, making it an ideal choice for users who require ample storage space for their data-intensive tasks. Whether you are a professional content creator, a gamer, or simply someone who needs to store a large amount of multimedia files, this SSD can meet your demands.

Increased Storage Capacity

With a capacity of 480GB, this SSD allows you to store a vast amount of data without worrying about running out of space. You can safely store your high-resolution photos, videos, and documents without compromising on quality or quantity. This is especially crucial for professionals who deal with large files on a daily basis, such as photographers, videographers, and graphic designers.

Additionally, the 480GB capacity provides flexibility in managing your data. You can keep all your files in one place, eliminating the need for multiple storage devices. This not only simplifies your workflow but also saves you time and effort in organizing and searching for your files.

Improved Performance and Speed

The 480GB capacity of the HPE P05320-001 SSD ensures that you can enjoy fast and efficient performance. With ample space available, the SSD can handle heavy workloads and multitasking without compromising on speed or responsiveness.

Whether you are editing large video files, running resource-intensive software, or playing demanding games, this SSD will provide you with the necessary storage capacity to handle these tasks smoothly. You can expect quicker load times, faster file transfers, and seamless performance that enhances your productivity and overall user experience.

Reliability and Durability

Another benefit of the 480GB capacity is the increased reliability and durability of the SSD. With more storage space available, the SSD can distribute the workload across a larger number of cells, reducing the strain on individual cells and prolonging the lifespan of the drive.

Furthermore, the 480GB capacity allows for efficient wear leveling, a process that evenly distributes write and erase cycles across the entire drive. This prevents specific areas of the SSD from being overused, reducing the risk of data corruption and extending the overall lifespan of the drive.

Enhanced Data Security

The 480GB capacity also offers enhanced data security. You can create multiple partitions on the SSD to separate your data, ensuring that sensitive information is kept separate from other files. This feature is particularly beneficial for businesses or individuals who need to store confidential data and want to maintain strict access controls.

In addition, the larger capacity allows for more efficient encryption algorithms to be implemented, providing an extra layer of protection for your data. With the 480GB capacity, you can rest assured that your files are secure and protected from unauthorized access.

Interface: SATA 6GBPS

The HPE P05320-001 SSD features a SATA 6Gbps interface, delivering high-speed data transfer rates and seamless connectivity. The SATA 6Gbps interface offers numerous benefits and is an essential feature for users who require fast and reliable performance.

Blazing Fast Data Transfer

The SATA 6Gbps interface allows for lightning-fast data transfer speeds, enabling you to move large files quickly without any lag or delay. Whether you are copying files between drives or accessing data from external sources, this interface ensures that your data is transferred at its maximum potential speed.

With this high-speed interface, you can experience significantly reduced waiting times when transferring files. This is particularly advantageous for professionals who deal with large files, such as video editors or photographers, as it allows them to save valuable time and focus on their work rather than waiting for file transfers to complete.

Seamless Compatibility

The SATA 6Gbps interface is widely supported by a variety of devices, making it highly compatible with different systems and setups. Whether you are using a desktop computer, laptop, or server, you can easily connect the HPE P05320-001 SSD and enjoy its fast and reliable performance.

Additionally, the SATA 6Gbps interface ensures seamless compatibility with existing storage devices, allowing you to upgrade your system without the need for extensive hardware changes. You can simply connect the SSD to an available SATA port and start benefiting from its enhanced performance.

Easy Installation

The SATA 6Gbps interface offers easy installation, making it accessible for users of all levels of technical expertise. With a simple plug-and-play setup, you can quickly connect the HPE P05320-001 SSD to your system without the need for specialized tools or complicated procedures.

This easy installation process saves you time and effort, allowing you to start using your new SSD immediately. Whether you are a professional IT technician or a casual computer user, the SATA 6Gbps interface ensures a hassle-free installation experience.

Usage: Read Intensive

The HPE P05320-001 SSD is specifically designed for read-intensive usage, making it an excellent choice for applications that require fast data access and retrieval. Whether you are running databases, web servers, or content delivery networks, this SSD can handle the demands of read-intensive workloads efficiently.

Accelerated Data Access

With its read-intensive design, this SSD excels in providing accelerated data access. It prioritizes read operations, allowing for faster retrieval of information from the drive. This is particularly beneficial for tasks that heavily rely on read operations, such as online transaction processing (OLTP), data analytics, and virtualization.

The accelerated data access provided by the HPE P05320-001 SSD ensures that your applications and systems can quickly retrieve the necessary information, resulting in improved performance and responsiveness. You can expect reduced latency, faster query execution times, and an overall smoother user experience.

Enhanced Reliability

Read-intensive usage places less strain on the SSD compared to write-intensive workloads, resulting in enhanced reliability and durability. With fewer write operations, the drive experiences less wear and tear, prolonging its lifespan and reducing the likelihood of failures or data loss.

For businesses or individuals who rely on continuous data access and cannot afford downtime, the enhanced reliability of the HPE P05320-001 SSD is a critical feature. You can trust that your applications will run smoothly and consistently without interruptions due to drive failures.

Optimized Cost Efficiency

The read-intensive design of this SSD offers optimized cost efficiency for users who prioritize performance while keeping costs in check. By focusing on read operations, this SSD delivers impressive performance levels at a more affordable price point compared to write-intensive SSDs.

If you have workloads that primarily involve reading data rather than writing, the HPE P05320-001 SSD offers a cost-effective solution without compromising on performance. You can enjoy the benefits of fast data access without exceeding your budget.

Form Factor: 2.5-inch

The HPE P05320-001 SSD features a 2.5-inch form factor, providing a compact and versatile storage solution for various devices and applications. The 2.5-inch form factor offers numerous benefits and is widely supported by a range of systems.

Compact and Space-Saving Design

The 2.5-inch form factor is smaller and more compact compared to traditional 3.5-inch hard drives. This compact design allows for easy integration into space-constrained systems, such as laptops, small form factor PCs, and embedded systems.

Whether you need to upgrade your laptop's storage or install additional drives in a compact server chassis, the HPE P05320-001 SSD's 2.5-inch form factor ensures a perfect fit without sacrificing performance or storage capacity.

Wide Compatibility

The 2.5-inch form factor is widely supported by a variety of devices, making it highly compatible with different systems and configurations. Whether you are using a desktop computer, server, or external storage enclosure, you can easily connect the HPE P05320-001 SSD and enjoy its reliable performance.

Furthermore, the wide compatibility of the 2.5-inch form factor ensures that you can seamlessly upgrade your existing storage without the need for extensive modifications or additional hardware. This allows for a hassle-free installation process and minimizes any potential disruptions to your workflow.

Enhanced Portability

The compact size of the 2.5-inch form factor also enhances the portability of the HPE P05320-001 SSD. If you frequently travel or work on multiple devices, this SSD can easily be transferred between systems without adding significant weight or bulk.

Whether you need to access your files on a different computer or carry your data with you on the go, the HPE P05320-001 SSD's 2.5-inch form factor provides convenience and flexibility. You can enjoy high-performance storage wherever you are, without being limited by the constraints of larger and bulkier drives.
