P19947-X21 HPE 480GB SATA 6GBPS 2.5in Mixed Use SSD

HPE P19947-X21 480GB SATA 6GBPS SSD

Brand Details

• Brand: HPE
• Model Number: P19947-X21
• Drive Category: Hot-Swap Solid State Drive

Technical Specifications

Storage Capacity & Format

• Size: 480 Gigabytes
• Form Factor: 2.5-inch Small Form Factor
• Interface Type: SATA III 6GBPS
• Flash Memory: Triple-Level Cell

Connectivity & Compatibility

• Port Configuration: Single Interface
• Plug Style: Hot-Pluggable
• Carrier Format: Smart Carrier (SC)
• Supported Platforms: HPE ProLiant Rack, Tower, BladeSystem, Synergy Servers
• Firmware: Digitally Signed (DS)

Physical Dimensions

• Height: 0.30 inches (7.00 mm)

Performance Metrics

Write & Read Efficiency

• 30-Day Write Volume: 4380
• Endurance Rating: 5 DWPD (Drive Writes Per Day)
• Transfer Speed: 6 Gb/sec

Input/Output Operations Per Second (IOPS)

• Random Read (4KiB, Q=16): 670,000
• Max Random Read (4KiB, Q=64): 76,000
• Random Write (4KiB, Q=16): 52,000
• Max Random Write (4KiB, Q=4): 53,000

Sequential Throughput

• Max Sequential Read: 520 MiB/s
• Max Sequential Write: 450 MiB/s

Latency Statistics

• Average Read Latency (4KiB, Q=1): 125 µs
• Average Write Latency (4KiB, Q=1): 37 µs

Expansion & Interface Options

• Connection Type: 1 x SATA 6 Gb/s
• Bay Compatibility: 2.5" Small Form Factor

Energy Usage Profile

Power Draw by Operation

• Idle Consumption: 1.18 Watts
• Random Read: 1.44 Watts
• Random Write: 1.44 Watts
• Sequential Read: 2.05 Watts
• Sequential Write: 2.76 Watts
• Combined Random Read/Write: 1.44 Watts
• Peak Usage: 2.76 Watts

Dimensions & Mass

• Height: 5.75 inches (14.61 cm)
• Width: 8.63 inches (21.92 cm)
• Depth: 9.00 inches (22.86 cm)
• Weight: 1.508 lbs (0.68 kg)

Compatible HPE ProLiant Server Families

Blade Series

• BL420c Gen8
• BL460c Gen8 / Gen9 / Gen10
• BL465c Gen8
• BL660c Gen8

Rack Series

• DL120 Gen9
• DL160 Gen8 / Gen9 / Gen10
• DL180 Gen9 / Gen10
• DL20 Gen10
• DL320e Gen8 / Gen8 v2
• DL325 Gen10 Plus
• DL360 Gen9 / Gen10 / Gen8e / Gen8p
• DL380 Gen9 / Gen10 / Gen8e / Gen8p
• DL385 Gen10 Plus / Gen8p
• DL388 Gen9
• DL560 Gen8 / Gen10
• DL580 Gen8 / Gen10

Tower Series

• ML110 Gen10
• ML150 Gen9
• ML310e Gen8 / Gen8 v2
• ML350 Gen9 / Gen10 / Gen11 / Gen8e / Gen8p

Scalable Series

• SL230s Gen8
• SL250s Gen8
• SL270s Gen8

Workstation Series

• WS460c Gen8

XL Series

• XL220a Gen8 v2
• XL230a Gen9

HPE P19947-X21 480GB SATA 6GBPS MU SFF SSD Overview

The HPE P19947-X21 Solid State Drive 480GB SATA 6GBPS Mixed Use is a high-performance storage solution designed for enterprise and data center applications requiring a balance of speed, reliability, and endurance. This mixed-use SSD provides an ideal combination of read and write capabilities, making it suitable for a wide range of workloads including databases, virtualized environments, and general-purpose storage. Engineered with HPE's proven technology, the P19947-X21 delivers consistent performance, low latency, and improved overall system efficiency.

Advanced SATA 6GBPS Interface

Equipped with a SATA 6GBPS interface, the HPE P19947-X21 ensures seamless integration with existing storage infrastructure. This interface supports high data transfer rates and offers backward compatibility with SATA 3GBPS systems. The 6GBPS bandwidth enables fast access to frequently used data and enhances the responsiveness of enterprise applications. By leveraging the SATA protocol, this SSD maintains reliability and simplicity while delivering improved performance compared to traditional hard drives.

Optimized for Mixed-Use Workloads

The mixed-use architecture of the HPE P19947-X21 allows it to efficiently handle both read-intensive and write-intensive tasks. Unlike single-use SSDs that are optimized exclusively for either read or write operations, mixed-use drives provide a balanced performance profile. This makes the P19947-X21 particularly suitable for environments where database transactions, virtualization, and mixed storage applications coexist. IT administrators benefit from predictable performance and extended drive endurance, ensuring storage longevity and system stability.

Enhanced Endurance and Reliability

Reliability is a critical factor in enterprise storage solutions, and the HPE P19947-X21 excels in this area. The drive is designed with advanced error correction algorithms, wear leveling, and thermal management features. These technologies minimize the risk of data loss and maintain consistent performance over the lifetime of the drive. The mixed-use SSD also supports robust power-loss protection, safeguarding critical data during unexpected system outages or power interruptions. This level of durability makes it an ideal choice for mission-critical applications and high-availability storage systems.

High IOPS Performance

The HPE P19947-X21 provides high input/output operations per second (IOPS), ensuring rapid data access for demanding enterprise applications. By delivering low latency and high throughput, this SSD enhances the performance of virtualized environments, transactional databases, and collaborative workloads. The consistent IOPS performance helps reduce application bottlenecks, enabling faster response times and improved user experience. IT departments can deploy these drives in a variety of configurations, optimizing performance across multiple server platforms and storage arrays.

Compatibility with HPE ProLiant Servers

The HPE P19947-X21 Solid State Drive is fully compatible with a wide range of HPE ProLiant servers, offering seamless integration and simplified deployment. Its compact form factor and standard SATA interface make it suitable for Small Form Factor (SFF) and rack-mounted systems. This compatibility ensures that organizations can easily scale storage capacity without significant changes to their existing infrastructure. IT teams benefit from reduced complexity and improved efficiency in managing server storage resources.

Scalable Storage Solutions

Organizations requiring scalable storage solutions will find the HPE P19947-X21 particularly advantageous. The 480GB capacity serves as a flexible building block for larger storage arrays, allowing administrators to create tailored storage configurations to meet specific performance and capacity requirements. The drive’s reliability and consistent performance enable seamless scaling, supporting growing workloads and fluctuating data demands. This scalability ensures that enterprise storage infrastructures remain agile and future-ready.

Data Security and Integrity

Data protection is a crucial consideration for enterprise SSDs, and the HPE P19947-X21 addresses this with advanced security features. The drive supports secure erase functions and firmware-based encryption options, ensuring that sensitive information remains protected throughout its lifecycle. In addition, data integrity is maintained through robust error correction mechanisms and continuous monitoring. These features reduce the risk of data corruption and unauthorized access, making the P19947-X21 suitable for industries with stringent compliance requirements.

Integration with HPE Storage Ecosystems

HPE P19947-X21 SSDs are fully integrated with HPE’s storage ecosystems, including HPE Smart Array controllers and HPE storage management software. This integration provides administrators with real-time monitoring, predictive analytics, and simplified drive management. Features like health monitoring, performance tracking, and proactive maintenance alerts help reduce downtime and enhance overall storage reliability. By using the P19947-X21 within the HPE ecosystem, organizations can maximize storage efficiency and simplify operational workflows.

Deployment Flexibility

The compact design and standard SATA interface of the HPE P19947-X21 allow for flexible deployment options. It can be installed in small form factor servers, rack-mounted arrays, and hybrid storage configurations. This flexibility enables organizations to tailor storage solutions to meet specific application demands and infrastructure constraints. The drive’s compatibility with existing HPE infrastructure reduces deployment time and complexity, ensuring that enterprises can quickly scale their storage capacity as needed.
