HPE Proliant BL460c G8 2x Intel Xeon E5 2650v2 2.6GHz 64GB DDR3 RAM 741446-S01

Processor

The HPE Proliant Bl460c G8 2 Way Blade Server is equipped with a powerful processor - the 2x Intel Xeon 8 Core E5 2650v2 2.6GHz. This processor is a significant feature of the server, providing users with enhanced performance and capabilities. In this section, we will explore the benefits and importance of this processor in detail.

Product Overview

Discover the HPE Proliant BL460c G8, a powerful 2-way blade server designed for high-performance computing needs. With advanced features and reliable components, this server is optimized for demanding applications and critical workloads.

Main Information of Bl460c

• Manufacturer: Hewlett Packard Enterprise (HPE)
• Part Number: 741446-S01
• Product Name: Proliant BL460c G8 2-way Blade Server S-buy

Processor & Chipset

• Processor Type: Intel Xeon E5-2650v2 at 2.6 GHz
• Number of Cores: 8-core
• 64-bit Computing: Supported
• Installed Quantity: 2
• Maximum Supported Quantity: 2
• Upgradability: Yes, upgradable
• Chipset Type: Intel C600

Cache Memory

• Cache Type: L3 Cache
• Installed Size: 40 MB
• Cache Per Processor: 20 MB

Memory Specifications

• Installed Size: 64 GB
• Maximum Capacity: 512 GB
• Memory Technology: DDR3 SDRAM
• Memory Speed: 1866 MHz
• Compliance: PC3-14900R
• Form Factor: DIMM 240-pin
• Features:
  • Registered
  • Quad Channel Memory Architecture
  • HP Smart Memory
• Configuration: 8 x 8 GB
• Supported RAM Types:
  • PC3-12800 - 512 GB - Registered
  • PC3-10600 - 128 GB - Unbuffered - Advanced ECC

Storage & Controller

• Hard Drive: None
• Optical Drive: None
• Internal Storage:
  • SAS: 2.0 TB
  • SATA: 2.0 TB
  • SAS SSD: 1.6 TB
• Storage Controller:
  • Type: 1 x Serial Attached SCSI 2 Integrated - PCI Express x4
  • Interface: Serial ATA-300 / SAS 2.0
  • Controller Name: Smart Array P220i with 512 MB FBWC
  • RAID Levels: RAID 0, RAID 1
  • Buffer Size: 512 MB

Display & Graphics

• Graphics Controller: Integrated
• Graphics Processor: Matrox G200
• Resolution:
  • 1280 x 1024 (32 Bpp)
  • 1920 x 1200 (16 Bpp)

Network & Communication

• Networking: Network Adapter - PCI Express 2.0 x8 - Integrated
• Ethernet Ports: 2 x 10 Gigabit Ethernet
• Data Link Protocol: Gigabit Ethernet, 10 Gigabit Ethernet
• Remote Management Protocols:
  • SNMP
  • IPMI 2.0
  • SMASH CLP
• Remote Management Controller: Integrated Lights-Out 4
• Additional Features: Wake On LAN (WOL)
• Compliance Standards:
  • IEEE 802.1Q
  • IEEE 802.1P
  • IEEE 802.3X
  • IEEE 802.3AD (LACP)
  • IEEE 802.3AP

Expansion & Connectivity

• Expansion Bays: 2 (total) / 2 (free) x Hot-swap - 2.5in SFF
• Expansion Slots:
  • 2 (total) / 0 (free) x Processor
  • 16 (total) / 8 (free) x Memory - DIMM 240-pin
  • 1 (total) / 1 (free) x Micro SDHC Card
  • 1 (total) / 0 (free) x FlexibleLOM

Interfaces & Ports

• Management Port: 1 x HP iLO - RJ-45
• Network Ports: 2 x Ethernet 10GBASE-KR - RJ-45
• USB Ports: 1 x USB 2.0 (1 Internal)

Dimensions & Weight

• Width: 2.2 in
• Depth: 20.4 in
• Height: 7.1 in
• Weight: 10.5 lbs

Enhanced Performance

The 2x Intel Xeon 8 Core E5 2650v2 2.6GHz processor offers exceptional performance, making it ideal for high-demand computing tasks. With eight cores per processor and a base clock speed of 2.6GHz, this processor delivers impressive processing power that allows for smooth and efficient multitasking. Whether you are running complex applications, virtualizing multiple operating systems, or handling data-intensive workloads, this processor ensures seamless performance.

Increased Speed and Efficiency

The high clock speed of 2.6GHz enables faster data processing and execution of instructions. This means reduced wait times and improved overall system responsiveness. With the ability to handle multiple tasks simultaneously, the processor enhances productivity and efficiency.

Improved Scalability

The HPE Proliant Bl460c G8 2 Way Blade Server's processor supports dual-socket configuration. This enables users to scale their computing power as per their requirements. The two processors work in tandem to handle demanding workloads effectively, ensuring optimal performance even in resource-intensive environments.

Optimized Virtualization

Virtualization has become a crucial aspect of modern IT infrastructure management. The 2x Intel Xeon 8 Core E5 2650v2 2.6GHz processor excels in virtualized environments, allowing for efficient utilization of server resources. With its robust processing capabilities, it can handle multiple virtual machines with ease, enabling organizations to maximize their virtualization investments.

Cache

Another important feature of the HPE Proliant Bl460c G8 2 Way Blade Server is its cache. The server utilizes L3 Cache technology, which plays a significant role in enhancing performance and reducing latency. Let's delve into the benefits and importance of this feature.

Improved Processing Speed

The L3 Cache serves as a high-speed memory buffer between the processor and main memory. It stores frequently accessed data, instructions, and calculations closer to the processor, reducing the time needed to retrieve them from the main memory. This results in faster data access and execution, ultimately improving the overall processing speed of the server.

Reduced Latency

Latency refers to the delay in data retrieval or transmission. By utilizing L3 Cache, the HPE Proliant Bl460c G8 2 Way Blade Server minimizes latency, enabling faster response times. With reduced latency, users experience improved system performance, particularly in tasks that require frequent data access, such as database operations or data analysis.

Better Workload Management

The L3 Cache capacity of the server is designed to handle larger workloads efficiently. With more cache space available, the processor can store and access a greater amount of frequently accessed data. This allows for smoother multitasking and better workload management, improving overall system performance and user experience.

Enhanced Virtualization Performance

Virtualized environments often involve running multiple virtual machines simultaneously. The L3 Cache technology of the HPE Proliant Bl460c G8 2 Way Blade Server ensures that each virtual machine has fast access to its frequently accessed data, reducing contention and improving overall virtualization performance. This enables organizations to achieve higher consolidation ratios and optimize their server resources.

Memory

The HPE Proliant Bl460c G8 2 Way Blade Server is equipped with 64GB DDR3 RAM, providing users with ample memory capacity to handle demanding workloads efficiently. In this section, we will explore the benefits and importance of this memory configuration.

Enhanced Performance and Responsiveness

With 64GB of DDR3 RAM, the server can accommodate large amounts of data, instructions, and processes in its memory. This allows for faster data access and retrieval, resulting in improved system performance and responsiveness. Whether you are running memory-intensive applications or handling multiple virtual machines, the ample memory capacity ensures smooth operation without slowdowns or bottlenecks.

Efficient Multitasking

The generous memory capacity of the HPE Proliant Bl460c G8 2 Way Blade Server enables efficient multitasking. With more RAM available, the server can store and access a larger number of active processes simultaneously. This means that users can run multiple applications or virtual machines without experiencing performance degradation or resource contention.

Scalability and Future-Proofing

The 64GB DDR3 RAM configuration provides room for scalability and future expansion. As your business grows or your workload requirements increase, you can easily upgrade the server's memory capacity to meet the new demands. This ensures that your investment in the HPE Proliant Bl460c G8 2 Way Blade Server remains relevant and capable of handling evolving computing needs.

Optimized Virtualization Performance

Virtualized environments heavily rely on RAM to allocate memory resources to virtual machines. The substantial memory capacity of the server allows for efficient provisioning of resources to virtual machines, ensuring optimal performance in virtualized workloads. Whether you are running a few virtual machines or implementing a large-scale virtualization infrastructure, the server's memory configuration can handle the task effectively.

Networking

The HPE Proliant Bl460c G8 2 Way Blade Server comes equipped with 2x10 Gigabit Ethernet, providing users with high-speed networking capabilities. In this section, we will explore the benefits and importance of this networking feature.

Fast and Reliable Connectivity

The 2x10 Gigabit Ethernet ports of the server deliver lightning-fast network connectivity. With speeds of up to 10 gigabits per second, users can transfer data quickly and efficiently, reducing network latency and bottlenecks. Whether you are accessing shared files, transferring large datasets, or running bandwidth-intensive applications, the high-speed networking ensures responsive and reliable connectivity.

Optimized Data Transfer

The increased bandwidth offered by the 2x10 Gigabit Ethernet ports allows for optimized data transfer between the server and other network devices. This is particularly beneficial in scenarios where large volumes of data need to be transferred, such as backup and restore operations or data replication. By minimizing transfer times, users can save valuable time and resources.

Improved Virtualization Performance

Virtualized environments heavily rely on networking for communication between virtual machines, host systems, and external networks. The 2x10 Gigabit Ethernet ports enable fast and efficient data transmission between virtual machines, ensuring smooth operation and optimal performance. This is especially important in scenarios where virtual machines need to communicate with each other intensively or handle high volumes of network traffic.

Enhanced Network Security

In addition to speed and performance benefits, the 2x10 Gigabit Ethernet ports provide enhanced network security capabilities. The increased bandwidth allows for efficient implementation of security measures such as intrusion detection systems, firewalls, and virtual private networks (VPNs). With robust network security in place, users can ensure the confidentiality, integrity, and availability of their data and applications.

In summary, the HPE Proliant Bl460c G8 2 Way Blade Server offers a powerful 2x Intel Xeon 8 Core E5 2650v2 2.6GHz processor, L3 Cache technology, 64GB DDR3 RAM, and 2x10 Gigabit Ethernet ports. These features provide users with enhanced performance, improved multitasking capabilities, efficient resource utilization, and fast networking options. Whether you are running resource-intensive applications or managing virtualized environments, this server is designed to meet your computing needs effectively.
