HPE Proliant DL360 519566-005 2.53 GHz DDR3 SDRAM Rack Server

Processor Speed: 2.53 GHz

When it comes to choosing a rack server for your business, one of the most crucial factors to consider is the processor speed. The HPE Proliant DL360 Rack Server boasts an impressive processor speed of 2.53 GHz, making it an ideal choice for businesses that require high-performance computing.

General Details of DDR3 SDRAM

• Manufacturer: Hewlett Packard Enterprise
• Part Number: 519566-005
• Product Name: Proliant Dl360 G6 - 2-Way 1U Rack Server (Smart Buy Model)

CPU Specifications

• Processor: Intel Xeon E5540 with 2.53 GHz base clock
• Maximum Turbo Frequency: 2.8 GHz
• Core Count: Quad-core
• 64-bit Architecture: Yes
• Number of CPUs: 2 (upgradable)
• Chipset: Intel 5520
• Front Side Bus: 1066 MHz

Cache Memory

• Cache Type: L3 Cache
• Cache Size: 16 MB total (8 MB per processor)

Memory Specifications

• Installed RAM: 8 GB, expandable up to 192 GB
• Memory Technology: DDR3 SDRAM
• Effective Memory Speed: 1333 MHz
• Memory Form Factor: DIMM 240-pin
• Total Memory Slots: 18 (16 available)
• Memory Features: Registered
• Typical Configuration: 2 x 4 GB

Storage Features

• Hard Drive: Not included
• Optical Drive: DVD-ROM with SATA interface
• Storage Controller: RAID plug-in card (PCIe x4)
• Controller Type: SATA 1.5 Gb/s / SAS
• Controller Model: Smart Array P410i with 512 MB BBWC
• Supported RAID Levels: 0, 1, 5, 10, 50
• Buffer Size: 512 MB

Display & Graphics

• Graphics Type: Integrated
• Graphics Processor: ATI ES1000
• Video Memory: 32 MB
• Video Interface: VGA

Network & Communication

• Network Type: Integrated
• Ethernet Ports: 2 x Gigabit Ethernet
• Ethernet Controller: HP NC382i
• Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management: Integrated Lights-Out 2 (iLO 2) Standard
• Additional Features: Wake On LAN (WOL), ACPI Support
• Compliance Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad (LACP)

Expansion Connectivity

• External Bays: 1 x 5.25" Slim Line (occupied), 4 x Hot-swap 2.5" SFF (available)

Expansion Slots

• CPU Slots: 2 (occupied)
• DIMM Slots: 18 (16 available)
• PCIe Slots: 1 x PCIe x8 (low-profile, occupied), 1 x PCIe x16 (full-length, available)

Interfaces & Ports

• PS/2 Ports: 1 x Keyboard, 1 x Mouse
• Serial Port: 1 x Serial
• VGA Port: 1 x VGA
• LAN Ports: 2 x Gigabit Ethernet
• HP iLO Port: 1 x HP iLO

Miscellaneous Features

• Security Features: Administrator Password, Power-on Password, Keyboard Password, Disk Configuration Lock, Diskette I/O Control, Serial Port I/O Control, Quicklock
• Compliance Standard: ACPI 1.0b

Manufacturer's Selling Program

• Program: HP Smart Buy

Power Description

• Device Type: Hot-plug Power Supply
• Redundancy: Yes, 1+1 scheme
• Installed Quantity: 2
• Max Supported Quantity: 2
• Required Voltage: AC 120/230 V (50/60 Hz)
• Power Provided: 460 Watt

Dimensions & Weight

• Width: 16.8 inches
• Depth: 27.2 inches
• Height: 1.7 inches
• Weight: 32 lbs

Unleash Productivity

With a processor speed of 2.53 GHz, the HPE Proliant DL360 Rack Server can handle demanding workloads with ease. Whether you're running resource-intensive applications or performing complex data analysis, this server's powerful processing capabilities ensure that your tasks are completed quickly and efficiently.

Enhanced Performance

The 2.53 GHz processor speed of the HPE Proliant DL360 Rack Server delivers exceptional performance, allowing you to maximize productivity and streamline your operations. With faster processing speeds, you can handle more concurrent users, process larger datasets, and run multiple applications simultaneously without experiencing any lag or performance issues.

Optimized Workflows

In today's fast-paced business environment, every second counts. The HPE Proliant DL360 Rack Server's 2.53 GHz processor speed enables you to optimize your workflows by reducing processing times and minimizing delays. This means that your employees can work more efficiently, resulting in improved productivity and better overall business outcomes.

Seamless Scalability

As your business grows, so do its computational demands. The HPE Proliant DL360 Rack Server's 2.53 GHz processor speed ensures that your server can handle increasing workloads without compromising performance. Whether you need to add more users, expand your applications, or process larger datasets, this server's processing power can scale alongside your business needs.

Reduced Downtime

Downtime can have a significant impact on your business, leading to lost productivity, missed opportunities, and dissatisfied customers. The 2.53 GHz processor speed of the HPE Proliant DL360 Rack Server helps minimize downtime by ensuring that your server can handle peak workloads without slowing down or crashing. This means that your critical applications and services remain accessible and operational, keeping your business running smoothly.

Memory Technology: DDR3 SDRAM

The HPE Proliant DL360 Rack Server is equipped with cutting-edge DDR3 SDRAM memory technology, providing users with unparalleled memory performance and reliability. This feature plays a crucial role in enhancing the overall functionality and efficiency of the server.

Lightning-Fast Data Access

DDR3 SDRAM offers significantly faster data access speeds compared to its predecessors, enabling the HPE Proliant DL360 Rack Server to retrieve and process information swiftly. This ensures that your applications and databases can operate at peak performance, effectively reducing latency and improving response times.

Improved Multitasking

Multitasking is an essential aspect of modern business operations. The DDR3 SDRAM memory technology in the HPE Proliant DL360 Rack Server provides the necessary bandwidth to support multiple applications running concurrently without compromising performance. This capability allows your employees to work seamlessly across different programs, increasing their productivity and efficiency.

Enhanced System Stability

System stability is crucial for businesses as it directly impacts data integrity and reliability. DDR3 SDRAM offers improved error correction capabilities compared to previous memory technologies, reducing the risk of data corruption or system crashes. This ensures that your critical business data remains intact, preventing potential loss or disruption.

Energy Efficiency

The DDR3 SDRAM memory technology utilized in the HPE Proliant DL360 Rack Server is designed to consume less power, contributing to energy efficiency and cost savings. This feature not only benefits the environment but also helps lower your electricity bills, making it a sustainable and cost-effective choice for your business.

Scalability and Future-Proofing

The HPE Proliant DL360 Rack Server's DDR3 SDRAM memory technology allows for easy scalability, ensuring that your server can accommodate future memory requirements as your business grows. With the ability to expand your server's memory capacity, you can adapt to evolving business needs without investing in additional hardware.

Seamless Compatibility

The part number, 519566-005, is a unique identifier that ensures seamless compatibility with the HPE Proliant DL360 Rack Server and its associated components. It plays a vital role in simplifying the procurement process and ensuring that you receive the correct parts for your server.

Easier Maintenance and Upgrades

By using the specific part number, 519566-005, you can easily identify and procure the exact components needed for maintenance or upgrades. This eliminates any guesswork or ambiguity and helps streamline the process, saving valuable time and effort.

Optimal Performance

Using the correct part number guarantees that you are utilizing components that are specifically designed and tested for compatibility with the HPE Proliant DL360 Rack Server. This ensures optimal performance and reliability, allowing you to leverage the full capabilities of your server without any compromises.

Warranty Validation

The part number, 519566-005, is often associated with a specific warranty period offered by HPE. By using this part number, you can easily validate your warranty and ensure that you receive the appropriate support and service from the manufacturer. This gives you peace of mind, knowing that your investment in the HPE Proliant DL360 Rack Server is protected.

Efficient Troubleshooting

In the event of any technical issues or troubleshooting requirements, having the correct part number, such as 519566-005, helps expedite the process. It allows support technicians to quickly identify the server model and its associated components, facilitating faster and more accurate troubleshooting, minimizing downtime, and ensuring prompt resolution.

Standardization and Documentation

The part number acts as a standardized reference across various documentation and support materials provided by HPE. This simplifies the process of finding relevant information, such as user manuals, technical specifications, or firmware updates, specific to your HPE Proliant DL360 Rack Server configuration. Having a consistent part number ensures that you can easily access the necessary resources to optimize your server's performance.

In conclusion, the HPE Proliant DL360 Rack Server offers impressive features that cater to the needs of modern businesses. With its 2.53 GHz processor speed, users can enjoy enhanced productivity, seamless scalability, and reduced downtime. The DDR3 SDRAM memory technology provides lightning-fast data access, improved multitasking capabilities, and increased system stability. Additionally, part number 519566-005 ensures seamless compatibility, easier maintenance and upgrades, warranty validation, efficient troubleshooting, and standardized documentation. By harnessing these features, businesses can maximize their server's performance and drive success in today's competitive landscape.
