HPE Proliant DL360 Gen10 NC 8SFF 800W RPS P19772-B21 Server

Sku: P19772-B21

The HPE Proliant DL360 Gen10 Server is equipped with the P19772-B21 SKU, which offers a range of benefits and features that are essential for users looking for a powerful and reliable server solution. This SKU is specifically designed to meet the demands of modern businesses, providing them with the performance and scalability they need to efficiently run their operations.

General Information

• Manufacturer: Hewlett Packard Enterprise
• Part Number: P19772-B21
• Model Name: Proliant DL360 Gen10 - 1U Rack-Mountable Server (NC Model)

Processor and Chipset

• CPU: 2nd Gen Intel Xeon Gold 6248, 2.5 GHz
• Max Turbo Speed: 3.9 GHz
• Number of Cores: 20-core
• Quantity of CPUs: 2
• CPU Upgradability: Yes
• Main Features: Hyper-Threading, Intel Turbo Boost Technology 2.0
• CPU Socket: FCLGA3647
• Chipset Type: Intel C621

Cache Memory

• Installed Size: L3 Cache - 55 MB
• Cache Per Processor: 27.5 MB

Memory Specifications

• Installed Size: 64 GB (expandable to 768 GB)
• Memory Technology: DDR4 SDRAM - Advanced ECC
• Effective Memory Speed: 2933 MHz
• Form Factor: DIMM 288-pin
• Memory Slots: 12 total (10 empty)
• Configuration: 2 x 32 GB
• Supported RAM: PC4-20800 (768 GB Registered, 3 TB Load-reduced, 192 GB Non-volatile)

Storage Configuration

• Hard Drive: Not included
• Optical Drive: Not included

Storage Controllers

• Type: RAID
• Controller Interface: SATA 6 Gb/s, SAS 12 Gb/s
• Controller Model: HPE Smart Array P408i-a
• Channels: 8
• RAID Levels: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM
• Buffer Size: 2 GB

Display and Graphics

• Video Memory: 16 MB
• Video Interfaces: VGA

Networking and Communication

• Ethernet Ports: 2 x 10/25 Gigabit Ethernet SFP28
• Ethernet Controller: HPE 640FLR
• Data Link Protocols: Gigabit Ethernet, 10 Gigabit Ethernet, 25 Gigabit Ethernet
• Remote Management Protocols: SNMP v3, IPMI 2.0, SMASH CLP
• Remote Management Controller: Integrated Lights-Out 5 (iLO 5)
• Additional Features: Wake on LAN (WoL), PXE Support

Expansion and Connectivity

• Bays:
  • 1 x External Universal Media Bay (free)
  • 8 x Hot-Swap 2.5 SFF (all free)
• Slots:
  • 1 x PCIe 3.0 x16 (Three-quarter-length, Full-height)
  • 1 x PCIe 3.0 x8 (Low-profile)
  • 1 x FlexibleLOM (Three-quarter-length, Full-height)
  • 1 x MicroSD Card (internal)
  • 1 x PCIe x16 (Full-height)
• Interfaces:
  • 1 x HPE iLO - Type A (front)
  • 1 x HPE iLO - RJ-45 (rear)
  • 5 x USB 3.0 (1 front, 2 rear, 2 internal)
  • 1 x VGA (rear)
  • 2 x LAN (Gigabit Ethernet, rear)

Additional Information

• Compliance Standards: AES, FIPS 140-2, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1

Power Specifications

• Power Supply Type: Hot-plug
• Power Redundancy: Optional (1+1 with additional power supply)
• Installed Quantity: 2
• Nominal Voltage: AC 120/230 V (50/60 Hz)
• Power Output: 800 Watts
• 80 Plus Certification: 80 Plus Platinum

Dimensions and Weight

• Width: 17.1 inches
• Depth: 27.8 inches
• Height: 1.7 inches
• Weight: 28.75 lbs

Enhanced Performance

One of the key advantages of the P19772-B21 SKU is its ability to deliver enhanced performance. With a powerful processor and ample memory capacity, this server can handle heavy workloads and demanding applications with ease. Whether you're running complex databases or virtualized environments, this SKU ensures that your server can keep up with your business needs.

Increased Productivity

The P19772-B21 SKU also helps improve productivity by reducing downtime and minimizing system disruptions. With its robust hardware components and advanced management features, this server can provide high availability and reliability. This means that your employees can work without interruptions, leading to increased productivity and efficiency in your organization.

Scalability for Future Growth

Another significant benefit of the P19772-B21 SKU is its scalability. As your business expands and your needs evolve, this server can easily accommodate your growing requirements. With support for additional memory, storage, and expansion options, you can future-proof your infrastructure and ensure that your server can scale alongside your business.

Optimized Energy Efficiency

The P19772-B21 SKU is designed to be energy-efficient, helping you reduce your carbon footprint and lower operating costs. With advanced power management technologies, this server intelligently adjusts power consumption based on workload demands, ensuring that energy is used efficiently without compromising performance. This not only benefits the environment but also saves you money on electricity bills.

Form Factor: Rack-mountable

The HPE Proliant DL360 Gen10 Server is a rack-mountable server, offering several advantages and benefits for users who require a server solution that can be easily integrated into their existing IT infrastructure.

Optimal Space Utilization

With its rack-mountable design, the DL360 Gen10 server allows for efficient use of space in your data center or server room. By mounting the server in a standard rack, you can maximize the available floor space, allowing for better organization and easier management of your IT infrastructure. This is particularly advantageous for businesses with limited space or those looking to optimize their data center layout.

Easier Maintenance and Serviceability

The rack-mountable form factor of the DL360 Gen10 server simplifies maintenance and serviceability. With the server mounted in a rack, it becomes easier to access and manage components, reducing downtime associated with hardware upgrades or repairs. This saves valuable time and effort, allowing your IT team to focus on more critical tasks rather than struggling with cumbersome server configurations.

Improved Airflow and Cooling

Rack-mountable servers like the DL360 Gen10 benefit from improved airflow and cooling mechanisms. The design of the rack allows for efficient airflow management, ensuring that hot air is effectively expelled from the server and cool air is drawn in. This helps prevent overheating and ensures optimal performance and reliability of the server components, increasing their lifespan.

Scalability and Flexibility

The rack-mountable form factor offers scalability and flexibility for businesses that anticipate future growth or changes in their IT infrastructure. With a rack-mounted server, it becomes easier to add or remove servers as needed, allowing for seamless expansion or reconfiguration. This ensures that your IT infrastructure can adapt to your evolving business requirements without significant disruptions or costly infrastructure overhauls.

Drive Bays: 8

The HPE Proliant DL360 Gen10 Server comes equipped with 8 drive bays, providing users with ample storage capacity and flexibility to meet their data storage needs.

Increased Storage Capacity

The 8 drive bays in the DL360 Gen10 server allow for a significant amount of storage capacity, offering users the ability to store large amounts of data and run applications that require extensive storage. This is particularly beneficial for businesses dealing with data-intensive workloads, such as databases, virtualization, and multimedia content.

Enhanced Data Redundancy

With 8 drive bays, users can configure their storage in various RAID configurations to achieve enhanced data redundancy. RAID (Redundant Array of Independent Disks) allows for data to be distributed across multiple drives, providing redundancy and protection against drive failures. This ensures that your data remains accessible and intact even if one or more drives fail, minimizing the risk of data loss and downtime.

Flexibility for Storage Expansion

The 8 drive bays offer flexibility for storage expansion as your business grows or your storage needs change. You can easily add more drives to the server to increase its storage capacity without the need for significant hardware modifications or disruptions to your operations. This scalability allows you to adapt your storage infrastructure to meet the evolving demands of your business.

Efficient Data Management

Having 8 drive bays enables efficient data management practices. With multiple drive bays, you can segregate data based on its importance, usage patterns, or security requirements. This allows you to optimize data access and retrieval, ensuring that critical data is readily available while less frequently accessed data can be stored on less expensive, slower drives. Efficient data management leads to improved system performance and streamlined operations.

Power Supply: 800W RPS

The HPE Proliant DL360 Gen10 Server is equipped with an 800W Redundant Power Supply (RPS), offering users a reliable and efficient power solution to support their server infrastructure.

High Availability and Redundancy

The 800W RPS provides high availability and redundancy by offering a redundant power supply configuration. In the event of a power supply failure, the redundant power supply automatically takes over, ensuring uninterrupted power to the server. This redundancy minimizes downtime and ensures that your server remains operational even in the face of power supply failures, increasing the reliability and availability of your server infrastructure.

Efficient Power Management

The 800W RPS is designed for efficient power management, helping you optimize energy consumption and reduce operating costs. With advanced power management features, the power supply adjusts power output based on the server's workload demands, minimizing energy waste and improving overall energy efficiency. This not only reduces your carbon footprint but also lowers your electricity bills, leading to cost savings in the long run.

Scalability and Flexibility

The 800W RPS offers scalability and flexibility for businesses with evolving power requirements. As your server infrastructure grows or changes, you can easily add additional power supplies to meet increased power demands without having to replace the existing power supply units. This scalability ensures that your server infrastructure can adapt to your business needs without significant disruptions or costly upgrades.

Improved System Stability

The 800W RPS enhances system stability by providing a consistent and reliable power supply to the server components. A stable power supply is essential for the proper functioning of the server, as fluctuations or interruptions in power can lead to system crashes, data corruption, or hardware failures. By ensuring a stable power supply, the 800W RPS helps maintain the performance and longevity of your server infrastructure.
