HPE Proliant DL360 Gen10 Server Silver 4116 874458-S01

Processor

The HPE Proliant DL360 Server Gen10 is powered by an impressive Silver 4116 processor with a clock speed of 2.1 GHz. This processor is equipped with 12 cores, providing exceptional performance and reliability for any business or organization.

General Details of Gen10 Intel

• Manufacturer: Hewlett Packard Enterprise
• Part Number: 874458-S01
• Product Name: Proliant DL360 Gen10 - 1U Rack Mountable Server (Smart Buy Model)

Processor & Chipset

• Processor: 1st Gen Intel Xeon Silver 4116 / 2.1 GHz
• Maximum Turbo Speed: 3.0 GHz
• Number of Cores: 12-core
• CPU Quantity: 1
• Maximum CPU Quantity: 2
• CPU Upgradability: Yes

Processor Features

• Hyper-Threading Technology
• Intel Turbo Boost Technology 2

Chipset Details

• Chipset Type: Intel C621

Cache Memory

• Installed Cache Size: 16.5 MB L3 Cache
• Cache Per Processor: 16.5 MB

Memory Configuration

• Installed Size: 32 GB / 768 GB (maximum)
• Memory Technology: DDR4 SDRAM - Advanced ECC
• Effective Memory Speed: 2400 MHz
• Rated Memory Speed: 2666 MHz
• Memory Specification Compliance: PC4-20800
• Form Factor: DIMM 288-pin
• Slots: 12 total / 10 empty

Memory Features

• Registered, Dual Rank
• HPE SmartMemory
• 6-Channel Memory Architecture

Supported RAM Configurations

• PC4-20800 - 768 GB Registered
• PC4-20800 - 3 TB Load-Reduced
• PC4-20800 - 192 GB Non-Volatile

Storage

• Hard Drive: None
• Optical Drive: None

Storage Controllers

• Controller Type: 1 x RAID
• Interface Type: SATA 6 Gb/s / SAS 12 Gb/s
• Controller Name: HPE Smart Array P408i-a
• Channel Quantity: 8
• RAID Levels Supported: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM
• Buffer Size: 2 GB

Display & Graphics

• Video Memory: 16 MB
• Video Interface: VGA

Network & Communication

• Ethernet Ports: 4 x Gigabit Ethernet
• Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet

Remote Management

• Remote Management Protocols: SNMP 3, IPMI 2.0, SMASH CLP
• Remote Management Controller: Integrated Lights-Out 5
• Features: Wake On LAN (WOL), PXE Support

Expansion & Connectivity

• External: 1 total / 1 free
• Hot-Swap 2.5 SFF: 8 total / 8 free

Slots

• FlexibleLOM - Three-Quarter-Length, Full-Height (Low-Profile): 1 total / 1 free
• PCIe 3.0 x16 - Full-Height: 1 total / 1 free
• PCIe 3.0 x8 (Low-Profile): 1 total / 1 free
• MicroSD Card (Internal): 1 total / 1 free
• CPU: 2 total / 2 free
• DIMM 288-pin: 12 total / 10 free

Interfaces

• LAN (Gigabit Ethernet) - RJ-45: 4 rear
• PoweredUSB 3.0: 1 front
• HP iLO - RJ-45: 1 rear
• USB 3.0: 4 (2 rear, 2 internal)
• HP iLO - Type A: 1 front
• SATA-600 / SAS 3.0: 8
• VGA: 1 rear

Miscellaneous

• HP Easy Install Rail Kit
• CPU Standard Heatsink
• 5 Standard Hot Plug Fans

Cables Included

• Power Cable

Compliance Standards

• AES
• FIPS 140-2
• IPv6 Ready
• PCI DSS
• TLS v1.2
• ASHRAE Class A4
• ASHRAE Class A3
• WEEE 2002/95/EC
• ACPI 6.1

Manufacturer Selling Program

• HPE Smart Buy

Power Specifications

• Device Type: Power Supply - Hot-Plug
• Power Redundancy: Optional
• Redundancy Scheme: 1+1 (with Optional Power Supply)
• Installed Quantity: 2
• Maximum Supported Quantity: 2
• Nominal Voltage: AC 120/230 V (50/60 Hz)
• Power Provided: 800 Watts

Dimensions

Enhanced Performance

The Silver 4116 processor delivers enhanced performance capabilities, allowing for faster data processing and improved multitasking abilities. With its 12 cores, this processor can handle complex tasks with ease, ensuring smooth operation even under heavy workloads.

Increased Efficiency

The 2.1 GHz clock speed of the Silver 4116 processor ensures efficient operation, allowing for quick response times and reduced lag. This is particularly beneficial for businesses that rely on real-time data processing or require fast computing power to meet demanding deadlines.

Improved Scalability

The HPE Proliant DL360 Server Gen10's processor comes with advanced scalability features, making it an ideal choice for businesses that anticipate future growth or expansion. The 12 cores provide ample room for additional workload demands, ensuring that the server can handle increased processing requirements as the business evolves.

Enhanced Security

The Silver 4116 processor offers enhanced security features to protect sensitive data and prevent unauthorized access. These security measures are crucial for businesses that handle confidential information or operate in industries with strict compliance requirements.

Reliability and Durability

The HPE Proliant DL360 Server Gen10's processor is built to last, with a robust design that ensures long-term reliability. This durability is essential for businesses that rely on continuous server operation and cannot afford unexpected downtime.

Power

The HPE Proliant DL360 Server Gen10 is equipped with a powerful power supply unit featuring 2X800 watts capacity. This high wattage ensures the server can handle demanding workloads while maintaining optimal performance.

High Performance

The 2X800-watt power supply provides ample power to support the server's hardware components, ensuring consistent and reliable performance. This is particularly beneficial for resource-intensive applications or businesses that require a high level of computational power.

Redundancy and Fault Tolerance

The dual 800-watt power supply units offer redundancy and fault tolerance, minimizing the risk of downtime due to power failures. In the event of one power supply failing, the other can seamlessly take over, ensuring uninterrupted operation and protecting critical data.

Energy Efficiency

Despite its high wattage, the HPE Proliant DL360 Server Gen10's power supply features advanced energy-efficient technologies. This helps minimize energy consumption, resulting in lower electricity bills and reduced environmental impact.

Scalability

The 2X800-watt power supply allows for easy scalability, accommodating future expansion or upgrades. As businesses grow, their server requirements may increase, and having a power supply capable of handling additional hardware ensures a smooth transition without the need for significant infrastructure changes.

Noise Reduction

The HPE Proliant DL360 Server Gen10's power supply is designed to minimize noise levels, creating a quieter working environment. This is particularly important for businesses that require a calm and focused atmosphere, such as offices or data centers.

Part Number

The HPE Proliant DL360 Server Gen10 has a unique part number - 874458-S01. This alphanumeric code serves as an identifier for this specific server model and plays a crucial role in procurement and support processes.

Streamlined Procurement

The part number simplifies the procurement process by eliminating any ambiguity when purchasing the HPE Proliant DL360 Server Gen10. With the part number, businesses can ensure they are acquiring the correct model, avoiding any compatibility issues or unnecessary delays.

Efficient Support and Maintenance

Having a unique part number enables businesses to easily communicate with support teams or service providers when seeking assistance or scheduling maintenance for their HPE Proliant DL360 Server Gen10. This streamlined communication ensures efficient troubleshooting and timely resolutions, minimizing any potential downtime.

Accurate Inventory Management

The part number is essential for accurate inventory management. Businesses can easily track the number of HPE Proliant DL360 Server Gen10 units they own, ensuring they have adequate stock to meet their operational requirements. This helps prevent any shortages or overstocking situations that could impact business operations.

Compatibility Verification

The part number also aids in compatibility verification when businesses need to add or replace components within the HPE Proliant DL360 Server Gen10. By referencing the part number, compatibility can be verified, ensuring seamless integration without any compatibility issues.

Product Differentiation

The part number distinguishes the HPE Proliant DL360 Server Gen10 from other server models, allowing businesses to easily identify and differentiate it within their IT infrastructure. This clear identification simplifies management and maintenance tasks, ensuring the correct server model is addressed when necessary.
