HPE ProLiant DL360p G8 1U Rack Server 670635-S01
- — Free Ground Shipping
- — Min. 6-month Replacement Warranty
- — Genuine/Authentic Products
- — Easy Return and Exchange
- — Different Payment Methods
- — Best Price
- — We Guarantee Price Matching
- — Tax-Exempt Facilities
- — 24/7 Live Chat, Phone Support
- — Visa, MasterCard, Discover, and Amex
- — JCB, Diners Club, UnionPay
- — PayPal, ACH/Wire Transfer
- — Apple Pay, Amazon Pay, Google Pay
- — Buy Now, Pay Later - Affirm, Afterpay
- — GOV/EDU/Institutions PO's Accepted
- — Invoices
- — Deliver Anywhere
- — Express Delivery in the USA and Worldwide
- — Ship to -APO -FPO
- — For USA - Free Ground Shipping
- — Worldwide - from $30
Same product also available in:
SKU/MPN | Warranty | Price | Condition | You save |
---|---|---|---|---|
670635-S01 | Six-Month (180 Days) | $1,370.00 | Factory-Sealed New in Original Box (FSB) | You save: $433.80 (24%) |
670635-S01 | Six-Month (180 Days) | $575.00 | Excellent Refurbished | You save: $506.75 (47%) |
Processor
The HPE ProLiant DL360p G8 Rack Server is equipped with a powerful processor - the 2 x Intel Xeon E5-2660 2.20GHz. This processor is one of the key features that make this server a top choice for businesses and organizations in need of high-performance computing.
General Information
- Manufacturer: Hewlett Packard Enterprise
- Manufacturer Part Number: 670635-S01
- Product Name: Proliant DL360p Gen8 - 2-way 1U Rack Server (Smart Buy Model)
Processor & Chipset
Processor Specifications
- Processor Type: Intel Xeon E5-2660 / 2.2 GHz
- Maximum Turbo Speed: 3 GHz
- Number of Cores: 8
- Installed Quantity: 2
- Maximum Supported Quantity: 2
- 64-bit Computing: Yes
- Chipset Type: Intel C600
Main Processor Features
- Hyper-Threading Technology
- Intel QuickPath Interconnect
- Intel Turbo Boost Technology
Cache Memory
- Cache Memory Type: L3 Cache
- Installed Size: 40 MB
- Cache Per Processor: 20 MB
Memory
Installed and Supported Memory
- Installed Size: 32 GB / 384 GB (maximum)
- Memory Technology: DDR3 SDRAM
- Effective Memory Speed: 1333 MHz
- Rated Memory Speed: 1333 MHz
- Memory Specification Compliance: PC3-10600
- Form Factor: DIMM 240-pin
- Total Slots: 24 (20 empty)
Configuration and Compatibility
- Features: Registered, Quad Channel Memory Architecture, HP SmartMemory
- Supported RAM Types: PC3-14900 (Registered, Load-Reduced, Unbuffered), Advanced ECC, Hypercloud
Storage & Optical Storage
- Hard Drive: Not Included
- Optical Drive Type: None
Storage Controller
- Type: 1 x RAID - Integrated - PCIe 3.0 x8
- Controller Interface Type: SATA 6Gb/s / SAS 6Gb/s
- Controller Name: Smart Array P420i with 1GB FBWC
- RAID Levels: 0, 1, 5, 6, 10, 50, 60
- Buffer Size: 1 GB
Display & Graphics Controllers
- Graphics Controller Type: Integrated
- Graphics Processor: Matrox G200
- Video Interfaces: VGA
Network & Communication
- Type: Plug-in Card
- Interface (Bus) Type: PCI Express x4
- Ethernet Ports: 4 x Gigabit Ethernet
- Ethernet Controller: HP 331FLR
- Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
- Remote Management Protocols: IPMI 2.0, SMASH CLP
- Remote Management Controller: Integrated Lights-Out 4
- Features: Wake On LAN (WOL), PXE Support
- Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad (LACP)
Expansions & Connectivity
Expansion Bays
- 1 x External 5.25-inch (free)
- 8 x Hot-swap 2.5-inch SFF (all free)
Expansion Slots
- 24 x DIMM 240-pin (20 free)
- 2 x CPU (none free)
- 1 x PCIe 3.0 x16 - Half-length, Full-height (free)
- 1 x PCIe 3.0 x8 - Low-profile (free)
- 1 x SD Card (internal, free)
Interfaces & Ports
- 1 x Serial
- 1 x VGA
- 4 x LAN (Gigabit Ethernet)
- 1 x HP iLO
- 6 x USB 2.0 (2 Front, 4 Rear)
Miscellaneous
Features
- Administrator Password
- Power-on Password
- Keyboard Password
- Serial Port I/O Control
- Redundant Fans
Compliant Standards
- ACPI 2.0b, FCC Class A Certified
- EN 61000-3-2, EN55022
- ICES-003, EN 61000-3-3
- EN55024, CISPR 22
- FCC CFR47 Part 15
- IEC 60950-1, EN 60950-1
- BSMI CNS 13438
Manufacturer Selling Program
- HP Smart Buy
Power Device
- Device Type: Hot-plug Power Supply
- Power Redundancy: Yes
- Power Redundancy Scheme: 1+1
- Installed Quantity: 2
- Maximum Supported Quantity: 2
- Nominal Voltage: AC 120/230 V (50/60 Hz)
- Power Provided: 460 Watt
- 80 Plus Certification: 80 Plus Gold
- Efficiency: 94%
Dimensions & Weight
- Width: 17.1 inches
- Depth: 27.5 inches
- Height: 1.7 inches
- Weight: 31.99 lbs
Unparalleled Performance
The Intel Xeon E5-2660 2.20GHz processor offers exceptional performance, making it ideal for demanding workloads and resource-intensive applications. With a total of 16 cores and 32 threads, this processor can handle heavy multitasking, allowing users to run multiple applications simultaneously without experiencing any lag or slowdown.
Enhanced Speed and Efficiency
The 2.20GHz clock speed of the Intel Xeon E5-2660 ensures fast data processing, enabling quick execution of tasks and reducing latency. This enhanced speed and efficiency translate into higher productivity and improved workflow for businesses, as operations can be executed swiftly and seamlessly.
Optimized Virtualization
Virtualization has become an essential component in modern IT infrastructure. The Intel Xeon E5-2660 processor is designed to optimize virtualization performance, allowing users to create and manage multiple virtual machines efficiently. This is particularly beneficial for businesses that rely heavily on virtualization technologies, as it enables them to maximize server resources and achieve higher consolidation ratios.
Advanced Security Features
In today's digital landscape, security is paramount. The Intel Xeon E5-2660 processor includes advanced security features that help protect sensitive data from potential threats. These features include Intel Trusted Execution Technology (TXT), which ensures the integrity of the server's platform by measuring and verifying the components during boot-up, and Intel Advanced Encryption Standard New Instructions (AES-NI), which accelerates encryption and decryption processes, enhancing data protection.
Scalability and Future-Proofing
The HPE ProLiant DL360p G8 Rack Server's 2 x Intel Xeon E5-2660 2.20GHz processor offers scalability, allowing businesses to easily expand their computing capabilities as their needs evolve. With the ability to support up to two processors, users can start with a single processor configuration and add another one when required, without the need for significant hardware changes.
Moreover, investing in a server with such a powerful processor ensures future-proofing. As technology advances and applications become more demanding, having a robust processor like the Intel Xeon E5-2660 allows businesses to stay ahead of the curve and handle emerging workloads without the need for immediate hardware upgrades.
Product Number
The HPE ProLiant DL360p G8 Rack Server is identified by its unique product number - 670635-S01. This product number is essential for users as it provides specific information about the server's configuration and helps in identifying and differentiating it from other server models.
Clear Identification
With a vast range of server models available in the market, having a distinct product number like 670635-S01 makes it easier for users to identify the HPE ProLiant DL360p G8 Rack Server. This eliminates any confusion that may arise when looking for this specific model among various options.
Quick Ordering and Replacement
The product number simplifies the ordering process for businesses. By providing the unique identifier 670635-S01, users can easily communicate their requirements to vendors or suppliers, ensuring they receive the correct server model without any ambiguity. Additionally, in case of any hardware failures or the need for component replacement, the product number allows users to quickly identify and order the necessary parts, minimizing downtime.
Technical Support and Documentation
The product number serves as a reference point for technical support and documentation. When seeking assistance or troubleshooting guidance, users can provide the product number to support teams, enabling them to understand the server's specifications and configuration accurately. It also helps in accessing detailed documentation, such as user manuals and technical specifications, specific to the HPE ProLiant DL360p G8 Rack Server model.
Compatibility and Expansion
The product number plays a crucial role in ensuring compatibility and expandability. By referring to the product number 670635-S01, users can verify whether the server supports their desired hardware upgrades or expansion options. This includes compatibility with additional storage drives, memory modules, networking cards, or any other component that may be required to meet evolving business needs. Having a clear product number simplifies the process of identifying compatible components and ensures smooth integration within the existing server infrastructure.
In conclusion, the HPE ProLiant DL360p G8 Rack Server's 2 x Intel Xeon E5-2660 2.20GHz processor and unique product number (670635-S01) are both essential features that contribute to its performance, versatility, and ease of use. The powerful processor provides unparalleled performance, enhanced speed and efficiency, optimized virtualization capabilities, advanced security features, scalability, and future-proofing. On the other hand, the product number ensures clear identification, simplifies ordering and replacement processes, facilitates technical support and documentation access, and enables compatibility and expansion. Together, these features make the HPE ProLiant DL360p G8 Rack Server a reliable choice for businesses seeking a high-performance computing solution.
