HPE Proliant DL380 G6 530779-005 4 Core 2.53GHz DDR3 SDRAM Gigabit Adapter Rack Server

Core

The HPE Proliant DL380 G6 Rack Server is equipped with a powerful 4-core processor, making it a highly capable and efficient server solution for various business needs. The number of cores in a server processor plays a crucial role in its performance and multitasking abilities.

Product Overview of Proliant DL380

Discover the Hewlett Packard Enterprise Proliant DL380 G6, a 2U rack server designed for efficiency and flexibility. This smart buy model, part number 530779-005, provides robust performance and scalability for diverse computing needs.

Processor & Chipset Details

• Processor: Intel Xeon E5540 with 2.53 GHz base clock speed
• Max Turbo Frequency: 2.8 GHz
• Cores: Quad-core architecture
• 64-bit Support: Yes
• CPU Quantity: 2 processors
• Socket Type: LGA1366
• Chipset: Intel 5520

Cache Memory

• Cache Type: L3 Cache
• Total Installed Cache Size: 16 MB
• Cache per Processor: 8 MB

Memory Specifications

• Installed Memory: 8 GB
• Maximum Memory Capacity: 192 GB
• Memory Technology: DDR3 SDRAM with Advanced ECC

Memory Speed and Configuration

• Effective Memory Speed: 1066 MHz
• Rated Memory Speed: 1333 MHz
• Memory Slots: 18 total, 16 available
• Form Factor: DIMM 240-pin
• Configuration: 2 x 4 GB
• Supported RAM: Up to 192 GB Registered - Advanced ECC, 48 GB Unbuffered - Advanced ECC

Storage Capabilities

• Hard Drive: None included
• Optical Drive: DVD-ROM with SATA interface

Storage Controllers

• Controller Type: RAID Plug-in Card (PCIe x8)
• Interface Type: SATA 1.5 Gb/s / SAS
• Controller Model: Smart Array P410i with 512 MB BBWC
• RAID Levels Supported: RAID 0, RAID 1, RAID 5, RAID 10, RAID 50
• Buffer Size: 512 MB

Graphics and Display

• Graphics Type: Integrated
• Graphics Processor: ATI ES1000
• Video Memory: 32 MB
• Video Interfaces: VGA

Network & Communication

• Ethernet Ports: 4 x Gigabit Ethernet
• Ethernet Controller: 2 x HP NC382i
• Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
• Features: Wake On LAN (WOL), ACPI Support
• Compliance Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad (LACP)

Expansion Connectivity Options

• External 5.25" Slim Line Bay: 1 total, 0 available
• Hot-Swap 2.5" SFF Bays: 8 total, 8 available

Expansion Slots

• CPU Slots: 2 total, 0 available
• DIMM Slots: 18 total, 16 available
• PCIe x8 Slots: 2 total, 1 available (Half-length, Full-height, x4 Mode)
• PCIe x16 Slot: 1 total, 1 available (Full-length, Full-height, x8 Mode)

Interfaces Ports

• PS/2 Ports: 1 for keyboard, 1 for mouse
• Serial Port: 1
• VGA Ports: 2 (1 at the front)
• USB Ports: 4 (2 at the front, 2 at the rear)
• LAN Ports: 4 x Gigabit Ethernet
• HP iLO Port: 1

Additional Features

• Security Features: Administrator Password, Power-on Password, Keyboard Password, Disk Configuration Lock, Diskette I/O Control, Parallel Port I/O Control, Serial Port I/O Control, Quicklock
• Compliance Standards: ACPI 2.0
• Manufacturer Selling Program: HP Smart Buy

Power Specifications

• Power Supply Type: Hot-plug
• Power Redundancy: Yes, 1+1 scheme
• Installed Power Supplies: 2
• Maximum Supported Power Supplies: 2
• Nominal Voltage: AC 120/230 V (50/60 Hz)
• Power Provided: 750 Watts

Physical Dimensions

• Height: 3.38 inches
• Width: 17.54 inches
• Depth: 27.25 inches
• Weight: 47.18 pounds

Improved Performance

The 4-core design of the HPE Proliant DL380 G6 Rack Server allows for better performance compared to servers with fewer cores. Each core is capable of executing multiple instructions simultaneously, enabling the server to handle more tasks at once. This results in improved overall performance and faster response times, ensuring that your business applications run smoothly even under heavy loads.

Efficient Multitasking

With 4 cores, the HPE Proliant DL380 G6 Rack Server can efficiently handle multiple tasks simultaneously. This is particularly beneficial for businesses that rely on running multiple applications or virtual machines on a single server. The server can allocate dedicated cores to different tasks, ensuring optimal performance and preventing any slowdowns or bottlenecks.

Scalability and Future-Proofing

Having 4 cores provides scalability and future-proofing for your business. As technology advances and software becomes more demanding, having additional cores allows your server to handle increasing workloads without the need for immediate upgrades. This reduces the cost and hassle of frequent server replacements, providing long-term value for your investment.

Improved Virtualization

Virtualization has become a vital aspect of modern IT infrastructure. With 4 cores, the HPE Proliant DL380 G6 Rack Server can efficiently host multiple virtual machines, allowing businesses to consolidate their hardware and maximize resource utilization. The server's robust processing power ensures smooth virtual machine performance, enabling businesses to leverage the benefits of virtualization without compromising on speed or responsiveness.

Enhanced Data Analysis

Data analysis and processing are essential for businesses to gain insights and make informed decisions. The 4-core processor in the HPE Proliant DL380 G6 Rack Server enables faster data processing, allowing businesses to analyze large datasets more efficiently. This is particularly beneficial for industries such as finance, research, and analytics, where quick data analysis can give businesses a competitive edge.

Speed

The HPE Proliant DL380 G6 Rack Server features a high-speed 2.53GHz processor, providing exceptional performance and responsiveness for various computing tasks. The speed of a server's processor is a critical factor in determining its overall performance and ability to handle complex workloads.

Fast Processing Power

With a 2.53GHz processor, the HPE Proliant DL380 G6 Rack Server offers fast processing power, ensuring quick execution of tasks and reduced waiting times. This speed is especially beneficial for businesses that require real-time data processing or resource-intensive applications. Whether you're running database queries or performing complex calculations, the server's high-speed processor enables efficient and timely results.

Improved User Experience

The speed of the HPE Proliant DL380 G6 Rack Server contributes to an enhanced user experience. Users accessing applications or services hosted on the server will notice improved responsiveness and reduced lag times. This is particularly crucial for businesses with customer-facing applications or websites, as slow response times can lead to customer dissatisfaction and loss of business opportunities.

Efficient Resource Utilization

A server with a fast processor like the HPE Proliant DL380 G6 Rack Server can efficiently utilize system resources. The quick execution of tasks allows for better resource allocation and management, ensuring optimal performance and preventing resource bottlenecks. This efficiency translates into cost savings by maximizing the server's capabilities and minimizing resource wastage.

Reduced Downtime

The fast processing power of the HPE Proliant DL380 G6 Rack Server helps reduce downtime by swiftly handling tasks and preventing performance issues that could lead to system crashes or slowdowns. This is particularly crucial for businesses that rely on continuous operations, such as e-commerce platforms or critical business applications. The server's speed ensures uninterrupted services, minimizing the risk of revenue loss and maintaining a seamless user experience.

Quick Data Transfer

In addition to processing power, the speed of the HPE Proliant DL380 G6 Rack Server's processor also affects data transfer rates. With a 2.53GHz processor, the server can quickly transmit and receive data, improving overall data transfer efficiency. This is especially beneficial for businesses that deal with large file transfers or require quick access to stored data. Quick data transfer speeds enable faster backups, efficient file sharing, and seamless access to critical information.

MemoryType

The HPE Proliant DL380 G6 Rack Server utilizes DDR3 SDRAM memory technology, offering several benefits in terms of performance, reliability, and future upgrade options. The memory type of a server plays a crucial role in its ability to handle data-intensive tasks and support the overall system performance.

Enhanced Performance

DDR3 SDRAM memory technology provides improved performance compared to its predecessors. The HPE Proliant DL380 G6 Rack Server's use of DDR3 SDRAM ensures faster data transfer rates, enabling quicker access to stored information and reducing latency. This enhanced performance is particularly advantageous for businesses that rely on memory-intensive applications or databases, as it allows for smoother and more efficient operations.

Better Multitasking

The DDR3 SDRAM memory in the HPE Proliant DL380 G6 Rack Server enables efficient multitasking capabilities. The server can handle multiple tasks simultaneously without experiencing significant performance degradation. Whether you're running multiple virtual machines, processing large datasets, or hosting resource-intensive applications, the server's memory type ensures optimal performance and minimizes any bottlenecks.

Reliability and Compatibility

DDR3 SDRAM memory technology is known for its reliability and compatibility across a wide range of systems. The HPE Proliant DL380 G6 Rack Server's use of DDR3 SDRAM ensures stable and consistent performance, reducing the risk of memory-related errors or system crashes. Additionally, DDR3 SDRAM is widely supported by various software applications and operating systems, ensuring seamless compatibility and ease of integration.

Future Upgrade Options

The use of DDR3 SDRAM memory in the HPE Proliant DL380 G6 Rack Server offers future upgrade options for businesses. DDR3 SDRAM technology allows for higher memory capacities compared to older memory types, providing scalability and flexibility for growing business needs. This means that as your business expands or requires additional memory resources, you can easily upgrade the server's memory without significant hardware changes or replacements.

Energy Efficiency

DDR3 SDRAM memory technology is designed to be energy-efficient, consuming less power compared to previous generations of memory. The HPE Proliant DL380 G6 Rack Server's use of DDR3 SDRAM helps reduce overall power consumption, resulting in lower energy costs and a smaller environmental footprint. This is particularly important for businesses striving to adopt sustainable practices and reduce their carbon footprint.

NetworkAdapter

The HPE Proliant DL380 G6 Rack Server is equipped with a Gigabit Adapter network interface card (NIC), offering high-speed connectivity and reliable network performance. The network adapter plays a vital role in connecting the server to your network infrastructure and ensuring seamless communication between your server and other devices.

Fast and Reliable Connectivity

The Gigabit Adapter in the HPE Proliant DL380 G6 Rack Server provides fast and reliable connectivity, enabling high-speed data transfer between the server and other devices on the network. With a Gigabit Adapter, you can benefit from network speeds up to 1000 Mbps, allowing for quick file transfers, seamless video streaming, and efficient data sharing. This is particularly important for businesses that rely on network-dependent applications or require fast data access.

Reduced Network Latency

The Gigabit Adapter's high-speed connectivity in the HPE Proliant DL380 G6 Rack Server helps reduce network latency. Latency refers to the delay in transmitting data packets across a network. By minimizing latency, the server can communicate with other devices on the network more quickly and efficiently. This is crucial for real-time applications such as video conferencing or online gaming, where even slight delays can hinder user experience.

Improved Network Performance

The Gigabit Adapter enhances the overall network performance of the HPE Proliant DL380 G6 Rack Server. It allows for better bandwidth utilization and efficient data transmission, resulting in improved network speeds and reduced congestion. This is especially beneficial for businesses with heavy network traffic or those that require uninterrupted access to critical resources.

Scalability and Flexibility

The Gigabit Adapter in the HPE Proliant DL380 G6 Rack Server offers scalability and flexibility for your business's network infrastructure needs. Gigabit Ethernet technology has become a standard in modern networks, ensuring compatibility with various networking equipment and systems. Additionally, the high-speed connectivity provided by the Gigabit Adapter allows for future expansion and increased network capacity without compromising performance.

Secure Data Transfer

The Gigabit Adapter's reliable and high-speed connectivity in the HPE Proliant DL380 G6 Rack Server helps ensure secure data transfer across your network. The server's network adapter supports advanced security features such as encryption and authentication protocols, safeguarding sensitive data from unauthorized access or interception. This is particularly critical for businesses that deal with confidential or personal information, ensuring data integrity and protecting against potential security breaches.
