General Overview of the HPE ProLiant DL380 Gen9 Server
Manufacturer Information
- Manufacturer: Hewlett Packard Enterprise
- Part Number: 800078-S01
- Product Name: ProLiant DL380 Gen9 - 2U Rack Mountable Server
- Category: PC & Servers
Processor Specifications
- Processor Type: Intel Xeon E5-2697v3
- Base Clock Speed: 2.6 GHz
- Max Turbo Speed: 3.6 GHz
- QuickPath Interconnect: 9.60 GT/s
- Number of Cores: 14-core
- 64-bit Support: Yes
- Processor Socket: FCLGA2011-3
- Installed Processors: 2
- Maximum Processors Supported: 2
- Chipset Type: Intel C610 Series
Cache Memory Details
- Cache Type: Smart Cache
- Total Installed Cache: 70 MB
- Cache Per Processor: 35 MB
Memory Specifications
- Installed Memory Size: 64 GB
- Maximum Memory Supported: 768 GB
- Memory Technology: DDR4 SDRAM - Advanced ECC
- Effective Memory Speed: 2133 MHz
- Memory Speed Rating: 2133 MHz
- Compliance: PC4-17000
- Memory Form Factor: DIMM 288-pin
- Memory Slots: 24 total (20 available)
- Features: Registered, Online Spare, Quad Channel, HP SmartMemory
- Configuration Example: 4 x 16 GB
- RAM Support: Up to 768 GB (PC4-17000 Registered), 1.5 TB (Load-reduced)
Storage & Controller Features
- Hard Drive: None
- Optical Drive: None
- Storage Controller: Smart Array P440ar
- Controller Buffer Size: 2 GB
- Disk Drive Support: 12 Gb/s SAS / 6 Gb/s SATA
- SAS Port Link Rate: 12 Gb/s per Physical Link
- PCIe Link Rate: PCI Express 3.0 x8
- Physical Drives Supported: Up to 26
- Logical Drives Supported: Up to 64
- RAID Support: RAID 0, 1, 5, 6, 10, 50, 60, 1 ADM, 10 ADM
Graphics & Display
- Graphics Type: Integrated
- Graphics Processor: Matrox G200eh2
- Video Memory: 16 MB
- Video Interface: VGA
Networking & Communication
- Ethernet Ports: 2 x 10 Gigabit Ethernet, 4 x Gigabit Ethernet
- Ethernet Controller: HP 331i, HP 556FLR-SFP+
- Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
- Remote Management Controller: Integrated Lights-Out 4
- Features: Wake On LAN (WOL), PXE Support
- Compliance Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Expansion & Connectivity Options
- Expansion Bays: 8 x Hot-swap 2.5" SFF (all free)
- Expansion Slots:
- 24 x DIMM 288-pin (20 free)
- 2 x CPU (all free)
- 2 x PCIe 3.0 x16 (half-length, full-height, x8 mode) (2 free)
- 1 x PCIe 3.0 x8 (half-length, full-height) (1 free)
- 1 x MicroSD Card (internal) (1 free)
Interfaces & Ports
- 4 x LAN (Gigabit Ethernet) - RJ-45
- 1 x HP iLO - RJ-45
- 1 x VGA
- 5 x USB 3.0 (1 front, 2 rear, 2 internal)
- 2 x LAN (10 Gigabit Ethernet)
Additional Information
- Included Accessories: HP Easy Install Rails
- Security Features:
- Administrator Password
- Power-on Password
- Keyboard Password
- Serial Port I/O Control
- QuickLock
- BIOS: UEFI
- Compliance Standards:
- ACPI 2.0b
- FCC Class A Certified
- EN 61000-3-2
- EN55022
- ICES-003
- EN 61000-3-3
- EN55024
- CISPR 22
- FCC CFR47 Part 15
- IEC 60950-1
- EN 60950-1
- WEEE
- GB 9254
- ASHRAE
- CNS 13438
- Manufacturer Selling Program: HP Smart Buy
Power Specifications
- Device Type: Power Supply - Hot-plug
- Power Redundancy: Yes
- Redundancy Scheme: 1+1
- Installed Power Supplies: 2
- Maximum Power Supplies Supported: 2
- Nominal Voltage: AC 120/230 V
- Power Provided: 800 Watts
- 80 Plus Certification: 80 Plus Platinum
- Efficiency: 94%
Dimensions & Weight
- Width: 17.5 inches
- Depth: 26.7 inches
- Height: 3.4 inches
- Weight: 32.5 lbs
Processor
The HPE DL380 G9 2u Rack Server is equipped with the powerful Intel Xeon 14-Core processor, making it an exceptional choice for businesses that require high-performance computing capabilities. This processor offers a host of benefits that greatly enhance the server's overall performance and efficiency.
General Information
- Manufacturer: Hewlett Packard Enterprise
- Part Number: 800078-S01
- Product: ProLiant DL380 Gen9 - 2U Rack-Mountable Server (S-buy)
Processor & Chipset
Processor Specifications
- Type: Intel Xeon E5-2697v3
- Base Frequency: 2.6 GHz
- Turbo Boost Frequency: 3.6 GHz
- QuickPath Interconnect: 9.60 GT/s
- Cores: 14-core
- 64-bit Computing: Supported
- Socket: FCLGA2011-3
- Installed Processors: 2
- Maximum Processors: 2
Chipset
- Type: Intel C610 Series
Cache Memory
- Type: Smart Cache
- Installed Size: 70 MB
- Cache per Processor: 35 MB
Memory
Memory Configuration
- Installed Size: 64 GB / Max Supported: 768 GB
- Technology: DDR4 SDRAM - Advanced ECC
- Effective Speed: 2133 MHz
- Memory Specification: PC4-17000
- Form Factor: DIMM 288-pin
- Slots: 24 total / 20 available
Memory Features
- Registered
- Online Spare Memory
- Quad Channel Memory Architecture
- HP SmartMemory
Storage & Storage Controller
Hard Drive
None Installed
Optical Drive
None Installed
Storage Controllers
- Controller: Smart Array P440ar
- Buffer Size: 2 GB
- Disk Drive: 12 Gb/s SAS / 6 Gb/s SATA
- SAS Port Link Rate: 12 Gb/s per physical link
- PCIe Link Rate: PCI Express 3.0 x8
- Physical Drives Supported: Up to 26
- Logical Drives Supported: Up to 64
- RAID Support: RAID 0, 1, 5, 6, 10, 50, 60, 1 ADM, 10 ADM
Display & Graphics Controllers
- Type: Integrated
- Graphics Processor: Matrox G200eh2
- Video Memory: 16 MB
- Video Interface: VGA
Network & Communication
Network Ports
- Ethernet Ports: 2 x 10 Gigabit, 4 x Gigabit Ethernet
Network Controllers
- HP 331i
- HP 556FLR-SFP+
Data Link Protocols
- Supported Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
Remote Management
- Controller: Integrated Lights-Out 4
- Features: Wake On LAN (WoL), PXE Support
- Compliance: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Expansion & Connectivity
Expansion Bays
- 8 x Hot-Swap 2.5 SFF
Expansion Slots
- DIMM Slots: 24 total / 20 available
- CPU Slots: 2 total / 0 available
- PCIe 3.0 x16: 2 total / 2 available
- PCIe 3.0 x8: 1 total / 1 available
- MicroSD Card (Internal): 1 total / 1 available
Interfaces & Ports
- LAN (Gigabit Ethernet) Ports: 4 x RJ-45
- HP iLO Port: 1 x RJ-45
- VGA Port: 1
- USB 3.0 Ports: 5 (1 Front, 2 Rear, 2 Internal)
- LAN (10 Gigabit Ethernet) Ports: 2
Miscellaneous
Included Accessories
- HP Easy Install Rails
Features
- Administrator Password
- Power-On Password
- Keyboard Password
- Serial Port I/O Control
- Quicklock
- UEFI BIOS
Compliant Standards
- ACPI 2.0b
- FCC Class A Certified
- EN 61000-3-2
- EN 55022
- ICES-003
- EN 61000-3-3
- EN 55024
- CISPR 22
- FCC CFR47 Part 15
- IEC 60950-1
- EN 60950-1
- WEEE
- GB 9254
- ASHRAE
- CNS 13438
Manufacturer Selling Program
HP Smart Buy
Power Description
- Type: Hot-Plug Power Supply
- Redundancy: Yes
- Redundancy Scheme: 1+1
- Installed Units: 2
- Maximum Supported Units: 2
- Nominal Voltage: AC 120/230 V
- Power Provided: 800 Watts
- 80 Plus Certification: Platinum
- Efficiency: 94%
Dimensions & Weight
- Width: 17.5 inches
- Depth: 26.7 inches
- Height: 3.4 inches
- Weight: 32.5 lbs
Enhanced Speed and Performance
With 14 cores, the Intel Xeon processor delivers exceptional speed and performance. Each core operates independently, allowing for efficient multitasking and faster data processing. This means that your server can handle multiple tasks simultaneously without experiencing any significant slowdowns.
Improved Productivity
The increased processing power of the Intel Xeon 14-Core processor translates into improved productivity for users. Complex calculations, data analysis, and resource-intensive applications can be executed quickly and efficiently, enabling your team to work more effectively and deliver results faster.
Optimized Virtualization
Virtualization has become a key component of modern server infrastructures, enabling businesses to maximize their resources and reduce costs. The Intel Xeon 14-Core processor is designed to handle virtualization workloads with ease. It supports advanced virtualization technologies, such as Intel Virtualization Technology (VT-x), which enhances the performance, security, and flexibility of virtualized environments.
Reliable Performance
The Intel Xeon 14-Core processor is built using advanced technology, ensuring reliable and stable performance. It is designed to handle heavy workloads without compromising on efficiency or reliability. This means that your server can operate at peak performance even under demanding conditions, providing a consistent user experience for all your business-critical applications.
Lower Power Consumption
Despite its impressive performance capabilities, the Intel Xeon 14-Core processor is designed to be energy-efficient. It incorporates various power-saving features that help reduce power consumption without sacrificing performance. This not only lowers your operational costs but also contributes to a greener and more sustainable IT infrastructure.
Scalability and Future-Proofing
The Intel Xeon 14-Core processor offers excellent scalability, allowing you to easily expand your server's capabilities as your business grows. With its robust architecture and support for advanced technologies, this processor ensures that your server can handle future demands and remain relevant for years to come.
Memory
The HPE DL380 G9 2u Rack Server is equipped with DDR4 SDRAM, a cutting-edge memory technology that offers significant advantages over its predecessors. The inclusion of DDR4 SDRAM in this server enhances its performance, reliability, and overall efficiency.
Higher Bandwidth
DDR4 SDRAM provides a significant increase in bandwidth compared to previous generations of memory technologies. This allows for faster data transfer rates between the processor and memory modules, resulting in improved overall system performance. With higher bandwidth, your server can handle more data-intensive tasks without experiencing bottlenecks or slowdowns.
Improved Data Integrity
DDR4 SDRAM incorporates advanced error correction capabilities, such as Error Correcting Code (ECC). This technology detects and corrects errors in real-time, ensuring that data stored in memory remains accurate and reliable. By minimizing the risk of data corruption or loss, DDR4 SDRAM enhances the stability and integrity of your server's operations.
Enhanced Multitasking
The increased capacity and speed of DDR4 SDRAM enable your server to handle multiple tasks simultaneously, making it ideal for multitasking environments. Whether you're running resource-intensive applications or virtual machines, DDR4 SDRAM ensures smooth performance and responsiveness, even under heavy workloads.
Lower Power Consumption
DDR4 SDRAM operates at lower voltage levels compared to its predecessors, resulting in reduced power consumption. This not only helps lower your energy costs but also contributes to a more environmentally friendly IT infrastructure. The power-saving features of DDR4 SDRAM make it an excellent choice for businesses looking to minimize their environmental impact.
Future-Proofing and Compatibility
DDR4 SDRAM is the latest industry-standard memory technology, ensuring compatibility with newer server platforms and future upgrades. By choosing a server equipped with DDR4 SDRAM, you can future-proof your investment and ensure that your server remains compatible with upcoming technologies and advancements in the memory space.
Reliability and Durability
DDR4 SDRAM is designed to be highly reliable and durable, offering improved resistance to physical and electrical stresses. This ensures that your server's memory modules can withstand demanding operating conditions without encountering failures or errors. With DDR4 SDRAM, you can have confidence in the long-term stability and reliability of your server's memory subsystem.
Sku
The HPE DL380 G9 2u Rack Server comes with the Sku number 800078-S01, which plays a crucial role in identifying the specific model and configuration of the server. Understanding the importance of Sku numbers can help businesses make informed decisions when purchasing servers and managing their IT infrastructure.
Easy Identification and Management
Sku numbers provide a convenient way to identify and manage different server models within an organization. By utilizing unique Sku numbers like 800078-S01, businesses can easily keep track of their servers, ensuring proper inventory management, maintenance, and support.
Accurate Configuration Management
Each Sku number corresponds to a specific server configuration, including hardware components, storage capacity, memory size, and other important specifications. Having accurate Sku numbers simplifies configuration management, making it easier to replicate or expand server setups when needed. This ensures consistency across your server infrastructure and helps streamline IT operations.
Compatibility and Scalability
Sku numbers also play a crucial role in ensuring compatibility and scalability within your server environment. By referring to the Sku number, you can easily identify compatible components, expansion options, and accessories for your server model. This simplifies the process of upgrading or expanding your server's capabilities, allowing you to scale your IT infrastructure without compatibility issues.
Warranty and Support
Sku numbers are often tied to warranty and support agreements provided by the manufacturer. By referencing the specific Sku number like 800078-S01, you can ensure that your server is covered under the appropriate warranty terms, allowing for timely repairs or replacements in case of any hardware failures. This provides peace of mind and protects your investment in the server.
Vendor-Specific Information
In addition to providing general identification and configuration information, Sku numbers may include vendor-specific details that can be useful for businesses. These details may include specific features or enhancements that differentiate a particular server model from others in the same product line. By understanding these vendor-specific details, businesses can make more informed decisions when selecting servers that best meet their unique requirements.
Pricing and Procurement
Sku numbers are closely associated with pricing and procurement processes. They allow businesses to accurately communicate their server requirements to vendors or resellers, ensuring that they receive the correct model with the desired specifications. Sku numbers also aid in price comparison and negotiation, allowing businesses to make cost-effective purchasing decisions.
In conclusion, the Intel Xeon 14-Core processor, DDR4 SDRAM memory, and Sku number 800078-S01 are key features of the HPE DL380 G9 2u Rack Server that offer numerous benefits to users. These features enhance performance, reliability, scalability, and compatibility, ensuring that businesses can meet their computing needs efficiently and effectively. By understanding the importance of these features, businesses can make informed decisions when selecting servers for their IT infrastructure.
