HPE Proliant DL380 Gen10 6132 2 Port 64GB-R 8SFF Server 875765-S01

Port

The HPE Proliant DL380 Gen10 6132 Server has an impressive 2-Port feature. This feature provides users with enhanced connectivity options, making it a standout choice for businesses looking for reliable and efficient server solutions.

General Overview of 875765-S01

The Proliant DL380 Gen10 from Hewlett Packard Enterprise is a robust 2U rack-mountable server designed to meet diverse IT needs. Below, find a comprehensive overview of its features:

Manufacturer Information

• Manufacturer: Hewlett Packard Enterprise
• Manufacturer Part Number: 875765-S01
• Product Name: Proliant DL380 Gen10 - 2U Rack Mountable Server (SMB NC Model)

Processor and Chipset

• CPU: 1st Gen Intel Xeon Gold 6132, 2.6 GHz
• Maximum Turbo Speed: 3.7 GHz
• Cores: 14-core
• Number of CPUs: 2
• Maximum Number of CPUs: 2
• CPU Upgradability: Upgradable
• Main Processor Features: Hyper-Threading Technology, Intel Turbo Boost Technology 2
• CPU Socket: FCLGA3647
• Chipset Type: Intel C621

Cache Memory

• Installed Cache Size: L3 Cache - 38.5 MB
• Cache per Processor: 19.25 MB

Memory Specifications

• Installed Memory: 64 GB / Up to 768 GB
• Memory Technology: DDR4 SDRAM
• Effective Memory Speed: 2666 MHz
• Rated Memory Speed: 2666 MHz
• Memory Compliance: PC4-20800
• Form Factor: DIMM 288-pin
• Memory Slots: 24 (Total) / 20 (Available)
• Memory Features: Registered, Dual Rank, HP SmartMemory, 6-Channel Memory Architecture
• Configuration Example: 4 x 16 GB
• Supported RAM: PC4-20800 - 768 GB Registered, PC4-20800 - 1.5 TB Load-Reduced

Storage Controllers

• Controller Type: RAID
• Controller Interface: SATA 6 Gb/s / SAS 12 Gb/s
• Controller Name: HPE Smart Array P408i-a
• Channels: 8
• RAID Levels: 0, 1, 5, 6, 10, 50, 60, 1 ADM, 10 ADM
• Buffer Size: 2 GB

Graphics Controller

• Video Memory: 16 MB
• Video Interfaces: VGA

Network and Communication

• Ethernet Ports: 4 x Gigabit Ethernet
• Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management Protocols: SNMP 3, IPMI 2.0, SMASH CLP
• Remote Management Controller: Integrated Lights-Out 5
• Features: Wake On LAN (WoL), PXE Support

Expansion and Connectivity

• External Bays: 1 (Total) / 1 (Free)
• Hot-Swap Bays: 8 (Total) / 8 (Free) x 2.5" SFF

Slots

• CPU Slots: 2 (Total) / 0 (Free)
• DIMM Slots: 24 (Total) / 20 (Free) x DIMM 288-pin
• FlexibleLOM Slots: 1 (Total) / 1 (Free)
• PCIe 3.0 x16 Slots: 2 (Total) / 2 (Free) - Half-length, Full-height
• PCIe 3.0 x8 Slots: 4 (Total) / 4 (Free) - Half-length, Full-height
• MicroSD Card Slot: 1 (Total) / 1 (Free)

Interfaces

• LAN Interfaces: 4 x Gigabit Ethernet - RJ-45
• HP iLO Interface: 1 x RJ-45 (Rear)
• VGA Interface: 1 x VGA (Rear)
• SATA/SAS Interfaces: 8 x SATA-600 / SAS 3.0
• HP iLO Type A Interface: 1 (Front)
• USB 3.0 Ports: 5 (1 Front, 2 Rear, 2 Internal)

Miscellaneous

• HPE Easy Install Rails
• 6 x Standard Hot Plug Fans
• High-performance Heatsink

Compliance Standards

• AES
• FIPS 140-2
• IPv6 Ready
• PCI DSS
• TLS v1.2
• ASHRAE Class A4
• ASHRAE Class A3
• WEEE 2002/95/EC
• ACPI 6.1

Manufacturer Selling Program

• HPE Smart Buy

Power Specifications

• Device Type: Power Supply - Hot-plug
• Power Redundancy: Optional
• Redundancy Scheme: 1+1 (with Optional Power Supply)
• Installed Power Supplies: 2
• Maximum Supported Power Supplies: 2
• Nominal Voltage: AC 120/230 V (50/60 Hz)
• Power Provided: 800 Watt
• 80 Plus Certification: 80 Plus Platinum

Dimensions and Weight

• Width: 17.5 inches
• Depth: 26.7 inches
• Height: 3.4 inches
• Weight: 32.85 lbs

Enhanced Connectivity

With the 2-Port feature, the HPE Proliant DL380 Gen10 6132 Server offers users the ability to connect multiple devices simultaneously. This allows for seamless data transfer and efficient communication between various components of your IT infrastructure. Whether you need to connect multiple storage devices, networking equipment, or other peripherals, the server's 2 Port feature ensures smooth data flow and reduces the risk of bottlenecks.

Improved Performance

The 2-Port feature enhances the overall performance of the HPE Proliant DL380 Gen10 6132 Server by providing ample bandwidth for data transmission. This means faster response times, reduced latency, and improved overall system efficiency. Users can expect accelerated data transfer rates, enabling them to complete tasks more quickly and efficiently.

Flexibility in Network Configuration

The 2 Port feature also offers users greater flexibility in network configuration. With multiple ports available, you can easily set up redundant connections or create separate networks for different purposes. This flexibility allows for better load balancing, improved network resilience, and greater scalability as your business grows.

High Availability

The redundancy provided by the 2 Port feature ensures high availability and minimizes the risk of network downtime. In the event of a port failure or connectivity issue, the server can seamlessly switch to the backup port, ensuring uninterrupted operation. This level of reliability is crucial for businesses that rely heavily on their servers to support critical operations and maintain productivity.

Streamlined Data Management

The 2 Port feature simplifies data management by allowing users to allocate specific ports for different tasks or departments within the organization. This segregation of network traffic helps optimize data flow, ensuring that each port is utilized efficiently and that critical processes are given priority. It also facilitates easier troubleshooting and monitoring of network activities.

Future-Proofing

Having a server with a 2-Port feature future-proofs your IT infrastructure to some extent. As technology advances and network requirements evolve, having additional ports ensures that your server can adapt to changing needs without requiring significant hardware upgrades. This scalability and flexibility help protect your investment and save costs in the long run.

Memory

The HPE Proliant DL380 Gen10 6132 Server boasts an impressive 64GB-R memory configuration, making it ideal for resource-intensive applications and demanding workloads. The generous memory capacity provides numerous benefits for users seeking high-performance computing solutions.

Improved System Responsiveness

The 64GB-R memory configuration ensures improved system responsiveness, allowing the server to handle multiple tasks simultaneously without experiencing performance degradation. This is particularly beneficial when running virtual machines, databases, or other memory-intensive applications that require fast access to data. With ample memory, the server can efficiently store and retrieve information, resulting in smoother operations and reduced latency.

Enhanced Multitasking Abilities

With its generous memory capacity, the HPE Proliant DL380 Gen10 6132 Server enables users to perform resource-intensive tasks more efficiently. Whether you need to run complex simulations, perform data analytics, or handle large-scale virtualization, the server's 64GB-R memory configuration ensures that you can execute multiple tasks simultaneously without a significant decrease in performance. This capability promotes productivity and allows your business to make the most of its computing resources.

Scalability and Future Expansion

The 64GB-R memory configuration provides scalability and future expansion options for businesses that anticipate growth or increased computing requirements. As your needs evolve, you can easily upgrade the server's memory capacity to accommodate higher workloads. This flexibility helps extend the lifespan of your infrastructure and saves costs by avoiding the need for a complete hardware overhaul.

Efficient Virtualization

The generous memory capacity of the HPE Proliant DL380 Gen10 6132 Server is especially advantageous for virtualization purposes. Virtual machines require dedicated memory resources to operate effectively, and the 64GB-R configuration ensures that each virtual machine can access sufficient memory without impacting overall system performance. This allows businesses to maximize their virtualization capabilities and run more virtual instances concurrently.

Faster Data Processing

The ample memory capacity of the server enables faster data processing and analysis. Whether you're handling large datasets, performing real-time analytics, or running memory-intensive applications, the 64GB-R configuration ensures that your server can quickly process and manipulate data. This capability is essential for businesses that rely on real-time insights to make informed decisions and gain a competitive edge.

Reliable Performance

The HPE Proliant DL380 Gen10 6132 Server's 64GB-R memory configuration offers reliable performance even under heavy workloads. With sufficient memory resources, the server can maintain optimal performance levels without experiencing bottlenecks or slowdowns. This reliability is crucial for businesses that require uninterrupted operations and cannot afford performance issues that may result in downtime or loss of productivity.

Drive Bays

The HPE Proliant DL380 Gen10 6132 Server is equipped with 8SFF drive bays, offering users ample storage capacity and flexibility to accommodate their data storage needs. This feature is essential for businesses dealing with large amounts of data and requires efficient storage solutions.

High Storage Capacity

The 8SFF drive bays provide high storage capacity, allowing users to store large volumes of data within the server itself. This eliminates the need for external storage devices and simplifies data management by centralizing all information in one location. Whether you're storing multimedia files, databases, or critical business data, the server's drive bays ensure that you have sufficient space to meet your storage requirements.

Hot-Swap Capability

The HPE Proliant DL380 Gen10 6132 Server's drive bays support hot-swapping, which means you can replace or add drives without interrupting server operations. This capability reduces downtime and improves system availability by allowing for seamless drive maintenance or upgrades. Whether you need to replace a faulty drive or expand your storage capacity, the hot-swap capability ensures that your server remains operational throughout the process.

RAID Configuration Options

The 8SFF drive bays support various RAID configurations, providing users with data redundancy and enhanced data protection. RAID technology allows for data mirroring or striping across multiple drives, ensuring that even if one drive fails, your data remains safe and accessible. The server's drive bays enable businesses to configure RAID setups that meet their specific needs, balancing data protection with performance requirements.

Improved Data Access Speed

The HPE Proliant DL380 Gen10 6132 Server's drive bays enable faster data access speeds, resulting in improved overall system performance. With multiple drives operating in parallel, the server can read and write data more quickly, reducing latency and improving response times. This is particularly beneficial for businesses that require fast access to large datasets or frequently perform data-intensive operations.

Data Security and Reliability

By utilizing the drive bays for RAID configurations, businesses can enhance data security and reliability. The redundancy provided by RAID ensures that even if one drive fails, your data remains intact and accessible. This minimizes the risk of data loss and helps businesses maintain business continuity. The server's drive bays offer a reliable storage solution that safeguards critical business information.

Easy Scalability

The 8SFF drive bays provide easy scalability options for businesses that anticipate future storage needs. As your data storage requirements grow, you can easily add additional drives to the server without disrupting operations. This scalability allows businesses to expand their storage capacity as needed, ensuring that they can adapt to changing demands without significant hardware investments.

Part Number

The HPE Proliant DL380 Gen10 6132 Server has a unique part number: 875765-S01. This part number identifies the specific configuration and components of the server, making it easier for users to identify and order the exact model they require.

Accurate Ordering

The part number, 875765-S01, ensures accurate ordering of the HPE Proliant DL380 Gen10 6132 Server. With numerous server configurations available, having a specific part number eliminates any confusion or potential mistakes when placing an order. Users can confidently provide the part number to their supplier, ensuring that they receive the exact server model they need.

Easy Identification

The unique part number makes it easy for users to identify the HPE Proliant DL380 Gen10 6132 Server among other models or product lines. Whether you're searching for the server online or in a catalog, the part number provides a quick and straightforward way to locate the specific model you're interested in. This saves time and effort in finding the right server for your business.

Configuration Verification

The part number, 875765-S01, allows users to verify the exact configuration of the HPE Proliant DL380 Gen10 6132 Server they have or plan to purchase. By referencing the part number, you can ensure that the server you receive matches your desired specifications, preventing any discrepancies or mismatches. This verification process helps users avoid potential issues and ensures that they receive a server that meets their requirements.

Compatibility Assurance

Having a unique part number, such as 875765-S01, helps ensure compatibility with other components or accessories. Users can cross-reference the part number with compatible hardware or software lists provided by HPE or other vendors. This compatibility assurance prevents any compatibility issues or conflicts that could arise when integrating the server into an existing infrastructure.

Warranty and Support

The part number serves as a reference for warranty and support purposes. When registering your HPE Proliant DL380 Gen10 6132 Server or contacting customer support, providing the part number allows for easy identification and ensures that you receive the appropriate assistance or coverage. This streamlines the support process and helps resolve any technical issues or inquiries more efficiently.

Product Differentiation

The part number, 875765-S01, distinguishes the HPE Proliant DL380 Gen10 6132 Server from other similar models or versions. It helps users differentiate between different configurations or options available for the server, ensuring that they select the one that best suits their needs. This product differentiation allows users to make informed decisions and choose a server that offers the specific features and capabilities they require.
