HPE Proliant DL380 Gen7 656765-S01 Xeon Server 2.8GHz 24GB

656765-S01
Hover on image to enlarge

Brief Overview of 656765-S01

HPE Proliant Dl380 Gen7 Xeon 2.8GHz 24GB Server 656765-S01. Excellent Refurbished with 6-Month Replacement Warranty
QR Code of HPE Proliant DL380 Gen7 656765-S01 Xeon Server 2.8GHz 24GB
$1,018.00
$566.00
You save: $452.00 (44%)
Ask a question
+
Quote
Additional 7% discount at checkout
SKU/MPN656765-S01Availability✅ In StockProcessing TimeUsually ships same day ManufacturerHPE Product/Item ConditionExcellent Refurbished ServerOrbit Replacement WarrantySix-Month (180 Days)
Our Advantages
  • Free Ground Shipping
  • — Min. 6-month Replacement Warranty
  • — Genuine/Authentic Products
  • — Easy Return and Exchange
  • — Different Payment Methods
  • — Best Price
  • — We Guarantee Price Matching
  • — Tax-Exempt Facilities
  • — 24/7 Live Chat, Phone Support
Payment Options
  • — Visa, MasterCard, Discover, and Amex
  • — JCB, Diners Club, UnionPay
  • — PayPal, ACH/Wire Transfer
  • — Apple Pay, Amazon Pay, Google Pay
  • — Buy Now, Pay Later - Affirm, Afterpay
  • — GOV/EDU/Institutions PO's Accepted
  • — Invoices
Delivery
  • — Deliver Anywhere
  • — Express Delivery in the USA and Worldwide
  • — Ship to -APO -FPO
  • For USA - Free Ground Shipping
  • — Worldwide - from $30
Description

Processor

The HPE DL380 Gen7 Server is equipped with a powerful Intel Xeon processor running at 2.8GHz. This processor is designed to deliver exceptional performance and reliability, making it an ideal choice for a wide range of applications and workloads.

General Product Details

Manufacturer: Hewlett Packard Enterprise
Part Number: 656765-S01
Product Name: Proliant DL380 G7 - 2U Rack Server (Smart Buy)

Processor and Chipset

Processor Specifications

  • Type: Intel Xeon X5660
  • Clock Speed: 2.80 GHz
  • Max Turbo Speed: 3.2 GHz
  • Core Count: 6-core
  • Installed Quantity: 2
  • Maximum Supported Quantity: 2
  • 64-bit Computing: Yes
  • Chipset Type: Intel 5520
  • Features: Hyper-Threading Technology, Intel Turbo Boost Technology

Cache Memory

  • Type: L3 Cache
  • Installed Size: 24 MB
  • Cache Per Processor: 12 MB

Memory Configuration

Installed and Maximum Memory

  • Installed Size: 24 GB
  • Maximum Capacity: 288 GB

Memory Technology and Speed

  • Technology: DDR3 SDRAM
  • Effective Memory Speed: 1333 MHz
  • Rated Memory Speed: 1333 MHz
  • Compliance: PC3-10600
  • Form Factor: DIMM 240-pin
  • Slots: 18 total, 12 free
  • Configuration: 6 x 4 GB
  • RAM Supported: PC3-8500 - 384 GB Registered, PC3-10600 - 288 GB Registered, PC3-10600 - 48 GB Unbuffered - ECC

Storage and Optical Drives

Hard Drive

  • Installed: None

Optical Drive

  • Installed: None

Storage Controller

Controller Specifications

  • Type: RAID - Integrated - PCIe 2.0 x4
  • Controller Interface: SATA 3 Gb/s / SAS 6 Gb/s
  • Controller Name: Smart Array P410i with 1 GB FBWC
  • RAID Levels: 0, 1, 5, 10, 50
  • Buffer Size: 1 GB

Display and Graphics

Graphics Processor

  • Type: ATI ES1000
  • Video Memory: 64 MB
  • Video Interface: VGA

Networking

Network Interfaces

  • Type: Integrated
  • Interface Type: PCI Express x4
  • Ethernet Ports: 4 x Gigabit Ethernet
  • Ethernet Controller: 2 x HP NC382i
  • Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
  • Remote Management Controller: Integrated Lights-Out 3
  • Features: Wake on LAN (WoL), ACPI Support
  • Compliance: IEEE 802.3, IEEE 802.3u, IEEE 802.1q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad (LACP)

Expansion and Connectivity

Expansion Bays

  • Front Accessible: 1 x 5.25-inch Slim Line (free)
  • Hot-swap Bays: 8 x 2.5-inch SFF (all available)

Expansion Slots

  • CPU Slots: 2 (all used)
  • DIMM Slots: 18 total, 12 free
  • PCIe 2.0 x16 Slot: 1 full-length, full-height (x8 Mode) (available)
  • PCIe 2.0 x8 Slots: 2 half-length, full-height (x4 Mode) (both free)
  • SD Card Slot: 1 (available)

Interfaces

  • PS/2 Keyboard: 1
  • PS/2 Mouse: 1
  • Serial Port: 1
  • VGA Ports: 2 (1 front, 1 rear)
  • USB Ports: 4 (2 front, 2 rear)
  • LAN Ports: 4 x Gigabit Ethernet
  • HP iLO Port: 1

Miscellaneous Features

  • Security Features: Administrator Password, Power-on Password, Keyboard Password, Serial Port I/O Control, QuickLock
  • Compliance Standards: ACPI 2.0, FCC Class A Certified, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, WEEE, BSMI CNS 13438
  • Manufacturer Selling Program: HP Smart Buy

Power Specifications

  • Device Type: Power Supply - Hot-plug
  • Power Redundancy: Yes, 1+1
  • Installed Quantity: 2
  • Maximum Supported Quantity: 2
  • Nominal Voltage: AC 120/230 V (50/60 Hz)
  • Power Provided: 750 Watts

Dimensions and Weight

  • Height: 3.38 inches
  • Width: 17.54 inches
  • Depth: 27.25 inches
  • Weight: 47.18 lbs

Enhanced Performance

The Xeon 2.8GHz processor offers enhanced performance capabilities, allowing users to handle demanding tasks and applications with ease. Whether you are running complex databases, virtualization environments, or high-performance computing workloads, this processor can handle it all.

With its high clock speed, the Xeon processor ensures faster data processing, enabling quicker response times and improved overall system performance. This is particularly beneficial for businesses that rely on real-time data analysis or need to process large volumes of information quickly.

Improved Efficiency

Efficiency is a key consideration for any server deployment. The Xeon 2.8GHz processor is designed to optimize power consumption while delivering maximum performance. This results in improved energy efficiency, reducing operational costs and environmental impact.

By utilizing advanced power management technologies, the processor intelligently adjusts its performance based on workload requirements, dynamically allocating power resources where they are needed most. This not only reduces energy consumption but also helps minimize heat generation, resulting in a cooler and more reliable server environment.

Reliability and Scalability

The Xeon 2.8GHz processor is built to deliver exceptional reliability, ensuring that your server remains up and running even under heavy workloads. It features advanced error correction mechanisms that help detect and correct errors in real-time, minimizing the risk of system crashes or data corruption.

Additionally, this processor offers excellent scalability options, allowing you to expand your server's capabilities as your business grows. With support for multiple cores and threads, it can handle increasing workload demands without compromising performance or stability.

Virtualization Capabilities

Virtualization has become a critical component of modern IT infrastructures, enabling businesses to optimize resource utilization and streamline management processes. The Xeon 2.8GHz processor is specifically designed to support virtualization technologies, making it an ideal choice for virtualized environments.

With its robust virtualization capabilities, this processor enables efficient consolidation of multiple virtual machines onto a single physical server. It provides the necessary processing power and resources to ensure smooth operation and optimal performance of virtualized workloads.

Conclusion

The Xeon 2.8GHz processor in the HPE DL380 Gen7 Server offers exceptional performance, efficiency, reliability, and scalability. Whether you need to run resource-intensive applications or virtualize your IT infrastructure, this processor delivers the power and capabilities required to meet your business needs.

Memory

The HPE DL380 Gen7 Server is equipped with 24GB of memory, providing ample capacity for running multiple applications simultaneously and handling large datasets. The memory plays a crucial role in overall system performance, making it an essential feature for users seeking optimal computing capabilities.

Enhanced Multitasking

With 24GB of memory, the DL380 Gen7 Server enables efficient multitasking, allowing users to run multiple applications concurrently without experiencing significant performance degradation. This is particularly beneficial for businesses that rely on running resource-intensive software or need to handle complex workloads simultaneously.

The ample memory capacity ensures that each application receives sufficient resources to operate smoothly, minimizing the risk of slowdowns or crashes. This is especially important in scenarios where tasks such as data analysis, virtualization, or database management require substantial memory resources.

Improved Workload Performance

The 24GB memory configuration in the DL380 Gen7 Server enhances workload performance by providing sufficient space for data storage and retrieval. Large datasets can be loaded into memory, significantly reducing the time required for accessing and processing information.

This is particularly advantageous in scenarios where real-time data analysis or rapid decision-making is crucial. By keeping critical data readily available in memory, the server can deliver faster response times, enabling businesses to make informed decisions quickly.

Scalability and Future-Proofing

The 24GB memory capacity of the DL380 Gen7 Server offers scalability options for businesses that anticipate future growth or increased workload demands. The server supports additional memory modules, allowing users to expand the memory capacity as needed.

By investing in a server with ample memory capacity, businesses can future-proof their infrastructure and avoid potential bottlenecks in performance. This ensures that the server can accommodate evolving business requirements without the need for a complete hardware overhaul.

Reliability and Error Correction

Memory errors can have severe consequences, leading to system crashes, data corruption, or application failures. The DL380 Gen7 Server's memory subsystem incorporates advanced error correction mechanisms to detect and correct errors in real-time, ensuring data integrity and system stability.

This feature is crucial for businesses that rely on uninterrupted operations and cannot afford downtime or data loss. The error correction capabilities of the server's memory subsystem provide an additional layer of protection, enhancing overall system reliability.

Conclusion

The 24GB memory configuration in the HPE DL380 Gen7 Server offers enhanced multitasking capabilities, improved workload performance, scalability options, and reliability. Whether you need to handle multiple applications simultaneously or process large datasets efficiently, this memory configuration provides the necessary resources for optimal computing performance.

Product Number

The HPE DL380 Gen7 Server is identified by its unique product number: 656765-S01. This product number serves as a key identifier for ordering, support, and documentation purposes. Understanding the benefits and importance of the product number can streamline your server deployment and ongoing management processes.

Easy Order Placement

The product number, 656765-S01, provides a quick and precise way to identify and order the HPE DL380 Gen7 Server. By using this product number when placing an order, you can ensure that you receive the correct configuration and specifications without any confusion or errors.

This simplifies the procurement process, especially when dealing with multiple servers or complex server configurations. Instead of having to list individual components or features, you can simply provide the product number, saving time and reducing the risk of order discrepancies.

Accurate Support and Documentation

The product number is also crucial for obtaining accurate support and accessing relevant documentation for the DL380 Gen7 Server. When seeking technical assistance or browsing through support resources, providing the product number allows support teams to identify your specific server model and tailor their assistance accordingly.

Similarly, documentation such as user manuals, hardware guides, or firmware updates are often organized based on product numbers. By referencing the correct product number, you can quickly locate the relevant documentation that pertains specifically to your server model, ensuring accurate information and guidance.

Replacement Parts and Upgrades

Over time, servers may require replacement parts or upgrades to address hardware failures, enhance performance, or accommodate changing business needs. The product number plays a vital role in identifying compatible components or upgrades for the DL380 Gen7 Server.

When ordering replacement parts or upgrades, providing the product number ensures that you receive components that are compatible with your specific server model. This eliminates the risk of compatibility issues or incorrect installations, saving time and avoiding potential damage to your server hardware.

Product Differentiation

The HPE DL380 Gen7 Server is available in various configurations and models, each tailored to specific business requirements. The product number helps differentiate between different models, allowing you to choose the one that best suits your needs.

By referencing the product number, you can ensure that you select the correct DL380 Gen7 Server variant with the desired specifications and features. This helps avoid confusion or misunderstandings, ensuring that you receive the server model that aligns with your specific requirements.

Conclusion

The product number, 656765-S01, plays a crucial role in ordering, support, documentation, and differentiation of the HPE DL380 Gen7 Server. By utilizing the correct product number, you can streamline your server procurement process, access accurate support and documentation, identify compatible replacement parts or upgrades, and select the appropriate server variant for your business needs.

Features
Product/Item Condition:
Excellent Refurbished
ServerOrbit Replacement Warranty:
Six-Month (180 Days)
