HPE Proliant DL380p 2.0GHz Server 32GB DDR3 8SFF 734791-S01

Processor

The HPE Proliant DL380p Server is equipped with a powerful 2.0GHz processor, which is one of its standout features. The processor is the brain of the server, responsible for executing instructions and performing calculations. With a clock speed of 2.0GHz, this server offers impressive processing power that can handle demanding workloads and complex tasks efficiently.

General Information

• Manufacturer: HPE
• Part Number: 734791-S01
• Product Name: Proliant DL380p G8 2U Rack Server S-Buy

Processor & Chipset

Processor Details

• Processor Type: Intel Xeon E5-2640 V2 / 2.0 GHz
• Socket Type: LGA2011
• Core Technology: Octa-core (8 cores)
• 64-bit Computing: Yes
• Installed Processors: 2
• Maximum Supported Processors: 2
• Chipset Model: Intel C600

Cache Memory

• Cache Memory Type: L3 Cache
• Installed Size: 20 MB
• Cache Per Processor: 40 MB

Memory Specifications

Installed Memory

• Installed Size: 32 GB / 768 GB (maximum)
• Technology: DDR3 SDRAM
• Memory Speed: 1600 MHz
• Compliance: PC3-10600
• Form Factor: DIMM 240-pin
• Total Memory Slots: 24

Memory Configuration

• Features: Registered, Dual Rank, Quad Channel Architecture, HP Smart Memory
• Configuration: 2 x 16 GB
• Supported RAM:
  • PC3-12800 - 384 GB - Registered
  • PC3-10600 - 768 GB
  • PC3-10600 - 128 GB - Unbuffered - Advanced ECC

Storage Options

• Hard Drive: None Included
• Internal Storage Bays: 8 SFF SAS/SATA HDD Bays
• Optical Drive Bay: Optional Slim Optical Bay (SATA DVD-RW/ROM)

Storage Controllers

• Controller Type: RAID Plug-in Card - PCI Express 3.0 x8
• Interface Type: SATA 6 Gb/s / SAS 6 Gb/s
• Controller Name: Smart Array P420i with 1 GB FBWC
• RAID Levels Supported: RAID 0, 1, 5, 10, 50
• Buffer Size: 1 GB

Display & Graphics

• Graphics Type: Integrated
• Graphics Controller: Matrox G200

Networking & Communication

Network Interfaces

• Networking Type: Plug-in Card
• Bus Type: PCI Express x4
• Ethernet Ports: 4 x Gigabit Ethernet
• Ethernet Controller: HP 331FLR
• Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management Controller: Integrated Lights-Out 4 (iLO 4)
• Features: Wake On LAN (WOL), PXE Support
• Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad (LACP)

Expansion & Connectivity

Expansion Bays

• Front Accessible: 1 x 5.25" Slim Line (Free)
• Hot-Swap Bays: 8 x 2.5" SFF (Free)

Expansion Slots

• Memory Slots: 24 (2 occupied, 22 free)
• Processor Slots: 2 (None free)
• PCI Express 3.0 x16 Slots: 2 (Free)
• PCI Express 3.0 x8 Slots: 3 (Free)
• PCI Express 2.0 x8 Slot: 1 (Free)
• FlexibleLOM Slot: 1 (Free)

Interfaces & Ports

• Serial Port: 1 x RS-232 (9-pin D-sub)
• Display/Video Ports: 2 x VGA (15-pin HD D-sub, 1 Front, 1 Rear)
• USB Ports: 7 x USB Type-A (2 Front, 4 Rear, 1 Internal)
• Network Ports: 4 x Ethernet (RJ-45)
• Management Port: HP iLO (RJ-45)

Power Description

• Device Type: Hot Plug Power Supply
• Power Redundancy: Yes (1+1 Scheme)
• Installed Power Supplies: 2
• Maximum Supported Power Supplies: 2
• Voltage Required: AC 120/220 V
• Power Provided: 460 Watts
• 80 Plus Certification: 80 Plus Platinum

Dimensions & Weight

• Width: 17.5 inches
• Depth: 27.5 inches
• Height: 3.4 inches
• Weight: 41 lbs

Improved Performance

The 2.0GHz processor ensures improved performance for the HPE Proliant DL380p Server. The higher clock speed allows for faster data processing and execution of instructions, resulting in quicker response times and reduced latency. Users will experience enhanced performance in various applications, including database management, virtualization, and high-performance computing.

Efficient Multitasking

With a faster clock speed, the HPE Proliant DL380p Server can handle multiple tasks simultaneously without compromising performance. The processor's speed enables efficient multitasking, allowing users to run multiple applications and processes concurrently without experiencing significant slowdowns or performance bottlenecks.

Optimized Virtualization

Virtualization has become a crucial aspect of modern server environments, enabling efficient utilization of hardware resources and facilitating workload management. The 2.0GHz processor in the HPE Proliant DL380p Server supports virtualization technologies, such as VMware and Hyper-V, ensuring optimized performance for virtual machines. Users can run multiple virtual instances smoothly, benefiting from enhanced responsiveness and reduced latency.

Resource-Intensive Applications

Resource-intensive applications, such as data analytics, rendering software, and scientific simulations, demand robust processing power. The 2.0GHz processor in the HPE Proliant DL380p Server is well-suited to handle these applications efficiently. Its high clock speed ensures swift execution of complex calculations and data processing, enabling users to complete tasks faster and improve productivity.

Scalability and Future-Proofing

The 2.0GHz processor provides scalability and future-proofing for the HPE Proliant DL380p Server. As technology advances and workload requirements increase, having a powerful processor is essential. The server's processor offers headroom for future growth and can handle more demanding applications, ensuring longevity and reducing the need for frequent hardware upgrades.

Memory

Another notable feature of the HPE Proliant DL380p Server is its 32GB DDR3 memory. The memory plays a crucial role in server performance by providing temporary storage for data and instructions. With 32GB of DDR3 memory, this server offers ample capacity to handle multiple applications and workloads simultaneously.

Enhanced Workload Management

The 32GB DDR3 memory in the HPE Proliant DL380p Server allows for efficient workload management. With more memory available, the server can store and access a larger amount of data in its fast-access storage, reducing the need for frequent data retrieval from slower storage mediums. This results in improved performance and responsiveness, especially when dealing with large datasets or memory-intensive applications.

Optimized Virtualization

Virtualization relies heavily on memory capacity to allocate resources to virtual machines effectively. The 32GB DDR3 memory in the HPE Proliant DL380p Server enables efficient virtual machine allocation, allowing users to run multiple instances without experiencing significant performance degradation. This enhances the server's virtualization capabilities, making it an ideal choice for organizations that heavily rely on virtualized environments.

Faster Data Processing

Large datasets require sufficient memory to be processed efficiently. The 32GB DDR3 memory in the HPE Proliant DL380p Server provides ample space for data processing, reducing the need for frequent disk access and improving overall performance. This is particularly beneficial for applications that involve data analytics, complex calculations, and real-time processing.

Improved System Stability

Insufficient memory can lead to system instability and crashes when the server is under heavy load. The 32GB DDR3 memory in the HPE Proliant DL380p Server ensures stability even during resource-intensive tasks. With ample memory available, the server can handle demanding workloads without running out of memory, resulting in a stable and reliable system.

Future-Proofing

As technology advances and applications become more memory-hungry, having sufficient memory capacity is crucial. The 32GB DDR3 memory in the HPE Proliant DL380p Server provides future-proofing, allowing for scalability and accommodating future memory requirements. Users can add more memory modules to the server as their needs grow, extending its lifespan and reducing the need for immediate hardware upgrades.

Drive Bays

The HPE Proliant DL380p Server comes with 8SFF drive bays, offering ample storage capacity and flexibility for users. Drive bays are crucial for storing data and applications, and having a sufficient number of bays allows for easy expansion and efficient storage management.

Increased Storage Capacity

The 8SFF drive bays in the HPE Proliant DL380p Server provide increased storage capacity compared to servers with fewer bays. Each bay can accommodate a hot-plug small form factor (SFF) hard drive, allowing users to store large amounts of data. With eight drive bays available, organizations can scale their storage capacity to meet growing data requirements without the need for additional external storage solutions.

Flexible Storage Configuration

The 8SFF drive bays offer flexible storage configuration options for the HPE Proliant DL380p Server. Users can mix and match different types of hard drives, including solid-state drives (SSDs) and traditional hard disk drives (HDDs), based on their specific needs. This flexibility enables organizations to optimize storage performance and cost-efficiency by choosing the most suitable drive types for different applications and workloads.

Improved Data Redundancy

Data redundancy is crucial for ensuring data integrity and protecting against data loss. The 8SFF drive bays in the HPE Proliant DL380p Server can be configured in RAID arrays, allowing for improved data redundancy. RAID configurations distribute data across multiple drives, providing redundancy and fault tolerance. In the event of a drive failure, data can be rebuilt from the remaining drives, minimizing downtime and reducing the risk of data loss.

Efficient Data Management

The 8SFF drive bays enable efficient data management in the HPE Proliant DL380p Server. With multiple bays available, users can segregate data based on different criteria such as application type, user access requirements, or data sensitivity. This facilitates better organization, easier maintenance, and streamlined backup and recovery processes.

Scalability and Future Growth

The 8SFF drive bays provide scalability and future growth potential for the HPE Proliant DL380p Server. As storage requirements increase over time, organizations can easily add more drives to the available bays without disrupting server operations or incurring additional costs associated with external storage solutions. This scalability ensures that the server can accommodate growing data needs without compromising performance or efficiency.

Part Number

The HPE Proliant DL380p Server's part number is 734791-S01. While it may seem like a simple alphanumeric identifier, the part number holds significance for users and IT professionals.

Easy Identification

The part number, 734791-S01, allows for easy identification of the HPE Proliant DL380p Server model. In complex IT environments with multiple servers and equipment, having a unique part number simplifies inventory management, asset tracking, and maintenance. IT professionals can easily identify and locate the server based on its part number, ensuring efficient troubleshooting and timely support.

Accurate Ordering and Replacement

When ordering or replacing server hardware, using the correct part number is crucial to ensure compatibility and avoid configuration issues. The 734791-S01 part number serves as a specific identifier for the HPE Proliant DL380p Server model, ensuring accuracy in procurement processes. IT administrators can confidently order replacement parts or additional servers knowing that they are obtaining the exact model required for their infrastructure.

Warranty and Support

The part number plays a role in warranty and support services for the HPE Proliant DL380p Server. Manufacturers often tie warranties and support agreements to specific part numbers to ensure accurate entitlements. By referring to the 734791-S01 part number, users can easily determine warranty coverage, access technical support, and receive timely assistance when needed.

Documentation and Resources

The part number serves as a reference point for accessing documentation, user manuals, and other resources related to the HPE Proliant DL380p Server. Manufacturers often provide detailed product information specific to each part number, including specifications, installation guides, and firmware updates. Users can leverage the 734791-S01 part number to access the relevant resources tailored to their server model, facilitating proper setup, configuration, and maintenance.

Future Compatibility

Part numbers also help ensure future compatibility when expanding or upgrading server infrastructure. Manufacturers release updated versions or revisions of server models, often identified by different part numbers. By knowing the part number of the HPE Proliant DL380p Server (734791-S01), users can easily identify compatible components and accessories that are designed to work seamlessly with their specific server model, avoiding compatibility issues and ensuring smooth integration.
