HPE Proliant DL580 G9 2.2GHz 256GB DDR4 SDRAM 4X 1500W RPS 4U Server 816815-B21

Processor

The HPE Proliant DL580 G9 Server is equipped with a powerful processor that ensures optimal performance and efficiency. With a clock speed of 2.2GHz, this server is designed to handle even the most demanding workloads with ease.

General Information

• Manufacturer: Hewlett Packard Enterprise (HPE)
• Part Number: 816815-B21
• Product Name: Proliant DL580 Gen9 - 4U Rack-Mountable High-Performance Server

Processor & Chipset

CPU Specifications

• Processor: Intel Xeon E7-8890v4
• Base Clock Speed: 2.2 GHz
• Max Turbo Speed: 3.4 GHz
• Core Count: 24 cores
• Number of CPUs: 4
• Maximum CPUs Supported: 4
• CPU Upgradeability: Upgradable
• Processor Features: Intel Turbo Boost Technology 2.0
• Chipset: Intel C602J

Cache Memory

• Type: Smart Cache
• Installed Size: 180 MB
• Cache Per Processor: 45 MB

Memory

• Installed Capacity: 256 GB, expandable up to 6 TB
• Memory Technology: DDR4 SDRAM
• Form Factor: DIMM 288-pin
• Configuration: 16 x 16 GB

Storage

• Hard Drive: Not included
• Optical Drive: Not included

Storage Controllers

• Controller Type: 1 x RAID - PCIe 2.0 x4
• Interface Type: SATA 6 Gb/s / SAS 12 Gb/s
• Controller Name: Smart Array P830i with 4 GB FBWC
• Channels: 8
• RAID Levels Supported: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
• Buffer Size: 4 GB

Network & Communication

• Interface (Bus) Type: PCI Express 2.0 x8
• Ethernet Ports: 2 x 10 Gigabit Ethernet
• Ethernet Controller: HP FlexFabric 534FLR-SFP+
• Data Link Protocol: 10 Gigabit Ethernet
• Remote Management: Integrated Lights-Out 4 (iLO 4)
• Features: Wake On LAN (WOL), ACPI Support, PXE Support
• Standards Compliance: IEEE 802.3, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.1ax, IEEE 802.1qbb, IEEE 802.1qaz, IEEE 802.1qau, IEEE 802.1qbg, IEEE 802.2x

Power Description

• Type: Hot-plug Power Supply
• Redundancy: Yes
• Installed Quantity: 4
• Maximum Supported Quantity: 4
• Nominal Voltage: AC 120/230 V (50/60 Hz)
• Power Output: 1500 Watts

Expansion & Connectivity

Expansion Bays

• Total Bays: 5 (all hot-swappable 2.5” SFF)

Expansion Slots

• Total DIMM Slots: 96 (80 available)
• CPU Slots: 4 (none available)
• PCIe 3.0 x16 Slots (Full-length, Full-height): 5 (all available)
• PCIe 3.0 x16 Slots (Half-length, Full-height, x8 Mode): 4 (all available)
• FlexibleLOM Slot: 1 (none available)
• MicroSD Card Slot: 1 (available)

Interfaces & Ports

• Serial Port: 1
• VGA Ports: 2 (1 front, 1 rear)
• HP iLO Port: 1
• USB 2.0 Ports: 8 (2 front, 4 rear, 2 internal)
• LAN Ports (10 Gigabit Ethernet, SFP+): 2

Dimensions & Weight

• Depth: 29 inches
• Width: 17.48 inches
• Height: 6.88 inches
• Weight: 70.94 lbs

Enhanced Performance

The 2.2GHz processor delivers exceptional performance, allowing users to run multiple applications simultaneously without any lag or slowdown. Whether you're running virtual machines, databases, or complex calculations, this server can handle it all.

Improved Productivity

With a faster processor, tasks are completed more quickly, enabling your team to be more productive. The 2.2GHz clock speed ensures that data processing is efficient, reducing wait times and increasing overall workflow efficiency.

Seamless Multitasking

Thanks to the powerful 2.2GHz processor, the HPE Proliant DL580 G9 Server can effortlessly handle multitasking operations. Users can run resource-intensive applications side by side without experiencing any performance issues or interruptions.

Furthermore, the 2.2GHz clock speed allows for smooth and uninterrupted multitasking, ensuring that all tasks are executed seamlessly without any compromise in performance.

Memory

The HPE Proliant DL580 G9 Server comes equipped with an impressive 256GB DDR4 SDRAM memory configuration. This substantial memory capacity provides several benefits and plays a crucial role in delivering exceptional performance.

Improved System Responsiveness

With 256GB of DDR4 SDRAM memory, the server can store and retrieve data at lightning-fast speeds. This results in improved system responsiveness, enabling users to access files and applications quickly without any delays.

Efficient Virtualization

Virtualization requires substantial memory resources to ensure optimal performance. The 256GB DDR4 SDRAM capacity of the HPE Proliant DL580 G9 Server allows for efficient virtualization, enabling the smooth operation of multiple virtual machines simultaneously.

Enhanced Workload Management

The generous memory capacity of this server facilitates efficient workload management. It allows for the seamless execution of resource-intensive applications and ensures that all tasks are completed without any performance bottlenecks.

Power Supply

The HPE Proliant DL580 G9 Server features a robust power supply system with 4X 1500W RPS (Redundant Power Supplies). This power configuration offers several benefits and is crucial for maintaining uninterrupted operations.

Redundancy and Reliability

With four redundant power supplies, the server can continue operating even if one or more power supplies fail. This redundancy ensures that your critical applications and data remain available, reducing the risk of downtime and data loss.

Stability and Load Balancing

The 4X 1500W RPS power supply configuration provides stability and load balancing capabilities. It ensures that power is distributed evenly across the server components, preventing any strain on the system and optimizing performance.

Scalability and Future-Proofing

The power supply system of the HPE Proliant DL580 G9 Server is designed to accommodate future expansion. With four power supplies, the server can handle increased power demands as your business grows, ensuring scalability and future-proofing your infrastructure.

Form Factor

The HPE Proliant DL580 G9 Server features a compact form factor of 4U. This form factor offers several benefits and plays a crucial role in optimizing space utilization and simplifying management.

Space Optimization

The 4U form factor allows for efficient use of rack space, enabling you to maximize the number of servers in your data center. This is particularly beneficial for businesses with limited rack space, as it allows for greater infrastructure density without compromising performance.

Easy Installation and Maintenance

The compact form factor of the server simplifies installation and maintenance processes. The 4U design makes it easier to access and replace components, reducing downtime and minimizing the effort required for routine maintenance tasks.

Improved Cooling Efficiency

The 4U form factor allows for better airflow and cooling within the server chassis. The efficient cooling system ensures that the components remain at optimal temperatures, preventing overheating and ensuring reliable performance.

Part Number

The HPE Proliant DL580 G9 Server is identified by its unique part number, which in this case is 816815-B21. This part number holds significance for users and facilitates easy identification and procurement of the server.

Accurate Identification

The part number serves as a unique identifier for the HPE Proliant DL580 G9 Server model. It allows users to accurately identify and differentiate this specific server from other models, ensuring that they acquire the correct hardware for their requirements.

Seamless Procurement

When procuring servers or spare parts, having the correct part number simplifies the procurement process. Users can easily communicate the part number to suppliers, ensuring that they receive the exact server model or components they need without any confusion or delays.

Technical Support and Documentation

The part number is also essential when seeking technical support or referring to product documentation. By providing the part number to support staff or referencing it in documentation, users can ensure that they receive accurate guidance or access relevant information pertaining specifically to the HPE Proliant DL580 G9 Server with part number 816815-B21.
