HPE Proliant DL580 G9 Server 816814-B21 Xeon E7-8893V4/3.2GHz, 256GB RAM

Processor

The HPE Proliant DL580 Server G9 is equipped with a powerful Xeon 18 Core E7-8893V4/3.2GHz processor, making it an exceptional choice for businesses that require high-performance computing capabilities. This processor is designed to handle the most demanding workloads, providing unparalleled speed and efficiency.

General Information

• Manufacturer: HPE
• Part Number: 816814-B21
• Product Name: Proliant DL580 G9 - 4U Rack Mountable Server (Database Models)

Processor & Chipset

CPU Specifications

• Processor: Intel Xeon E7-8893v4
• Clock Speed: 3.2 GHz
• Max Turbo Speed: 3.5 GHz
• Core Count: Quad-core
• Quantity: 4 CPUs
• Upgradability: Yes

Chipset

• Chipset Type: Intel C602j
• Main Features: Intel Turbo Boost Technology 2

Cache Memory

• Type: Smart Cache
• Installed Size: 180 MB
• Cache Per Processor: 45 MB

Memory

• Installed Size: 256 GB, expandable up to 6 TB
• Type: DDR4 SDRAM
• Form Factor: DIMM 288-pin
• Configuration: 16 x 16 GB

Storage

• Hard Drive: None
• Optical Drive: None

Graphics Controller

• Graphics Processor: Matrox G200
• Video Interfaces: VGA

Storage Controllers

Controller Specifications

• Type: RAID - PCIe 2.0 x4
• Interface Type: SATA 6Gb/s, SAS 12Gb/s
• Controller Name: Smart Array P830i with 2GB FBWC
• Channel Quantity: 8
• RAID Levels: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
• Buffer Size: 4 GB

Network & Communication

• Interface Type: PCI Express 2.0 x8
• Ethernet Ports: 2 x 10 Gigabit Ethernet
• Ethernet Controller: HP FlexFabric 534FLR-SFP+
• Data Link Protocol: 10 Gigabit Ethernet
• Remote Management: Integrated Lights-Out 4
• Features: Wake On LAN (WOL), ACPI Support, PXE Support
• Standards Compliance: IEEE 802.3, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.1ax, IEEE 802.1qbb, IEEE 802.1qaz, IEEE 802.1qau, IEEE 802.1qbg, IEEE 802.2x

Power Description

• Device Type: Hot-plug Power Supply
• Power Redundancy: Yes
• Installed Quantity: 4
• Maximum Supported Quantity: 4
• Nominal Voltage: AC 120/230 V (50/60 Hz)
• Power Provided: 1500 Watts

Expansion & Connectivity

Expansion Bays

• Total: 10 (all hot-swappable 2.5" SFF)
• Free: 10

Expansion Slots

• Total DIMM Slots: 96 (80 free)
• Total CPU Slots: 4 (0 free)
• Total PCIe 3.0 x16 Full-Length Slots: 5 (5 free)
• Total PCIe 3.0 x16 Half-Length Slots (x8 Mode): 4 (4 free)
• Total FlexibleLOM Slots: 1 (0 free)
• Total microSD Card Slots: 1 (1 free)

Interfaces & Ports

• Serial Port: 1
• VGA Ports: 2 (1 front, 1 rear)
• HP iLO Port: 1
• USB 2.0 Ports: 8 (2 front, 4 rear, 2 internal)
• LAN Ports: 2 (Gigabit Ethernet)

Dimensions & Weight

• Depth: 29 inches
• Width: 17.48 inches
• Height: 6.88 inches
• Weight: 70.94 lbs

Unmatched Performance

The Xeon 18 Core E7-8893V4/3.2GHz processor delivers unparalleled performance, allowing users to execute complex tasks with ease. With its impressive number of cores and high clock speed, this processor can handle multiple threads simultaneously, ensuring efficient multitasking capabilities. Whether you're running resource-intensive applications or performing data analysis, this processor will exceed your expectations.

Increased Productivity

By incorporating the Xeon 18 Core E7-8893V4/3.2GHz processor into the HPE Proliant DL580 Server G9, Hewlett Packard Enterprise has provided users with a tool that boosts productivity. The processor's responsive performance enables faster data processing, reducing the time required for complex calculations and analysis. This increased efficiency translates into improved productivity for businesses, allowing them to accomplish more in less time.

Enhanced Scalability

Scalability is an essential aspect of any server infrastructure. The Xeon 18 Core E7-8893V4/3.2GHz processor offers exceptional scalability options, allowing businesses to expand their computing capabilities as their needs grow. With its advanced architecture and support for virtualization technologies, this processor enables businesses to optimize their resources and adapt to changing workloads seamlessly.

Reliability and Stability

When it comes to mission-critical applications, reliability is paramount. The Xeon 18 Core E7-8893V4/3.2GHz processor is designed to deliver exceptional reliability and stability, ensuring uninterrupted operation for critical workloads. Its robust architecture and advanced features, such as error-correcting code (ECC) memory support, help prevent system failures and data corruption, providing businesses with peace of mind.

Security Features

Security is a top concern for businesses today. The Xeon 18 Core E7-8893V4/3.2GHz processor includes built-in security features that help protect sensitive data and mitigate the risk of cyber threats. With features like Intel® vPro™ technology and Intel® Trusted Execution Technology (TXT), businesses can safeguard their systems and ensure the integrity of their data.

Memory

The HPE Proliant DL580 Server G9 is equipped with an impressive 256GB DDR4 SDRAM memory, providing exceptional performance and scalability for memory-intensive workloads. This substantial memory capacity allows businesses to tackle complex tasks efficiently, ensuring smooth operation even under heavy loads.

Improved Workload Performance

The 256GB DDR4 SDRAM memory elevates the performance of the HPE Proliant DL580 Server G9 by enabling faster data access and manipulation. With a high memory capacity, businesses can handle larger datasets without experiencing slowdowns or bottlenecks. Whether you're running virtual machines, performing data analytics, or managing databases, this ample memory will enhance your workload performance.

Efficient Multi-tasking

Multi-tasking is a common requirement in modern business environments. The 256GB DDR4 SDRAM memory enables efficient multi-tasking by providing sufficient space for running multiple applications simultaneously. With this large memory capacity, you can switch between tasks seamlessly, ensuring smooth operation and improved productivity.

Scalability for Growing Needs

As businesses expand and their requirements evolve, having a scalable server infrastructure is crucial. The HPE Proliant DL580 Server G9's 256GB DDR4 SDRAM memory offers excellent scalability options, allowing businesses to accommodate increasing demands. By easily adding additional memory modules, the server can adapt to changing workloads and ensure optimal performance.

Reliability and Data Integrity

Reliability is essential when dealing with critical business data. The 256GB DDR4 SDRAM memory in the HPE Proliant DL580 Server G9 is built with advanced error-correcting code (ECC) technology. ECC memory helps detect and correct errors that may occur during data storage or retrieval, ensuring the integrity of your valuable information. This feature minimizes the risk of data corruption and enhances the overall reliability of the server.

Enhanced Virtualization Performance

Virtualization has become a fundamental component of modern IT infrastructures. With its large memory capacity, the 256GB DDR4 SDRAM memory allows businesses to create and manage more virtual machines efficiently. This enhanced virtualization performance enables organizations to consolidate their resources, reduce hardware costs, and improve overall efficiency.
