HPE Proliant ML30 Gen9 E3-1220V6 8GB-U Perf Server P03705-S01

Processor

The HPE Proliant ML30 Gen9 Server is equipped with an E3-1220V6 processor, which is a powerful and efficient component that plays a crucial role in the performance of the server. With its quad-core architecture and a base clock speed of 3.0GHz, this processor delivers exceptional processing power and enables the server to handle demanding workloads with ease.

Product Overview of P03705-S01

• Manufacturer: Hewlett Packard Enterprise
• Part Number: P03705-S01

Product Name

Proliant ML30 Gen10 - 4U Tower Server (Performance Model)

Processor and Chipset Specifications

• CPU Model: Intel Xeon E3-1220v6
• Clock Speed: 3 GHz
• Max Turbo Speed: 3.5 GHz
• Cores: Quad-core
• CPU Quantity: 1 (single)
• CPU Upgradability: Yes
• Main Features: Intel Turbo Boost Technology 2
• Chipset Type: Intel C236

Cache Memory

• Cache Size: 8 MB L3 Cache per processor

Memory Specifications

• Standard Size: 8 GB
• Maximum Capacity: 64 GB

Memory Technology and Features

• Technology: DDR4 SDRAM - ECC
• Effective Memory Speed: 2400 MHz
• Rated Memory Speed: 2400 MHz
• Compliance: PC4-19200
• Form Factor: DIMM 288-pin
• Configuration: 1 x 8 GB
• RAM Supported: Up to 64 GB Unbuffered

Storage Controllers

• Type: RAID Controller - PCIe x4
• Interface Type: SATA 6 Gb/s
• Controller Name: HP Dynamic Smart Array B140i
• Channel Quantity: 10
• RAID Levels Supported: RAID 0, RAID 1, RAID 5, RAID 10

Optical Storage

• Type: DVD Writer - SATA

Graphics and Video

• Processor: Matrox G200
• Video Interface: VGA

Network and Communication

• Bus Type: PCI Express x2
• Ethernet Ports: 2 x Gigabit Ethernet
• Ethernet Controller: Broadcom BCM5720
• Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management: Integrated Lights-Out 4 (iLO)
• Features: Wake On LAN (WOL), PXE Support
• Standards Compliance: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

Expansion and Connectivity

• External 5.25": 1 total (none free)
• Hot-swap 3.5" LFF: 4 total (all free)

Expansion Slots

• PCIe 3.0 x16: 1 total (1 free)
• PCIe 3.0 x4: 2 total (2 free, x1 Mode)
• PCIe 3.0 x8: 1 total (1 free, x4 Mode)
• Internal MicroSD Card: 1

Interfaces

• VGA: 1 rear
• Gigabit Ethernet LAN: 2 x front, 1 x iLO
• USB 3.0 Ports: 6 (4 front, 2 rear)
• USB 2.0 Ports: 4 (2 rear, 2 internal)

Miscellaneous Information

• ACPI 2.0b
• FCC Class B Certified
• EN 61000-3-2
• EN55022
• ICES-003
• EN 61000-3-3
• EN55024
• CISPR 22
• FCC CFR47 Part 15
• IEC 60950-1
• EN 60950-1
• GB 9254
• CNS 13438
• K22, K24

Power Supply

• Type: Internal Power Supply
• Installed Quantity: 1
• Nominal Voltage: AC 120/230 V (50/60 Hz)
• Power Output: 350 Watts

Physical Dimensions and Weight

• Width: 6.9 inches
• Depth: 18.7 inches
• Height: 14.5 inches
• Weight: 29.89 lbs

Enhanced Performance

The E3-1220V6 processor is designed to deliver enhanced performance and efficiency, making it an ideal choice for businesses that require robust computing capabilities. Its quad-core design allows for simultaneous execution of multiple tasks, resulting in improved overall performance and faster response times.

Increased Productivity

With the E3-1220V6 processor, users can experience increased productivity and efficiency. The processor's high clock speed ensures that tasks are executed quickly, reducing wait times and allowing users to complete their work more efficiently. This is particularly beneficial for businesses that rely on speedy data processing and analysis.

Improved Energy Efficiency

The E3-1220V6 processor is built using Intel's advanced 14nm manufacturing process, which ensures improved energy efficiency compared to previous generations. This means that the server can deliver high-performance computing while minimizing power consumption, resulting in lower energy costs for businesses.

Optimized Virtualization

Virtualization has become increasingly important for businesses as it allows for more efficient use of resources and enables the creation of virtual machines to run multiple operating systems simultaneously. The E3-1220V6 processor supports Intel's Virtualization Technology (VT-x), which enhances the server's ability to run virtualized environments efficiently.

Reliable Performance

The E3-1220V6 processor is built to deliver reliable performance, ensuring that the server can handle demanding workloads and operate smoothly even under heavy usage. This reliability is essential for businesses that require continuous access to critical applications and services.

Memory

The HPE Proliant ML30 Gen9 Server comes with 8GB of memory, providing sufficient capacity for running multiple applications and handling data-intensive tasks. The memory plays a vital role in the performance and responsiveness of the server, allowing it to handle concurrent processes efficiently.

Seamless Multitasking

With 8GB of memory, the server can seamlessly handle multitasking, enabling users to run multiple applications simultaneously without experiencing a significant drop in performance. This is particularly beneficial for businesses that require employees to work on multiple tasks simultaneously.

Faster Data Processing

The 8GB memory capacity allows for faster data processing, as more data can be stored in the server's memory instead of being accessed from slower storage devices. This results in quicker response times and improved overall system performance.

Scalability and Future-Proofing

The 8GB memory capacity provides room for scalability, allowing businesses to easily upgrade their server's memory in the future as their needs grow. This ensures that the server remains capable of handling increasing workloads and can adapt to changing business requirements.

Enhanced Virtualization

The 8GB memory capacity enables efficient virtualization by providing sufficient resources for running multiple virtual machines simultaneously. This is particularly important for businesses that rely heavily on virtualization to consolidate their IT infrastructure and reduce costs.

Reliable Performance

The 8GB memory ensures reliable performance by providing ample resources for the server to handle demanding applications and workloads. This reliability is crucial for businesses that require uninterrupted access to critical services and applications.

Storage

The HPE Proliant ML30 Gen9 Server is equipped with 4LFF (Large Form Factor) storage, offering ample storage capacity for businesses that deal with large amounts of data. Storage plays a critical role in storing and retrieving data quickly, ensuring efficient data management and accessibility.

High Storage Capacity

The 4LFF storage configuration provides high storage capacity, allowing businesses to store large volumes of data on the server. This is particularly beneficial for businesses that deal with data-intensive applications or require long-term data retention.

Flexible Storage Options

The 4LFF storage configuration offers flexibility in terms of storage options. It allows businesses to choose the type of storage media that best suits their needs, whether it be traditional hard disk drives (HDDs) or solid-state drives (SSDs). This flexibility enables businesses to optimize their storage solution based on performance, capacity, and budget requirements.

Improved Data Accessibility

The 4LFF storage configuration ensures improved data accessibility by providing ample space for storing frequently accessed files and applications. This results in faster data retrieval times and improved overall system performance.

Data Redundancy and Protection

The 4LFF storage configuration allows for the implementation of data redundancy and protection measures, such as RAID (Redundant Array of Independent Disks) configurations. These configurations ensure that data remains accessible even in the event of a disk failure, providing businesses with added data security and peace of mind.

Scalability and Expansion

The 4LFF storage configuration offers scalability and expansion options, allowing businesses to easily add more storage capacity as their needs grow. This ensures that the server can accommodate future data growth and adapt to changing business requirements.

Power Supply

The HPE Proliant ML30 Gen9 Server is equipped with a 350W power supply, which is essential for providing a stable and reliable power source to the server's components. The power supply plays a crucial role in ensuring uninterrupted operation and protecting the server from power-related issues.

Stable Power Delivery

The 350W power supply delivers stable and consistent power to the server's components, ensuring reliable operation even under heavy load conditions. This stability is crucial for businesses that require continuous access to critical applications and services.

Energy Efficiency

The 350W power supply is designed to be energy efficient, minimizing power consumption and reducing energy costs for businesses. This is particularly important for businesses that operate multiple servers or have high power requirements.

Protection Against Power Outages

The 350W power supply offers protection against power outages and fluctuations by providing a reliable backup power source. In the event of a power outage, the server can continue to operate using an uninterruptible power supply (UPS) or other backup power solutions.

Reduced Downtime

The 350W power supply reduces downtime by ensuring that the server remains operational even during power-related issues. This is particularly important for businesses that rely on continuous access to critical data and applications.

Enhanced System Stability

The 350W power supply contributes to enhanced system stability by providing clean and stable power to the server's components. This stability minimizes the risk of system crashes or data corruption caused by unstable power supply conditions.

Optical Drive

The HPE Proliant ML30 Gen9 Server features a DVD optical drive, which allows for the reading and writing of CDs and DVDs. While optical drives have become less common in recent years, they still offer certain benefits and are useful in specific scenarios.

Data Backup and Archiving

The DVD optical drive enables users to back up important data onto DVDs, providing an additional layer of protection against data loss. DVDs can be easily stored off-site, ensuring that critical data remains safe even in the event of a catastrophic failure or data breach.

Software Installation

The DVD optical drive allows for the installation of software from physical media, such as operating systems or proprietary software. This can be particularly useful when dealing with legacy systems or specialized software that is only available on physical media.

Media Playback

The DVD optical drive enables users to play CDs and DVDs, allowing for the playback of audio CDs, video content, or installation of software that is distributed on physical media. This can be beneficial for businesses that need to access content from CDs or DVDs regularly.

Legacy Support

The presence of an optical drive ensures compatibility with legacy systems or software that may still rely on CDs or DVDs for installation or access to content. This can be important for businesses that have specific requirements or dependencies on older technologies.

Flexibility and Versatility

Even though optical drives are less common nowadays, having one in the server offers flexibility and versatility. It allows businesses to interact with different types of media and provides an additional option for data backup and software installation.

Features

The HPE Proliant ML30 Gen9 Server is classified as a performance server, offering a range of features and capabilities that are designed to enhance performance, reliability, and scalability for businesses of all sizes.

Robust Performance

As a performance server, the HPE Proliant ML30 Gen9 is built to deliver robust performance. It is equipped with powerful components, such as the E3-1220V6 processor and 8GB of memory, which ensure that the server can handle demanding workloads and deliver exceptional performance.

Reliability and Availability

The performance server is designed to offer high reliability and availability, ensuring that critical applications and services remain accessible at all times. Features such as redundant power supplies, advanced error correction mechanisms, and hot-swappable components minimize downtime and contribute to overall system stability.

Scalability and Flexibility

The performance server is highly scalable, allowing businesses to easily expand their infrastructure as their needs grow. It supports additional memory, storage, and expansion cards, providing flexibility and adaptability to changing business requirements.

Efficient Resource Utilization

The performance server optimizes resource utilization through features such as virtualization support, advanced management tools, and power management capabilities. This ensures that resources are allocated efficiently, resulting in cost savings and improved overall system performance.

Enhanced Data Security

The performance server offers enhanced data security features, such as built-in encryption capabilities, secure boot options, and comprehensive access control mechanisms. These features help businesses protect their sensitive data from unauthorized access or breaches.

In conclusion, the HPE Proliant ML30 Gen9 Server with its E3-1220V6 processor, 8GB of memory, 4LFF storage configuration, 350W power supply, DVD optical drive, and performance server features offers businesses a reliable, high-performance solution. Whether it's handling demanding workloads, providing ample storage capacity, ensuring uninterrupted operation, or offering flexibility and scalability, this server is designed to meet the needs of businesses seeking a powerful and efficient solution for their IT infrastructure.
