HPE Proliant ML30 Gen9 Xeon 3.7GHz 8GB DDR4 Server 872659-001

Processor

The HPE ML30 Gen9 Server is equipped with a powerful Xeon Quad-Core 3.7GHz processor. This feature sets it apart from other servers in its class, providing users with exceptional performance and reliability.

General Product Details of 872659-001

• Manufacturer: Hewlett Packard Enterprise
• Manufacturer Part Number: 872659-001
• Product Name: Proliant ML30 Gen9 - 4U Tower Server (Base Model)

Processor & Chipset Specifications

• Processor: Intel Xeon E3-1240v6
• Clock Speed: 3.7 GHz
• Turbo Boost Speed: 4.1 GHz
• Core Count: Quad-core
• Number of CPUs Supported: 1
• Socket Type: LGA1151
• Chipset: Intel C236

Cache Memory

• Cache Type: Smart Cache
• Cache Size: 8 MB per processor

Memory Specifications

• Standard Size: 8 GB
• Maximum Capacity: 64 GB
• Memory Type: DDR4 SDRAM - ECC
• Effective Speed: 2400 MHz
• Form Factor: DIMM 288-pin
• Configuration: 1 x 8 GB

Storage Capabilities

• Hard Drive: None
• Optical Drive: None

Storage Controllers

• Controller Type: RAID - PCIe x4
• Interface Type: SATA 6 Gb/s
• Controller Name: HP Dynamic Smart Array B140i
• Channels: 10
• RAID Levels: 0, 1, 5, 10

Display & Graphics

• Type: Integrated Matrox G200

Network & Communication

• Ethernet Ports: 2 x Gigabit Ethernet
• Controller: Broadcom BCM5720
• Protocols Supported: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management: Integrated Lights-Out 4
• Additional Features: Wake On LAN (WoL), PXE Support
• Compliance Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

Expansion & Connectivity

• Total Bays: 5.25" External: 1 (free), 3.5" LFF Hot-swap: 4 (free)

Expansion Slots

• Total Slots: DIMM 288-pin: 4 (3 free), CPU: 1 (0 free)
• PCIe Slots:
  • PCIe 3.0 x16: 1 (full-length, full-height, 1 free)
  • PCIe 3.0 x4: 2 (full-length, full-height, x1 Mode, 2 free)
  • PCIe 3.0 x8: 1 (half-length, full-height, x4 Mode, 1 free)
• MicroSD Card Slot: 1 (internal, 1 free)

Interfaces & Ports

• Video Output: 1 x VGA (Rear)
• Networking Ports: 2 x Gigabit Ethernet (Rear), 1 x Gigabit Ethernet / HP iLO
• USB Ports:
  • USB 3.0: 6 (4 Front, 2 Rear)
  • USB 2.0: 4 (2 Rear, 2 Internal)

Miscellaneous Specifications

• ACPI 2.0b
• FCC Class B Certified
• EN 61000-3-2
• EN55022
• ICES-003
• EN 61000-3-3
• EN55024
• CISPR 22
• FCC CFR47 Part 15
• IEC 60950-1
• EN 60950-1
• GB 9254
• CNS 13438

Power Specifications

• Power Supply Type: Internal
• Installed Quantity: 1
• Nominal Voltage: AC 120/230 V (50/60 Hz)
• Power Output: 460 Watts

Dimensions & Weight

• Width: 6.9 inches
• Depth: 18.7 inches
• Height: 14.5 inches
• Weight: 29.89 lbs

Unmatched Processing Power

The Xeon Quad-Core 3.7GHz processor is designed to handle demanding workloads and complex applications with ease. It offers four cores, each capable of executing multiple tasks simultaneously. This means that you can run resource-intensive applications, such as virtualization software or databases, without experiencing any slowdowns or performance bottlenecks.

Enhanced Efficiency

The processor's high clock speed of 3.7GHz ensures swift and responsive performance, allowing you to complete tasks quickly and efficiently. Whether you are running data analytics, hosting websites, or managing a small business infrastructure, the HPE ML30 Gen9 Server with its powerful processor ensures that you can handle your workload efficiently.

Seamless Scalability

The Xeon Quad-Core 3.7GHz processor is designed to scale effortlessly as your business grows. It supports the latest technologies and can accommodate future upgrades, ensuring that your server can keep up with your expanding needs.

Reliability and Stability

Reliability is crucial for any server environment, and the HPE ML30 Gen9 Server's Xeon Quad-Core 3.7GHz processor delivers just that. It is built to withstand continuous operation without compromising on performance or stability. This means that you can rely on this server to handle your critical workloads without any interruptions.

Improved Security

The Xeon Quad-Core 3.7GHz processor also incorporates advanced security features that protect your server and data from potential threats. These features include hardware-enhanced encryption techniques and built-in security protocols, ensuring that your sensitive information remains secure.

RAM

In addition to its powerful processor, the HPE ML30 Gen9 Server is equipped with 8GB DDR4 RAM. This generous amount of memory ensures smooth multitasking and efficient handling of data, making it an ideal choice for businesses of all sizes.

Enhanced Multitasking

The 8GB DDR4 RAM allows you to run multiple applications simultaneously without experiencing any performance degradation. Whether you are performing complex calculations, running virtual machines, or managing a large database, this server's ample memory ensures that you can handle your workload efficiently.

Faster Data Access

The DDR4 RAM technology employed in the HPE ML30 Gen9 Server offers faster data transfer rates compared to its predecessors. This means that your applications can access data from memory more quickly, resulting in improved overall system performance. With 8GB of DDR4 RAM, you can expect faster response times and reduced latency, ensuring a seamless user experience.

Scalability and Future-Proofing

With 8GB of RAM, the HPE ML30 Gen9 Server provides a solid foundation for your growing business needs. It allows you to run resource-intensive applications and handle large datasets without any performance constraints. Additionally, this server supports expandable memory configurations, enabling you to upgrade to higher capacities as your requirements evolve.

Reliability and Stability

The HPE ML30 Gen9 Server's 8GB DDR4 RAM is built for reliability and stability. It undergoes rigorous testing to ensure optimal performance and compatibility with the server's hardware components. This ensures that you can rely on this server to deliver consistent performance even under heavy workloads.

Efficient Virtualization

Virtualization has become an essential technology for businesses, allowing them to consolidate their infrastructure and improve resource utilization. The 8GB DDR4 RAM in the HPE ML30 Gen9 Server enables efficient virtualization, allowing you to run multiple virtual machines simultaneously without compromising on performance. This feature is particularly beneficial for businesses that rely on virtualization for their operations, such as cloud service providers or organizations with extensive testing and development needs.

Part Number

The HPE ML30 Gen9 Server has a unique part number, 872659-001. This alphanumeric code is essential for identifying and ordering the specific server model and its associated components.

Accurate Identification

The part number, 872659-001, ensures accurate identification of the HPE ML30 Gen9 Server model. It allows you to communicate precisely with vendors or support teams when requesting assistance or placing orders. By providing the correct part number, you can avoid any confusion or errors that may arise from using generic descriptions or incomplete product identifiers.

Seamless Upgrades

The part number also plays a crucial role when upgrading or expanding your server infrastructure. By referencing the part number, you can ensure compatibility between existing components and any new additions. This simplifies the upgrade process and minimizes the risk of compatibility issues, saving you time and effort.

Efficient Inventory Management

For businesses that manage a large number of servers, having a unique part number like 872659-001 makes inventory management more efficient. It enables you to keep track of each server model and its specific configuration accurately. This information is invaluable for planning future upgrades, tracking warranties, or troubleshooting any hardware-related issues that may arise.

Warranty and Support

The part number is also essential when it comes to warranty and support services. By providing the correct part number, you can ensure that you receive the appropriate level of service and support for your specific server model. This includes access to firmware updates, technical assistance, and any warranty claims you may need to make.

Product Differentiation

In a market saturated with various server models and configurations, the unique part number, 872659-001, helps differentiate the HPE ML30 Gen9 Server from its competitors. It allows users to identify this specific server model easily and understand its distinct features and capabilities. This differentiation is crucial for businesses looking for a reliable, high-performance server that meets their specific requirements.

Overall, the Xeon Quad-Core 3.7GHz processor, 8GB DDR4 RAM, and unique part number 872659-001 are all integral features of the HPE ML30 Gen9 Server. These features combine to deliver exceptional performance, scalability, reliability, and ease of management. Whether you are a small business owner or an IT professional managing a complex infrastructure, this server provides the power and flexibility you need to support your operations effectively.
