Processor
The HPE ML310e Gen8 V2 736661-S01 Tower Server is equipped with an Intel Xeon Quad Core E3 1230v3 processor, which offers exceptional performance and reliability for demanding applications. This powerful processor is designed to handle intensive workloads and deliver efficient multitasking capabilities. With a base clock speed of 3.3GHz and a maximum turbo frequency of 3.7GHz, the E3 1230v3 ensures smooth and seamless operation even under heavy load.
General Details
Manufacturer Information
- Brand: Hewlett Packard Enterprise
- Part Number: 736661-S01
- Product Name: Proliant ML310e G8 V2 - 1-Way 4U Tower Server (S-buy)
Processor & Chipset
Processor Specifications
- Type: Intel Xeon E3-1230v3
- Clock Speed: 3.3 GHz
- Max Turbo Frequency: 3.7 GHz
- Core Count: Quad-core
- 64-bit Support: Yes
- Installed Quantity: 1
- Maximum Supported Quantity: 1
- Upgradability: Upgradable
- Chipset: Intel C222
Cache Memory
Details
- Cache Type: L3 Cache
- Installed Capacity: 8 MB
- Cache Per Processor: 8 MB
RAM
Memory Specifications
- Installed Size: 8 GB (upgradable to 32 GB)
- Technology: DDR3 SDRAM with ECC
- Effective Memory Speed: 1600 MHz
- Memory Speed Rating: 1600 MHz
- Memory Standard: PC3-12800
- Form Factor: DIMM 240-pin
- Slots Available: 4 total (2 free)
- Features: Unbuffered, Dual Channel Architecture, HP SmartMemory
- Configuration: 2 x 4 GB
Storage & Optical Drives
Hard Drive & Optical Drive
- Hard Drive: Not Included
- Optical Drive Type: DVD-RW / DVD-Writer - SATA
Storage Controller
Controller Specifications
- Type: Integrated SATA
- Interface: PCIe 2.0
- Controller Name: HP Dynamic Smart Array B120i
- Channels: 6
- RAID Levels: RAID 0, RAID 1, RAID 10
Display & Graphics
Graphics Controller
- Type: Integrated
- Graphics Processor: Matrox G200
- Video Output: VGA
Network & Communication
Networking Details
- Networking Type: Integrated
- Interface: PCI Express x2
- Ethernet Ports: 2 x Gigabit Ethernet
- Ethernet Controller: HP NC332i
- Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
- Remote Management Protocol: Integrated Lights-Out 4
- Features: Wake On LAN (WOL), PXE Support
- Compliance Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Expansion & Connectivity
Expansion Bays
- External 5.25-inch: 1 total (1 free)
- Hot-swap 3.5-inch LFF: 4 total (4 free)
Expansion Slots
- CPU Slot: 1 total (0 free)
- DIMM 240-pin: 4 total (2 free)
- PCIe 2.0 x4: 1 total (1 free)
- PCIe 2.0 x8: 1 total (1 free)
- PCIe 3.0 x8: 1 total (1 free)
- PCIe 3.0 x16: 1 total (1 free)
Interfaces & Ports
- Serial Port: 1
- VGA Port: 1
- Gigabit Ethernet Ports: 2
- HP iLO Port: 1
- USB 2.0 Ports: 5 (4 front, 1 internal)
- USB 3.0 Ports: 2
Miscellaneous
Features
- Administrator Password Protection
- Power-on Password Protection
Compliance Standards
- ACPI 2.0b
- FCC Class B Certified
- EN 61000-3-2
- EN55022
- ICES-003
- EN 61000-3-3
- EN55024
- CISPR 22
- FCC CFR47 Part 15
- IEC 60950-1
- EN 60950-1
- BSMI CNS 13438
Manufacturer Selling Program
HP Smart Buy
Power Supply
Specifications
- Device Type: Power Supply
- Nominal Voltage: AC 120/230 V (50/60 Hz)
- Power Output: 350 Watt
- Efficiency: 85%
Dimensions & Weight
- Width: 6.9 inches
- Depth: 18.7 inches
- Height: 14.5 inches
- Weight: 25.3 lbs
Benefits of the Intel Xeon Quad Core E3 1230v3 Processor
1. Enhanced Performance
The E3 1230v3 processor delivers excellent performance thanks to its advanced architecture and quad-core design. It provides substantial processing power for tasks such as virtualization, data analysis, and content creation. The high clock speeds and efficient processing cores enable faster execution of instructions, resulting in improved overall system performance.
2. Efficient Multitasking
With four processing cores and Intel Hyper-Threading technology, the E3 1230v3 allows for efficient multitasking. It can handle multiple threads simultaneously, enabling smooth execution of concurrent tasks. This is particularly beneficial for businesses that require running multiple applications or virtual machines concurrently without experiencing lag or slowdowns.
3. Enhanced Security Features
The E3 1230v3 processor incorporates advanced security features to protect sensitive data and prevent unauthorized access. It supports Intel's Trusted Execution Technology (TXT), which helps safeguard the server against malicious attacks and ensures the integrity of critical system components.
4. Energy Efficiency
Intel's processors are renowned for their energy efficiency, and the E3 1230v3 is no exception. It is designed to deliver optimal performance while minimizing power consumption, resulting in reduced energy costs for businesses. This processor also supports Intel's Enhanced SpeedStep Technology, which dynamically adjusts the processor's power and performance based on workload demands.
Importance of the Intel Xeon Quad Core E3 1230v3 Processor
1. High Performance Computing
The E3 1230v3 processor is well-suited for high-performance computing (HPC) applications that require significant processing power. It can handle complex calculations, simulations, and data analysis tasks with ease. Whether you are running sophisticated scientific simulations or performing financial analysis, the E3 1230v3 ensures fast and accurate results.
2. Virtualization Capabilities
Virtualization has become a crucial aspect of modern IT infrastructure. The E3 1230v3 processor's capabilities make it an ideal choice for virtualization environments. It can efficiently handle virtual machines, allowing businesses to consolidate their physical servers and optimize resource utilization. This not only reduces hardware costs but also simplifies management and improves scalability.
3. Media and Content Creation
For media professionals and content creators, the E3 1230v3 processor offers exceptional performance for tasks such as video editing, rendering, and encoding. Its powerful cores and high clock speeds ensure smooth playback and speedy processing of multimedia files. Whether you are editing high-resolution videos or working with complex 3D models, the E3 1230v3 can handle the most demanding content creation tasks.
4. Reliable Server Operation
Reliability is a critical factor in server environments, where downtime can result in significant financial losses and damage to reputation. The E3 1230v3 processor is known for its stability and dependability, ensuring uninterrupted server operation even under heavy workloads. With error-correcting code (ECC) memory support, it can detect and correct memory errors, further enhancing system reliability.
Overall, the Intel Xeon Quad Core E3 1230v3 processor provides exceptional performance, efficient multitasking capabilities, enhanced security features, and energy efficiency. Its high clock speeds, advanced architecture, and reliable operation make it an excellent choice for businesses that require powerful computing capabilities for a wide range of applications and workloads.
