HPE Proliant Ml350 G9 S-Buy 1x Xeon E5-2640v3/2.6GHz, 16GB DDR4, HPE Smart Array P440ar - 776978-S01

Processor

The HPE Proliant Ml350 G9 S-Buy Tower Server is equipped with a powerful 1x Xeon E5-2640v3/2.6GHz Octa-Core processor, which is a key feature that sets it apart from other servers in its class. This processor delivers exceptional performance and reliability, making it an ideal choice for businesses of all sizes.

Main Information of HPE Proliant

• Manufacturer: Hewlett Packard Enterprise
• Manufacturer Part Number: 776978-S01
• Product Name: Proliant ML350 G9 5U-Tower Server (Smart Buy)

Processor & Chipset

• Type: Intel Xeon E5-2640v3
• Clock Speed: 2.6 GHz
• Cores: Octa-core (8 cores)
• 64-bit Support: Yes
• Installed Quantity: 1
• Maximum Supported Quantity: 2
• Upgradability: Upgradable
• Chipset Model: Intel C610

Cache Memory

• Cache Type: L3 Cache
• Installed Size: 20 MB
• Cache Per Processor: 20 MB

Memory

• Size: 16 GB (upgradable to 384 GB)
• Technology: DDR4 SDRAM
• Speed: 1866 MHz
• Compliance: PC4-17000
• Form Factor: DIMM 288-pin

Supported RAM Configurations

• PC4-17000: Up to 768 GB (Load-reduced)
• PC4-17000: Up to 384 GB (Registered)

Storage & Controller

• Hard Drive: No HDD Included
• Storage Controller Type: RAID - Plug-in Card - PCI Express 3.0 x8
• Controller Interface: SATA-600 / SAS 3.0
• Controller Name: Smart Array P440ar with 2 GB FBWC
• RAID Levels: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 60, RAID 1 ADM, RAID 10 ADM
• Buffer Size: 2 GB

Display & Graphics

• Graphics Type: Integrated
• Graphics Controller: Matrox G200
• Video Interfaces: VGA

Network & Communication

• Networking Type: Integrated
• Ethernet Ports: 4 x Gigabit Ethernet
• Ethernet Controller: HP 331i
• Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management Protocol: IPMI 2.0, SMASH CLP
• Remote Management Controller: Integrated Lights-Out 4
• Features: Wake on LAN (WoL), PXE Support
• Standards Compliant: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

Expansion & Connectivity

• Front Accessible: 1 x 5.25" Slim Line
• Hot-Swap: 8 x 2.5" SFF

Expansion Slots

• Memory Slots: 24 (total) / 23 (free) DIMM 288-pin
• Processor Slots: 2 (total) / 1 (free)
• PCI Express 3.0 x16: 1 (total) / 1 (free) - Full-length, Full-height (x8 Mode)
• PCI Express 3.0 x8: 4 (total) / 4 (free) - Full-length, Full-height (x4 Mode)
• PCI Express 2.0 x8: 1 (total) / 1 (free) - Half-length, Full-height (x4 Mode)
• PCIe 3.0 x16: 3 (total) / 3 (free) - Full-length, Full-height
• SD Card Slot: 1 (total) / 1 (free) - Internal

Interfaces & Ports

• Serial Port: 1
• VGA Port: 1
• LAN Ports: 4 x Gigabit Ethernet
• HP iLO Port: 1
• USB 3.0 Ports: 2
• USB 2.0 Ports: 4 (2 Front, 2 Rear)

Power Description

• Device Type: Hot-plug Power Supply
• Redundancy: Yes
• Redundancy Scheme: 1+1
• Installed Quantity: 2
• Maximum Supported Quantity: 2
• Voltage Required: AC 120/220 V (50/60 Hz)
• Power Provided: 800 Watt
• 80 Plus Certification: 80 Plus Platinum

Dimensions & Weight

• Width: 8.6 in
• Depth: 30.3 in
• Height: 18.3 in
• Weight: 66.1 lbs

Unparalleled Performance

The Xeon E5-2640v3 processor boasts eight cores and a clock speed of 2.6GHz, allowing it to handle demanding workloads with ease. Whether you're running resource-intensive applications or performing complex computations, this processor ensures smooth and efficient operations, improving overall productivity.

Multitasking Efficiency

With eight cores and sixteen threads, the Xeon E5-2640v3 processor excels at multitasking. It can effortlessly handle multiple tasks simultaneously, ensuring that your server can efficiently handle a high volume of requests without any lag or slowdowns. This capability is particularly beneficial for businesses that rely on their servers to support numerous users or run multiple applications simultaneously.

Enhanced Virtualization

Virtualization has become an essential aspect of modern server infrastructure, and the Xeon E5-2640v3 processor is designed to excel in virtualized environments. With support for advanced virtualization technologies such as Intel VT-x and VT-d, this processor enhances the performance and efficiency of virtual machines, allowing businesses to consolidate their infrastructure and optimize resource utilization.

Improved Energy Efficiency

Energy efficiency is a crucial consideration for any server deployment, as it directly impacts operating costs. The Xeon E5-2640v3 processor incorporates Intel's advanced power-saving technologies, such as Enhanced SpeedStep and Demand-Based Switching, to dynamically adjust power consumption based on workload demands. This feature not only reduces electricity costs but also contributes to a greener IT infrastructure.

Reliability and Scalability

The Xeon E5-2640v3 processor is built on Intel's reliable and scalable architecture, ensuring the server's long-term stability and future scalability. It supports up to 768GB of DDR4 memory, allowing businesses to easily expand their server's memory capacity as their needs grow. This scalability ensures that the server can accommodate increasing workloads and adapt to changing business requirements.

Security Features

In today's digital landscape, data security is of utmost importance. The Xeon E5-2640v3 processor incorporates Intel's advanced security features, including Intel AES-NI and Intel Trusted Execution Technology (TXT). These features provide hardware-based encryption and secure execution environments, protecting sensitive data and ensuring the integrity of critical applications.

In summary, the HPE Proliant Ml350 G9 S-Buy Tower Server's 1x Xeon E5-2640v3/2.6GHz Octa-Core processor offers exceptional performance, multitasking efficiency, enhanced virtualization capabilities, improved energy efficiency, reliability, scalability, and advanced security features. This processor is a crucial component for businesses that require a powerful and reliable server solution to support their demanding workloads.
