HPE Proliant ML350p G8 5U Rack Server 646677-001

Processor

The HPE ML350p G8 Rack Server is equipped with an Intel Xeon 2.3GHz processor. This powerful processor is designed to deliver exceptional performance and reliability, making it an ideal choice for users who require high computing capabilities.

General Product Information

Manufacturer Details

• Brand: Hewlett Packard Enterprise
• Part Number: 646677-001
• Model: ProLiant ML350p Gen8 - 2U Rack-Mountable Server (Base Model)

Processor & Chipset Specifications

Processor Type

• Type: Intel Xeon E5-2630
• Clock Speed: 2.30 GHz
• Core Count: Hexa-core (6 cores)
• 64-bit Architecture: Yes
• Installed Quantity: 1
• Maximum Supported Quantity: 2
• Upgradability: Supports Upgrade

Chipset and Features

• Chipset Model: Intel C600
• Main Features: Hyper-Threading Technology

Cache Memory Details

• Type: L3 Cache
• Installed Size: 15 MB
• Cache per Processor: 15 MB

Memory Specifications

Installed RAM

• Size: 8 GB
• Maximum Supported: 384 GB
• Technology: DDR3 SDRAM
• Effective Memory Speed: 1333 MHz
• Rated Memory Speed: 1333 MHz
• Memory Compliance: PC3L-10600R
• Form Factor: DIMM 240-pin
• Memory Slots: 24 total, 22 empty
• Configuration: 2 x 4 GB
• Supported RAM Types: PC3-12800 (384 GB Registered), PC3-10600 (128 GB Unbuffered), Advanced ECC

Storage & Optical Drives

Hard Drive

• Type: None

Optical Drive

• Type: DVD-ROM
• Interface: Serial ATA

Storage Controller Information

• Type: Integrated RAID Controller
• Interface Type: SATA 6 Gb/s / SAS 6 Gb/s
• Controller Name: Smart Array P420i with 1 GB FBWC
• Channel Quantity: 8
• RAID Levels Supported: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
• Buffer Size: 1 GB

Graphics & Display

Graphics Processor

• Type: Integrated
• Processor: Matrox G200
• Video Interface: VGA

Networking & Communication

Network Interfaces

• Type: Integrated Ethernet
• Ports: 4 x Gigabit Ethernet
• Controller: HP 331i
• Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management Protocols: IPMI 2.0, SMASH CLP
• Management Controller: Integrated Lights-Out 4 (iLO 4)
• Additional Features: Wake-On-LAN (WoL), PXE Support
• Standards Compliance: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

Expansion & Connectivity

Expansion Bays

• Front Accessible: 3 total, 2 free (5.25in x 1/2h)
• Hot-Swap: 6 total, 6 free (3.5in LFF)

Expansion Slots

• DIMM Slots: 24 total, 22 free (240-pin)
• CPU Slots: 2 total, 1 free
• PCIe 3.0 x16: 1 total, 1 free (Full-length, Full-height, x8 mode)
• PCIe 3.0 x8: 4 total, 4 free (Full-length, Full-height, x4 mode)
• PCIe 2.0 x8: 1 total, 1 free (Half-length, Full-height, x4 mode)
• PCIe 3.0 x16: 3 total, 3 free (Full-length, Full-height)
• SD Card (internal): 1 total, 1 free

Interfaces & Ports

• Serial Port: 1
• VGA Port: 1
• LAN Ports: 4 x Gigabit Ethernet
• HP iLO Port: 1
• USB Ports: 8 x USB 2.0 (4 front, 4 rear)

Additional Features

Security & Compliance

• Administrator Password
• Power-On Password
• Serial Port I/O Control
• Compliance Standards: ACPI 2.0b, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, IEC 60950-1, EN 60950-1, BSMI CNS 13438, FCC CFR47 Part 15 B

Power Supply

• Type: Hot-Plug Power Supply
• Redundancy: Optional (1+1 with Optional Power Supply)
• Installed Quantity: 1
• Maximum Supported Quantity: 2
• Voltage Required: AC 120/230 V (50/60 Hz)
• Power Output: 750 Watts
• 80 Plus Certification: 80 Plus Gold

Physical Dimensions & Weight

• Width: 19 in
• Depth: 28.8 in
• Height: 8.6 in
• Weight: 60.85 lbs

Enhanced Performance

With the Intel Xeon 2.3GHz processor, the HPE ML350p G8 Rack Server offers enhanced performance that can handle demanding workloads efficiently. The processor's high clock speed ensures faster data processing, allowing users to run resource-intensive applications without experiencing significant slowdowns. Whether you are running complex simulations or handling large databases, the processor's power enables smooth and uninterrupted operations.

Improved Multitasking

Multitasking is a crucial aspect of any server environment, and the Intel Xeon 2.3GHz processor excels in this area. Its multiple cores and threads enable efficient multitasking, allowing users to run multiple applications simultaneously without compromising performance. This feature is particularly beneficial for businesses that require their servers to handle a variety of tasks simultaneously, such as virtualization, database management, and web hosting.

Energy Efficiency

The Intel Xeon 2.3GHz processor is designed with energy efficiency in mind. It incorporates advanced power-saving technologies that optimize power consumption without sacrificing performance. By efficiently utilizing power resources, this processor helps reduce energy costs, making it an environmentally-friendly choice for businesses aiming to minimize their carbon footprint.

Reduced Downtime

With the Intel Xeon 2.3GHz processor's reliability and stability, users can experience reduced downtime. The server's robust processing capabilities enable rapid data processing, minimizing the chances of bottlenecks and system failures. This feature is crucial for businesses that rely heavily on their servers' continuous availability and cannot afford prolonged periods of downtime.

Scalability

The HPE ML350p G8 Rack Server's Intel Xeon 2.3GHz processor offers scalability options to accommodate future growth and changing business needs. With multiple cores and threads, the processor can handle increased workloads as your business expands. This scalability ensures that your server investment remains relevant and capable of meeting your evolving requirements.

Virtualization Capabilities

The Intel Xeon 2.3GHz processor is well-suited for virtualization environments. Its high performance and multitasking capabilities enable efficient virtual machine management, allowing businesses to consolidate their infrastructure and reduce hardware costs. Moreover, virtualization enhances flexibility and agility by enabling rapid deployment of new applications and services.

Security Features

Security is of paramount importance in today's digital landscape, and the Intel Xeon 2.3GHz processor includes built-in security features that help protect sensitive data. These features include hardware-based encryption, secure boot, and integrated security technologies that defend against various threats. By leveraging these security capabilities, businesses can ensure the integrity and confidentiality of their critical data.

Form Factor

The HPE ML350p G8 Rack Server boasts a 5U form factor, which is an essential feature for users looking for a server that optimizes space utilization while offering expandability and ease of maintenance.

Space Efficiency

The 5U form factor of the HPE ML350p G8 Rack Server allows for efficient use of rack space. With this compact design, businesses can maximize their server density within a limited rack footprint. This is particularly advantageous for data centers with space constraints or organizations that need to accommodate multiple servers within a limited physical area.

Easy Maintenance

The 5U form factor simplifies server maintenance tasks due to its spacious interior. IT personnel can easily access and replace components, such as hard drives, RAM modules, and expansion cards, without the need for intricate maneuvers. This ease of maintenance reduces downtime during hardware upgrades or repairs, ensuring that the server remains operational and minimizing disruptions to business operations.

Expansion Possibilities

The 5U form factor provides ample room for expansion, making the HPE ML350p G8 Rack Server a versatile choice for businesses with growing needs. The server can accommodate additional storage drives, PCI cards, and other peripherals, allowing users to scale their infrastructure without requiring a complete overhaul. This scalability ensures that the server can adapt to changing business requirements and support future growth.

Improved Airflow and Cooling

The spacious design of the 5U form factor facilitates better airflow management within the server chassis. This helps dissipate heat efficiently and prevents overheating, which can lead to system failures and performance degradation. With improved cooling capabilities, the HPE ML350p G8 Rack Server can operate reliably even under heavy workloads or in environments with restricted airflow.

Reduced Cable Clutter

The 5U form factor enables better cable management within the server chassis. With more space to route and organize cables, IT personnel can ensure a tidy and clutter-free environment. Reduced cable clutter not only improves aesthetics but also enhances airflow and simplifies troubleshooting by providing clear visibility of connections and minimizing the chances of accidental disconnections.

Rack Space Optimization

The HPE ML350p G8 Rack Server's 5U form factor allows businesses to make optimal use of their rack space. By utilizing this compact design, organizations can reduce their overall rack count while maintaining or increasing their server capacity. This optimization leads to cost savings in terms of rack space rental costs and lower power consumption.

Compatibility with Existing Infrastructure

The 5U form factor of the HPE ML350p G8 Rack Server ensures compatibility with standard server racks and cabinets. This compatibility eliminates the need for additional infrastructure modifications or investments, saving businesses time and money. The server seamlessly integrates into existing rack setups, making it a convenient choice for organizations that want to upgrade their servers without extensive reconfigurations.

Part Number

The HPE ML350p G8 Rack Server's part number is 646677-001. This unique identifier plays a crucial role in identifying and procuring the server model accurately.

Model Identification

The part number, 646677-001, helps businesses and IT personnel identify the exact model variant of the HPE ML350p G8 Rack Server. With numerous server models available in the market, having a specific part number ensures that you are purchasing the correct server with the desired specifications and features. This eliminates any confusion or potential compatibility issues that may arise from selecting an incorrect model.

Easy Maintenance and Support

The part number simplifies maintenance and support processes for the HPE ML350p G8 Rack Server. When contacting technical support or ordering replacement parts, providing the part number ensures accuracy and speeds up the resolution of issues. IT personnel can easily reference the part number to access relevant documentation, firmware updates, and drivers specific to the server model, streamlining maintenance activities.

Compatibility Assurance

The part number guarantees compatibility with other HPE products and accessories. It ensures that any expansion cards, storage drives, or networking components designed for the HPE ML350p G8 Rack Server will seamlessly integrate without compatibility issues. This assurance simplifies the process of expanding or upgrading the server by eliminating the need for extensive product research and validation.

Warranty Validation

The part number serves as a reference point for warranty validation. By providing the part number, businesses can easily determine the warranty status and coverage of their HPE ML350p G8 Rack Server. This information is crucial for effective asset management and planning future maintenance activities or upgrades.

Inventory Management

The part number facilitates efficient inventory management for businesses that own multiple HPE ML350p G8 Rack Servers. By accurately tracking the part numbers of individual servers, organizations can maintain an organized inventory and quickly identify available resources. This streamlines asset allocation, prevents over or underutilization of servers, and enables effective resource planning.

Procurement Accuracy

When procuring additional HPE ML350p G8 Rack Servers or replacement parts, having the correct part number ensures accuracy during the procurement process. IT personnel can use the part number to order servers or components directly, avoiding any confusion or delays caused by incorrect identification. This accuracy minimizes procurement errors and eliminates unnecessary returns or exchanges.

Future Compatibility

The part number is also essential for ensuring future compatibility and interoperability with upcoming server models or product releases. It allows businesses to track product updates and technological advancements in the HPE ML350p G8 Rack Server series, ensuring that future upgrades or expansions remain compatible with existing infrastructure. This future-proofing capability maximizes the longevity and flexibility of the server investment.

In conclusion, the HPE ML350p G8 Rack Server's Intel Xeon 2.3GHz processor offers enhanced performance, improved multitasking capabilities, energy efficiency, reduced downtime, scalability, virtualization capabilities, and built-in security features. The server's 5U form factor provides space efficiency, easy maintenance, expansion possibilities, improved airflow and cooling, reduced cable clutter, rack space optimization, and compatibility with existing infrastructure. The part number, 646677-001, ensures accurate model identification, easy maintenance and support, compatibility assurance, warranty validation, inventory management, procurement accuracy, and future compatibility. These features and benefits make the HPE ML350p G8 Rack Server an excellent choice for users who require a powerful, space-efficient, and reliable server solution.
