SDFHQ85DAB02T Kioxia 1.6TB PCI-E NVME TLC Mixed Use SSD

Kioxia SDFHQ85DAB02T PCI-E NVMe 1.6TB Enterprise SSD

The exceptional capabilities of the Kioxia SDFHQ85DAB02T, a high-performance solid state drive engineered for demanding enterprise environments requiring balanced read/write operations and exceptional reliability.

Product Overview

• Manufacturer: Kioxia
• Model Identifier: SDFHQ85DAB02T
• Storage Category: Enterprise Mixed-Use Solid State Drive
• Storage Capacity: 1.6 Terabytes

Technical Specifications

• Form Factor: 2.5-inch
• Height Profile: 15mm (suitable for most server bays)
• Physical Dimensions: 69.85mm width × 100.45mm length
• Host Connection: PCI Express 4.0 interface
• NVMe Protocol Support: Yes, optimized for low latency
• Flash Memory Type: BiCS FLASH™ TLC (3-bit per cell)
• Write Endurance Rating: 3 Drive Writes Per Day (DWPD)
• Memory Architecture: Triple-Level Cell with enterprise enhancements

Performance Capabilities and Speed Metrics

Sequential Data Transfer Rates

• Maximum Sequential Read Throughput: Up to 6,900 MB/s
• Maximum Sequential Write Throughput: Up to 2,800 MB/s

Random Access Performance

• Random Read Operations (4K): Up to 1,300,000 IOPS
• Random Write Operations (4K): Up to 215,000 IOPS

Kioxia SDFHQ85DAB02T 1.6TB PCI-E NVME SSD Overview

The Kioxia SDFHQ85DAB02T 1.6TB PCI-E NVME TLC Enterprise Mixed Use SSD represents a robust solution for modern data centers and enterprise storage infrastructures. Engineered to deliver high-performance storage with exceptional reliability, this SSD is tailored for workloads that require a balance between read-intensive and mixed-use operations. Utilizing advanced TLC NAND technology, the drive ensures both endurance and efficiency, making it an ideal choice for database applications, virtualization, and high-transaction environments.

High-Performance PCI-E NVMe Architecture

Built on the PCI-E NVMe interface, the SDFHQ85DAB02T leverages the full potential of NVMe protocol for ultra-low latency and high throughput. Unlike traditional SATA-based drives, this NVMe SSD provides significantly faster data transfer rates, which are critical for enterprise applications where every millisecond counts. Its architecture is optimized to handle simultaneous read and write operations efficiently, ensuring minimal bottlenecks in multi-threaded workloads.

Advanced TLC NAND Technology

This enterprise SSD incorporates Triple-Level Cell (TLC) NAND flash, which stores three bits of data per cell. This design provides an optimal balance between storage density, performance, and cost-efficiency. TLC NAND in the Kioxia SDFHQ85DAB02T is engineered for enterprise-grade endurance, supporting high workloads while maintaining consistent data integrity. Enhanced error correction algorithms further ensure long-term reliability, protecting sensitive enterprise data from potential corruption.

Mixed-Use Endurance and Reliability

Designed for mixed-use workloads, the 1.6TB Kioxia NVMe SSD can manage a combination of read and write operations with remarkable efficiency. Enterprises can depend on it for applications such as online transaction processing, virtualization, and heavy database operations. Its endurance rating is tailored to handle substantial write cycles, minimizing the risk of performance degradation over time. Additionally, features like power-loss protection and robust firmware safeguards ensure that data is secure even in unexpected scenarios.

Enterprise Storage Optimization

The SDFHQ85DAB02T is optimized for data centers seeking to maximize performance while reducing operational costs. With low latency and consistent IOPS, this SSD enables faster application response times and improved overall system performance. The high bandwidth of the PCI-E interface allows IT administrators to consolidate workloads without compromising performance, making it suitable for large-scale deployment in servers, storage arrays, and cloud infrastructures.
