WS-C3560-12PC-S Cisco Catalyst 12 Ports Ethernet Switch

Ports

The Cisco WS-C3560-12PC-S Ethernet Switch is equipped with 12 ports, making it an ideal choice for small to medium-sized businesses that require a reliable and efficient network solution. These ports provide users with the ability to connect multiple devices, such as computers, printers, and servers, to the network.

Overview of the Cisco WS-C3560-12PC-S Ethernet Switch

• Manufacturer: Cisco
• Part Number (SKU#): WS-C3560-12PC-S
• Product Family: Catalyst
• Series: 3560
• Product Category: Managed Ethernet Switch

Comprehensive Interfaces and Ports

• Network Ports: Total of 12 ports available
• PoE Capable Ports: All 12 ports support Power over Ethernet (PoE)
• Expansion Slots: 1 Gigabit Ethernet expansion slot
• Additional Network Connections: 12 Fast Ethernet ports

Robust Performance Features

• Supported Media: Twisted Pair cables
• Ethernet Technology: Compatible with Fast Ethernet standards
• Network Standards: Supports 10/100Base-TX protocols

Environmental Specifications

• Operating Temperature: From 32°F to 113°F
• Humidity Range: Operates efficiently between 10% and 85% humidity

Flexible I/O Expansion Capabilities

• Expansion Slots: One available slot for SFP modules

Advanced Features of the Catalyst 3560 Series

• Supports auto-sensing and auto-negotiation per device
• Includes IP-routing, DHCP support, and ARP protocol
• Enhanced with VLAN support, IGMP snooping, and trunking
• Comprehensive traffic shaping features, including storm control for broadcast, multicast, and unicast traffic
• Supports multiple Spanning Tree Protocols (STP, RSTP, MSTP)
• Equipped with Quality of Service (QoS) and Jumbo Frames support
• Additional features include DHCP snooping, Dynamic ARP Inspection (DAI), and fanless design

Networking and Communication Capabilities

• Network Layer: Operates at Layer 2

Management and Protocol Support

• Manageability: Fully manageable with extensive protocol support
• Routing Protocols: RIP-1, RIP-2, HSRP, static IP routing, RIPng
• Remote Management: SNMP versions 1, 2, 3, RMON 1, 2, 3, 9, Telnet, TFTP, SSH-2

Power Supply Details

• Input Voltage: Compatible with both 110V AC and 220V AC

Compatibility and Compliance Standards

• Optional Rack Mounting Kit: Available for purchase
• Compliance Certifications: FCC Class A, UL, TUV GS, cUL, EN 60950, EN55022, NOM, VCCI Class A ITE, IEC 60950, EN55024, UL 60950 Third Edition, CB, AS/NZ 3548 Class A, FCC Part 15, CSA C22.2 No. 60950-00, MIC

Increased Connectivity

With 12 ports available on the Cisco WS-C3560-12PC-S Ethernet Switch, users can connect a wide range of devices simultaneously. This increased connectivity is especially beneficial for businesses that require multiple devices to be connected to the network at the same time. It eliminates the need for additional switches or routers, simplifying the network infrastructure and reducing costs.

Improved Network Performance

Having 12 ports on this Ethernet switch allows for better network performance. Each port offers Fast Ethernet connectivity, enabling data transfer at speeds up to 100 Mbps. This ensures that data flows smoothly between connected devices, enhancing productivity and minimizing delays. Whether it's transferring large files or streaming high-definition videos, the Cisco WS-C3560-12PC-S Ethernet Switch can handle it with ease.

VLAN Support

The Cisco WS-C3560-12PC-S Ethernet Switch supports Virtual Local Area Networks (VLANs), a feature that allows network administrators to segment their network into smaller, more manageable subnetworks. With 12 ports available, users can create multiple VLANs and assign specific ports to each VLAN. This provides enhanced security and control over network traffic, as well as improved network performance by reducing broadcast traffic.

Power over Ethernet (PoE)

One of the standout features of the Cisco WS-C3560-12PC-S Ethernet Switch is its Power over Ethernet capability. This means that the switch can deliver both data and power to compatible devices connected to its ports, eliminating the need for separate power sources. With 12 PoE ports, users can connect and power devices such as IP phones, wireless access points, and IP cameras without the hassle of running additional power cables. This simplifies installation and reduces clutter, making it an ideal choice for businesses with limited space.

Cost Savings

By utilizing the PoE feature of the Cisco WS-C3560-12PC-S Ethernet Switch, businesses can save on both installation and operational costs. Traditional network setups often require separate power outlets for each device, resulting in increased installation complexity and higher costs. With PoE, businesses can reduce the number of power outlets required and avoid the need for additional electrical work. Furthermore, the switch intelligently manages power consumption, optimizing energy usage and reducing electricity bills.

Flexibility and Scalability

The 12 ports on the Cisco WS-C3560-12PC-S Ethernet Switch provide businesses with the flexibility to expand their network as needed. Whether it's adding new devices or accommodating future growth, this switch offers the scalability required to meet changing business demands. The ability to connect multiple devices ensures that businesses can adapt to evolving technologies without worrying about network limitations.

Efficient Network Management

The Cisco WS-C3560-12PC-S Ethernet Switch also offers advanced network management features that simplify administration tasks. It supports Cisco's intuitive web-based interface, allowing network administrators to easily configure and monitor the switch. Additionally, it supports Simple Network Management Protocol (SNMP), which enables centralized monitoring and management of network devices. These features save time and effort when it comes to network maintenance and troubleshooting.

In conclusion, the Cisco WS-C3560-12PC-S Ethernet Switch with its 12 ports provides users with increased connectivity, improved network performance, VLAN support, Power over Ethernet capability, cost savings, flexibility, scalability, and efficient network management. Whether it's a small office or a growing business, this switch offers the features and functionality required to build a reliable and efficient network infrastructure.
