WS-C3650-48FS-L Cisco Catalyst 3650 48 Ports Managed Ethernet Switch

Overview of Cisco Catalyst 3650-48F Switch

Product Specifications

• Manufacturer: Cisco
• Model Number: WS-C3650-48FS-L
• Product Line: Catalyst
• Series: 3650
• Product Name: Catalyst 3650-48F Switch
• Type: Ethernet Switch

Network Ports and Interfaces

• Total Network Ports: 48 Gigabit Ethernet Ports
• Stack Port: Yes
• PoE+ Ports: 48 RJ-45 Ports
• Uplink Ports: 4 Gigabit Ethernet

Media and Performance

• Supported Media Type: Twisted Pair
• Ethernet Technology: Gigabit Ethernet
• Network Technology: 10/100/1000Base-T
• Form Factor: Rack-mountable or Desktop

Switch Features

• Switching Layer: Layer 2
• Protocols: ARP, Trunking, VLAN, IGMP Snooping
• Spanning Tree Support: RSTP, MSTP, PVRST+
• Security: DHCP Snooping, DAI, ACL, RADIUS, MLD Snooping
• Link Aggregation: LACP, PAGP
• Monitoring: RSPAN
• Energy Efficiency: Energy Efficient Ethernet

Expansion and Management

• Expansion Slots: 4 SFP Slots
• Manageable: Yes
• Layer Supported: Layer 2

Power Specifications

• Power Frequency: 50/60 Hz
• Power Capacity: 1025 Watts
• Installed Power Supply: 1 (up to 2 supported)
• Nominal Voltage: AC 120/230 V
• Redundancy: Optional (1+1 with optional power supply)
• Type: Internal Power Supply

Compliance and Standards

• Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1d, IEEE 802.1q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at
• Additional Compliance: BSMI CNS 13438 Class A, CISPR 22 Class A, CSA C22.2 No. 60950-1 2nd Edition, EN 60950-1 2nd Edition, EN 61000-3-2, EN 61000-3-3, EN55022 Class A, FCC Part 15 A, GOST, ICES-003 Class A, IEC 60950-1 2nd Edition, ISO 7779, KCC, NOM, RoHS, UL 60950-1 2nd Edition, VCCI Class A

Authentication and Reliability

• Authentication Methods: Kerberos, RADIUS, SSH, TACACS+
• MTBF: 383,760 hours

Ports

The Cisco WS-C3650-48FS-L Managed Ethernet Switch is a powerful networking solution that offers a remarkable 48 ports. These ports are essential for connecting multiple devices to the network, making it an ideal choice for medium to large-scale businesses.

Increased Connectivity

With 48 ports, this Cisco switch provides ample connectivity options for various devices such as computers, printers, servers, and more. This abundance of ports ensures that your organization's network is capable of handling the growing number of devices and users.

Scalability

The WS-C3650-48FS-L switch allows for easy scalability as your business expands. You can effortlessly add more devices to your network without worrying about running out of ports. This flexibility eliminates the need for additional switches and simplifies the network infrastructure.

Improved Network Performance

Having 48 ports on a single switch eliminates the need for daisy-chaining multiple switches together. This reduces the complexity of your network and improves overall performance. Each connected device can communicate directly with the switch, resulting in faster data transfer rates and reduced latency.

Streamlined Network Management

Managing a network with numerous devices can be challenging, but with a 48-port switch like the WS-C3650-48FS-L, network management becomes easier and more efficient. You can group devices based on their connectivity requirements or departments, allowing for better organization and control. Additionally, this switch supports advanced management features such as VLANs (Virtual Local Area Networks) and QoS (Quality of Service), enabling you to prioritize critical traffic and optimize network performance.

Cost Savings

Investing in a switch with 48 ports eliminates the need for purchasing multiple smaller switches. This not only saves you money but also reduces power consumption, rack space, and cabling requirements. Consolidating your network infrastructure with a single switch simplifies maintenance and lowers operational costs in the long run.

Redundancy and High Availability

The WS-C3650-48FS-L switch offers built-in redundancy features to ensure high availability of your network. It supports Cisco StackWise-160 technology, allowing you to stack multiple switches together to create a single logical switch with increased port density and redundancy. In case of a switch failure, the stack automatically redistributes traffic, minimizing downtime and ensuring uninterrupted connectivity.

Network Security

Having 48 ports on a single switch enables the implementation of robust security measures. You can easily configure access control lists (ACLs) and apply them to specific ports or groups of ports, restricting unauthorized access to your network. Additionally, this switch supports advanced security features like Cisco TrustSec, which provides secure access control and identity-based networking.

Network Flexibility

The 48 ports on this Cisco switch offer tremendous flexibility in terms of network design and deployment. You can create separate VLANs to segregate traffic, ensuring better network performance and security. Additionally, you can connect devices directly to the switch or use additional networking equipment such as routers or firewalls, depending on your organization's requirements.

Future-Proofing

Investing in a switch with a large number of ports ensures that your network infrastructure is future-proofed for upcoming technologies and expansion. As the demand for connected devices continues to grow, having 48 ports allows you to accommodate new devices seamlessly without the need for costly upgrades or replacements.

In conclusion, the Cisco WS-C3650-48FS-L Managed Ethernet Switch with its 48 ports offers numerous benefits and importance for users. It provides increased connectivity options, scalability, improved network performance, streamlined management, cost savings, redundancy, high availability, network security, flexibility, and future-proofing. Whether you are a medium-sized business or a large enterprise, this switch is an excellent choice to meet your networking needs.
