WS-C4503 Cisco Catalyst 4500 Series Chassis

Series: Catalyst 4500

The Cisco WS-C4503 Chassis belongs to the Catalyst 4500 series, which is a widely recognized and trusted line of switches in the networking industry. The Catalyst 4500 series is known for its exceptional performance, reliability, and scalability, making it an ideal choice for medium to large-sized enterprises.

Overview of Cisco Catalyst WS-C4503 Switch Chassis

• Part Number: WS-C4503
• Brand: Cisco
• Series: Catalyst 4500
• Model: 4503-E
• Product Type: Switch Chassis

Expansion Capabilities

Flexible I/O Expansions

• Supports Supervisor Engine Modules for enhanced processing
• Compatible with a range of switching modules to extend functionality

Advanced Networking and Communication Features

Layer 4 Networking Support

• Optimized for complex network tasks with Layer 4 capabilities

Comprehensive Management Protocols

• Fully manageable through multiple interfaces:
  • Cisco Network Assistant for intuitive control
  • Integration with CiscoWorks for seamless management
  • Supports SNMP versions 1, 2c for monitoring
  • Command Line Interface (CLI) access
  • Quality of Service (QoS) controls for traffic prioritization
  • Remote Monitoring (RMON) enabled for performance tracking
  • Telnet access for remote configuration

Power Features and Redundancy

Power-over-Ethernet (PoE) Capabilities

• Supports PoE through RJ-45 ports for powering connected devices
• Equipped with a reliable power supply unit

Redundant Power Supply

• Built-in redundancy to ensure continuous operation

Included Components and Accessories

Package Contents

• Catalyst 4503-E Switch Chassis
• Catalyst 4500 Supervisor II-Plus with IOS, 2 Gigabit Ethernet ports, and console access (RJ-45) - Model: WS-X4013+
• 48-Port Catalyst 4500 PoE 802.3af 10/100 module (RJ-45) - Model: WS-X4248-RJ45V
• 1300W AC Power Supply for data and PoE functionality - Model: PWR-C45-1300ACV

Benefits of the Catalyst 4500 Series

The Catalyst 4500 series offers several benefits that make it an excellent investment for businesses:

1. High Performance

The Catalyst 4500 series switches are designed to handle high network traffic and provide consistent performance even during peak usage. With advanced hardware and software features, these switches can efficiently process and forward data packets, ensuring smooth operation and minimal latency.

2. Scalability

As businesses grow and their networking needs evolve, the Catalyst 4500 series offers the flexibility to scale up the network infrastructure. With various expansion modules and line cards available, users can easily add or upgrade ports to accommodate increasing network demands without replacing the entire switch.

3. Reliability

The Catalyst 4500 series switches are built to deliver exceptional reliability and uptime. With redundant components and hot-swappable modules, these switches minimize downtime during maintenance or hardware failures. This reliability ensures uninterrupted connectivity for critical business operations.

4. Advanced Security

Security is a top priority for any network infrastructure. The Catalyst 4500 series offers robust security features to protect against unauthorized access, data breaches, and network attacks. These switches support advanced security protocols, such as Access Control Lists (ACLs), VLANs, and port security, providing a secure network environment for sensitive data.

Ports: Depends on modules installed

The Cisco WS-C4503 Chassis supports a wide range of ports depending on the modules installed. This flexibility allows businesses to customize their network setup according to their specific requirements.

Benefits of Flexible Port Configuration

The ability to choose the appropriate modules and configure the desired number and type of ports offers several benefits:

1. Customization

By selecting the right modules, businesses can tailor their network infrastructure to meet their unique needs. Whether it's a combination of copper Ethernet ports for end devices, fiber optic ports for long-distance connectivity, or PoE (Power over Ethernet) ports for powering IP phones and wireless access points, the flexible port configuration ensures compatibility with various networking devices.

2. Future-Proofing

Network requirements often change over time, and the ability to expand or modify port configurations allows businesses to adapt to these changes without significant investments in new equipment. The Cisco WS-C4503 Chassis provides the flexibility to add or replace modules as needed, ensuring scalability and future-proofing of the network infrastructure.

3. Simplified Troubleshooting

The modular design of the Cisco WS-C4503 Chassis simplifies troubleshooting and maintenance. If a particular port or module malfunctions, it can be easily identified and replaced without affecting the rest of the network. This reduces downtime and enhances overall network reliability.

Power Supply: Redundant power supplies available

The Cisco WS-C4503 Chassis supports redundant power supplies, providing enhanced reliability and uptime for critical network operations.

Benefits of Redundant Power Supplies

Redundant power supplies offer several advantages for businesses:

1. Increased Reliability

Power supply failures can cause significant disruptions to network operations. By utilizing redundant power supplies, the Cisco WS-C4503 Chassis ensures that even if one power supply fails, the other can seamlessly take over, preventing downtime and maintaining uninterrupted network connectivity.

2. Load Balancing

Redundant power supplies also allow for load balancing, distributing the power load across multiple supplies. This ensures that no single power supply is overloaded and minimizes the risk of overheating or premature failure. Load balancing enhances the overall performance and longevity of the network infrastructure.

3. Hot-Swappable Modules

The Cisco WS-C4503 Chassis supports hot-swappable power supply modules, which means they can be replaced without shutting down the switch. This feature simplifies maintenance and reduces downtime, as faulty power supplies can be easily swapped out while the switch remains operational.

Dimensions: 17.25 x 17.25 x 12.25 inches

The Cisco WS-C4503 Chassis has compact dimensions of 17.25 x 17.25 x 12.25 inches, making it suitable for installations with space constraints.

Benefits of Compact Dimensions

The compact size of the Cisco WS-C4503 Chassis offers several benefits:

1. Space Efficiency

In environments where space is limited, such as server rooms or network closets, the compact dimensions of the chassis allow for efficient utilization of available space. These switches can be easily mounted on racks or placed in tight spaces without occupying excessive room.

2. Easy Integration

The compact size facilitates easy integration of the Cisco WS-C4503 Chassis into existing network infrastructures. The switch can be seamlessly incorporated alongside other networking equipment without requiring significant rearrangements or modifications.

3. Portability

Due to its compact dimensions, the Cisco WS-C4503 Chassis is relatively lightweight and portable. This portability makes it suitable for temporary network setups or deployments in remote locations where mobility is essential.

Weight: 20.5 lbs

The Cisco WS-C4503 Chassis has a weight of 20.5 lbs, which contributes to its overall portability and ease of installation.

Benefits of Lightweight Design

The lightweight nature of the Cisco WS-C4503 Chassis offers several advantages:

1. Easy Installation

The manageable weight of the chassis simplifies the installation process. Network technicians can easily handle and position the switch without requiring additional assistance or specialized equipment. This facilitates faster deployment and reduces installation costs.

2. Mobility

The lightweight design enables easy relocation of the Cisco WS-C4503 Chassis when required. Whether it's a temporary network setup for an event or a need to reposition the switch within the premises, its lightweight nature allows for hassle-free mobility.

3. Reduced Strain on Infrastructure

Heavy networking equipment can place a strain on racks, cabinets, and other mounting structures. The relatively low weight of the Cisco WS-C4503 Chassis helps mitigate this issue, ensuring that the infrastructure can support the switch without compromising stability or safety.

Management Interfaces: Console port, Ethernet management port

The Cisco WS-C4503 Chassis provides convenient management interfaces, including a console port and an Ethernet management port, for efficient monitoring and configuration of the switch.

Benefits of Management Interfaces

The management interfaces offer several benefits to users:

1. Enhanced Control and Configuration

The console port allows for direct access to the switch's command-line interface (CLI), enabling network administrators to have complete control over the configuration and management of the device. It provides a secure and reliable way to monitor and troubleshoot the switch, ensuring optimal performance.

2. Remote Management

The Ethernet management port enables remote access to the switch's management interface. Network administrators can conveniently monitor and configure the switch from a central location, saving time and effort. This feature is particularly useful in distributed network environments or when physical access to the switch is limited.

3. Simplified Troubleshooting

Both the console port and Ethernet management port streamline troubleshooting processes. Administrators can quickly diagnose and resolve network issues by accessing real-time data, logs, and system information through these interfaces. This reduces downtime and enhances overall network reliability.

Compatibility: Compatible with various line cards and modules

The Cisco WS-C4503 Chassis is designed to be compatible with a wide range of line cards and modules, offering flexibility and versatility in network deployments.

Benefits of Compatibility

The compatibility feature provides several advantages:

1. Customization

With compatibility across various line cards and modules, businesses have the freedom to choose the specific components that best suit their networking requirements. This allows for customization of the switch's capabilities, ensuring optimal performance and functionality.

2. Investment Protection

The Cisco WS-C4503 Chassis's compatibility with different line cards and modules provides investment protection for businesses. As technology evolves and networking needs change, users can easily upgrade or add new components without needing to replace the entire switch. This approach saves costs and extends the lifespan of the networking infrastructure.

3. Seamless Integration

Compatibility ensures seamless integration between the Cisco WS-C4503 Chassis and other networking equipment, such as routers, switches, and modules from Cisco and other vendors. This interoperability simplifies network deployments and allows for easy expansion or integration of existing infrastructure.
