Cisco C9300-48UXM-M Catalyst Meraki 48 Ports Multigigabit Switch

Product Overview: Cisco C9300-48UXM-M Catalyst Meraki 48 Ports Multigigabit Switch

Core Specifications

• Manufacturer: Cisco Systems, Inc.
• Model: C9300-48UXM-M
• Product Type: Ethernet Switch
• Brand Name: Meraki
• Part Number (SKU): C9300-48UXM-M

Technical Features

• Network Ports: 48 ports for extensive connectivity
• Modular Design: Yes, with flexibility for network expansion
• Uplink Ports: Available for enhanced connection to core networks
• Stacking Support: Stackable, enabling seamless scalability
• Layer Support: Layer 3 for routing capabilities

Port and Slot Configuration

• 36 Ports: 2.5 Gigabit Ethernet for standard devices
• 12 Ports: 10 Gigabit Ethernet with UPoE support
• 1 Uplink Slot: High-speed uplink for advanced networking
• 2 Stack Ports: Allow for seamless stack integration

Expansion and Connectivity

• Expansion Slot Type: Uplink Module for future-proofing your network
• Total Expansion Slots: 1 slot for additional network adaptability
• Network Technologies Supported: 2.5GBase-T and 10GBase-T
• Media Type: Twisted Pair for reliable connections

Networking Standards

• Compliance: IEEE 802.1p, 802.1Q, 802.1s, 802.1ab, 802.1ad, and 802.1x

Physical Characteristics

• Form Factor: Rack-mountable, fits standard 1U rack units
• Dimensions: Height: 1.7", Width: 17.5", Depth: 22.2"
• Weight: Approximately 20.05 lbs
• Power Consumption: 785.50 W for optimal performance
• Power Supply: Includes 1 installed power supply with support for redundancy

Power Options

• Redundant Power Supply: Supported to enhance uptime
• Power-over-Ethernet (PoE): RJ-45 port with a PoE budget of 490 W
• Number of Power Supplies: 2 slots available; 1 pre-installed

Management Capabilities

• Manageability: Yes, designed for ease of network management
• Advanced Features: Stackable and modular for versatile network growth

Cisco C9300-48UXM-M Catalyst Meraki 48 Ports Multigigabit Switch

The Cisco C9300-48UXM-M Catalyst Meraki 48 Ports Multigigabit Switch is a high-performance network switch designed to address the demands of modern enterprises. Built for high-density environments, this switch supports advanced security, scalability, and flexibility, making it an ideal choice for businesses looking to enhance their network infrastructure with Cisco's advanced Catalyst series.

Key Features of Cisco C9300-48UXM-M

Enhanced Multigigabit Support

The Cisco C9300-48UXM-M Catalyst offers robust multigigabit support, which is essential for businesses that require high-speed connections to handle large data volumes. This switch features 48 ports that allow for data speeds up to 10Gbps, accommodating the needs of high-density access points and power-hungry devices.

Advanced Security Features

Security is a top priority for any network, and the Cisco C9300-48UXM-M does not disappoint. With built-in security features such as encrypted traffic analytics, Identity Services Engine (ISE) integration, and Cisco TrustSec technology, this switch helps protect networks from internal and external threats. Additionally, its segmentation capabilities allow organizations to create secure network segments, reducing the risk of unauthorized access.

Power over Ethernet (PoE) Capabilities

Supporting PoE+ (Power over Ethernet Plus), the Cisco C9300-48UXM-M provides power to connected devices directly through Ethernet cables. This functionality eliminates the need for additional power adapters for compatible devices such as IP cameras, wireless access points, and IP phones, simplifying installation and reducing overall operational costs.

Modular Design and Flexibility

This switch is designed with modularity in mind, allowing businesses to customize their network setup based on their unique requirements. The Cisco C9300-48UXM-M supports optional uplinks, which can be swapped as needed, making it a highly flexible choice for enterprises that anticipate network growth and changes over time.

Performance and Scalability

High Bandwidth and Low Latency

Equipped with Cisco's state-of-the-art ASIC and forwarding architecture, the C9300-48UXM-M delivers superior bandwidth and low latency. This switch is capable of handling high-demand applications, ensuring that data is transferred seamlessly across the network. This performance makes it suitable for organizations with extensive real-time data needs, such as financial institutions and healthcare facilities.

Stacking Capabilities with Cisco StackWise

One of the standout features of the Cisco Catalyst 9300 series is its StackWise technology, which allows multiple switches to operate as a single unit. By stacking up to 8 switches, enterprises can increase their network’s bandwidth capacity, simplify management, and improve redundancy. This enhances overall performance, allowing businesses to maintain high uptime and efficiency across network operations.

Future-Proofing with Modular Uplinks

The Cisco C9300-48UXM-M is designed for scalability. With support for modular uplinks, this switch can adapt to increasing data demands without requiring a complete network overhaul. Modular uplink support ensures that the switch can meet future technology upgrades, reducing the need for extensive replacements or modifications.

Management and Control

Integrated Meraki Cloud Management

The C9300-48UXM-M integrates seamlessly with Cisco Meraki's cloud-based management platform, giving administrators an extensive control suite for managing configurations, monitoring performance, and troubleshooting. The Meraki dashboard provides real-time insights, enabling proactive network management that enhances efficiency and minimizes downtime.

Automated Software Updates and Monitoring

With Cisco's automated software update system, the C9300-48UXM-M can keep firmware up-to-date with minimal human intervention. This automated approach ensures that the switch remains secure and optimized for performance. Cisco's monitoring features also allow administrators to keep an eye on the network's health and receive alerts for potential issues before they impact operations.

Intuitive Interface and Customizable Options

Through the Meraki dashboard, network managers can enjoy a highly intuitive interface that simplifies complex configurations and tasks. The customizable options available in the Meraki platform allow administrators to fine-tune their network to match specific operational needs, improving overall usability and operational efficiency.

Applications and Use Cases

High-Density Campus Networks

The Cisco C9300-48UXM-M Catalyst switch is ideal for large campus networks where a high volume of devices requires multigigabit connections. Educational institutions and large corporate campuses can benefit from this switch's multigigabit support, which ensures that users can access data quickly and reliably across expansive areas.

IoT and Device Connectivity

As IoT devices proliferate in workplaces, the demand for reliable and secure connectivity increases. The Cisco C9300-48UXM-M can handle large numbers of connected IoT devices, providing the necessary bandwidth and power through its PoE+ support. This makes it ideal for environments with security cameras, sensors, and other IoT applications.

Remote and Branch Office Deployments

For businesses with remote or branch offices, the Cisco C9300-48UXM-M provides a reliable, high-performance solution that can be managed remotely through the Meraki dashboard. This centralized management capability allows for consistent configurations across multiple locations, ensuring a uniform network experience and simplifying management for IT teams.

Technical Specifications of Cisco C9300-48UXM-M

Port Configuration

This switch features 48 multigigabit ports, supporting speeds from 100Mbps up to 10Gbps. These ports are designed to accommodate high-bandwidth applications and devices, making the switch an ideal choice for modern enterprises with diverse networking needs.

Performance Ratings

With a forwarding rate of up to 1,440 million packets per second (mpps) and a switching capacity of up to 480Gbps, the Cisco C9300-48UXM-M provides excellent performance for data-intensive environments. Its architecture ensures that data is processed and routed efficiently, supporting high-throughput applications seamlessly.

Environmental Resilience

The Cisco C9300-48UXM-M Catalyst switch is built to endure various environmental conditions, with an operating temperature range that suits different deployment scenarios. It includes features like variable fan speed and an optimized airflow system to prevent overheating, maintaining performance in demanding situations.

Energy Efficiency

As part of Cisco’s commitment to sustainability, the C9300-48UXM-M incorporates energy-efficient features, including EEE (Energy Efficient Ethernet) and dynamic power allocation. These features help reduce the switch's energy consumption, aligning with green initiatives and reducing operating costs over time.

Competitive Advantages of Cisco C9300-48UXM-M

Seamless Integration with Cisco’s Ecosystem

The Cisco C9300-48UXM-M Catalyst switch is part of Cisco's expansive ecosystem, offering easy integration with other Cisco products such as Cisco DNA Center, Cisco ISE, and Cisco Meraki. This compatibility enhances network performance, simplifies management, and improves overall security by providing a cohesive network environment.

Robust Software Capabilities

The Cisco IOS XE software that powers the C9300-48UXM-M provides extensive functionality, enabling advanced networking features like Layer 3 routing, MPLS, and Software-Defined Access (SD-Access). This software enables organizations to set up complex network configurations, improving their ability to meet modern operational demands.

Unmatched Customer Support and Reliability

With Cisco's industry-leading support and service, businesses using the C9300-48UXM-M Catalyst switch have access to technical resources and dedicated customer support, ensuring quick resolution of issues. Cisco’s reputation for reliability ensures that this switch is a dependable choice for mission-critical networks.

Conclusion

The Cisco C9300-48UXM-M Catalyst Meraki 48 Ports Multigigabit Switch is designed to meet the demands of high-performance, secure, and scalable network environments. Its combination of advanced multigigabit support, powerful security features, PoE+ capabilities, and modular design make it an ideal solution for businesses looking to enhance their network infrastructure. With support for cloud-based management and future-ready technologies, this switch provides the tools necessary for efficient, reliable, and secure network operations.
