Cisco MDS 9396S Switch DS-C9396S-96E8K9 (96 Ports)

Overview of Cisco DS-C9396S-96E8K9

General Specifications

• Manufacturer: Cisco
• Part Number: DS-C9396S-96E8K9
• Device Type: 96-port Managed Switch with 96x 8Gb Fibre Channel SFP+ Transceivers
• Form Factor: Rack-Mountable, 2U
• Switch Subtype: Fibre Channel
• Number of Ports: 96 x 16Gb Fibre Channel

Fibre Channel Protocols Supported

• FC-DA, FC-FLA, FC-FS
• FC-GS-3, FC-GS-4, FC-MI
• FC-PH, FC-PH-2, FC-PH-3
• FC-PI, FC-PLDA, FC-SB-2
• FC-SW-2, FC-Tape, FC-VI
• FCP-4, FC-BB-2, FCP, FCP-2
• FC-BB-5, FC-BB-3, FC-FS-2
• FC-GS-5, FC-SW-4, FCP-3
• FC-LS, FC-MI-2, FC-PI-4
• FC-FS-3, FC-GS-6, FC-PI-3
• FC-SW-5, FC-BB-4, FC-IFR
• FAIS, FAIS-2, FC-PI-5
• FC-LS-2, FC-SP-2, FC-SB-4
• FC-DA-2, FC-MI-3, FC-MSQS
• FC-BB-6, FC-SB-5

Networking Features

• Routing Protocol: VRRP
• Remote Management Protocols: RMON, SNMP 3, SMI-S, SSH-2, CLI
• Encryption: AES
• Authentication: RADIUS, TACACS+, Secure Shell v.2 (SSH2)
• Additional Features: ARP Support, IPv6 Support, Access Control List (ACL), Quality of Service (QoS), IPv4 Support
• Advanced Capabilities: Remote Switch Port Analyzer (RSPAN), Registered State Change Notification (RSCN), Port Exhaust, In-Service Software Upgrade (ISSU), Fabric Configuration Server (FCS), Cisco Inter-Switch Link (ISL)

Connectivity and Expansion

• Interfaces:
  • 1 x 1000Base-T RJ-45 for management
  • 1 x Management (RS-232)
  • 1 x USB Port
  • 96 x 16Gb Fibre Channel SFP+ Ports

Power Specifications

• Power Supply: Internal, Hot-Plug
• Installed Quantity: 2 (installed), 2 (maximum)
• Redundancy: Yes, 1+1 Scheme
• Power Provided: 1200 Watts
• Voltage Requirement: AC 100/230 V (50/60 Hz)
• Operational Power Consumption: 700 Watts

Included Accessories and Compliance

• Included Accessories: 2 Fan Trays, Accessory Kit
• Standards Compliance: CISPR 22 Class A, EN 60950, EN 61000-3-2, IEC 60950, EN 61000-3-3, EN55024, UL 60950, EN50082-1, EN 61000-6-1, ACA TS001, AS/NZS 3260, EMC, ICES-003 Class A, FCC CFR21 Part 1040, EN 60825, AS/NZS 3548 Class A, IEC 60825, CAN/CSA C22.2 No. 60950, VCCI Class A, EN 55022 Class A, FCC CFR47 Part 15 A

Ports

The Cisco MDS 9396S Switch is equipped with a remarkable feature that sets it apart from other switches in its class - a staggering 96 ports. This abundance of ports provides users with unparalleled connectivity options and ensures that their network infrastructure can handle the most demanding workloads.

Increased Scalability

With 96 ports at your disposal, you can easily expand your network infrastructure to accommodate growing business needs. Whether you are adding new servers, or storage devices, or connecting to additional switches, the Cisco MDS 9396S Switch offers the flexibility to scale your network seamlessly without compromising performance.

Efficient Data Transfer

The high port count of the Cisco MDS 9396S Switch allows for efficient data transfer between devices. With more ports available, you can establish direct connections between servers and storage devices, eliminating the need for additional hops or intermediate switches. This direct connectivity minimizes latency and ensures optimal data transfer rates, enabling faster access to critical information and improving overall system performance.

Enhanced Redundancy

Redundancy is crucial for ensuring uninterrupted network operations. The Cisco MDS 9396S Switch's 96 ports enable you to create redundant connections to critical devices, eliminating single points of failure. By implementing redundant links, you can protect your network from potential disruptions and maintain continuous access to vital resources, even in the event of hardware failures.

Simplified Network Architecture

With a wealth of available ports, the Cisco MDS 9396S Switch allows for streamlined network architecture. You can consolidate multiple switches into a single unit, reducing complexity and minimizing management overhead. This simplified design not only saves space but also simplifies troubleshooting and maintenance tasks, leading to improved operational efficiency.

Management

The Cisco MDS 9396S Switch boasts a comprehensive management feature set, making it an ideal choice for organizations seeking a highly manageable network infrastructure. With its managed capabilities, this switch empowers users with granular control over their network, ensuring optimal performance and security.

Centralized Network Management

The Cisco MDS 9396S Switch can be seamlessly integrated into network management platforms, allowing administrators to centrally monitor and manage their entire network infrastructure. Through a unified interface, administrators can easily configure, troubleshoot, and monitor the switch, simplifying day-to-day operations and reducing the time spent on manual tasks.

Enhanced Security

As a managed switch, the Cisco MDS 9396S provides advanced security features to protect your network from unauthorized access and potential threats. Administrators can implement access control lists (ACLs) to restrict traffic based on specific criteria, ensuring that only authorized devices can communicate with the switch. Additionally, features like Secure Shell (SSH) encryption and Secure File Transfer Protocol (SFTP) help safeguard sensitive configuration files and prevent unauthorized tampering.

Quality of Service (QoS)

The Cisco MDS 9396S Switch offers sophisticated QoS capabilities to prioritize critical traffic and ensure consistent application performance. Administrators can define QoS policies based on parameters such as VLAN ID, IP address, or protocol, guaranteeing that important data receives adequate bandwidth and minimizing the impact of non-critical traffic on overall network performance.

Effortless Network Provisioning

The managed nature of the Cisco MDS 9396S Switch simplifies network provisioning and reduces deployment time. Administrators can leverage features like automatic port configuration and VLAN management to quickly set up new devices or make changes to the network infrastructure. This streamlined provisioning process minimizes human errors, improves efficiency, and accelerates time-to-service.

Part Number

The Cisco MDS 9396S Switch is identified by its unique part number - DS-C9396S-96E8K9. This alphanumeric code holds crucial information about the switch's specifications, making it an essential reference for users and network administrators.

Product Identification

The part number DS-C9396S-96E8K9 allows users to accurately identify the Cisco MDS 9396S Switch model, distinguishing it from other switches in the Cisco MDS series. This ensures that users can procure the specific switch they require, avoiding any potential compatibility issues or mismatches with their existing network infrastructure.

Specification Details

The part number DS-C9396S-96E8K9 provides valuable information about the switch's key specifications. The "96" in the part number denotes the impressive 96-port count, as discussed earlier. This specification is crucial for users who require a switch with a high port density to meet their connectivity needs.

Feature Set

The "E8K9" in the part number indicates the feature set of the Cisco MDS 9396S Switch. This alphanumeric code denotes specific software capabilities and feature enhancements available on the switch. Users can refer to Cisco documentation or consult with their network administrators to understand the precise features associated with this part number and ensure it aligns with their requirements.

Compatibility and Support

The part number DS-C9396S-96E8K9 also facilitates compatibility and support inquiries. Users can provide this part number when seeking assistance from Cisco technical support or when searching for compatible accessories or software updates. Having the correct part number ensures accurate troubleshooting and facilitates efficient resolution of any issues that may arise during operation.
